Special Tool(s)
SPECIAL TOOL SPECIFICATION Coolant/Battery Refractometer 023-00164 or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Pressure Test Kit 014-R1072 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware or equivalent scan tool
Scheme 4
Scheme 5
Scheme 6
SPECIAL TOOL SPECIFICATION RADIATOR REFILLER 078-00592
Scheme 7
SPECIAL TOOL SPECIFICATION Disconnect Tool, Transmission Cooler Line 307-569
Scheme 8
Scheme 9
| Item | Part Number | Description |
|---|---|---|
| 1 | W705764 | Battery power cable nut |
| 2 | Battery power cable terminal (part of 12A581) | |
| 3 | Battery Junction Box (BJB) (part of 12A581) | |
| 4 | Wiring harness retainer (part of 12A581) | |
| 5 | W710897 | Power steering fluid reservoir stud bolt |
| 6 | 3E764 | Power steering fluid reservoir |
| 7 | Power steering fluid cooler hose retainer (part of 3A713) |
PART NUMBER REFERENCE
Scheme 10
| Item | Part Number | Description |
|---|---|---|
| 1 | Wiring harness retainer (part of 14305) | |
| 2 | Electrical connector retainer (part of 12A581) | |
| 3 | Wiring harness retainer (part of 12A581) |
PART NUMBER REFERENCE
Scheme 11
| Item | Part Number | Description |
|---|---|---|
| 1 | Wiring harness retainer (part of 12A581) | |
| 2 | Upper radiator hose retainer (part of 8B274) | |
| 3 | Wiring harness retainer (part of 12A581) (3 required) |
PART NUMBER REFERENCE
Scheme 12
| Item | Part Number | Description |
|---|---|---|
| 1 | Cooling fan electrical connector (part of 12A581) (2 required) | |
| 2 | Cooling fan wiring harness retainer (part of 12A581) (3 required) |
PART NUMBER REFERENCE
Scheme 13
| Item | Part Number | Description |
|---|---|---|
| 1 | W500110 | Condenser inlet fitting bolt |
| 2 | W520413 | Condenser outlet fitting nut |
| 3 | 19E558 | Condenser inlet jumper line fitting |
| 4 | Condenser outlet fitting (part of 19A834) | |
| 5 | 19B596 | O-ring seal and gasket seal kit (2 required) |
PART NUMBER REFERENCE
Scheme 14
| Item | Part Number | Description |
|---|---|---|
| 1 | 8N029 | Radiator overflow hose |
| 2 | 8B274 | Upper radiator hose |
| 3 | 8B273 | Lower radiator hose |
| 4 | 8B365 | Lower radiator hose spring clip |
PART NUMBER REFERENCE
Scheme 15
| Item | Part Number | Description |
|---|---|---|
| 1 | 16B975 | Hood latch assembly cable retainer |
| 2 | W711848 | Hood latch assembly bolts (2 required) |
| 3 | 6100 | Hood latch assembly |
| 4 | 7J801 | Transmission fluid cooler tube secondary latch (2 required) |
| 5 | 7H420 | Transmission fluid cooler tube (2 required) |
| 6 | Power steering fluid cooler hose clamp (2 required) | |
| 7 | 3A713 | Power steering gear-to-fluid cooler return hose |
| 8 | 3B726 | Power steering fluid cooler supply hose |
| 9 | W701835 | Cooling module upper bolt (2 required) |
| 10 | W701835 | Cooling module front bolt (4 required) |
PART NUMBER REFERENCE
