Accessory Drive Belts 26 illustrations ~559 words

BELT ADJUSTMENT

CAUTIONIncorrect drive belt installation will cause excessive drive belt wear and may cause the drive belt to come off the drive pulleys.

Inspect belt for fraying. If fraying has occurred, ensure belt and tensioner are aligned properly. (Scheme 1) If tensioner has reached its limit of travel, belt is excessively stretched and replacement of belt is required. (Scheme 2)- (Scheme 4). If excessive noise is noticed from tensioner or idler, check for possible bearing failure. With the engine running, visually observe the grooves in the pulleys (not the pulley flanges or the pulley forward faces) for excessive wobble. Install new components as necessary. Check all accessories, mounting brackets, and the drive belt tensioner for any interference that would prevent the components from mounting correctly. Correct any interference condition and recheck the drive belt tracking. Tighten all accessories, mounting brackets, and the drive belt tensioner retaining hardware to specification. Recheck the drive belt tracking.

Belt tension adjustment is not required on vehicles with automatic belt tensioners. DO NOT apply belt dressing or any other additive to belt(s). Ensure belts are properly installed. (Scheme 12)- (Scheme 16). See BELT TENSION ADJUSTMENT SPECIFICATIONS.

Scheme 1

Scheme 1

BELT TENSION ADJUSTMENT SPECIFICATIONS (VILLAGER)

ApplicationLbs. (kg)
A/C, P/S & W/P
New Belt136-155 (62-70)
Used Belt (1)112-131 (51-59)
Generator
New Belt151-170 (68-77)
Used Belt (1)125-144 (57-65)
(1) Any belt operated for 5 minutes is considered used.
(1)Any belt operated for 5 minutes is considered used.

BELT TENSION ADJUSTMENT SPECIFICATIONS (VILLAGER)

Application(1) In. (mm)
A/C
New Belt0.16-0.24 (4.1-6.1)
Used Belt (2)0.20-0.28 (5.1-7.1)
Generator
New Belt0.26-0.30 (6.6-7.6)
Used Belt (2)0.30-0.34 (7.6-8.6)
W/P & P/S
New Belt0.31-0.39 (7.8-9.9)
Used Belt (2)0.39-0.47 (9.9-11.9)
(1) Measure deflection by applying 22 Lbs. (10 kg) of pressure to drive belt midway between specified component and crankshaft pulley. (2) Any belt operated for 5 minutes is considered used.
(1)Measure deflection by applying 22 Lbs. (10 kg) of pressure to drive belt midway between specified component and crankshaft pulley.
(2)Any belt operated for 5 minutes is considered used.

BELT DEFLECTION SPECIFICATIONS (VILLAGER)

Scheme 2

Scheme 2: BELT TENSION ADJUSTMENT SPECIFICATIONS (EXCEPT VILLAGER)

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Note. Belt routings on models not shown was not available from manufacturer. Underhood label may reflect belt routing.

Scheme 5

Scheme 5: DRIVE BELT ROUTING (ECONOLINE & F150 PICKUP - 4.2L)

Scheme 6

Scheme 6

Scheme 7

Scheme 7: DRIVE BELT ROUTING (BLACKWOOD, ECONOLINE, EXCURSION, EXPEDITION, F150-550 PICKUP & NAVIGATOR 4.6L, 5

Scheme 8

Scheme 8

Scheme 9

Scheme 9: DRIVE BELT ROUTING (ECONOLINE - 7.3L)

Scheme 10

Scheme 10

Scheme 11

Scheme 11: DRIVE BELT ROUTING (ESCAPE - 2.0L)

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15: DRIVE BELT ROUTING (EXCURSION & F250-550 PICKUP 7.3L DIESEL)

Scheme 16

Scheme 16

Scheme 17

Scheme 17: DRIVE BELT ROUTING (EXPLORER, EXPLORER SPORT, EXPLORER SPORT TRAC, MOUNTAINEER & RANGER - 4.0L SOHC

Scheme 18

Scheme 18: DRIVE BELT ROUTING (F150 LIGHTNING 5.4L SC)

Scheme 19

Scheme 19

Scheme 20

Scheme 20: Drive Belt Routing (Ranger - 2.3L)

Scheme 21

Scheme 21

Scheme 22

Scheme 22: Drive Belt Routing (Ranger - 3.0L)

Scheme 23

Scheme 23

Scheme 24

Scheme 24: Drive Belt Routing (Ranger - 4.0L SOHC)

Scheme 25

Scheme 25: Drive Belt Routing (Villager - 3.3L With A/C)

Scheme 26

Scheme 26: Drive Belt Routing (Windstar - 3.8L)

COOLANT REPLACEMENT INTERVAL

WARNINGNever remove the radiator cap under any conditions while the engine is operating. Failure to follow these instructions could result in personal injury and/or damage to the cooling system or engine. To avoid having scalding hot coolant or steam blow out of the radiator, use extreme care when removing the radiator cap from a hot radiator. Wait until the engine has cooled, then wrap a thick cloth around the radiator cap and turn it slowly to the first stop. Step back while the pressure is released from the cooling system. When you are certain all the pressure has been released, press down on the radiator cap (with a cloth), turn and remove.

Note. The addition of Motorcraft Cooling System Stop Leak Pellets (VC-6), darkens Motorcraft Premium Gold Engine Coolant from Yellow to Golden Tan.

To maintain the integrity of the coolant and the cooling system

  1. Add Motorcraft Premium Engine Coolant VC-4-A (in Oregon VC-5, in Canada CXC-10) or equivalent meeting Ford specification ESE-M97B44-A (Green color), Motorcraft Specialty Orange Engine Coolant such as VC-2, meeting Ford specification WSS-M97B44-D or Motorcraft Premium Gold Engine Coolant VC-7-A or equivalent meeting Ford specification WSS-M97B51-A1 (Yellow color). Use the same coolant that was drained from the cooling system. Do not mix coolant types.
  2. Do not add/mix Orange-colored Motorcraft Speciality Orange Engine Coolant VC-2 or equivalent meeting Ford specification WSS-M97B44-D. Mixing coolants may degrade the coolant's corrosion protection.
  3. Do not add alcohol, methanol, or brine, or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing.
  4. Do not mix with recycled coolant unless it meets the requirements of Ford specification ESE-M97B44-A or WSS-M97B51-A1. Not all coolant recycling processes meet these Ford specifications. Use of such coolants can harm the engine and cooling system components.
ApplicationSpecification - Miles
Green Coolant (1)45,000
Orange Coolant (2)150,000
Yellow Coolant (3)100,000
(1) Motorcraft Premium Engine Coolant VC-4-A (in Oregon, VC-5, in Canada CXC-10), or equivalent meeting Ford specification ESE-M97B44-A (Green in color). (2) Motorcraft Specialty Orange Engine Coolant such as VC-2, meeting Ford specification WSS-M97B44-D. (3) The addition of Motorcraft Cooling System Stop Leak Pellets, VC-6, darkens Motorcraft Premium Gold Engine Coolant from Yellow to Golden Tan.
(1)Motorcraft Premium Engine Coolant VC-4-A (in Oregon, VC-5, in Canada CXC-10), or equivalent meeting Ford specification ESE-M97B44-A (Green in color).
(2)Motorcraft Specialty Orange Engine Coolant such as VC-2, meeting Ford specification WSS-M97B44-D.
(3)The addition of Motorcraft Cooling System Stop Leak Pellets, VC-6, darkens Motorcraft Premium Gold Engine Coolant from Yellow to Golden Tan.

COOLANT REPLACEMENT INTERVAL

COOLING SYSTEM SPECIFICATIONS (BLACKWOOD)

ApplicationSpecification
Coolant Capacity (1)18.9 Qts. (17.9L)
Cooling System Test Pressure18 psi (1.27 kg/cm 2 )
Pressure Relief Cap Opening Pressure16 psi (1.1 kg/cm 2 )
Thermostat Opens
Starts188-195°F (87-91°C)
Fully Open212°F (100°C)
(1) Includes degas bottle fluid level between the COOLANT FILL LEVEL lines.
(1)Includes degas bottle fluid level between the COOLANT FILL LEVEL lines.

COOLING SYSTEM SPECIFICATIONS (BLACKWOOD)

COOLING SYSTEM SPECIFICATIONS (ECONOLINE)

ApplicationSpecification
Coolant Capacity
4.2L23.3 Qts. (22.0L)
4.6L25.0 Qts. (23.7L)
5.4L29.0 Qts. (27.4L)
6.8L(1)
7.3L Diesel30.0 Qts. (28.4L)
Cooling System Test Pressure18 psi (1.27 kg/cm 2 )
Pressure Relief Cap Opening Pressure13 psi (.91 kg/cm 2 )
Thermostat Opens
4.2L, 4.6L & 5.4L
Starts188-195°F (87-91°C)
Fully Open212°F (100°C)
6.8L
Starts181-187°F (83-86°C)
Fully Open210°F (99°C)
7.3L Diesel(1)
(1) Information not provided by manufacturer.
(1)Information not provided by manufacturer.

COOLING SYSTEM SPECIFICATIONS (ECONOLINE)

COOLING SYSTEM SPECIFICATIONS (EXPEDITION & NAVIGATOR)

ApplicationSpecification
Coolant Capacity
4.6L18.9 Qts. (17.9L)
5.4L(1)
Pressure Relief Cap Opening Pressure16 psi (1.1 kg/cm 2 )
Thermostat Opens
Starts188-195°F (87-91°C)
Fully Open212°F (100°C)
(1) Information not provided by manufacturer.
(1)Information not provided by manufacturer.

COOLING SYSTEM SPECIFICATIONS (EXPEDITION & NAVIGATOR)

COOLING SYSTEM SPECIFICATIONS (EXCURSION & F250-550 PICKUPS)

ApplicationSpecification
Coolant Capacity
5.4L26.4 Qts. (25.0L)
6.8L28.5 Qts. (27.0L)
7.3L Diesel32.75 Qts. (31.0L)
Cooling System Test Pressure18 psi (1.27 kg/cm 2 )
Pressure Relief Cap Opening Pressure18 psi (1.3 kg/cm 2 )
Thermostat Opens
5.4L
Starts188-195°F (87-91°C)
Fully Open208-215°F (98-102°C)
6.8L
Starts181-189°F (83-87°C)
Fully Open206-213°F (97-101°C)
7.3L
Starts192°F (88.8)
Fully Open219°F (103.8)

COOLING SYSTEM SPECIFICATIONS (EXCURSION & F250-550 PICKUPS)

COOLING SYSTEM SPECIFICATIONS (ESCAPE)

ApplicationSpecification
Coolant Capacity
2.0L Zetec7.4 Qts. (7.0L)
3.0L 4V10.5 Qts (10.0L)
Cooling System Test Pressure20 psi (1.4 kg/cm 2 )
Pressure Relief Cap Opening Pressure17.4-21.7 psi (1.2-1.5 kg/cm 2 )
Thermostat Opens
2.0L Zetec
Starts194-201°F (90-94°C)
Fully Open223°F (106°C)
3.0L 4V
Starts194-200°F (90-93°C)
Fully Open223°F (106°C)

COOLING SYSTEM SPECIFICATIONS (ESCAPE)

EXPLORER, EXPLORER SPORT, EXPLORER SPORT TRAC, MOUNTAINEER

ApplicationSpecification
Coolant Capacity
Explorer Sport & Explorer Sport Trac14.0 Qts. (13.2L)
Explorer & Mountaineer
4.0L
Without Auxiliary Heater16.3 Qts. (15.4L)
W/Aux Auxiliary Heater18.2 Qts. (17.2L)
4.6L
Without Auxiliary Heater18.6 Qts. (17.6L)
W/Aux Auxiliary Heater20.1 Qts. (19.0L)
Cooling System Test Pressure20 psi (1.4 kg/cm 2 )
Pressure Relief Cap Opening Pressure13-18 psi (0.9-1.3 kg/cm 2 )
Thermostat Opens
Starts To Open194°F (90°C)
Fully Open210°F (99°C)

COOLING SYSTEM SPECIFICATIONS (EXPLORER, EXPLORER SPORT, EXPLORER SPORT TRAC, MOUNTAINEER)

COOLING SYSTEM SPECIFICATIONS (F150 PICKUP)

ApplicationSpecification
Coolant Capacity (1)
4.2L17.3 Qts. (18.4L)
4.6L & 5.4L19.4 Qts. (18.4L)
Supercharger Intercooler4.2 Qts. (4.0L)
Cooling System Test Pressure (2)
Radiator20 psi (1.4 kg/cm 2 )
Intercooler20 psi (1.4 kg/cm 2 )
Pressure Relief Cap Opening Pressure (2)
Engine System16 psi (1.1 kg/cm 2 )
Supercharger Intercooler System10 psi (.7 kg/cm 2 )
Thermostat Opens
Starts188-195°F (87-91°C)
Fully Open208-215°F (98-102°C)
(1) Includes degas bottle fluid level between the COOLANT FILL LEVEL lines. (2) Intercooler system is not connected to the main engine cooling system.
(1)Includes degas bottle fluid level between the COOLANT FILL LEVEL lines.
(2)Intercooler system is not connected to the main engine cooling system.

COOLING SYSTEM SPECIFICATIONS (F150 PICKUP)

COOLING SYSTEM SPECIFICATIONS (RANGER)

ApplicationSpecification
Coolant Capacity
2.3L
Automatic Transmission10.9 Qts. (10.3L)
Manual Transmission10.6 Qts. (11.2L)
3.0L
Automatic Transmission14.8 Qts. (14.1L)
Manual Transmission15.2 Qts. (14.4L)
4.0L
Automatic Transmission13.2 Qts. (12.5L)
Manual Transmission13.5 Qts. (12.8L)
Cooling System Test Pressure20 psi (1.4 kg/cm 2 )
Pressure Relief Cap Opening Pressure13-18 psi (.9-1.3 kg/cm 2 )
Thermostat Opens
Starts194°F (90°C)
Fully Open207-223°F (97-106°C)

COOLING SYSTEM SPECIFICATIONS (RANGER)

COOLING SYSTEM SPECIFICATIONS (VILLAGER)

ApplicationSpecification
Coolant Capacity11.2 Qts. (10.6L)
Cooling System Test Pressure14.9 psi (1.0 kg/cm 2 )
Pressure Relief Cap Opening Pressure14.4-17.6 psi (1.0-1.2 kg/cm 2 )
Radiator Pressure Test20 psi (1.4 kg/cm 2 )
Thermostat Opens
Starts180°F (82°C)
Fully Open(1)
(1) Information is not available from manufacturer.
(1)Information is not available from manufacturer.

COOLING SYSTEM SPECIFICATIONS (VILLAGER)

COOLING SYSTEM SPECIFICATIONS (WINDSTAR)

ApplicationSpecification
Coolant Capacity16.0 Qts (15.1L)
Cooling System Test Pressure16 psi (1.1 kg/cm 2 )
Pressure Relief Cap Opening Pressure14-18 psi (1.0-1.3 kg/cm 2 )
Thermostat Opens
Starts183-190°F (84-88°C)
Fully Open210°F (99°C)

COOLING SYSTEM SPECIFICATIONS (WINDSTAR)
