Rear View Mirrors Ford Explorer Sport Trac I

Scheme 1

The rear view mirrors consist of the following components

1. Interior Rear View Mirror
2. Auto Dimming Interior Mirror (If Equipped)
3. Exterior Rear View Mirrors
4. Exterior Rear View Mirror Motors
5. Exterior Rear View Mirror Glass
6. Exterior Rear View Mirrors With Ground Illumination Lamps
7. Exterior Mirror Control Switch

On vehicles built after July of 2001, the exterior rear view mirror motor and glass is replaced separately. On vehicles built before July of 2001, the exterior rear view mirror is serviced as an assembly.

Wiring Diagrams

For Explorer Sport wiring diagram, see POWER MIRRORS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport wiring diagram, see POWER MIRRORS in SYSTEM WIRING DIAGRAMS article.

Scheme 2

Scheme 3

1. Verify the customer concern by operating the exterior rear view mirrors.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, determine the symptom. See «SYMPTOM CHART»(/ford/explorer-sport-trac/i-2000-2005/remont/mirrors/#rear-view-mirrors) .

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Pinpoint Test D: The Auto Dimming Mirror Does Not Operate Correctly

Note. If the transmission range sensor is malfunctioning so that the backup lamps are on, the auto dimming interior mirror will not darken.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Disconnect the battery ground cable.
2. Remove the front door trim panel.
3. Remove the door speaker. Remove the screws. Disconnect the electrical connector. Remove the door speaker.
4. Disconnect the exterior rear view mirror electrical connector.
5. Remove the nuts and the exterior rear view mirror. Feed the power mirror wiring through the opening in the front door.

Scheme 21

Scheme 22

Scheme 23

1. Install the exterior rear view mirror. Feed the power mirror wiring through the opening in the front door. Position the exterior rear view mirror at the top of the slots and tighten in the sequence shown. (Scheme 21)
2. Connect the exterior rear view mirror electrical connector.
3. Install the door speaker. Connect the electrical connector. Position the door speaker in the door. Install the screws.
4. Install the front door trim panel.
5. Connect the battery ground cable.

EXTERIOR MIRROR MOTOR

Note. The exterior mirror motor is serviceable only on vehicles built after July of 2001.

Note. Passenger side exterior mirror shown, driver side exterior mirror similar.

Scheme 24

Scheme 25

1. Remove the exterior mirror glass. For additional information, refer to «EXTERIOR MIRROR GLASS»(/ford/explorer-sport-trac/i-2000-2005/remont/mirrors/#rear-view-mirrors) .
2. Position aside the exterior mirror motor (17D696). Remove the screws. Position aside the exterior mirror motor.
3. Disconnect the electrical connectors and remove the exterior mirror motor.
4. To install, reverse the removal procedure.

Removal

Note. Exterior mirror glass is serviceable only on vehicles built after July of 2001.

Note. Passenger side exterior mirror shown, driver side exterior mirror similar.

All Mirrors

Installation

Heated Mirrors

Scheme 26

Auto Dimming Interior Mirror

All Interior Mirrors
