Exterior Lighting Ford Explorer Sport Trac I

TORQUE SPECIFICATIONS

Torque Specifications

The exterior lighting system consists of the following components

1. Fog Lamp Switch
2. Highmounted Stoplamp
3. Multifunction Switch
4. Rear Lamp
5. Reversing Lamp
6. Headlamp Switch
7. Headlamp
8. Parking Lamp
9. Fog Lamp
10. Brake Pedal Position (BPP) Switch
11. Autolamp Switch (If Equipped) (Integral To The Rear View Mirror)
12. Photocell (If Equipped) (Integral To The Rear View Mirror)

For removal and installation of the reversing lamp switch, refer to AUTOMATIC TRANSMISSION article.

Wiring Diagrams

For Explorer Sport wiring diagrams see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagrams see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 1

Scheme 2

Inspection & Verification

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If the fault is not visually evident, determine the symptom and go to the «SYMPTOM CHART»(/ford/explorer-sport-trac/i-2000-2005/remont/exterior-lights/#exterior-lighting) .

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

For Explorer Sport wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 15

Note. The autolamp switch, autolamp sensor and time delay control are integral to the internal rear view mirror.

Scheme 16

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If the fault is not visually evident, determine the symptom and proceed to the Symptom Chart. (Scheme 17)

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

For Explorer Sport wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 23

Scheme 24

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If the fault is not visually evident, determine the symptom and go to the Symptom Chart.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

For Explorer Sport wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 32

Scheme 33

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If the fault is not visually evident, determine the symptom and go to the Symptom Chart. (Scheme 34)

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

For Explorer Sport wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 39

Scheme 40

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If the fault is not visually evident, determine the symptom and go to the Symptom Chart. (Scheme 41)

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

For Explorer Sport wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 51

Scheme 52

1. Verify the customer concern by operating the fog lamps.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If the fault is not visually evident, determine the symptom and proceed to the Symptom Chart. (Scheme 53)

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

REVERSING LAMPS

For Explorer Sport wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 61

Scheme 62

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If the fault is not visually evident, determine the symptom and go to the Symptom Chart. (Scheme 63)

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

TRAILER LAMPS

For Explorer Sport wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article. For Explorer Sport Trac wiring diagram, see EXTERIOR LIGHTS in SYSTEM WIRING DIAGRAMS article.

Scheme 69

Scheme 70

1. Verify the customer concern.
2. Verify the exterior lighting system of the vehicle is operating correctly. If not, refer to the appropriate pinpoint test in this section.
3. Visually inspect for obvious signs of mechanical or electrical damage.
4. If the fault is not visually evident, determine the symptom and go to the Symptom Chart. (Scheme 71)

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Headlamp Aiming

1. The headlamp aiming procedure depends on what type of beam pattern the headlamp is equipped with. To identify the headlamp beam pattern, look on the headlamp lens. Molded in small letters on the headlamp lens is one of the following: SAE VOL VOR
2. Once the headlamp beam pattern is identified, aim the headlamps using one of the following methods as applicable. Photometric aimers can aim SAE, VOL and VOR type headlamps. This is the preferred method of headlamp aiming. Visual or screen method aiming can be used to aim SAE, VOL and VOR type headlamps. Mechanical aimers can only be used with SAE type headlamps. Lamps that can be aimed mechanically will have three nibs molded into the lens of the lamp.

Photometric Aiming

1. For the photometric aiming procedure, refer to the appropriate photometric headlamp aimer instruction manual.

All Headlamp Types

Note. Horizontal aim is not necessary for VOL or VOR headlamps.

Note. Consult your state vehicle inspection manual for recommended tolerance ranges for visual aiming.

Note. The sight shield may need to be positioned or removed for access to the adjusters.

Scheme 77

Scheme 78

1. Before starting headlamp adjustment: Check the tire inflation. Check that no other load is in the vehicle other than a half tank of fuel. Check that the headlamps are clean. Check for correct headlamp operation. Check that the vehicle is on level ground. If the vehicle is equipped with air suspension, make sure that the switch is on.
2. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from the vertical wall or screen directly in front of it.
3. Mark a horizontal reference line on the vertical wall or screen. Measure the center of the headlamp height to ground and record. Make a 2.4 meters (8 feet) horizontal mark (masking tape) on the vertical wall or screen at the same distance from the ground as previously recorded.
4. Turn on the low beam headlamps to illuminate the wall or screen and open the hood.
5. On the wall or screen, locate the high intensity area of the beam pattern. Place the top edge of the high intensity zone even with the horizontal reference line.
6. VOR Type Headlamps Identify at the top edge of this high intensity area a distinct horizontal cutoff in the beam pattern. If the top edge of this cutoff is not even with the horizontal reference line, the headlamp beam will need to be adjusted.
7. VOL Type Headlamps For VOL type headlamps, there will be a distinct cutoff in the left portion of the beam pattern. The edge of this cutoff should be positioned 50.2 mm (2 in) below the horizontal reference line. Horizontal reference line. Top edge of the beam pattern. High intensity zone.

Mechanical Aiming

1. For the mechanical aiming procedure, refer to the appropriate mechanical headlamp aimer instruction manual.

Removal & Installation

Scheme 79

Scheme 80

1. Remove the headlamp assembly. For additional information, refer to Headlamp Assembly in this section.
2. Rotate the headlamp bulb retainer counterclockwise and remove.
3. Remove the headlamp bulb.
4. To install, reverse the removal procedure.

Scheme 81

Scheme 82

Scheme 83

1. Remove the liftgate glass. Refer to «GLASS, FRAMES & MECHANISMS»(/ford/explorer-sport-trac/i-2000-2005/remont/windows/#glass-frames-mechanisms) article.
2. Remove the tape.
3. Remove the three nuts. Disconnect wiring harness tab. Remove the nuts.
4. Remove the high-mounted stoplamp. Disconnect the electrical connector. Remove the high-mounted stoplamp.
5. To install, reverse the removal procedure.

Scheme 84

Scheme 85

Scheme 86

1. Depress the locking tab and open the upper radiator sight shield access door.
2. Lift the tabs up and remove.
3. Disconnect the electrical connector and remove the headlamp assembly.
4. To install, reverse the removal procedure.

Scheme 87

Scheme 88

1. Remove the parking lamp bolt.
2. Remove the parking lamp. Pull the parking lamp assembly forward just enough to expose the electrical connector. Disconnect the electrical connector.
3. To install, reverse the removal procedure.

Scheme 89

Scheme 90

1. Lower the tailgate.
2. Remove the plugs.
3. Remove the rear lamp assembly. Remove the bolts. Pull the lamp assembly rearward. Disconnect the electrical connectors.
4. To install, reverse the removal procedure.

Scheme 91

1. Open the rear liftgate.
2. Remove the two screws. Pull the lamp assembly rearward. Disconnect the electrical connectors.
3. To install, reverse the removal procedure.

Scheme 92

Scheme 93

1. Disconnect the fog lamp bulb electrical connector.
2. Remove the fog lamp assembly. Remove the bolts. Remove the fog lamp assembly.
3. To install, reverse the removal procedure.

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

1. Disconnect the battery ground cable.
2. Remove the instrument panel center finish panel. Remove the screws. Remove the instrument panel center finish panel. Disconnect electrical connectors.
3. Remove the hood latch release handle. Remove the screws. Remove the hood latch release handle.
4. Remove the lower instrument panel steering column cover. Remove the screws. Remove the lower instrument panel steering column cover.
5. Remove the bolts and the lower instrument panel reinforcement.
6. If equipped, position the column gear shift lever out of the way.
7. Position the cluster finish panel aside. Remove the screws. Position the cluster finish panel aside.
8. Remove the cluster finish panel. Disconnect the electrical connectors and remove the headlamp switch knob. Remove the cluster finish panel.
9. Remove the headlamp switch. Remove the screws. Remove the headlamp switch.
10. To install, reverse the removal procedure.

Scheme 101

Scheme 102

1. Disconnect the brake pedal position (BPP) switch electrical connector.
2. Remove the BPP switch. Remove the self-locking pin. Remove the spacer. Remove the BPP switch.
3. To install, reverse the removal procedure.

Scheme 103

Scheme 104

1. Disconnect the battery ground cable.
2. Remove the instrument panel finish panel. Remove the screws Remove the center instrument panel finish panel. Disconnect the electrical connectors.
3. Remove the fog lamp switch. Remove the screws. Remove the mounting bezel. Release the two tabs and remove the fog lamp switch.
4. To install, reverse the removal procedure.
