Rear View Mirror: Component Locations Ford Expedition III

Special Tool(s)

SPECIAL TOOL CHART Flex Probe Kit 300-NUD105-R025DE or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 50

Scheme 51

Scheme 52

SPECIAL TOOL CHART Flex Probe Kit 300-NUD105-R025DE or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

The interior auto-dimming rear view mirror automatically reduces the glare caused by headlamps reflecting in the interior rear view mirror. The auto-dimming feature is disabled when the vehicle is in REVERSE. Power is supplied to the interior auto-dimming mirror when the ignition is in the RUN position or the accessory delay is active.

The interior auto-dimming rear view mirror has 2 photoelectric sensors, a forward facing sensor and a rearward facing sensor, that detect forward and rearward light conditions. Based on these inputs, the automatic dimming feature adjusts the reflectance level of the interior rear view mirror glass to eliminate unwanted glare. The reflectance level of the mirror glass is variable and depends on the amount of rear glare in relation to ambient light conditions in front of the interior mirror.

When the forward sensor detects daytime conditions, the rearward sensor is inactive and the interior rear view mirror stays in a high reflectance mode. When the forward sensor detects nighttime conditions, the rearward sensor is active and detects glare from the headlights of vehicles approaching from the rear or other glare-producing light sources. To provide increased visibility when backing up, the interior rear view mirror will automatically return to a high reflectance mode whenever the vehicle is in REVERSE.

If the forward or rearward sensors are blocked, the interior auto-dimming rear view mirror might not work correctly.

For vehicles that are equipped with a rear-mounted object detection camera, a video image will be displayed on the LH side of the interior rear view mirror glass when the transmission is in the REVERSE position. For information on the rear-mounted object detection system, refer to PARKING AID .

SPECIAL TOOL CHART Mirror Remover 501-D118

Note. Interior auto-dimming mirror without microphone shown in illustration, interior auto-dimming mirror with microphone similar.

Scheme 53

ITEM DESCRIPTION

Scheme 54

1. Remove the wire cover.
2. Disconnect the electrical connector.
3. Insert the Mirror Remover between the mirror mount and windshield bracket from the top.
4. NOTE: Twisting the interior rear view mirror base from right to left may cause a stress fracture to the windshield. Release the mirror mount from the windshield bracket by pulling the Mirror Remover and mirror down and away from the windshield.

Scheme 55

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the upward position.
2. Quickly press the mirror assembly downward along the windshield until a click is felt. The click indicates the base is engaged to the windshield bracket.
3. Connect the electrical connector and wire cover.
4. If equipped, install the compass module. Check the compass zone and calibration. For additional information, refer to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-364063) .
