GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Fluid | |
| MERCON® V Automatic Transmission Fluid XT-5-QM - Transmission | MERCON® V or equivalent |
Transmission Cooling General Specification
Scheme 55
Scheme 56
All vehicles with automatic transmissions are equipped with integral transmission fluid coolers. The integral transmission fluid cooler is contained inside of the radiator outlet tank and cannot be repaired separately. All (AWD) vehicles are equipped with the transmission auxiliary fluid cooler which is mounted in front of the radiator. In operation, transmission fluid travels from the transmission to the integral transmission fluid cooler to the transmission auxiliary fluid cooler then back to the transmission. The integral transmission fluid cooler transfers heat from the transmission fluid to the engine coolant. The transmission auxiliary fluid cooler transfers heat from the transmission fluid to the outside air.
For transmission fluid cooler flow test, refer to TRANSMISSION FLUID COOLER FLOW TEST .
For transmission fluid cooler backflushing and cleaning, refer to TRANSMISSION FLUID COOLER -- BACKFLUSHING & CLEANING .
Scheme 57
Inspection & Verification
| WARNING | Never remove the radiator cap under any conditions while the engine is operating. Failure to follow these instructions could result in personal injury and/or damage to the cooling system or engine. To avoid having scalding hot coolant or steam blow out of the radiator, use extreme care when removing the radiator cap from a hot radiator. Wait until the engine has cooled, then wrap a thick cloth around the radiator cap and turn it slowly to the first stop. Step back while the pressure is released from the cooling system. When you are certain all the pressure has been released, press down on the radiator cap (with a cloth), turn and remove. |
Check for fluid leakage. If fluid leakage is found at any of the transmission fluid cooling components, the component must be replaced.
Scheme 58
Scheme 59
Scheme 60
Scheme 61
- Disconnect the battery cables.
- Raise and support the vehicle.
- Remove the radiator air deflector (8327). Remove the bolts. Remove the radiator air deflector.
- Place a drain pan under the transmission auxiliary fluid cooler.
- Loosen the two upper radiator hold down screws.
- Remove the transmission auxiliary fluid cooler. Disconnect the hoses. Remove the bolts. Remove the transmission auxiliary fluid cooler.
Scheme 62
Scheme 63
Scheme 64
- Follow the removal procedure in reverse order.
Scheme 65
Scheme 66
Scheme 67
- Raise and support the vehicle.
- Remove the radiator air deflector (8327). Remove the bolts. Remove the radiator air deflector.
- Remove the nut, bolt and transmission cooler line bracket.
- Remove the transmission fluid cooler tubes. Remove the clips. Disconnect the fittings. Use a backup wrench to hold the case fitting secure. Remove the nut. Remove the transmission fluid cooler tubes.
Installation
Note. When a transmission fluid cooler tube is replaced, each replacement tube must be fabricated from the same size tube as the original.
Scheme 68
Scheme 69
- Shape a new transmission fluid cooler tube. Use the prior tube as a guide. Install the appropriate fittings.
- Install the transmission fluid cooler tubes. Install the clips. Connect the tube fittings to the radiator. Connect the tube fittings to the transmission. Use a backup wrench to hold the case fitting secure. Install the tube bracket nut. Install the transmission fluid cooler tubes.
- Install the nut, bolt, and transmission cooler line bracket.
- Install the radiator air deflector. Install the bolts.
- Lower the vehicle.
- Fill transmission fluid to the proper level using the correct fluid and inspect for leaks.
