Engine Controls - System & Component Tests - Eec-V - Gasoline Ford Explorer Sport Trac I

INTRODUCTION

Note. References to Econoline include Cutaway and RV Cutaway. References to F250-550 Super Duty Pickup include Cab & Chassis.

Note. Testing individual components does not isolate shorted or open circuits. Perform all voltage tests with a Digital Volt-Ohmmeter (DVOM) with a minimum 10-megohm input impedance, unless stated otherwise in test procedure. Use ohmmeter to isolate shorted or open wiring harness. For identification of circuits and terminals referenced in test procedures, see WIRING DIAGRAMS article.

Before testing separate components or systems, perform appropriate procedures in BASIC DIAGNOSTIC PROCEDURES - CARS or BASIC DIAGNOSTIC PROCEDURES - TRUCKS - EXCEPT DIESEL article. Computer-controlled and monitored components should set a Diagnostic Trouble Code (DTC) if they malfunction. Check for Key On Engine Off (KOEO), Key On Engine Running (KOER) and/or Continuous Memory DTCs prior to testing individual components. Perform QUICK TEST procedures in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. In many cases a circuit that is open, or shorted to ground or power can be at fault. Component replacement is only suggested after testing and passing circuits and control devices. A component test may direct you to a system test in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to help avoid replacement of a good component. If the component can be tested properly on its own, it will be included here.

Removal & Installation

On models with console, open storage bin and press clips to remove storage bin. Press and hold lock clip and slide console up to remove. On all models, remove instrument panel cover under steering column. Disconnect 4 engine cover latches and remove engine cover. To install, reverse removal procedure.

Intake Manifold Runner Control Solenoid

See INTAKE MANIFOLD RUNNER CONTROL SOLENOID under RELAYS & SOLENOIDS.

Intake Manifold Swirl Control Solenoid

See INTAKE MANIFOLD SWIRL CONTROL SOLENOID under RELAYS & SOLENOIDS.

Intake Manifold Tuning Valve Solenoid

See INTAKE MANIFOLD TUNING VALVE SOLENOID under RELAYS & SOLENOIDS.

Ground Circuits

1. Turn ignition off. Locate Powertrain Control Module (PCM). See «POWERTRAIN CONTROL MODULE LOCATION»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline) table. Using a DVOM, check continuity between ground and PCM connector terminals. See «IDENTIFYING PCM GROUND TERMINALS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline) table. (Scheme 1)or (Scheme 2). If continuity does not exist, repair open ground circuit as necessary. If continuity exists, go to next step. POWERTRAIN CONTROL MODULE LOCATION Application Location Blackwood, Expedition, Explorer, Explorer Sport, Explorer Sport Trac, F150 Pickup, Mountaineer & Navigator Right Rear Of Engine Compartment, Mounted On Cowl Continental, Escape, Ranger & Town Car Center Of Engine Compartment, Mounted On Cowl Cougar, LS, Sable, Taurus, Thunderbird & Windstar Right Rear Of Engine Compartment, Mounted On Cowl Crown Victoria & Grand Marquis Behind Left Kick Panel, Near Instrument Panel Econoline Left Rear Of Engine Compartment, Near Brake Master Cylinder Escort Center Of Instrument Panel, Below Center Console Excursion & F250-550 Behind Left Side Of Instrument Panel, Near Brake Pedal Focus & Mustang Behind Right Kick Panel IDENTIFYING PCM GROUND TERMINALS Application PCM Ground Terminal No. Blackwood 3, 25, 51, 76 & 103 Continental, Crown Victoria, F150 Pickup (Lightning 5.4L SC), Grand Marquis, Mustang (4.6L) & Town Car 3, 51, 77 & 103 Cougar 24, 25, 51, 77 & 103 Econoline 4.2L 24, 51, 76, 77 & 103 4.6L & 5.4L Gas 3, 24, 51, 76, 77 & 103 5.4L NGV 3, 24, 25, 51, 77 & 103 6.8L 3, 23, 24, 51, 76, 77 & 103 Escape 24, 25, 51, 76, 77 & 103 Escort & Focus (2.0L) 24, 51, 77 & 103 Excursion & F250-F550 (5.4L & 6.8L) 3, 23, 24, 51, 76, 77 & 103 Expedition & Navigator (4.6L & 5.4L Gas), F150 Pickup (4.6L & 5.4L, & 5.4L NGV), & Mustang (3.8L) 3, 51, 76 & 103 Explorer Sport, Explorer Sport Trac & F150 Pickup (4.2L) 24, 51, 76, 77 & 103 Explorer, LS, Mountaineer & Thunderbird A24, A25, A26, A27 & A43 Ranger, Sable, Taurus & Windstar 24, 25, 51, 76, 77 & 103
2. Touch DVOM negative lead to a good ground. With vehicle running, use DVOM positive lead to backprobe each ground terminal. DVOM should indicate less than one volt. If reading is more than one volt, check for open, corrosion or loose connection on ground circuit.

Power Circuits

Turn ignition off. Using a DVOM, check for battery voltage between ground and B+ circuit at PCM terminal No. 55 (104-pin PCM), or terminal No. A44 (150-pin PCM). (Scheme 1)or (Scheme 2). Turn ignition switch to START or RUN position. Check for battery voltage between ground and specified VPWR circuit at PCM harness connector. See PCM VPWR CIRCUIT TERMINAL IDENTIFICATION table. If battery voltage is not present, check for an open in VPWR circuit between PCM and PCM power relay. For additional testing procedures, see TEST B: EEC-V POWER RELAY under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

PCM VPWR CIRCUIT TERMINAL IDENTIFICATION

Scheme 1

Scheme 2

Brake Pedal Applied/Brake Pedal Position Switch

See TEST FD: BRAKE PEDAL POSITION SWITCH under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for testing procedures and specifications.

Clutch Pedal Position Switch

See TEST TA: PARK/NEUTRAL POSITION OR CLUTCH PEDAL POSITION SWITCHES under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for testing procedures and specifications.

Inertia Fuel Shutoff Switch

Ensure ignition is off. Locate Inertia Fuel Shutoff (IFS) switch. See INERTIA FUEL SHUTOFF SWITCH LOCATIONS table. Shake or jar IFS switch to cause switch to open. IFS switch reset button should pop up. Fuel pump should not operate and car should stall. Push down on reset button. Restart engine. Fuel pump should operate.

INERTIA FUEL SHUTOFF SWITCH LOCATIONS

Park/Neutral Position Or Clutch Pedal Position Switch

See TEST TA: PARK/NEUTRAL POSITION OR CLUTCH PEDAL POSITION SWITCHES under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for testing procedures and specifications.

Power Steering Pressure Switch

See TEST FF: POWER STEERING PRESSURE SWITCH under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for testing procedures and specifications.

Reverse Switch

See TEST TH: REVERSE SWITCH under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for testing procedures and specifications.

Transmission Control Switch

See TEST TB: TRANSMISSION CONTROL SWITCH/TRANSMISSION CONTROL INDICATOR LAMP under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for testing procedures and specifications.

SENSORS

Note. For additional sensor testing specifications, see SENSOR OPERATING RANGE CHARTS - EXCEPT VILLAGER article.

Air Conditioning Evaporator Temperature Sensor

See TEST DJ: AIR CONDITIONING EVAPORATOR TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Air Conditioning Evaporator Temperature (ACET) sensor testing procedures and specifications.

Air Conditioning Pressure Sensor

See TEST DS: AIR CONDITIONING PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Air Conditioning Pressure (ACP) sensor testing procedures and specifications.

Barometric Pressure Sensor

See TEST DQ: BAROMETRIC PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Barometric Pressure (BARO) sensor testing procedures and specifications.

Camshaft Position Sensor

See TEST DR: CAMSHAFT POSITION SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Camshaft Position (CMP) sensor testing procedures and specifications.

Crankshaft Position Sensor

See TEST JD: CRANKSHAFT POSITION SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Crankshaft Position (CKP) sensor testing procedures and specifications.

Cylinder Head Temperature Sensor

See TEST DL: CYLINDER HEAD TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Cylinder Head Temperature (CHT) sensor testing procedures and specifications.

Engine Coolant Temperature Sensor

See TEST DA: TEMPERATURE SENSOR TEST (IAT, ECT & EOT) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Engine Coolant Temperature (ECT) sensor testing procedures and specifications.

Engine Oil Temperature Sensor

See TEST DA: TEMPERATURE SENSOR TEST (IAT, ECT & EOT) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Engine Oil Temperature (EOT) sensor testing procedures and specifications.

Engine Fuel Temperature Sensor

See TEST DB: ENGINE FUEL TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Engine Fuel Temperature (EFT) sensor testing procedures and specifications.

Fuel Rail Pressure Sensor

See TEST DD: FUEL RAIL PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Fuel Rail Pressure (FRP) sensor testing procedures and specifications.

Heated Oxygen Sensor

See TEST H: FUEL CONTROL under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Heated Oxygen Sensor (HO2S) testing procedures and specifications.

Intake Air Temperature Sensor

Note. On some models, IAT sensor is part of Mass Airflow (MAF) sensor assembly. If all 6 terminals of MAF sensor connector are being used, IAT sensor is integral to MAF sensor. See WIRING DIAGRAMS article.

See TEST DA: TEMPERATURE SENSOR TEST (IAT, ECT & EOT) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Intake Air Temperature (IAT) sensor testing procedures and specifications.

Intake Air Temperature 2 Sensor (F150 Lightning 5.4L SC Only)

See TEST DU: INTAKE AIR TEMPERATURE 2 under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Intake Air Temperature 2 (IAT2) sensor testing procedures and specifications.

Knock Sensor

See TEST DG: KNOCK SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Knock Sensor (KS) testing procedures and specifications.

Mass Airflow Sensor

See TEST DC: MASS AIRFLOW SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Mass Airflow (MAF) sensor testing procedures and specifications.

Output Shaft Speed Sensor

See TEST TJ: OUTPUT SHAFT SPEED SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Output Shaft Speed (OSS) sensor testing procedures and specifications.

Power Steering Pressure Sensor

See TEST DT: POWER STEERING PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Power Steering Pressure (PSP) sensor testing procedures and specifications.

Thermal Manifold Absolute Pressure Sensor

See TEST DM: THERMAL MANIFOLD ABSOLUTE PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Thermal Manifold Absolute Pressure (TMAP) sensor testing procedures and specifications.

Throttle Position Sensor

See TEST DH: THROTTLE POSITION SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Throttle Position (TP) sensor testing procedures and specifications.

Transfer Case Speed Sensor

See TEST DP: VEHICLE SPEED SENSOR/TRANSFER CASE SPEED SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Transfer Case Speed Sensor (TCSS) testing procedures and specifications.

Vehicle Speed Sensor

See TEST DP: VEHICLE SPEED SENSOR/TRANSFER CASE SPEED SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Vehicle Speed Sensor (VSS) testing procedures and specifications.

RELAYS

Note. On Escort and Mustang, a Constant Control Relay Module (CCRM) is used. See TEST X: CONSTANT CONTROL RELAY MODULE under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for Constant Control Relay Module (CCRM) testing procedures.

Cooling Fan Control, Fuel Pump & PCM Power Relay

Note. Two different types of relay can be used. An ISO micro relay (relay terminals are numbered 1-5), or an ISO mini relay (terminals are numbered 30, 85, 86, 87 and 87A). On ISO micro relays, relay coil terminals are No. 1 and 2. On ISO mini relays, relay coil terminals are No. 85 and 86. (Scheme 3)or (Scheme 4).

Turn ignition switch to OFF position. On ISO micro fuel pump relay terminals that are numbered 1-5, measure resistance between relay terminal No. 1 and all other relay terminals. Resistance should be 40-120 ohms between terminals No. 1 and 2 and more than 10 k/ohms between terminal No. 1 and all other relay terminals. On ISO mini fuel pump relay terminals that are numbered 30, 85, 86, 87 and 87A, measure resistance between relay terminal No. 85 and all other relay terminals. Resistance should be 40-120 ohms between terminals No. 85 and 86 and more than 10 k/ohms between terminal No. 85 and other relay terminals. On both relays, if resistance is not as specified replace relay. If resistance is as specified, relay is okay. Check associated circuits for possible open or shorts.

Scheme 3

Scheme 4

Air Injection By-Pass Solenoid

See SECONDARY AIR INJECTION under EMISSION SYSTEMS & SUB-SYSTEMS.

Air Injection Diverter Solenoid

See SECONDARY AIR INJECTION under EMISSION SYSTEMS & SUB-SYSTEMS.

Canister Vent Solenoid

See FUEL EVAPORATION under EMISSION SYSTEMS & SUB-SYSTEMS.

EGR Vacuum Regulator Solenoid

See EGR SYSTEMS under EMISSION SYSTEMS & SUB-SYSTEMS.

Fuel Rail Solenoid

See TEST DD: FUEL RAIL PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for additional testing and specifications.

Idle Air Control Solenoid

See IDLE AIR CONTROL SOLENOID under IDLE CONTROL SYSTEM.

See TEST HU: AIR INTAKE SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for additional Intake Manifold Runner Control (IMRC) testing and specifications.

Intake Manifold Swirl Control Solenoid (Ranger 2.3L Only)

See TEST HU: AIR INTAKE SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for additional Intake Manifold Swirl Control (IMSC) testing and specifications.

See TEST HU: AIR INTAKE SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for additional Intake Manifold Tuning Valve (IMTV) testing and specifications.

Supercharger (Boost) By-Pass Solenoid

Turn ignition off. Disconnect Supercharger By-Pass (SCB) solenoid connector. Measure resistance between SCB solenoid terminals. If resistance is not 68-78 ohms, replace solenoid. If resistance is 68-78 ohms, IAC solenoid is okay. For additional testing and specifications, see TEST KJ: SUPERCHARGER BY-PASS CONTROL under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Variable Cam Timing Solenoid

See TEST HK: VARIABLE CAM TIMING under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for additional testing and specifications.

Fuel Pressure Regulator

See TEST HC: GASOLINE FUEL DELIVERY SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Fuel Pump Relay

See RELAYS under RELAYS & SOLENOIDS.

Fuel System Pressure Check

See FUEL SYSTEM PRESSURE under FUEL SYSTEMS in BASIC DIAGNOSTIC PROCEDURES - CARS or BASIC DIAGNOSTIC PROCEDURES - TRUCKS - EXCEPT DIESEL article.

Fuel Injector

Disconnect fuel injector harness connectors. Using a DVOM, measure resistance between injector terminals. (Scheme 5) If resistance of any injector is not as specified, replace injector. If injector resistance is within specification, injector is okay. For additional fuel injector testing and specifications, see TEST HD: MISFIRE DETECTION MONITOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Scheme 5

Note. Idle Air Control (IAC) solenoid may also be referred to as IAC valve.

Idle Air Control (IAC) solenoid is a by-pass air type. Ensure ignition is off. Disconnect IAC solenoid harness connector. Measure resistance between IAC solenoid terminals. Solenoid has an internal diode and resistance will be infinite if voltmeter is hooked up incorrectly. If resistance is not 6-13 ohms, replace solenoid. If resistance is 6-13 ohms, IAC solenoid is okay. For additional testing and specifications, see TEST KE: IDLE AIR CONTROL VALVE under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

IGNITION SYSTEMS

Note. For additional information and descriptions, see IGNITION SYSTEMS in THEORY & OPERATION - EEC-V - GASOLINE & NGV article

Faults in ignition system should set a DTC. If any DTCs are present, perform appropriate system test in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. If no DTCs are present, check secondary ignition system. See TEST JB: SECONDARY IGNITION under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

CATALYTIC CONVERTER

Note. If vehicle fails emissions test or catalytic converter efficiency is in question, perform EMISSIONS COMPLIANCE procedures. See EMISSIONS COMPLIANCE .

EMISSIONS COMPLIANCE

Canada and some states or metropolitan areas in the United States require periodic emission, or Inspection/Maintenance (I/M) tests. All Ford products have been designed to pass these tests. If a Ford vehicle fails an I/M test, ensure correct model, year, test weight (less than vehicle's GVW) and correct calibration (California or Federal) are on the test report.

Identify which gas readings are high or low and identify in which mode the gas(es) failed. If all gases were high at the beginning of the test then decreased, the engine or catalytic converter temperature may not have been at operating temperature and stabilized prior to the test, or the vehicle had idled for an excessive period of time prior to the test. Perform DIAGNOSTIC ROUTINES after analyzing I/M test report.

If any emission component is changed, Keep-Alive Memory (KAM) should be cleared and basic adaptive strategy should be relearned before repeating state emission test procedure. To clear KAM and perform basic adaptive strategy, perform KEEP ALIVE RANDOM ACCESS MEMORY RESET PROCEDURE under CLEARING CODES under SELF-DIAGNOSTIC SYSTEM in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Diagnostic Routines

1. 1) Analyze Vehicle Inspection/Maintenance (I/M) Test Report Ensure vehicle Inspection/Maintenance (I/M) test report has been analyzed. Check for data entry errors, correct model, year, vehicle test weight and correct calibration (California or Federal). Identify which gas readings are HIGH and which were LOW. If report includes a drive trace, identify during which mode the gas(es) failed. When report has been analyzed completely, go to next step.
2. 2) Vehicle Failed EVAP Compliance If vehicle failed an EVAP Emissions System Leak Test or a Purge Flow Test only, go to step 35) . If vehicle failed EVAP, Purge Flow and gas tests, go to next step.
3. 3) Baseline Vehicle Using an exhaust gas analyzer, baseline vehicle. If vehicle must be driven to achieve baseline, ensure baseline drive cycle is able to be repeated to verify the repairs. During baseline, check for any related symptoms that may be present (driveability, A/T shifting or exhaust smoke). When vehicle has been baselined, go to next step.
4. 4) Check For Other Symptoms Check for driveability concerns (including idle and A/T shifting concerns, exhaust smoke and for cooling system concerns (engine unable to reach normal operating temperature). If other symptoms are present, perform «QUICK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Repair as necessary, then go to step 40) to verify repairs. If no other symptoms are present, go to next step.
5. 5) Preliminary Checks Check for vacuum leaks or blockage. Check wiring harness connectors. Ensure proper scheduled maintenance has been performed. Check intake air tube and air cleaner for obstructions, leaks or dirty element. Ensure proper emission controls and components are installed on vehicle. Repair as necessary, then go to step 40) to verify repairs. If no repairs are necessary and all checks are okay, go to next step.
6. 6) Perform PCM Quick Test Perform «QUICK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to retrieve Diagnostic Trouble Codes (DTCs). If no DTCs are present, go to next step. If DTCs are present, service DTC. See «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE article to service appropriate DTC, then go to step 40) to verify repairs.
7. 7) Check Carbon Monoxide (CO) Levels Check vehicle CO levels. If vehicle did not have excessive CO levels, go to next step. If vehicle had excessive CO levels, this indicates that engine is running rich. Go to step 15) .
8. 8) Check Hydrocarbon (HC) Levels Check vehicle HC levels. If vehicle did not have excessive HC levels, go to next step. If vehicle had excessive HC levels with low to normal CO levels, this indicates that engine is running lean. Go to step 25) .
9. 9) Check Oxides Of Nitrogen (NOx) Levels Check vehicle NOx levels. If vehicle did not have excessive NOx levels, verify all previous testing. If vehicle had excessive NOx levels, go to step 30) .
10. 15) High CO Levels: Check HC Levels Check vehicle HC levels. If vehicle had excessive HC levels, check for incomplete combustion/running rich. Go to next step. If vehicle did not have excessive HC levels, go to step 17) to check for running rich concern.
11. 16) Check Secondary Ignition System Go to «TEST JB: SECONDARY IGNITION»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to check secondary ignition system. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs. If secondary ignition system is okay, go to next step.
12. 17) Check Fuel Delivery System For High Fuel Pressure Or Leak-Down Check fuel delivery system. On Natural Gas models, go to «TEST HB: NATURAL GAS FUEL DELIVERY SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. On all other models, go to «TEST HC: GASOLINE FUEL DELIVERY SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs. If fuel delivery system is okay, go to next step.
13. 18) Check PCV System Check PCV system. Go to «TEST HG: PCV SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs. If PCV system is okay, go to next step.
14. 19) Check Exhaust System Check exhaust system. Go to «TEST HF: CATALYST EFFICIENCY MONITOR & EXHAUST SYSTEMS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs. If exhaust system is okay, go to next step.
15. 20) Check Engine Mechanical Condition See appropriate article in ENGINES. Check compression, camshaft, valve train components, etc. Repair as necessary, then go to step 40) to verify repairs. If no engine mechanical problems are indicated and all checks are okay, go to next step.
16. 21) Additional Checks Ensure correct PCV valve is installed for application. Service as necessary, then go to step 40) to verify repairs. If PCV valve is correct, go to step 45) .
17. 25) High HC With Normal To Low CO Level, Check Fuel Delivery System For Leak-Down Or Low Fuel Pressure Check fuel delivery system for leak-down or low pressure. On Natural Gas models, go to «TEST HB: NATURAL GAS FUEL DELIVERY SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. On all other models, go to «TEST HC: GASOLINE FUEL DELIVERY SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs. If fuel delivery system is okay, go to next step.
18. 26) Check Secondary Ignition System Go to «TEST JB: SECONDARY IGNITION»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to check secondary ignition system. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs. If secondary ignition system is okay, go to next step.
19. 27) Check PCV System Go to «TEST HG: PCV SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to check PCV system. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs. If PCV system is okay, go to next step.
20. 28) Check Engine Mechanical Condition See appropriate article in ENGINES. Check compression, camshaft, valve train components, etc. Repair as necessary, then go to step 40) to verify repairs. If no engine mechanical problems are indicated and all checks are okay, go to next step
21. 29) Additional Checks Ensure correct PCV valve is installed for application. Service as necessary, then go to step 40) to verify repairs. If PCV valve is correct, go to step 45) .
22. 30) High NOx With Normal To Low HC & CO Levels Check engine for concerns such as excessive carbon build-up in combustion chamber. See appropriate article in ENGINES. Repair as necessary, then go to step 40) to verify repairs. If no engine mechanical problems are indicated, go to next step.
23. 31) Additional Checks Check Torque Converter Clutch (TCC) operation. See appropriate OVERHAUL or DIAGNOSIS article in AUTOMATIC TRANSMISSIONS. Check intake air system for add-on aftermarket parts or modifications which may restrict airflow into intake air system. Check for running lean concerns (vacuum leaks or low fuel pressure), refer to procedures starting at step 25) . Repair as necessary, then go to step 40) to verify repairs. If all checks are okay, go to step 45) .
24. 35) EVAP System Concern: Preliminary Checks Analyze I/M test report to determine when concern is present. Verify concern and inspect and repair the following as necessary: Check fuel filler cap for proper installation, physical damage or contamination. Check EVAP system hoses and lines for proper connection, damage or blockage. Check fuel vapor storage canister for damage. If all checks are okay, go to next step. If repairs have been performed, go to step 38) to verify repairs.
25. 36) Perform PCM Quick Test Perform «QUICK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to retrieve Diagnostic Trouble Codes (DTCs). If no DTCs are present, go to next step. If DTCs are present, service DTC. See «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to service appropriate DTC, then go to step 38) to verify repairs.
26. 37) Check EVAP Emissions System For Leaks See appropriate symptom under «EVAPORATIVE EMISSION SYSTEM TESTS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emission-system-tests) . Follow diagnostic procedures and repair as necessary, then go to step 38) . If EVAP emission system is okay, verify test results. If results are okay, go to «TEST Z: INTERMITTENT»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article, or return to «SYMPTOM DIAGNOSIS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-trouble-shooting-no-codes-eec-v-gasoline-ngv__symptom-diagnosis) under SYMPTOMS in TROUBLE SHOOTING - NO CODES - EEC-V - GASOLINE & NGV article to repair any additional symptoms. Follow diagnostic procedures and repair as necessary, then go to step 38) .
27. 38) EVAP Emissions System Repair Verification After making repairs to EVAP emissions system, reset KAM and relearn basic adaptive strategy. See «KEEP ALIVE RANDOM ACCESS MEMORY RESET PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under CLEARING CODES under SELF-DIAGNOSTIC SYSTEM in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Repeat «QUICK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Repair any DTCs that may be retrieved and perform «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) under EVAPORATIVE EMISSION SYSTEM TESTS. If original concern has not been corrected or if another concern exists, repeat step 1) .
28. 40) Repair Verification After making repairs to appropriate system, reset KAM and relearn basic adaptive strategy. See «KEEP ALIVE RANDOM ACCESS MEMORY RESET PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under CLEARING CODES under SELF-DIAGNOSTIC SYSTEM in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Repeat «QUICK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Repair any DTCs that may be retrieved. Repeat baseline test using gas analyzer. If vehicle requires driving for the baseline test, drive at least 5 miles to relearn some additional Adaptive Learning Strategy (trim values). Ensure same drive mode is used as original baseline test performed in step 3) . If all gas levels are within acceptable range, save all repair documentation that may be required by local or federal law and return vehicle to customer. If any gas level is not within acceptable range, go to step 1) .
29. 45) Catalyst Delta Temperature Test Disable secondary AIR system, if equipped. Start and run engine for 2 minutes at 2500 RPM to heat exhaust system. Turn ignition switch to OFF position. Disconnect and ground one spark plug wire from each cylinder bank (for Coil On Plug applications, disconnect one coil connector from each cylinder bank). Start and run engine at 1000 RPM. Disconnect Idle Air Control (IAC) valve while maintaining 1000 RPM. Using an infrared temperature probe, measure temperature at both the inlet and outlet of each catalytic converter. If the temperature difference between inlet and outlet of each catalytic converter is 50°F (28°C) or less, testing indicates catalytic converter is not operating correctly. Repeat test step to verify readings. If temperature differences are still 50°F (28°C) or less, replace affected catalytic converter. Reconnect all connectors, IAC valve and AIR system. Go to step 40) to verify repairs. If the temperature difference between inlet and outlet of each catalytic converter is more than 50°F (28°C), the catalytic converters are operating correctly. Reconnect all connectors, IAC valve and AIR system. Perform «PCM RESET PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under CLEARING CODES under SELF-DIAGNOSTIC SYSTEM in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Repeat QUICK TEST to clear any DTCs set during testing. See «QUICK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Verify previous test results. If results are okay, go to «TEST Z: INTERMITTENT»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) , step 1) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Follow diagnostic procedures and repair as necessary, then go to step 40) to verify repairs.

FUEL EVAPORATION

Note. For testing of EVAP emission system and/or EVAP component not found here, perform appropriate symptom test under EVAPORATIVE EMISSION SYSTEM TESTS , or TEST HX: EVAPORATIVE EMISSION MONITOR & SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Turn ignition off. Disconnect Canister Vent (CV) solenoid wiring harness connector. Using a DVOM, measure resistance between CV solenoid terminals. If resistance is not 48-65 ohms, replace CV solenoid and repeat QUICK TEST in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. If resistance is 48-65 ohms, solenoid is okay. If fault is still present, perform TEST HX: EVAPORATIVE EMISSION MONITOR & SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

EVAP Canister (All Models)

There are no moving parts in canister. Check for loose, missing, cracked or broken connections and parts. Repair or replace canister as necessary. There should be no liquid in canister.

EVAP Canister Purge Valve

Note. EVAP canister purge valve resistance reading must be taken with engine cooled down.

Turn ignition switch to OFF position. Disconnect EVAP canister purge valve. Using a DVOM, measure resistance between EVAP canister purge valve terminals. If resistance is not 30-38 ohms, replace EVAP canister purge valve. Perform EVAPORATIVE EMISSIONS SYSTEM LEAK TEST under EVAPORATIVE EMISSION SYSTEM TESTS to verify repair. If resistance is 30-38 ohms, EVAP canister purge valve is okay. If fault is still present, perform TEST HX: EVAPORATIVE EMISSION MONITOR & SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

SECONDARY AIR INJECTION

For additional Secondary Air Injection (AIR) system testing and specifications, see TEST HM: SECONDARY AIR INJECTION SYSTEM under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Electric Exhaust Gas Recirculation (Ranger 2.3L Only)

For additional Electric Exhaust Gas Recirculation (EEGR) system testing and specifications, see TEST KD: ELECTRIC EXHAUST GAS RECIRCULATION under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Exhaust Gas Recirculation

1. Ensure all vacuum hoses are correctly routed and securely attached. Replace any crimped or broken hoses. Ensure there is less than one in. Hg vacuum to EGR valve at idle with engine at normal operating temperature. Install tachometer. Disconnect Idle Air Control (IAC) wiring harness connector. Remove and plug vacuum hose at EGR valve. Place transmission in Neutral.
2. Start and operate engine at idle. Note idle speed. Using a hand-held vacuum pump, slowly apply 5-10 in. Hg vacuum to EGR valve. When vacuum is fully applied, engine should do one or more of the following: Engine should stall. Idle speed should drop more than 100 RPM. Idle speed should return to normal when vacuum is released.
3. Service or replace EGR valve if engine does not stall or idle speed does not respond as specified. Reconnect IAC harness connector. Unplug and reconnect vacuum hose at EGR valve. For additional EGR system testing and specifications, go to «TEST HE: EGR SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

POSITIVE CRANKCASE VENTILATION

Note. Use this test to diagnose Positive Crankcase Ventilation (PCV) valve and related vacuum hoses only.

1. 1) Stuck PCV Valve Check Ensure PCV valve maintenance schedule has been followed. Ensure proper PCV valve is installed. Remove PCV valve. Shake valve and listen for rattle. If PCV valve rattles when shaken, install PCV valve and go to next step. Replace PCV valve if it does not rattle when shaken. Verify repair.
2. 2) PCV System Check Start engine and warm to normal operating temperature. Disconnect fresh air hose from remote air cleaner or outlet tube connecting MAF sensor to throttle body. Place a stiff piece of paper over end of hose. If vacuum from hose does not hold paper in place for one minute, go to next step. If vacuum from hose holds paper in place for one minute, PCV system is okay. Return to «SYMPTOM DIAGNOSIS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-trouble-shooting-no-codes-eec-v-gasoline-ngv__symptom-diagnosis) under SYMPTOMS in TROUBLE SHOOTING - NO CODES - EEC-V - GASOLINE & NGV article to complete testing.
3. 3) Evaporative Emission System Check Disconnect evaporative emission hose from PCV system and plug connector. Again, place a stiff piece of paper over end of hose. If vacuum from hose does not hold paper in place for one minute, isolate vacuum leak or restriction in PCV system and repair as necessary. If vacuum from hose holds paper in place for one minute, PCV system is working properly at this time. Go to «EVAPORATIVE EMISSION SYSTEM TESTS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emission-system-tests) to diagnose EVAP system vacuum leak.

EVAPORATIVE EMISSION SYSTEM TESTS

Note. For additional evaporative emission system testing and DTC-related procedures, see EVAPORATIVE EMISSIONS DIAGNOSTIC TROUBLE CODE DEFINITIONS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

Note. On Cougar, evaporative emission diagnostic procedures are not available from manufacturer.

CANISTER VENT SOLENOID CLOSING PROCEDURE

Connect scan tool to DLC. Turn ignition on. Using scan tool, select OUTPUT TEST MODE. Select FTP and FTP V PID from PID/DATA MONITOR & RECORD menu. Select ALL OFF mode. Close canister vent solenoid by pressing START button on scan tool.

EVAPORATIVE EMISSIONS SYSTEM LEAK TEST

Connect Evaporative Emissions System Leak Tester (134-00056) to EVAP test port. Close canister vent solenoid. See CANISTER VENT SOLENOID CLOSING PROCEDURE . Pressurize EVAP system to 14 in. H 2 O (3.48 kPa). Monitor system pressure for 2 minutes. EVAP system pressure should not fall below 8 in. H 2 O (2 kPa). Repair leaks as necessary. Repeat EVAP system leak test until system pressure remains greater than 8 in. H 2 O (2 kPa) after 2 minutes.

HISSING SOUND WHEN REMOVING FUEL CAP

Note. After each service or repair procedure has been completed, reconnect all components and perform DRIVE CYCLE PROCEDURE under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. Clear DTCs and repeat QUICK TEST in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to ensure all EEC-V systems are working properly and DTCs are no longer present.

Note. Enter this test only when all steps under QUICK TEST have been successfully completed and hiss still exists when fuel cap is opened or if directed here from another test or chart.

Blackwood, Econoline, Escape, Excursion, Expedition, Explorer, F250-550 Super Duty Pickup, Mountaineer, Navigator, Ranger & Windstar

1. Testing EVAP Canister, Canister Vent Solenoid Flow & Canister Vent Hose - Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, EVAP system is not blocked, go to step 6 . On models equipped with a canister vent hose assembly, if pressure does not drop immediately, go to next step. On models equipped with canister vent solenoid, if pressure does not drop immediately, go to step 3 . On all other models, if pressure does not drop immediately, go to step 4 .
2. Testing Canister Vent Hose Assembly For Blockage Disconnect canister vent hose assembly from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
3. Testing Canister Vent Solenoid For Blockage Remove canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
4. Testing EVAP Canister Disconnect EVAP canister tube from fuel tank at "F" fitting from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Testing EVAP Canister Tube Or Fuel Vapor Vent Valve For Blockage Disconnect fuel vapor valve assembly from EVAP canister tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister tube and/or fuel vapor valve tube between fuel tank and EVAP canister and bracket assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor valve(s) or assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
6. Testing For Blockage Between EVAP Canister Purge Valve & Fuel Tank Remove fuel tank fuel vapor hose from EVAP canister purge valve. Turn ignition on. On models with a canister vent solenoid, using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. On models without canister vent solenoid, plug canister vent hose assembly or plug canister vent cap. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, replace fuel vapor hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure drops immediately, system has passed. Reconnect all components. On models with a canister vent solenoid, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. On models without canister vent solenoid, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Continental

1. Testing EVAP Canister & Canister Vent Solenoid Flow - Connect Evaporative Emissions System Leak Tester (134-00056) to test port. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to step 8 . If pressure does not drop immediately, go to next step.
2. Testing Canister Vent Solenoid Remote Vent Hose Assembly For Blockage Disconnect canister vent solenoid hose from solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid remote vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If pressure does not drop immediately, go to next step.
3. Testing Canister Vent Solenoid Hose Assembly For Blockage Disconnect canister vent solenoid hose assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If pressure does not drop immediately, go to next step.
4. Testing Canister Vent Solenoid Elbow For Blockage Remove canister vent solenoid elbow. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid elbow. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
5. Testing EVAP Canister Disconnect EVAP canister tube at canister that runs from EVAP canister to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See EVAPORATIVE EMISSIONS SYSTEM LEAK TEST. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
6. Testing EVAP Canister Tube Disconnect EVAP canister tube at fuel vapor valve tube assembly that runs from EVAP canister to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
7. Testing EVAP Canister Purge Outlet Tube Disconnect EVAP canister purge outlet tube at fuel vapor valve tube assembly that runs from EVAP purge valve to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to step 9 . If pressure does not drop immediately, go to next step.
8. Testing Evaporative Emissions Test Port Disconnect evaporative emissions test port from EVAP canister purge outlet tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister purge outlet tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace evaporative emissions test port. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
9. Testing Fuel Vapor Valve Tube Assembly Disconnect EVAP canister purge outlet tube at fuel vapor valve tube assembly. Connect EVAP tester to fuel filler tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Crown Victoria, Grand Marquis & Town Car

1. Testing EVAP Canister & Canister Vent Solenoid Flow - Connect Evaporative Emissions System Leak Tester (134-00056) to test port. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, EVAP canister and vent solenoid are not blocked, go to step 9 . If pressure does not drop immediately, go to next step.
2. Testing Canister Vent Solenoid Remote Vent Hose Assembly For Blockage Disconnect canister vent solenoid remote vent hose from in-line connector. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid remote vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If pressure does not drop immediately, go to next step.
3. Testing Canister Vent Solenoid Hose Assembly For Blockage Disconnect canister vent solenoid hose assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If pressure does not drop immediately, go to next step.
4. Testing Canister Vent Solenoid For Blockage Remove canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
5. Testing EVAP Canister Disconnect EVAP canister tube at canister that runs from EVAP canister to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
6. Testing EVAP Canister Tube Disconnect EVAP canister tube at fuel vapor valve tube assembly that runs from EVAP canister to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
7. Testing EVAP Canister Purge Outlet Tube Disconnect EVAP canister purge outlet tube at fuel vapor valve tube assembly that runs from EVAP purge valve to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to step 9 . If pressure does not drop immediately, go to next step.
8. Testing Evaporative Emissions Test Port Disconnect evaporative emissions test port from EVAP canister purge outlet tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister purge outlet tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace evaporative emissions test port. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
9. Testing Fuel Vapor Valve Tube Assembly Disconnect EVAP canister purge outlet tube at fuel vapor valve tube assembly. Connect EVAP tester to fuel filler tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Escort, Escort ZX2 & Focus

1. Testing EVAP Canister & Canister Vent Solenoid Flow - Connect Evaporative Emissions System Leak Tester (134-00056) to test port. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, EVAP canister and vent solenoid are not blocked, go to step 5 . If pressure does not drop immediately, go to next step.
2. Testing Canister Vent Solenoid Hose Assembly Disconnect canister vent solenoid hose assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
3. Testing Canister Vent Solenoid For Blockage Remove canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
4. Testing EVAP Canister Disconnect EVAP canister tube at canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace EVAP canister outlet tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Testing Fuel Vapor Control Valve Tube Assembly (With ORVR Only) Disconnect fuel vapor valve from fuel vapor control valve tube. Plug hose on fuel vapor valve assembly and at fuel vapor control valve tube assembly. Move EVAP tester to fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed and go to next step. If pressure does not drop immediately, replace fuel vapor control valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
6. Testing Fuel Vapor Valve Assembly Disconnect fuel vapor valve tube assembly at EVAP canister tube "T" fitting connector and at fuel vapor valve. Plug both open ports at tube assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor valve assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

F150 Pickup

1. Testing EVAP Canister And Canister Vent Solenoid Flow - Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, EVAP system is not blocked, go to step 5 . If pressure does not drop immediately, go to next step.
2. Testing Canister Vent Hose Assembly For Blockage Disconnect canister vent hose assembly from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
3. Testing Canister Vent Solenoid For Blockage Remove canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
4. Testing EVAP Canister For Blockage Disconnect EVAP purge outlet tube from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Testing EVAP Fuel Vapor Vent Valve(s) Or Assembly Disconnect battery ground terminal. Connect leak tester to fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, reconnect all disconnect components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If pressure does not drop immediately, replace fuel vapor vent valve(s) or EVAP canister assembly. After repairs, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Scheme 6

1. Testing Fuel Tank Pressure Sensor - Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is not 4.22-4.90 volts, go to step 3. If FTP V PID is 4.22-4.90 volts, go to next step.
2. Testing Venting Portion Of EVAP System For Blockage Using scan tool, open canister vent solenoid. If pressure drops immediately, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to step 5.
3. Testing For Fuel Filler Pipe Blockage Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, replace fuel filler pipe. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
4. Testing Fuel Vapor Control Valve Tube For Pinch Or Blockage Reconnect fuel filler pipe to fuel tank. Lower fuel tank about 3/4" (19 mm). Connect EVAP tester to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, fuel vapor control tube is pinched, replace fuel tank assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If FTP V PID is not 4.22-4.90 volts, fuel vapor control valve tube or fuel tank vapor control valve is blocked, replace fuel tank assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV articleS. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Isolate Location Of Blockage Disconnect fuel vapor control valve tube from EVAP canister purge outlet tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, replace fuel tank assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
6. Testing EVAP Canister Vent Solenoid For Blockage Reconnect fuel vapor control valve tube from EVAP canister purge outlet tube. Lower differential to access canister vent solenoid. See appropriate DIFFERENTIALS article in DRIVE AXLES. Disconnect canister vent solenoid from canister vent hose. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace canister vent solenoid. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
7. Testing Canister Vent Solenoid Hose Assembly For Blockage Reinstall differential. Lower rear subframe to access EVAP canister and bracket assembly. Lower EVAP canister and bracket assembly. Disconnect canister vent solenoid hose from 1.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
8. Testing 1.0L EVAP Canister Disconnect fuel vapor storage EVAP canister inlet tube at 1.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace 1.0L EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
9. Testing Fuel Vapor Storage Canister Inlet Tube Disconnect fuel vapor storage canister inlet tube from 2.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fuel vapor storage canister inlet tube. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
10. Testing 2.0L EVAP Canister Disconnect EVAP canister purge outlet tube at 2.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace 2.0L EVAP canister. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace EVAP canister purge outlet tube. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Mustang

1. Testing Fuel Tank Pressure Sensor - Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, go to next step. If FTP V PID is not 4.22-4.90 volts, go to step 3 .
2. Testing Venting Portion Of EVAP System For Blockage Using scan tool, open canister vent solenoid by selecting STOP button. If pressure drops immediately, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to step 7 .
3. Testing Fuel Tank Pressure Sensor Operation Move EVAP tester to evaporative emission test port. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, go to next step. If FTP V PID is not 4.22-4.90 volts, perform «TEST HX: EVAPORATIVE EMISSION MONITOR & SYSTEM»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
4. Testing For Location Of Blockage Using scan tool, open canister vent solenoid by selecting STOP button. If pressure drops immediately, go to next step. If pressure does not drop immediately, go to step 7 .
5. Testing For Pinched Or Blocked Fuel Vapor Control Valve Tube Lower fuel tank about 3/4" (19 mm). Connect EVAP tester to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, replace fuel vapor control tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If FTP V PID is not 4.22-4.90 volts, go to next step.
6. Testing Fuel Filler Tube Assembly Disconnect tank vapor recirculation hose at fuel filler pipe and plug both openings. Pressurize system to 14 in. H 2 O (3.48 kPa). Remove plug from tank vapor recirculation hose. If pressure drops immediately, replace fuel vapor control valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel filler pipe assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
7. Testing Fresh Air Vent Hose Disconnect fresh air vent hose from inside trunk. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fresh air vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
8. Testing Fresh Air Vent Hose At Fuel Filler Pipe Disconnect fresh air vent hose at fuel filler pipe. Pressurize system to 14 in. H 2 OH 2 O (3.48 kPa). If pressure drops immediately, replace fuel filler pipe. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
9. Testing Tank Vapor Valve Assembly Disconnect tank vapor valve assembly fresh air tube from canister vent solenoid vent hose. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace tank vapor valve assembly fresh air tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
10. Testing Canister Vent Solenoid Hose Assembly For Blockage Disconnect canister vent solenoid hose assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
11. Testing Canister Vent Solenoid For Blockage Remove canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
12. Testing EVAP Canister Disconnect EVAP canister inlet elbow tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
13. Testing EVAP Canister Inlet Elbow Tube Disconnect fuel vapor valve tube assembly from EVAP canister inlet elbow tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister inlet elbow tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Sable & Taurus

1. Testing EVAP Canister & Canister Vent Solenoid Flow - Connect Evaporative Emissions System Leak Tester (134-00056) to test port. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, EVAP canister and vent solenoid are not blocked, go to step 8 . If pressure does not drop immediately, go to next step.
2. Testing Canister Vent Solenoid Hose Assembly For Blockage Disconnect canister vent solenoid hose assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If pressure does not drop immediately, go to next step.
3. Testing Canister Vent Solenoid For Blockage Remove canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
4. Testing EVAP Canister Disconnect EVAP canister tube at canister that runs from EVAP canister to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
5. Testing EVAP Canister Tube Disconnect EVAP canister tube at fuel vapor valve tube assembly that runs from EVAP canister to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
6. Testing EVAP Canister Purge Outlet Tube Disconnect EVAP canister purge outlet tube at fuel vapor valve tube assembly that runs from EVAP purge valve to fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to step 8 . If pressure does not drop immediately, go to next step.
7. Testing Evaporative Emissions Test Port Disconnect evaporative emissions test port from EVAP canister purge outlet tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister purge outlet tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace evaporative emissions test port. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
8. Testing Fuel Vapor Valve Tube Assembly Disconnect EVAP canister purge outlet tube at fuel vapor valve tube assembly. Connect EVAP tester to fuel filler tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

EXCESSIVE FUEL ODOR

Note. After each service or repair procedure has been completed, reconnect all components and perform DRIVE CYCLE PROCEDURE under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. Clear DTCs and repeat QUICK TEST in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to ensure all EEC-V systems are working properly and DTCs are no longer present.

Note. Enter this test only when all steps under QUICK TEST have been successfully completed and when excessive fuel odor still exists or if directed here from another test or chart.

Blackwood, Econoline, Escape, Expedition, Excursion, Explorer, F250-550 Super Duty Pickup, Mountaineer, Navigator, Ranger & Windstar

1. Testing Evaporative Emission Running Loss System Monitor - Perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If PCM DTCs P0442, P0455, P1443 or P1450 are retrieved, see «EVAPORATIVE EMISSIONS DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If any other PCM DTCs are retrieved, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If no PCM DTCs are retrieved, go to next step.
2. Testing For Restriction In EVAP Test Port Through Canister Vent Solenoid Connect Evaporative Emissions System Leak Tester (134-00056) to test port. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to «TEST D»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__hissing-sound-when-removing-fuel-cap) .
3. Testing For Restriction Between Fuel Tank & EVAP Canister Move EVAP tester to fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
4. Testing EVAP Canister Tube Or Fuel Vapor Vent Valve Blockage Disconnect fuel vapor vent valve from EVAP canister tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fuel vapor tubes between fuel tank and EVAP canister and/or EVAP canister tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor vent valve. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Continental, Escort, Escort ZX2, Focus, Crown Victoria, Grand Marquis, Sable, Taurus & Town Car

1. Testing Evaporative Emission Running Loss System Monitor - Perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If PCM DTC P0442, P0455, P1443 or P1450 is retrieved, see «EVAPORATIVE EMISSIONS DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If any other PCM DTC(s) are retrieved, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If no PCM DTC(s) are retrieved, go to next step.
2. Testing Evaporative Emissions Test Port Through Canister Vent Solenoid Connect Evaporative Emissions System Leak Tester (134-00056) to test port. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, go to «HISSING SOUND WHEN REMOVING FUEL CAP»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__hissing-sound-when-removing-fuel-cap) .
3. Testing EVAP System Between Fuel Filler Pipe & Canister Vent Solenoid Move EVAP tester to fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. On Escort, Escort ZX2 and Focus, if pressure does not drop immediately, go to «HISSING SOUND WHEN REMOVING FUEL CAP»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__hissing-sound-when-removing-fuel-cap) . On all other models, if pressure does not drop immediately, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

1. Testing Evaporative Emission Running Loss System Monitor - Perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If PCM DTCs P0442, P0455, P1443 or P1450 are retrieved, see «EVAPORATIVE EMISSIONS DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If any other PCM DTCs are retrieved, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If no PCM DTCs are retrieved, go to next step.
2. Testing For Restriction In EVAP Test Port Through Canister Vent Solenoid Connect Evaporative Emissions System Leak Tester (134-00056) to test port. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, go to «HISSING SOUND WHEN REMOVING FUEL CAP»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__hissing-sound-when-removing-fuel-cap) .
3. Testing For Restricted EVAP System Between Fuel Filler Pipe And Canister Vent Solenoid Connect leak tester to fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel vapor vent valve. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

LS & Thunderbird

1. Testing Evaporative Emission Running Loss System Monitor - Perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If PCM DTCs P0442, P0455, P1443 or P1450 are retrieved, see «EVAPORATIVE EMISSIONS DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If any other PCM DTCs are retrieved, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If no PCM DTCs are retrieved, go to next step.
2. Evaporative Emission System Leak Test Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, go to next step. If system does not pass, go to step 9.
3. Testing Fuel Tank Pressure Sensor Operation Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, go to next step. If FTP V PID is not 4.22-4.90 volts, go to «TEST D»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__hissing-sound-when-removing-fuel-cap).
4. Testing Vent Portion Of EVAP System Using scan tool, open canister vent solenoid. If pressure drops immediately, go to next step. If pressure does not drop immediately, go to «TEST D»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__hissing-sound-when-removing-fuel-cap).
5. Testing Evaporative Emissions Test Port Move EVAP tester to test port. Using scan tool, close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, evaporative emission system is operating normally. If FTP V PID is not 4.22-4.90 volts, go to next step.
6. Testing Fuel Vapor Control Valve Tube Disconnect fuel vapor control valve tube from under vehicle fuel supply and vapor tube assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fuel tank assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
7. Testing Under Vehicle Fuel Supply & Vapor Tube Assembly Disconnect under vehicle fuel supply and vapor tube assembly from engine compartment fuel supply and vapor tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace under vehicle fuel supply and vapor tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
8. Testing Engine Compartment Fuel Supply & Vapor Tube Assembly Disconnect engine compartment fuel supply and vapor tube assembly from canister purge valve. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace engine compartment fuel supply and vapor tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace EVAP canister purge valve. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
9. Testing For Location Of Leak Connect EVAP tester to fuel filler pipe. Disconnect fuel vapor control valve tube from under vehicle fuel supply and vapor tube assembly. Plug both tube open ends. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, leaks are in front portion of EVAP system, go to next step. If system does not pass, leaks are in rear portion of EVAP system, go to step 14.
10. Testing To Confirm Leak In Front Portion Of EVAP System Move EVAP tester to test port. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system does not pass, go to next step. If system passes, replace "O" ring seals between fuel vapor control valve tube and under vehicle fuel supply and vapor tube assembly. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
11. Testing Under Vehicle Fuel Supply & Vapor Tube Assembly Disconnect under vehicle fuel supply and vapor tube assembly from engine compartment fuel supply and vapor tube assembly. Plug engine compartment fuel supply and vapor tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system did not pass, go to next step. If system passes, replace under vehicle fuel supply and vapor tube assembly. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
12. Testing Engine Compartment Fuel Supply & Vapor Tube Assembly Disconnect engine compartment fuel supply and vapor tube assembly from canister purge valve. Plug EVAP canister purge valve. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system did not pass, go to next step. If system passes, replace engine compartment fuel supply and vapor tube assembly. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
13. Testing EVAP Canister Purge Valve Disconnect evaporative emission return tube from EVAP canister purge valve. Plug EVAP canister purge valve. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, replace evaporative emission return tube. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If system did not pass, replace EVAP canister purge valve. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
14. Testing To Determine Is In EVAP Canister Or Fuel Tank Portion Of System Disconnect fuel vapor control valve tube from EVAP canister purge outlet tube. Plug open end of fuel vapor control valve tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, reconnect all components and go to next step. If system does not pass, go to step 20.
15. Testing EVAP Canister Vent Solenoid Reconnect fuel vapor control valve tube. Lower differential to gain access to canister vent solenoid. See appropriate DIFFERENTIALS article in DRIVE AXLES. Disconnect canister vent solenoid from canister vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system does not pass, go to next step. If system passes, replace canister vent solenoid. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
16. Testing Canister Vent Solenoid Hose Assembly Reinstall differential. Lower rear subframe to access EVAP canister and bracket assembly. Remove EVAP canister and bracket assembly. Move EVAP tester to EVAP canister purge outlet tube. (Scheme 6) Disconnect canister vent solenoid hose from 1.0L EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure holds, replace canister vent solenoid hose assembly. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not hold, go to next step.
17. Testing 1.0L EVAP Canister Disconnect fuel vapor storage EVAP canister inlet tube at 1.0L EVAP canister and plug inlet tube. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure holds, replace 1.0L EVAP canister. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not hold, go to next step.
18. Testing Fuel Vapor Storage Canister Inlet Tube Disconnect fuel vapor storage canister inlet tube from 2.0L EVAP canister and plug EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure holds, replace fuel vapor storage canister inlet tube. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not hold, go to next step.
19. Testing 2.0L EVAP Canister Disconnect EVAP canister purge outlet tube at 2.0L EVAP canister and plug outlet tube. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure holds, replace 2.0L EVAP canister. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not hold, replace EVAP canister purge outlet tube. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
20. Testing Fuel Vapor Control Valve Tube & Fuel Tank Disconnect fuel filler pipe hose at tank and plug hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system does not pass, go to next step. If system passes, replace fuel tank assembly. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
21. Testing Fuel Filler Pipe Hose Disconnect fuel filler pipe hose at fuel filler pipe and plug pipe. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, replace fuel filler pipe hose. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If system did not pass initial test, replace fuel filler pipe assembly. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

1. Evaporative Emission System Leak Test - Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, go to next step. If system does not pass, go to step 3 .
2. Testing Evaporative Emission Running Loss System Monitor Perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If PCM DTCs P0442, P0455, P1443 or P1450 are retrieved, see «EVAPORATIVE EMISSIONS DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure. If any other PCM DTCs are retrieved, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article for appropriate test procedure.
3. Testing For Location Of Leak Connect Evaporative Emissions System Leak Tester (134-00056) to evaporative emissions test port. Disconnect fuel vapor control valve tube from under vehicle fuel supply and vapor return tube assembly. Plug both tube open ends. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, go to step 9 .
4. Testing Vapor Hose From Fuel Tank To Under Vehicle Fuel Supply & Vapor Return Tube Assembly Disconnect fuel vapor return tube from under vehicle fuel supply and vapor return tube assembly. Plug fuel supply and vapor return tube assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, replace fuel vapor return hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Testing Fuel Supply & Vapor Return Tube Assembly Disconnect fuel supply and vapor return tube assembly from canister purge outlet tube. Plug EVAP canister purge outlet tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, replace fuel supply and vapor return tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
6. Testing Evaporative Emissions Test Port Disconnect and plug evaporative emissions test port tube from EVAP canister purge outlet tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace evaporative emissions test port. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, reconnect all components and go to next step.
7. Testing EVAP Canister Purge Outlet Tube Disconnect and plug EVAP canister purge outlet tube from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister purge outlet tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, reconnect all components and go to next step.
8. Testing EVAP Canister Purge Valve Disconnect evaporative emission return tube from EVAP canister purge valve. Plug EVAP canister purge valve. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister purge valve. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace evaporative emissions return tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
9. Testing Venting Portion Of EVAP System For Blockage Reconnect all components. Move EVAP tester to fuel filler pipe. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). Open canister vent solenoid. If pressure drops immediately, go to step 14 . If pressure does not drop immediately, go to next step.
10. Testing Fresh Air Vent Hose For Blockage Disconnect fresh air vent hose from fuel filler pipe inside trunk. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fresh air vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
11. Testing Fresh Air Vent Hose At Fuel Filler Pipe For Blockage Disconnect fresh air vent hose at fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fuel filler pipe. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
12. Testing Tank Vapor Valve Tube Assembly For Blockage Disconnect tank vapor valve tube assembly fresh air tube from canister vent solenoid vent hose. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace tank vapor valve assembly fresh air tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
13. Testing Canister Vent Solenoid Hose Assembly For Blockage Disconnect canister vent solenoid hose assembly. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
14. Testing EVAP Canister For Leak Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, EVAP system diagnosis is complete. Go to step 18 . If system does not pass, go to next step.
15. Testing EVAP Canister Vent Solenoid For Leak Disconnect canister vent solenoid from EVAP canister and plug canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system does not pass, go to next step. If system passes, replace canister vent solenoid. Reconnect all components. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
16. Testing EVAP Canister Disconnect EVAP canister inlet elbow tube and plug tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system does not pass, go to next step. If system passes, replace EVAP canister. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
17. Testing EVAP Canister Inlet Elbow Tube Disconnect fuel vapor valve tube assembly from EVAP canister inlet elbow tube. Plug fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, replace EVAP canister inlet elbow tube. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If system does not pass, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
18. Testing Fuel Filler Pipe Grommet Reconnect all components. Move EVAP tester to fuel filler pipe. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops, repair fuel filler pipe as necessary. Repeat step. If pressure does not drop, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

UNABLE TO REFUEL VEHICLE

Note. Testing procedures are not available for Blackwood, Cougar, Econoline, Excursion, Expedition, Explorer, Pickup and Navigator.

Note. After each service or repair procedure has been completed, reconnect all components and perform DRIVE CYCLE PROCEDURE under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. Clear DTCs and repeat QUICK TEST in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article to ensure all EEC-V systems are working properly and DTCs are no longer present.

Note. Enter this test only when all steps under QUICK TEST have been successfully completed and unable to refuel condition still exists or if directed here from another test or chart.

Continental, Crown Victoria, Escape, Grand Marquis & Town Car

1. Testing Fuel Filler Pipe & Check Valve - Remove fuel filler cap. Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Access PCM PID FTP V. Pressurize system to 14 in. H 2 O (3.48 kPa). If PCM PID FTP V is 4.22-4.90 volts, go to next step. If PCM PID FTP V is not as specified, replace fuel filler pipe and check valve. Perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
2. Testing EVAP System For Restriction Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). On Crown Victoria, Escape, Grand Marquis and Town Car, if system pressurizes, go to next step. On all other models, if system pressurizes, go to step 4 . On all models, if system does not pressurize, remove tester from fuel filler pipe and install fuel filler cap. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
3. Testing Canister Vent Solenoid Remote Vent Hose Assembly For Blockage Disconnect canister vent solenoid remote vent hose from in-line connector. Pressurize system to 14 in. H 2 O (3.48 kPa). If system does not pressurize, repair or replace canister vent solenoid remote vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system pressurizes, go to next step.
4. Testing Canister Vent Hose For Blockage Remove canister vent hose from canister vent solenoid. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, replace canister vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Testing Canister Vent Solenoid Or Dust Separator For Blockage Remove canister vent solenoid from EVAP canister. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
6. Testing EVAP Canister For Blockage Remove EVAP canister tube from EVAP canister. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
7. Testing Fuel Vapor Valve Tube Assembly For Blockage Disconnect EVAP canister tube at fuel vapor valve tube assembly. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If system does not pressurize, replace EVAP canister tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Escort, Escort ZX2, Focus, Ranger, Sable & Taurus (With ORVR Only)

1. Testing Fuel Filler Pipe & Check Valve - Remove fuel filler cap. Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Access PCM PID FTP V. Pressurize system to 14 in. H 2 O (3.48 kPa). If PCM PID FTP V is 4.22-4.90 volts, go to next step. If PCM PID FTP V is not as specified, replace fuel filler pipe and check valve. Perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
2. Testing EVAP System For Restriction Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, remove tester from fuel filler pipe and install fuel filler cap. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
3. Testing Canister Vent Hose For Blockage Remove canister vent hose from canister vent solenoid. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, replace canister vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
4. Testing Canister Vent Solenoid For Blockage Remove canister vent solenoid from EVAP canister. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Testing EVAP Canister For Blockage Remove EVAP canister tube from EVAP canister. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
6. Testing Fuel Vapor Valve Tube Assembly For Blockage Disconnect EVAP canister tube at fuel vapor valve tube assembly. Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, replace fuel vapor valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If system does not pressurize, replace EVAP canister tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

1. Testing Fuel Tank Pressure Sensor Operation - Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, go to next step. If FTP V PID is not 4.22-4.90 volts, go to 3.
2. Testing Vent Portion Of EVAP System Using scan tool, open canister vent solenoid. If pressure drops immediately, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to step 5.
3. Testing Fuel Filler Pipe Connect EVAP tester to fuel filler pipe. Disconnect fuel filler pipe from fuel tank. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, replace fuel filler pipe. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
4. Testing Fuel Vapor Control Valve Tube Reconnect fuel filler pipe to fuel tank. Lower fuel tank about 3/4" (19 mm). Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If FTP V PID is 4.22-4.90 volts, fuel vapor control valve tube is pinched. Replace fuel tank assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If FTP V PID is not 4.22-4.90 volts, fuel vapor control valve tube is or fuel tank fuel vapor control valve is blocked. Replace fuel tank assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
5. Isolate Location Of Blockage Disconnect fuel vapor control valve tube from EVAP canister purge outlet tube. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, go to next step. If pressure does not drop immediately, replace fuel tank assembly. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
6. Testing EVAP Canister Vent Solenoid Reconnect fuel vapor control valve tube. Lower differential to gain access to canister vent solenoid. See appropriate DIFFERENTIALS article in DRIVE AXLES. Disconnect canister vent solenoid from canister vent hose. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure does not drop immediately, go to next step. If pressure drops immediately, replace canister vent solenoid. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
7. Testing Canister Vent Solenoid Hose Assembly Reinstall differential. Lower rear subframe to access EVAP canister and bracket assembly. Lower EVAP canister and bracket assembly. Disconnect canister vent solenoid hose from 1.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose assembly. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
8. Testing 1.0L EVAP Canister Disconnect fuel vapor storage EVAP canister inlet tube at 1.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace 1.0L EVAP canister. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
9. Testing Fuel Vapor Storage Canister Inlet Tube Disconnect fuel vapor storage canister inlet tube from 2.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fuel vapor storage canister inlet tube. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
10. Testing 2.0L EVAP Canister Disconnect EVAP canister purge outlet tube at 2.0L EVAP canister. (Scheme 6) Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace 2.0L EVAP canister. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace EVAP canister purge outlet tube. Reconnect all components. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test). If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

1. Testing fuel Filler Pipe & Check Valve - Remove fuel filler cap. Connect Evaporative Emissions System Leak Tester (134-00056) to fuel filler pipe. Turn ignition on. Using scan tool, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Access PCM PID FTP V. Pressurize system to 14 in. H 2 O (3.48 kPa). If PCM PID FTP V is 4.22-4.90 volts, go to next step. If PCM PID FTP V is not as specified, go to step 10 .
2. Testing EVAP System For Restriction Attempt to pressurize system to 14 in. H 2 O (3.48 kPa). If system pressurizes, go to next step. If system does not pressurize, perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.
3. Testing Fresh Air Vent Hose For Blockage Disconnect fresh air vent hose from fuel filler pipe inside trunk. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fresh air vent hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
4. Testing Fresh Air Vent Hose At Fuel Filler Pipe For Blockage Disconnect fresh air vent hose at fuel filler pipe. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace fuel filler pipe. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
5. Testing Tank Vapor Valve Assembly Fresh Air Tube For Blockage Disconnect tank vapor valve assembly fresh air tube from canister vent solenoid vent hose. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace tank vapor valve assembly fresh air tube. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
6. Testing Canister Vent Solenoid Hose Assembly For Blockage Disconnect canister vent solenoid hose assembly at canister vent solenoid. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid hose. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
7. Testing EVAP Canister Vent Solenoid For Blockage Disconnect canister vent solenoid from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace canister vent solenoid. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
8. Testing EVAP Canister For Blockage Disconnect EVAP canister inlet elbow from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
9. Testing EVAP Canister Inlet Elbow For Blockage Disconnect fuel vapor control valve tube from EVAP canister. Pressurize system to 14 in. H 2 O (3.48 kPa). If pressure drops immediately, replace EVAP canister inlet elbow. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, go to next step.
10. Check For Pinched Fuel Vapor Control Valve Tube Lower fuel tank about 3/4" (19 mm). If not already done, close canister vent solenoid. Select OUTPUT TEST MODE, FTP and FTP V PID. Select ALL OFF mode. Press START button on scan tool to close canister vent solenoid. Access PCM PID FTP V. Pressurize system to 14 in. H 2 O (3.48 kPa). If PCM PID FTP V is 4.22-4.90 volts, replace fuel vapor control valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If PCM PID FTP V is not as specified, go to next step.
11. Testing For Fuel Filler Tube Assembly Blockage Disconnect tank vapor recirculation tube fuel filler pipe and plug both ends. Pressurize system to 14 in. H 2 O (3.48 kPa). Remove plug from tank vapor recirculation tube. If pressure drops immediately, replace fuel vapor control valve tube assembly. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed. If pressure does not drop immediately, replace fuel filler pipe. Perform evaporative emissions system leak test. See «EVAPORATIVE EMISSIONS SYSTEM LEAK TEST»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-system-component-tests-eec-v-gasoline__evaporative-emissions-system-leak-test) . If system passes, perform «DRIVE CYCLE PROCEDURE»(/ford/explorer-sport-trac/i-2000-2005/remont/testing-diagnostics/#engine-controls-self-diagnostics-eec-v-gasoline-ngv) under DIAGNOSTIC MONITORS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. Ensure PENDING CODE CHECK & EVAP MONITOR "BYPASS" CHECK is performed.

Windstar

Check for restriction in canister vent solenoid, dust filter, carbon canisters, canister attachment hoses, vent tubing, fuel fill hose or fuel fill pipe. Perform diagnostic procedures for TEST C: DTC P1450: EXCESSIVE VACUUM DETECTED IN FUEL TANK under SYSTEM TESTS (EVAPORATIVE EMISSION) in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

See also:
• BASIC DIAGNOSTIC PROCEDURES - TRUCKS - EXCEPT DIESEL
• QUICK TEST
• SENSOR OPERATING RANGE CHARTS - EXCEPT VILLAGER
• IGNITION SYSTEMS
• SYMPTOM DIAGNOSIS
• INTAKE MANIFOLD RUNNER CONTROL SOLENOID
• INTAKE MANIFOLD SWIRL CONTROL SOLENOID
• SECONDARY AIR INJECTION
• FUEL EVAPORATION
• RELAYS
• EMISSIONS COMPLIANCE
• DIAGNOSTIC ROUTINES
• EVAPORATIVE EMISSION SYSTEM TESTS
• EVAPORATIVE EMISSIONS SYSTEM LEAK TEST
• CANISTER VENT SOLENOID CLOSING PROCEDURE
• TEST D
