Engine Controls - Sensor Operating Range Charts Ford Explorer Sport Trac I

Sensor Range Charts 1 illustration ~149 words

INTRODUCTION

Note. For sensor information on Villager, see SENSOR OPERATING RANGE CHARTS - VILLAGER . For sensor information on 7.3L diesel, see SELF-DIAGNOSTICS - EEC-V - DIESEL article.

Sensor operating range information can help determine if a sensor is out of calibration. An out-of-calibration sensor may not set a trouble code, but it will cause driveability problems.

Note. Unless specified otherwise, perform all voltage tests using a Digital Volt-Ohmmeter (DVOM) with minimum 10-megohm input impedance.

Temperature - °F (°C)(2) Volts(3) Ohms
4 (-20)4.66276,960
14 (-10)4.45160,310
32 (0)4.1495,850
50 (10)3.7358,990
68 (20)3.2637,340
86 (30)2.7424,250
104 (40)2.2316,110
122 (50)1.7710,930
140 (60)1.377550
158 (70)1.055340
176 (80)0.803840
194 (90)0.612800
212 (100)0.472080
(1) Values may differ by as much as 15 percent. For additional testing, see TEST DJ: AIR CONDITIONING EVAPORATOR TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. (2) Measure voltage by backprobing signal circuit to ground. (3) Measure resistance between sensor terminals.
(1)Values may differ by as much as 15 percent. For additional testing, see TEST DJ: AIR CONDITIONING EVAPORATOR TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(2)Measure voltage by backprobing signal circuit to ground.
(3)Measure resistance between sensor terminals.

AIR CONDITIONING EVAPORATOR TEMPERATURE SENSOR SPECIFICATIONS (1)

In. HgKPaFrequency (Hz)Altitude (Ft.)
3.511.889.3N/A
516.992.8N/A
1033.8104.6N/A
1550.7117.014,000
2067.5129.610,000
2170.9132.59000
2274.3135.48000
2377.7138.37000
2481.1141.16000
2584.4144.05000
2687.8146.94000
2791.2149.83000
2894.6152.82000
2997.9155.81000
(1) Using scan tool, select BARO PID from PID/DATA monitor menu. BARO PID should be within 2 in. Hg (6 Hz) of altitude value. For additional testing, see TEST DQ: BAROMETRIC PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(1)Using scan tool, select BARO PID from PID/DATA monitor menu. BARO PID should be within 2 in. Hg (6 Hz) of altitude value. For additional testing, see TEST DQ: BAROMETRIC PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

BARO SENSOR SPECIFICATIONS (1)

Temperature - °F (°C)Cold End VoltsHot End Volts(2) Ohms
40 (-40)4.89N/A965,808
22 (-30)4.81N/A513,019
4 (-20)4.67N/A283,664
14 (-10)4.45N/A162,584
32 (0)4.14N/A96,255
50 (10)3.73N/A59,175
68 (20)3.26N/A37,387
86 (30)2.74N/A24,215
104 (40)2.23N/A16,043
122 (50)1.76N/A10,850
140 (60)1.36N/A7487
158 (70)1.04N/A5268
176 (80) (3).793.993775
185 (85) (3).693.863215
194 (90) (3).603.712750
203 (95) (3).533.562361
212 (100) (3).463.412034
230 (110)N/A3.071523
248 (120)N/A2.741155
266 (130)N/A2.41887
284 (140)N/A2.10689
302 (150)N/A1.81542
320 (160)N/A1.55430
338 (170)N/A1.33345
356 (180)N/A1.13279
374 (190)N/A.96228
392 (200)N/A.82188
410 (210)N/A.70155
428 (220)N/A.60130
446 (230)N/A.51109
464 (240)N/A.4492
482 (250)N/A.3578
500 (260)N/A.3367
(1) Value may vary by 15 percent. For additional testing, see TEST DL: CYLINDER HEAD TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. (2) Measure resistance between cylinder head temperature sensor terminals. (3) At this temperature, there is a voltage overlap zone where it is possible to have either a cold end (low voltage) or hot end (high voltage) reading at the same temperature. Either voltage specification listed is correct.
(1)Value may vary by 15 percent. For additional testing, see TEST DL: CYLINDER HEAD TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(2)Measure resistance between cylinder head temperature sensor terminals.
(3)At this temperature, there is a voltage overlap zone where it is possible to have either a cold end (low voltage) or hot end (high voltage) reading at the same temperature. Either voltage specification listed is correct.

CYLINDER HEAD TEMPERATURE SENSOR SPECIFICATIONS (1)

Temperature - °F (°C)(2) (3) Volts(2) (4) Volts(5) Ohms
14 (-10)4.454.15160,310
32 (0)4.143.9195,850
50 (10)3.733.5158,750
68 (20)3.263.0737,300
86 (30)2.742.6024,270
104 (40)2.232.1316,150
122 (50)1.771.7010,970
140 (60)1.371.337600
158 (70)1.051.025370
176 (80)0.800.783840
194 (90)0.610.602800
212 (100)0.470.462070
230 (110)0.360.351550
248 (120)0.280.271180
(1) Values may differ by as much as 15 percent. For additional testing, see TEST DA: TEMPERATURE SENSOR TEST (IAT, ECT & EOT) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. (2) Measure voltage by backprobing signal circuit to ground. (3) Applies to Focus models only. (4) Applies to all models, except Focus. (5) Measure resistance between sensor terminals.
(1)Values may differ by as much as 15 percent. For additional testing, see TEST DA: TEMPERATURE SENSOR TEST (IAT, ECT & EOT) under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(2)Measure voltage by backprobing signal circuit to ground.
(3)Applies to Focus models only.
(4)Applies to all models, except Focus.
(5)Measure resistance between sensor terminals.

ENGINE COOLANT TEMPERATURE SENSOR, INTAKE AIR TEMPERATURE SENSOR & ENGINE OIL TEMPERATURE SENSOR SPECIFICATIONS (1)

Temperature - °F (°C)(2) Volts(3) Ohms
40 (-40)4.5492,500
50 (10)3.5158,750
68 (20)3.0727,300
86 (30)2.6024,270
104 (40)2.1316,150
122 (50)1.7010,970
140 (60)1.337700
158 (70)1.025370
176 (80)0.783840
194 (90)0.602800
212 (100)0.462070
230 (110)0.351550
248 (120)0.271180
275 (135)0.19810
302 (150)0.13560
(1) Values may differ by as much as 15 percent. For additional testing, see TEST DB: ENGINE FUEL TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. (2) Measure by backprobing signal circuit to ground. (3) Measure resistance between sensor terminals.
(1)Values may differ by as much as 15 percent. For additional testing, see TEST DB: ENGINE FUEL TEMPERATURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(2)Measure by backprobing signal circuit to ground.
(3)Measure resistance between sensor terminals.

ENGINE FUEL TEMPERATURE SENSOR SPECIFICATIONS (1)

Volts (1)Pressure - psi (kPa)
Natural Gas Vehicles
4.5150 (1034)
4.1140 (965)
3.7130 (896)
3.3120 (827)
2.9110 (758)
2.5100 (689)
2.190 (620)
1.780 (551)
1.370 (482)
0.960 (413)
0.550 (344)
0.140 (275)
0.037.6 (259)
Except Natural Gas Vehicles
4.570 (482)
3.960 (413)
3.450 (344)
2.840 (275)
2.230 (207)
1.620 (138)
1.110 (69)
0.50.0 (0.0)
(1) For additional testing, see TEST DD: FUEL RAIL PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(1)For additional testing, see TEST DD: FUEL RAIL PRESSURE SENSOR under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

FUEL RAIL PRESSURE SENSOR VOLTAGE-TO-FUEL PRESSURE CONVERSION

Temperature - °F (°C)(2) Volts(3) Ohms
50 (10)3.5158,750
68 (20)3.0737,300
86 (30)2.6024,270
104 (40)2.1316,150
122 (50)1.7010,970
140 (60)1.337600
158 (70)1.025370
176 (80)0.783840
194 (90)0.602800
212 (100)0.462070
230 (110)0.351550
248 (120)0.271180
(1) Values may differ by as much as 15 percent. For additional testing, see TEST DU: INTAKE AIR TEMPERATURE 2 under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article. (2) Measure voltage by backprobing signal circuit to ground. (3) Measure resistance between sensor terminals.
(1)Values may differ by as much as 15 percent. For additional testing, see TEST DU: INTAKE AIR TEMPERATURE 2 under SYSTEM TESTS in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(2)Measure voltage by backprobing signal circuit to ground.
(3)Measure resistance between sensor terminals.

INTAKE AIR TEMPERATURE 2 SENSOR SPECIFICATIONS (1)

Barometric Pressure - In. Hg (kPa)BARO/MAP PID (Hz)Altitude
3.5 (11.8)89.3N/A
5.0 (16.9)92.8N/A
10.0 (33.8)104.6N/A
15.0 (50.7)117.014,000
20.0 (67.5)129.610,000
21.0 (70.90132.59000
22.0 (74.3)135.48000
23.0 (77.7)138.37000
24.0 (81.1)141.16000
25.0 (84.4)144.05000
26.0 (87.8)146.94000
27.0 (91.2)149.83000
28.0 (94.6)152.82000
29.0 (97.9)155.81000
30.0 (101.3)158.90 (Sea Level)
31.0 (104.7)162.0N/A
31.875 (107.70164.7N/A

MASS AIRFLOW SENSOR

Scheme 1

Scheme 1
