Multifunction Electronic Modules: Diagnosis — Ford Expedition III (2006-2014)

Diagnostic Trouble Code (DTC) Chart

Note. Most powertrain (P-code) DTCs are diagnosed in the INTRODUCTION - GASOLINE MODELS . If the P-code retrieved is not listed below, refer to the INTRODUCTION - GASOLINE MODELS to continue diagnostics.

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

Note. Some of these modules utilize a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.

DTC	Description	Source	Action
B1003	Mode Door Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1031	SDARS Satellite Antenna Open	Satellite Digital Audio Receiver System (SDARS) module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1032	SDARS Satellite Antenna Short	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B103B	Thermoelectric Driver Overcurrent Low	Dual Climate Controlled Seat Module (DCSM)	REFER to SEATING .
B103C	Thermoelectric Driver Open Load	DCSM	REFER to SEATING .
B103D	Blower Driver Overtemperature	DCSM	REFER to SEATING .
B106A	TPMS Sensor Pressure Range Bit Incorrect State	Smart Junction Box (SJB)	REFER to WHEELS & TIRES .
B106B	Tire Pressure Sensor Low Battery	SJB	REFER to WHEELS & TIRES .
B106C	Tire Pressure Monitor System ( TPMS ) Low Frequency Subsystem Fault	SJB	REFER to WHEELS & TIRES .
B106D	Tire Pressure Monitor System ( TPMS ) Initiators Not Configured	SJB	REFER to WHEELS & TIRES .
B106E	Solid State Driver Disabled Due to Short Circuit	Driver Seat Module (DSM)	REFER to DRIVER SEAT MODULE (DSM) .
B106E	Solid State Driver Disabled Due to Short Circuit	Liftgate/Trunk Module (LTM)	REFER to BODY CLOSURES .
B106E	Solid State Driver Disabled Due to Short Circuit	SJB	REFER to SMART JUNCTION BOX (SJB) .
B106F	Module Disabled Due to External Fault	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B106F	Module Disabled Due to External Fault	LTM	REFER to BODY CLOSURES .
B106F	Module Disabled Due to External Fault	SJB	REFER to SMART JUNCTION BOX (SJB) .
B107D	Obstacle Detected While Closing	LTM	REFER to BODY CLOSURES .
B1105	Rear Open/Close Switch Active During Self Test	LTM	REFER to BODY CLOSURES .
B1111	Driver Thermoelectric Device Control Over Temperature Fault	DCSM	REFER to SEATING .
B1113	Passenger Thermoelectric Device Control Over Temperature Fault	DCSM	REFER to SEATING .
B1117	Audio Steering Wheel Button Stuck	Audio Control Module (ACM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1119	Audio Disc DVD Player Thermal Shutdown	Rear Entertainment Module (RETM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B111B	Passenger Thermoelectric Driver Overcurrent Low	DCSM	REFER to SEATING .
B111C	Passenger Thermoelectric Driver Open Load	DCSM	REFER to SEATING .
B111D	Passenger Blower Driver Overtemperature	DCSM	REFER to SEATING .
B111F	LCD Thermal Shutdown	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B112B	Mirror Power Fold Switch Input Short to Battery	DSM	REFER to REAR VIEW MIRRORS .
B1137	Data Not Programmed	Instrument Cluster (IC)	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1138	Memory Full	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1138	Memory Full	SJB	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1139	Invalid Transmitter Identification Code	IC	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1139	Invalid Transmitter Identification Code	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1162	Power Running Board Hall Effect Sensor Power Circuit Short to Battery	Power Running Board (PRB) module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1163	Left Power Running Board Hall Effect Sensor Failure	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1164	Power Running Board Hall Effect Sensor Power Circuit Short To Ground	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1167	Left Power Running Board Deploy and/or Stow Circuit Short To Battery	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1168	Left Power Running Board Stow Circuit Short To Ground	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1169	LH Motor Traveled Too Far	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B116A	RH Motor Traveled Too Far	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B116B	LH Power Running Board Motor Short	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B116C	RH Power Running Board Motor Short	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B116D	LH Power Running Board Motor Line Open	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B116E	RH Power Running Board Motor Line Open	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1170	Right Power Running Board Hall Effect Sensor Failure	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1171	Left Power Running Board Hall Effect Signal Noisy	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1172	Right Power Running Board Hall Effect Signal Noisy	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1175	Right Power Running Board Stow Circuit Short To Ground	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1178	Right Power Running Board Deploy and/or Stow Circuit Short To Battery	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1179	Latch Motor Circuit Short to Battery	LTM	REFER to BODY CLOSURES .
B117A	Latch Motor Circuit Short to Ground	LTM	REFER to BODY CLOSURES .
B117B	Latch Motor Circuit Open	LTM	REFER to BODY CLOSURES .
B117C	Latch Centering Switch Invalid	LTM	REFER to BODY CLOSURES .
B119F:01	GPS Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B119F:13	GPS Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:1C	Steering Wheel Audio Switch Pack: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:63	Steering Wheel Audio Switch Pack: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1200	Climate Control Pushbutton Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	Accessory Protocol Interface Module (APIM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1202	Fuel Sender Circuit Open	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1204	Fuel Sender Circuit Short to Ground	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1213	Anti-Theft Number of Programmed Keys Is Below Minimum	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B121C:01	Hard Drive: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1231	Event Threshold Exceeded	Restraints Control Module (RCM)	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1242	Air Flow Recirculation Door Driver Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1251	Air Temperature Internal Sensor Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1252:04	USB Port: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1252:11	USB Port: Circuit Short To Ground	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1253	Air Temperature Internal Sensor Circuit Short to Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1255	Air Temperature External Sensor Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1255	Air Temperature External Sensor Circuit Open	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1257	Air Temperature External Sensor Circuit Short to Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1257	Air Temperature External Sensor Circuit Short to Ground	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1299	Power Supply Sensor Circuit Short To Ground	Parking Aid Module (PAM)	REFER to PARKING AID .
B12B8:04	USB Port #2: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B12B8:11	USB Port #2: Circuit Short To Ground	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1302	Accessory Delay Relay Coil Circuit Failure	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1304	Accessory Delay Relay Coil Circuit Short To Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1317	Battery Voltage High	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1317	Battery Voltage High	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1317	Battery Voltage High	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1317	Battery Voltage High	LTM	REFER to BODY CLOSURES .
B1317	Battery Voltage High	PAM	REFER to PARKING AID .
B1317	Battery Voltage High	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1317	Battery Voltage High	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1317	Battery Voltage High	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1317	Battery Voltage High	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1317	Battery Voltage High	Vehicle Dynamics Module (VDM)	REFER to VEHICLE DYNAMIC SUSPENSION .
B1318	Battery Voltage Low	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1318	Battery Voltage Low	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	Audio RCU	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1318	Battery Voltage Low	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1318	Battery Voltage Low	LTM	REFER to BODY CLOSURES .
B1318	Battery Voltage Low	PAM	REFER to PARKING AID .
B1318	Battery Voltage Low	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1318	Battery Voltage Low	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1318	Battery Voltage Low	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1318	Battery Voltage Low	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
B1320	Driver Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1328	Passenger Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1331	Decklid Ajar Rear Door Circuit Failure	SJB	REFER to INTERIOR LIGHTING .
B1336	Door Ajar RR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1342	ECU Is Faulted	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1342	ECU Is Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1342	ECU Is Faulted	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU Is Faulted	Audio RCU	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU Is Faulted	DCSM	REFER to SEATING .
B1342	ECU Is Faulted	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1342	ECU Is Faulted	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1342	ECU Is Faulted	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1342	ECU Is Faulted	LTM	REFER to BODY CLOSURES .
B1342	ECU Is Faulted	PAM	REFER to PARKING AID .
B1342	ECU Is Faulted	PCM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PCM. REFER to ELECTRONIC ENGINE CONTROLS . TEST the system for normal operation.
B1342	ECU Is Faulted	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B1342	ECU Is Faulted	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1342	ECU Is Faulted	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU Is Faulted	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU Is Faulted	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1342	ECU Is Faulted	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
B1352	Ignition Key-In Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1472	Lamp Headlamp Input Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B1483	Brake Pedal Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1485	Brake Pedal Input Short to Battery	SJB	REFER to VEHICLE DYNAMIC SYSTEMS .
B1510	Flash To Pass Switch Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B1520	Hood Switch Circuit Open	SJB	REFER to ANTI-THEFT - PERIMETER .
B1530	Memory Set Switch Circuit Short to Ground	DSM	REFER to SEATING .
B1534	Memory 1 Switch Circuit Short to Ground	DSM	REFER to SEATING .
B1538	Memory 2 Switch Circuit Short to Ground	DSM	REFER to SEATING .
B1555	Ignition Run/Start Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1566	Door Ajar Circuit Short To Ground	VDM	REFER to INTERIOR LIGHTING .
B1572	Door Ajar LR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1578	Lamp Park Input Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B1600	PATS Ignition Key Transponder Signal Is Not Received	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1601	PATS Received Incorrect Key-Code From Ignition Key Transponder	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1602	PATS Received Invalid Format Of Key-Code From Ignition Key Transponder	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1624	Lamp Keypad Output Open Circuit	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1626	Lamp Keypad Output Short Circuit To Ground	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1663	Seat Driver Front Up/Down Motor Stalled	DSM	REFER to SEATING .
B1664	Seat Driver Rear Up/Down Motor Stalled	DSM	REFER to SEATING .
B1665	Seat Driver Forward/Backward Motor Stalled	DSM	REFER to SEATING .
B1666	Seat Recline Forward/Rearward Motor Stalled	DSM	REFER to SEATING .
B1667	Mirror Driver Up/Down Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1668	Mirror Driver Right/Left Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1669	Mirror Passenger Up/Down Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1670	Mirror Passenger Right/Left Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1676	Battery Pack Voltage Out of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1676	Battery Pack Voltage Out of Range	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1681	PATS Transceiver Module Signal Is Not Received	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1685	Lamp Dome Input Circuit Failure	SJB	REFER to INTERIOR LIGHTING .
B1688	Lamp Dome Input Circuit Short To Ground	SJB	REFER to INTERIOR LIGHTING .
B1696	Autolamp On Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B1703	Seat Driver Recline Forward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1707	Seat Driver Recline Rearward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1711	Seat Driver Front Up Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1715	Seat Driver Front Down Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1719	Seat Driver Forward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1723	Seat Driver Rearward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1727	Seat Driver Rear Up Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1731	Seat Driver Rear Down Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1733	Mirror Driver Vertical Switch Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B1737	Mirror Driver Horizontal Switch Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B1741	Mirror Passenger Vertical Switch Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B1745	Mirror Passenger Horizontal Switch Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B1791	Autolamp Sensor Input Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B1793	Autolamp Sensor Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1868	Lamp Air Bag Warning Indicator Circuit Failure	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1915	Air Bag Driver Circuit Failure	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1952	Seat Rear Up/Down Feedback Potentiometer Circuit Short to Battery	DSM	REFER to SEATING .
B1953	Seat Rear Up/Down Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1956	Seat Front Up/Down Feedback Potentiometer Circuit Short to Battery	DSM	REFER to SEATING .
B1957	Seat Front Up/Down Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1960	Seat Recline Forward/Backward Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1961	Seat Recline Forward/Rearward Feedback Potentiometer Circuit Failure	DSM	REFER to SEATING .
B1964	Seat Horizontal Forward/Rearward Feedback Potentiometer Circuit Short to Battery	DSM	REFER to SEATING .
B1965	Seat Horizontal Forward/Rearward Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1987	Pedal Forward/Rearward Motor Stalled	DSM	REFER to BRAKE SYSTEM - GENERAL INFORMATION .
B1988	Pedal Position Forward Switch Circuit Short to Battery	DSM	REFER to BRAKE SYSTEM - GENERAL INFORMATION .
B1989	Pedal Position Rearward Switch Circuit Short to Battery	DSM	REFER to BRAKE SYSTEM - GENERAL INFORMATION .
B1991	Pedal Forward/Rearward Feedback Potentiometer Circuit Short to Battery	DSM	REFER to BRAKE SYSTEM - GENERAL INFORMATION .
B19A1	Passenger Seat Cushion Blower Speed Short to Battery	DCSM	REFER to SEATING .
B19A2	Passenger Seat Back Blower Speed Short to Battery	DCSM	REFER to SEATING .
B19A3	Driver Seat Cushion Blower Speed Short to Battery	DCSM	REFER to SEATING .
B19A4	Driver Seat Back Blower Speed Short to Battery	DCSM	REFER to SEATING .
B19A5	Passenger Seat Cushion Blower Speed Short to Ground	DCSM	REFER to SEATING .
B19A6	Passenger Seat Back Blower Speed Short to Ground	DCSM	REFER to SEATING .
B19A7	Driver Seat Cushion Blower Speed Short to Ground	DCSM	REFER to SEATING .
B19A8	Driver Seat Back Blower Speed Short to Ground	DCSM	REFER to SEATING .
B1A01:01	Speaker #1: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:11	Speaker #1: Circuit Short To Ground	Audio Digital Signal Processing (DSP) module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:12	Speaker #1: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:13	Speaker #1: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:01	Speaker #2: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:11	Speaker #2: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:12	Speaker #2: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:13	Speaker #2: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:01	Speaker #3: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:11	Speaker #3: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:12	Speaker #3: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:13	Speaker #3: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:01	Speaker #4: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:11	Speaker #4: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:12	Speaker #4: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:13	Speaker #4: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:01	Speaker #5: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:11	Speaker #5: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:12	Speaker #5: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:13	Speaker #5: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:01	Speaker #6: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:11	Speaker #6: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:12	Speaker #6: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:13	Speaker #6: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:01	Speaker #7: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:11	Speaker #7: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:12	Speaker #7: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:13	Speaker #7: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:11	Speaker #8: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:12	Speaker #8: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:13	Speaker #8: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:11	Speaker #9: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:12	Speaker #9: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:13	Speaker #9: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A10:11	Speaker #10: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A10:12	Speaker #10: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A10:13	Speaker #10: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A11:11	Speaker #11: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A11:12	Speaker #11: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A11:13	Speaker #11: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A12:11	Speaker #12: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A12:12	Speaker #12: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A12:13	Speaker #12: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A56:21	Antenna: Signal Amplitude	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A89:01	Satellite Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A89:13	Satellite Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D19:49	Compact Disc Unit: Internal Electronic Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D19:4B	Compact Disc Unit: Over Temperature	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D78:13	Auxiliary Input: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D79:01	Microphone Input: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D79:01	Microphone Input: General Electrical Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2008	Wipers On Signal Circuit Short to Ground	SJB	REFER to WIPERS AND WASHERS .
B2019	Liftgate Exceeded Time Allowed to Cinch Door	LTM	REFER to BODY CLOSURES .
B201A	Power System Disabled Due to High Manual Closing Speed	LTM	REFER to BODY CLOSURES .
B2031	Left Corner Lamp Output Circuit Failure	SJB	REFER to EXTERIOR LIGHTING .
B2032	Right Corner Lamp Output Circuit Failure	SJB	REFER to EXTERIOR LIGHTING .
B2044	Left Rear Stop Lamp Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2045	Left Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2046	Right Rear Stop Lamp Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2047	Right Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2048	Left Rear Turn Lamp Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2049	Left Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2050	Right Rear Turn Lamp Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2051	Right Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2071	Hazard Switch Signal Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2077	Liftgate Ajar Sw Circuit Failure	SJB	REFER to INTERIOR LIGHTING .
B2084	Memory Set Indicator Short to Ground	DSM	REFER to SEATING .
B2097	Compass Module Failure	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2100	Door Driver Key Cylinder Switch Failure	SJB	REFER to SMART JUNCTION BOX (SJB) .
B2103	Antenna Not Connected	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2103	Antenna Not Connected	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B2108	Trunk Key Cylinder Switch Failure	SJB	REFER to SMART JUNCTION BOX (SJB) .
B2139	Data Mismatch (Receive Data Does Not Match What Was Expected)	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B213A	Digital Dimmer Switch Input Circuit Failure	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2141	NVM Configuration Failure	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B2143	NVM Memory Failure	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2212	Panel Dim Switch Out of Range	SJB	REFER to INTERIOR LIGHTING .
B2223	Mirror Driver Drive Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2224	Mirror Passenger Drive Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2254	Front Fog Lamp Switch Failure	SJB	REFER to EXTERIOR LIGHTING .
B2266	Driver Blend Door/Lower Actuator Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2267	Passenger Blend Door/Lower Actuator Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2268	Steering Wheel Climate Control Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2269	Steering Wheel Climate Control Circuit Short to Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2274	Phone Transceiver Active Circuit Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2275	Pedal Forward/Rearward Pot. Feedback Ckt. Short to GND	DSM	REFER to BRAKE SYSTEM - GENERAL INFORMATION .
B2276	Less Than Two Transmitters Programmed	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2281	Right Turn Switch Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2282	Left Turn Switch Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2292	Restraint System - Seatbelt Pretensioner Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2293	Restraint System - Airbag Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2294	Restraint System - Curtain Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2295	Restraint System - Side Airbag Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2296	Restraint System - Impact Sensor Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2312	Mirror Passenger Horizontal Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2314	Mirror Passenger Horizontal Feedback Potentiometer Circuit Short to Battery	DSM	REFER to REAR VIEW MIRRORS .
B2316	Mirror Passenger Vertical Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2318	Mirror Passenger Vertical Feedback Potentiometer Circuit Short to Battery	DSM	REFER to REAR VIEW MIRRORS .
B2320	Mirror Driver Horizontal Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2322	Mirror Driver Horizontal Feedback Potentiometer Circuit Short to Battery	DSM	REFER to REAR VIEW MIRRORS .
B2324	Mirror Driver Vertical Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2326	Mirror Driver Vertical Feedback Potentiometer Circuit Short to Battery	DSM	REFER to REAR VIEW MIRRORS .
B2330	Column Reach Feedback Potentiometer Circuit Short to Battery	DSM	REFER to STEERING SYSTEM .
B2331	Column Reach Feedback Potentiometer Circuit Short to Ground	DSM	REFER to STEERING SYSTEM .
B2334	Column Tilt Feedback Potentiometer Circuit Short to Battery	DSM	REFER to STEERING SYSTEM .
B2335	Column Tilt Feedback Potentiometer Circuit Short to Ground	DSM	REFER to STEERING SYSTEM .
B2340	Column Reach Motor Stalled	DSM	REFER to STEERING SYSTEM .
B2341	Column Tilt Motor Stalled	DSM	REFER to STEERING SYSTEM .
B236A	Chime Output Circuit Open	LTM	REFER to BODY CLOSURES .
B2384	Audio Reverse Aid Mute Input Ckt. Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2404	Audio Steering Wheel Switch Circuit Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2405	Audio Disc CD Player Thermal Shutdown Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2406	Audio Disc CD Player Internal Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2418	Sensor Power Short to Ground	LTM	REFER to BODY CLOSURES .
B2419	Sensor 1 Invalid	LTM	REFER to BODY CLOSURES .
B2420	Sensor 2 Invalid	LTM	REFER to BODY CLOSURES .
B2425	Remote Keyless Entry Out of Synchronization	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2426	Passenger Solar Radiation Sensor Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2427	Passenger Solar Radiation Sensor Circuit Short to Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2431	Transponder Programming Failed	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B2434	Drivers Seat Belt Buckle Switch Circuit Short to Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2435	Drivers Seat Belt Buckle Switch Resistance Out of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2438	Passengers Seat Belt Buckle Switch Circuit Short to Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2439	Passengers Seat Belt Buckle Switch Resistance Out of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2477	Module Configuration Failure	ABS module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	ACM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Audio RCU	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DCSM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DSM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	IC	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	PAM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	RCM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	RETM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SDARS module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SJB	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	VDM	REFER to MODULE CONFIGURATION .
B2479	Park Brake Switch Circuit Short to Ground	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2486	Climate Controlled Module Seat Voltage Out of Range	DCSM	REFER to CHARGING SYSTEM .
B2498	Headlamp Switch Multiple Signals Input Active	SJB	REFER to EXTERIOR LIGHTING .
B2552	Vbatt 2 Circuit Open	LTM	REFER to BODY CLOSURES .
B2572	Brake Shift Interlock Output Circuit Failure	SJB	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
B2607	Harness/Configuration Mismatch	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2627	Fuel Sender Circuit Open #2	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2628	Fuel Sender Circuit Short to Ground #2	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2656	DVD (Digital Versatile Disk) Error	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2666	Liftgate Release Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2667	Liftglass Release Switch Circuit Failure	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B2691	Seat Belt Buckle Switch Circuit Fault, Front Driver's side	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2692	Front Passenger's Seat Belt Buckle Switch Circuit Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2699	Left Pinch Strip Open or Short to Battery	LTM	REFER to BODY CLOSURES .
B2700	Right Pinch Strip Open or Short to Battery	LTM	REFER to BODY CLOSURES .
B2701	Left Pinch Strip Stuck Active	LTM	REFER to BODY CLOSURES .
B2702	Right Pinch Strip Stuck Active	LTM	REFER to BODY CLOSURES .
B2703	Open/Close Switch Stuck Active	LTM	REFER to BODY CLOSURES .
B2718	Liftgate/Decklid Ajar Output Short to Battery	LTM	REFER to BODY CLOSURES .
B2721	Liftgate/Decklid Ajar Output Short to Ground or Open	LTM	REFER to BODY CLOSURES .
B2723	Glass Position Switch Active During Self-test	LTM	REFER to BODY CLOSURES .
B2729	Cushion Over-Temperature Detected	DCSM	REFER to SEATING .
B272A	Passenger Cushion-Over Temp Detected	DCSM	REFER to SEATING .
B272B	Passenger Back-Over Temp Detected	DCSM	REFER to SEATING .
B272C	Driver Differential Temperature Fault	DCSM	REFER to SEATING .
B272D	Passenger Differential Temperature Fault	DCSM	REFER to SEATING .
B272E	Driver Ignition Run/Blower Circuit Short to Ground	DCSM	REFER to SEATING .
B272F	Passenger Ignition Run/Blower Circuit Short to Ground	DCSM	REFER to SEATING .
B2730	Back-over Temperature Detected	DCSM	REFER to SEATING .
B273A	Liftgate Release Output Circuit Shorted to Ground	SJB	REFER to BODY CLOSURES .
B273B	Liftgate Release Output Circuit Open or Shorted to Battery Voltage	SJB	REFER to BODY CLOSURES .
B2741	Sensor Cluster Loop End	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2783	Interior Humidity Sensor to DATC Short Circuit	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2784	Interior Humidity Sensor to DATC Open Circuit	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2792	Cross Link Between Firing Loops	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2794	3rd Row Power Fold Circuit Failure	SJB	REFER to SEATING .
B2795	Driver Solar Radiation Sensor Circuit Short to Ground	HVAC module	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2796	Driver Solar Radiation Sensor Circuit Open	HVAC module	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2813	LH Power Running Board Stow Time Fail	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B2814	LH Power Running Board Deploy Time Fail	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B2816	RH Power Running Board Stow Time Fail	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B2817	RH Power Running Board Deploy Time Fail	PRB module	REFER to EXTERIOR TRIM AND ORNAMENTATION .
B2819	Gate Motor Circuit Short to Battery	LTM	REFER to BODY CLOSURES .
B2826	Front Evaporator Temp Sensor Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2827	Front Evaporator Temp Sensor Short to Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2844	Ignition Fault	SJB	REFER to STEERING COLUMN SWITCHES .
B2868	Left Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2869	Right Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2870	Right Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2871	Left Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2872	Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2879	Fuel Tank Jet Pump Fault	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B287A	Tire Pressure System Fault	SJB	REFER to WHEELS & TIRES .
B287B	Incorrect Tire Pressure Sensor Installed	SJB	REFER to WHEELS & TIRES .
B2900	VIN Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2900	VIN Mismatch	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2903	Chime Output Circuit Short to Battery	LTM	REFER to BODY CLOSURES .
B2908	Latch Switch Invalid	LTM	REFER to BODY CLOSURES .
B2916	Rear Blend Door Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2917	Rear Mode Door Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2918	Aux Temp Blend Input Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2919	Aux Blower Motor Speed Input Circuit Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B2924	Audio Button Stuck	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2924	Audio Button Stuck	Audio RCU	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2924	Audio Button Stuck	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2935	Drive Unit Failure	LTM	REFER to BODY CLOSURES .
B2936	Gate Motor Open	LTM	REFER to BODY CLOSURES .
B2937	Gate Motor Short to Ground	LTM	REFER to BODY CLOSURES .
B2939	Gate Clutch Short to Ground or Open	LTM	REFER to BODY CLOSURES .
B2940	Chime Output Circuit Short to Ground	LTM	REFER to BODY CLOSURES .
B2947	Global Opening/Closing Circuit Open	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B2949	Global Opening/Closing Circuit Short to Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B2965	Audio System Speaker Circuit Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B29B7	White Lighting Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B29B8	White Lighting Output Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B2A20	Ignition Stuck in START	SJB	REFER to STEERING COLUMN SWITCHES .
B2A21	One or More Configuration Files Missing or Corrupt	SJB	REFER to MODULE CONFIGURATION .
B2A22	Headlamp OFF Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A23	High Beam Input Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A24	Turn Signal Input Circuit Failure	SJB	REFER to EXTERIOR LIGHTING .
B2A25	Trim Panel Lock Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2A26	Keypad Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2A27	Right Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A28	Right Front Turn Lamp Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A29	Left Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2A	Left Front Turn Lamp Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2B	Left Corner Lamp Output Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2C	Right Corner Lamp Output Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2D	3rd Row Power Fold Circuit Short to Ground	SJB	REFER to SEATING .
B2A2E	Right Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2F	Right Front Lamp Low Beam Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A30	Left Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A31	Left Front Lamp Low Beam Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A32	LED Backlighting Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A33	LED Backlighting Output Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B2A35	Interior Lighting Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A36	Interior Lighting Output Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B2A37	Floor Lamp Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A38	Floor Lamp Output Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B2A39	Puddle Lamp Output Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A3A	Puddle Lamp Output Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A3B	TPMS Initiator Left (1) Output Circuit Open	SJB	REFER to WHEELS & TIRES .
B2A3C	TPMS Initiator Left (1) Output Circuit Short to Ground	SJB	REFER to WHEELS & TIRES .
B2A3D	TPMS Initiator Right (2) Output Circuit Open	SJB	REFER to WHEELS & TIRES .
B2A3E	TPMS Initiator Right (2) Output Circuit Short to Ground	SJB	REFER to WHEELS & TIRES .
B2A41	Steering Column Telescopic Rear Switch Short to Battery	DSM	REFER to STEERING SYSTEM .
B2A42	Steering Column Tilt Up Switch Short to Battery	DSM	REFER to STEERING SYSTEM .
B2A44	Steering Column Telescopic Forward Switch Short to Battery	DSM	REFER to STEERING SYSTEM .
C1001:01	Vision System Camera: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
C1095	ABS Hydraulic Pump Motor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1125	Brake Fluid Level Sensor Input Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
C1145	Speed Wheel Sensor RF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1155	Speed Wheel Sensor LF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1165	Speed Wheel Sensor RR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1175	Speed Wheel Sensor LR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1233	Speed Wheel LF Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1234	Speed Wheel RF Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1235	Speed Wheel RR Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1236	Speed Wheel LR Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1277	Steering Wheel Angle 1 and 2 Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1278	Steering Wheel Angle 1 and 2 Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1279	Yaw Rate Sensor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1280	Yaw Rate Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1281	Lateral Accelerometer Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1282	Lateral Accelerometer Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1285	Booster Solenoid Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1287	Booster Pedal Force Switch Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1288	Pressure Transducer Main/Primary Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1414	Incorrect Module Design Level	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
C1440	Pressure Transducer Main/Primary Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1470	TCS Functions Temporarily Disabled (Thermal Brake Protection)	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1516	Roll Rate Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1517	Roll Rate Sensor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1699	Left Rear Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1700	Left Rear Sensor Circuit Failure or Blockage	PAM	REFER to PARKING AID .
C1701	Left Rear Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1702	Right Rear Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1703	Right Rear Sensor Circuit Failure or Blockage	PAM	REFER to PARKING AID .
C1704	Right Rear Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1705	Left Rear Center Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1706	Left Rear Center Sensor Circuit Failure	PAM	REFER to PARKING AID .
C1707	Left Rear Center Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1708	Right Rear Center Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1709	Right Rear Center Sensor Circuit Failure	PAM	REFER to PARKING AID .
C1710	Right Rear Center Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1711	Left Front Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1712	Left Front Sensor Circuit Failure	PAM	REFER to PARKING AID .
C1713	Left Front Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1714	Right Front Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1715	Right Front Sensor Circuit Failure	PAM	REFER to PARKING AID .
C1716	Right Front Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1717	Left Front Center Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1718	Left Front Center Sensor Circuit Failure	PAM	REFER to PARKING AID .
C1719	Left Front Center Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1724	Air Suspension Height Sensor Power Circuit Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1726	Air Suspension Rear Pneumatic Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1729	Transfer Case Unable to Transition between 4H and 4L	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
C1739	Right Front Center Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID .
C1740	Right Front Center Sensor Circuit Failure	PAM	REFER to PARKING AID .
C1741	Right Front Center Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1742	Rear Sounder Circuit Failure	PAM	REFER to PARKING AID .
C1743	Rear Sounder Circuit Short to Vbatt	PAM	REFER to PARKING AID .
C1744	Front Sounder Circuit Failure	PAM	REFER to PARKING AID .
C1745	Front Sounder Circuit Short to Vbatt	PAM	REFER to PARKING AID .
C1770	Air Suspension Vent Solenoid Output Circuit Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1790	Air Suspension LR Air Spring/Shock Solenoid Output Circuit Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1795	Air Suspension RR Air Spring/Shock Solenoid Output Circuit Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1805	Mismatched PCM and/or ABS-TC Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1810	Air Suspension Height Sensor Out of Range	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1830	Air Suspension Compressor Relay Circuit Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1885	Air Suspension RR Height Sensor Circuit Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1893	Air Suspension LR Height Sensor Circuit Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1945	Park Switch Indicates Park With Vehicle Moving	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
C1946	Front Driver's Seat Track Position Switch Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
C1947	Front Driver's Seat Track Position Switch Circuit Short to Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
C1948	Front Driver's Seat Track Position Switch Circuit Resistance Out of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
C1963	Stability Control Inhibit Warning	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1964	Air Suspension Air Compressor Request Exceeded Max Timing	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1979	IWE Solenoid Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
C1980	IWE Solenoid Short to Battery	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
C1981	Front Driver's Seat Track Position Switch Circuit Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
C1990	Incomplete Online Tests	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1991	Module Calibration Failure	ABS module	REFER to MODULE CONFIGURATION .
C1991	Module Calibration Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C1992	Vehicle Speed Circuit Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
C1996	Active Yaw and Roll Stability Control Disabled	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2001	Ride Height Calibration Error	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C2002	Pneumatic Test Failure	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
C2205	Forward Seat Extender Position Switch Circuit Short to Battery	DSM	REFER to SEATING .
C2206	Rearward Seat Extender Position Switch Circuit Short to Battery	DSM	REFER to SEATING .
C2207	Forward/Rearward Seat Extender Potentiometer Feedback Circuit Short to Battery	DSM	REFER to SEATING .
C2208	Forward/Rearward Seat Extender Potentiometer Feedback Circuit Short to Gnd	DSM	REFER to SEATING .
C2209	Forward/Rearward Seat Extender Motor Stalled	DSM	REFER to SEATING .
C2769	Longitudinal Acceleration Sensor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2770	Longitudinal Acceleration Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2777	Sensor Cluster Bus Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2778	Sensor Power Supply Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2780	ECU in Manufacturer Sub-State	SJB	REFER to WHEELS & TIRES .
C2784	RAM Checksum Error	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0218	Transmission Fluid Overtemperature Condition	Transmission Control Module (TCM)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0512	Starter Request Circuit	PCM	REFER to STARTING SYSTEM .
P0562	System Voltage Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0563	System Voltage High	PCM	REFER to CHARGING SYSTEM .
P0563	System Voltage High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0579	Cruise Control Multi-Function Input A Circuit Range/Performance	PCM	REFER to CRUISE CONTROL .
P0581	Cruise Control Multi-Function Input A Circuit High	PCM	REFER to CRUISE CONTROL .
P0602	Powertrain Control Module Programming Error	PCM	REFER to MODULE CONFIGURATION .
P0605	Internal Control Module Read Only Memory ( ROM ) Error	PCM	REFER to MODULE CONFIGURATION .
P0605	Internal Control Module Read Only Memory ( ROM ) Error	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0613	TCM Processor	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0622	Generator Field Terminal Circuit	PCM	REFER to CHARGING SYSTEM .
P062F	Internal Control Module EEPROM Error	SJB	REFER to SMART JUNCTION BOX (SJB) .
P062F	Internal Control Module EEPROM Error	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0634	PCM/ ECM / TCM Internal Temperature Too High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0641	Sensor Reference Voltage A Circuit/Open	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0657	Actuator Supply Voltage A Circuit/Open	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0658	Actuator Supply Voltage A Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0659	Actuator Supply Voltage A Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0667	PCM/ ECM / TCM Internal Temperature Sensor Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0701	Transmission Control System Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0705	Transmission Range Sensor A Circuit (PRNDL Input)	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0711	Transmission Fluid Temperature Sensor A Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0712	Transmission Fluid Temperature Sensor A Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0713	Transmission Fluid Temperature Sensor A Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0714	Transmission Fluid Temperature Sensor A Circuit Intermittent	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0715	Turbine/Input Shaft Speed Sensor A Circuit	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0716	Turbine/Input Shaft Speed Sensor A Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0717	Turbine/Input Shaft Speed Sensor A Circuit No Signal	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0720	Output Shaft Speed Sensor Circuit	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0721	Output Shaft Speed Sensor Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0722	Output Shaft Speed Sensor Circuit No Signal	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0723	Output Shaft Speed Sensor Circuit Intermittent	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0729	Gear 6 Incorrect Ratio	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0731	Gear 1 Incorrect Ratio	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0732	Gear 2 Incorrect Ratio	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0733	Gear 3 Incorrect Ratio	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0734	Gear 4 Incorrect Ratio	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0735	Gear 5 Incorrect Ratio	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0736	Reverse Incorrect Ratio	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0740	Torque Converter Clutch Solenoid Circuit/Open	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0741	Torque Converter Clutch Solenoid Circuit Performance Or Stuck Off	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0750	Shift Solenoid A	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0755	Shift Solenoid B	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0760	Shift Solenoid C	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0765	Shift Solenoid D	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0770	Shift Solenoid E	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0781	1-2 Shift	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0782	2-3 Shift	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0783	3-4 Shift	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0784	4-5 Shift	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0812:12	Reverse Input Circuit: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
P0829	5-6 Shift	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0960	Pressure Control Solenoid A Control Circuit/Open	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0961	Pressure Control Solenoid A Control Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0962	Pressure Control Solenoid A Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0963	Pressure Control Solenoid A Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0972	Shift Solenoid A Control Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0973	Shift Solenoid A Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0974	Shift Solenoid A Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0975	Shift Solenoid B Control Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0976	Shift Solenoid B Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0977	Shift Solenoid B Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0978	Shift Solenoid C Control Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0979	Shift Solenoid C Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0980	Shift Solenoid C Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0981	Shift Solenoid D Control Circuit Range/Performance	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0982	Shift Solenoid D Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0983	Shift Solenoid D Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0985	Shift Solenoid E Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P0986	Shift Solenoid E Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P1260	Theft Detected, Vehicle Immobilized	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1572	Brake Pedal Switch Circuit	PCM	REFER to CRUISE CONTROL .
P1639	Vehicle ID Block Corrupted, Not Programmed	PCM	REFER to MODULE CONFIGURATION .
P1703	Brake Pedal Switch Out of Self-Test Range	PCM	REFER to CRUISE CONTROL .
P1707	Transfer Case Neutral or Park/Neutral Indication Circuit	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P1812	Transmission Four-Wheel Drive Mode Select Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1815	Transmission Four-Wheel Drive Mode Select Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1824	Transmission Four-Wheel Drive Clutch Relay Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1825	4-Wheel Drive Clutch Relay Open Circuit	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1826	Transmission Four-Wheel Drive Low Clutch Relay Short Circuit to Battery	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1827	Transmission Four-Wheel Drive Low Clutch Relay Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1849	Transmission Transfer Case Contact Plate "A" Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1853	Transmission Transfer Case Contact Plate "B" Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1857	Transmission Transfer Case Contact Plate "C" Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1861	Transmission Transfer Case Contact Plate "D" Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1867	Transmission Transfer Case Contact Plate General Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1886	4X4 Initialization Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1891	Transmission Transfer Case Contact Plate Ground Return Open Circuit	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1910	Reverse Lamp Control Circuit/Open	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P1911	Reverse Lamp Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P1912	Reverse Lamp Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P2763	Torque Converter Clutch Pressure Control Solenoid Control Circuit High	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
P2764	Torque Converter Clutch Pressure Control Solenoid Control Circuit Low	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
PXXXX	All other DTCs	PCM	REFER to the INTRODUCTION - GASOLINE MODELS .
U0001	High Speed CAN Communication Bus	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0037	Vehicle Communication Bus B	IC	REFER to MODULE COMMUNICATIONS NETWORK .
U0073	Control Module Communication Buss Off	VDM	REFER to MODULE COMMUNICATIONS NETWORK .
U0073	Control Module Communication Buss Off	TCM	REFER to MODULE COMMUNICATIONS NETWORK .
U0100	Lost Communication With ECM /PCM	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0100	Lost Communication With ECM /PCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0100	Lost Communication With ECM /PCM	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0100	Lost Communication With ECM /PCM	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
U0100	Lost Communication With ECM /PCM	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0101	Lost Communication with TCM	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0101	Lost Communication with TCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0101	Lost Communication with TCM	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0102	Lost Communication with Transfer Case Control Module (4x4CM)	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0102	Lost Communication with Transfer Case Control Module (4x4CM)	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
U0114	Lost Communication With Four-Wheel Drive Clutch Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	TCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .
U0122	Lost Communication With Vehicle Dynamics Control Module	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0140	Lost Communication With Body Control Module ( GEM )	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	Audio RCU	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	DSM	REFER to DRIVER SEAT MODULE (DSM) .
U0140	Lost Communication With Body Control Module ( GEM )	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0140	Lost Communication With Body Control Module ( GEM )	LTM	REFER to BODY CLOSURES .
U0140	Lost Communication With Body Control Module ( GEM )	PAM	REFER to PARKING AID .
U0140	Lost Communication With Body Control Module ( GEM )	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Global Positioning System Module (GPSM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0151	Lost Communication With Restraints Control Module	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	DSM	REFER to DRIVER SEAT MODULE (DSM) .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	LTM	REFER to BODY CLOSURES .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	PAM	REFER to PARKING AID .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	SJB	REFER to SMART JUNCTION BOX (SJB) .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	VDM	REFER to VEHICLE DYNAMIC SUSPENSION .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0159	Lost Communication With Parking Assist Control Module ( PAM )	IC	REFER to PARKING AID .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0162:00	Lost Communication With Navigation Display Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0164	Lost Communication With HVAC Control Module ( EATC )	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0164:00	Lost Communication With HVAC Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U016A:00	Lost Communication With Global Positioning System Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184	Lost Communication With Radio ( ACM )	Audio RCU	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184	Lost Communication With Radio ( ACM )	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184	Lost Communication With Radio ( ACM )	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193	Lost Communication With Digital Audio Control Module ( SDARS )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193	Lost Communication With Digital Audio Control Module ( SDARS )	Audio RCU	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193	Lost Communication With Digital Audio Control Module ( SDARS )	RETM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193:00	Lost Communication With "Digital Audio Control Module A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196	Lost Communication With Entertainment Control Module - Rear (AUX)	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196	Lost Communication With Entertainment Control Module - Rear (AUX)	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module - Rear "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module-Rear "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module-Rear "A": No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197	Lost Communication With Telephone Control Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197	Lost Communication With Telephone Control Module	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0208	Lost Communication With Seat Control Module ( DSM )	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0230	Lost Communication With Rear Gate Module ( LTM )	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0238	Lost Communication With Digital Audio Control Module "D" ( DSP )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0238:00	Lost Communication With Digital Audio Control Module "D": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0242	Lost Communication With Headlamp Control Module 2 (HCM-2)	IC	REFER to EXTERIOR LIGHTING .
U0244	Lost Communication With Running Board Control Module ( PRB )	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0249	Lost Communication With Entertainment Control Module - Rear "B" ( RCU )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249	Lost Communication With Entertainment Control Module - Rear "B" ( RCU )	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249:00	Lost Communication With Entertainment Control Module - Rear "B": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249:00	Lost Communication With Entertainment Control Module - Rear "B": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255	Lost Communication With Front Controls Interface Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255	Lost Communication With Front Controls Interface Module	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256	Lost Communication With Front Display Interface Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256	Lost Communication With Front Display Interface Module	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0300	Internal Control Module Software Incompatibility	PCM	REFER to MODULE CONFIGURATION .
U0300	Internal Control Module Software Incompatibility	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0301	Software Incompatibility with Engine/Powertrain Control Module	PCM	REFER to MODULE CONFIGURATION .
U0401	Invalid Data Received from ECM /PCM A	ABS module	RETRIEVE and FOLLOW DTCs from the PCM.
U0402	Invalid Data Received from TCM	ABS module	RETRIEVE and FOLLOW DTCs from the TCM .
U0414	Invalid Data Received from TCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0422:00	Invalid Data Received From Body Control Module: No Sub Type Information	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U0422:00	Invalid Data Received From Body Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0423:00	Invalid Data Received From Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U0423:00	Invalid Data Received From Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U046B:00	Invalid Data Received From Global Positioning System Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0485:00	Invalid Data Received From Radio: No Sub Type Information	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U1900	CAN Communication Bus Fault - Receive Error	PRB module	REFER to MODULE COMMUNICATIONS NETWORK .
U1900	CAN Communication Bus Fault - Receive Error	RCM	REFER to MODULE COMMUNICATIONS NETWORK .
U1901	Communication Fault from Sensor Cluster	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U2011	Module Transmitted Invalid Data (Non SCP )	VDM	RETRIEVE and FOLLOW non-network DTCs from other modules.
U2013	Compass Module Is Not Responding	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U2013:63	Switch Pack: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:09	Control Module Hardware: Component Failures	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:42	Control Module Hardware: General Memory Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:4B	Control Module Hardware: Over Temperature	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:96	Control Module Hardware: Component Internal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U201A:51	Control Module Main Calibration Data: Not Programmed	ACM	REFER to MODULE CONFIGURATION .
U201A:51	Control Module Main Calibration Data: Not Programmed	Audio DSP module	REFER to MODULE CONFIGURATION .
U2023	Fault Received From External Node	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U2023	Fault Received From External Node	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U2023	Fault Received From External Node	PAM	REFER to PARKING AID .
U2050	No Application Present	4X4 control module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ABS module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ACM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	Audio RCU	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2050	No Application Present	DCSM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	DSM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	HVAC module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	IC	REFER to MODULE CONFIGURATION .
U2050	No Application Present	LTM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	PAM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	PRB module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2050	No Application Present	RETM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	SDARS module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	SJB	REFER to SMART JUNCTION BOX (SJB) .
U2050	No Application Present	VDM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	ACM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	IC	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	LTM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	PAM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	RCM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	Audio DSP module	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2199	Invalid 'Engine Coolant Temperature' Data	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U2471	Unexpected PRNDL State	LTM	REFER to BODY CLOSURES .
U2471	Unexpected PRNDL State	PAM	REFER to PARKING AID .
U2472	Unexpected Ignition State	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U2472	Unexpected Ignition State	LTM	REFER to BODY CLOSURES .
U2472	Unexpected Ignition State	PAM	REFER to PARKING AID .
U2472	Unexpected Ignition State	SJB	REFER to STEERING COLUMN SWITCHES .
U2473	Unexpected Vehicle Speed ( VSS )	LTM	REFER to BODY CLOSURES .
U2473	Unexpected Vehicle Speed ( VSS )	PAM	REFER to PARKING AID .
U2473	Unexpected Vehicle Speed ( VSS )	SJB	REFER to SMART JUNCTION BOX (SJB) .
U2510	CAN - Invalid data for Vehicle Security	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U2511	CAN - Data Mis-Match (Receive Data Does Not Match Expected)	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U261A	CAN Data/Configuration Setup Mismatch	IC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:04	Control Module: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:09	Control Module: Component Failures	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:88	Control Module: Bus Off	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .

DTC CHART

Inspection and Verification

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery Junction Box (BJB) fuse 56 (30A) Smart Junction Box (SJB) fusible link D (10 Ga) SJB fuse(s): 5 (10A) 6 (20A) 7 (10A) 8 (10A) 9 (15A) 10 (15A)
If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
NOTE: Make sure to use the latest scan tool software release. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM . If the scan tool does not communicate with the VCM : Check the VCM connection to the vehicle. Check the scan tool connection to the VCM . Refer to «MODULE COMMUNICATIONS NETWORK»(ref-364058) , No Power To The Scan Tool, to diagnose no power to the scan tool.
If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-364058) to diagnose no response from the PCM.
Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-364058) . If the network test passes, retrieve and record the continuous memory DTCs.
Clear the continuous DTCs and carry out the self-test diagnostics for the SJB .
If the DTCs retrieved are related to the concern, go to «DTC CHARTS»(ref-364059-S22903000992010062700000) .
If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-364059-S11596008462010062700000) .

DTC Charts

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	GO to PINPOINT TEST A .
B106F	Module Disabled Due to External Fault	GO to PINPOINT TEST A .
B1317	Battery Voltage High	GO to PINPOINT TEST B .
B1318	Battery Voltage Low	GO to PINPOINT TEST C .
B1342	ECU Is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new Smart Junction Box (SJB). REFER to SMART JUNCTION BOX (SJB) .
B2100	Door Driver Key Cylinder Switch Failure	DISREGARD this DTC. The vehicle is not equipped with a driver door key cylinder switch on the SJB C2280E-8 and C2280E-9. CLEAR the DTCs. REPEAT the self-test. If DTC B2100 is retrieved again, the SJB may be incorrectly configured. CARRY OUT the Programmable Module Installation (PMI) procedure. REFER to MODULE CONFIGURATION .
B2108	Trunk Key Cylinder Switch Failure	DISREGARD this DTC. The vehicle is not equipped with a trunk key cylinder switch. CLEAR the DTCs. REPEAT the self-test. If DTC B2108 is retrieved again, the SJB may be incorrectly configured. CARRY OUT the PMI procedure. REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	REFER to MODULE CONFIGURATION .
P062F	Internal Control Module EEPROM Error	CLEAR the DTCs. REPEAT the self-test. If DTC P062F is retrieved again, INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	GO to PINPOINT TEST D .
U2050	No Application Present	CARRY out PMI on the SJB . REFER to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC U2050 is retrieved again, INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
U2473	Unexpected Vehicle Speed ( VSS )	REFER to SMART JUNCTION BOX (SJB) .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) CHART .

SMART JUNCTION BOX (SJB) DTC CHART

Symptom Chart

Condition	Possible Sources	Action
The Smart Junction Box (SJB) does not respond to the scan tool	Fuse(s) Wiring, terminals or connectors SJB	REFER to MODULE COMMUNICATIONS NETWORK .

SYMPTOM CHART

PINPOINT TEST A: DTCs B106E, B106F

Note. If DTC B106F is present and a new SJB is to be installed, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new SJB , resulting in a repeat repair.

A1 REVIEW THE DTCs Review the DTCs from the SJB self-test. Are only DTCs B106E and B106F present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-364059-S20508366472010062700000) . TEST the system for normal operation. No: CORRECT any DTCs present other than DTCs B106E and B106F. REFER to the «DTC CHARTS»(ref-364059-S22903000992010062700000) . After the repair, GO to A2 .
A2 CARRY OUT THE SJB SELF-TEST Carry out the SJB self-test. Is DTC B106F present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-364059-S20508366472010062700000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits.

Pinpoint Test B: DTC B1317

Refer to SYSTEM WIRING DIAGRAMS (Expedition), SYSTEM WIRING DIAGRAMS (Expedition EL), SYSTEM WIRING DIAGRAMS (Navigator) or SYSTEM WIRING DIAGRAMS (Navigator L) for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

B1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All Modules) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «CHARGING SYSTEM»(ref-364045) to diagnose an overcharging condition. No: GO to B2 .
B2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-364045) to diagnose an overcharging condition. No: GO to B3 .
B3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the continuous memory DTCs. Carry out the SJB self-test. Is DTC B1317 present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-364059-S20508366472010062700000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test C: DTC B1318

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 107

Scheme 107: PINPOINT TEST C: DTC B1318

Scheme 108

C1 RECHECK THE SJB DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs. Repeat the SJB self-test. Is DTC B1318 still present? Yes: GO to C2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
C2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «CHARGING SYSTEM»(ref-364045) . No: GO to C3 .
C3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-364088) , Battery Condition Test. Is the battery OK and fully charged? Yes: GO to C4 . No: REFER to «CHARGING SYSTEM»(ref-364045) .
C4 CHECK THE SJB VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: SJB C2280g. Ignition ON. Measure the voltage between the SJB C2280g-1, circuit SDC04 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to C5 . No: REPAIR the circuit for high resistance. CLEAR the DTC. REPEAT the self-test.
C5 CHECK THE SJB GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: SJB C2280d. Measure the resistance between the SJB C2280d-7, C2280d-8, C2280d-12 and C2280d-24, circuit GD138 (BK/WH), harness side and ground. Is the resistance less than 5 ohms? Yes: CONNECT the negative battery cable. GO to C6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
C6 CHECK FOR CORRECT SJB OPERATION Disconnect the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-364059-S20508366472010062700000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test D: DTC U0155

D1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to D2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IC pass the network test? Yes: GO to D3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-364058) .
D3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded SJB DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST B»(ref-364059-S40833876952010062700000) . For DTC B1318, GO to «PINPOINT TEST C»(ref-364059-S25341657862010062700000) . No: GO to D4 .
D4 RECHECK THE SJB DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the SJB self-test. Is DTC U0155 still present? Yes: GO to D5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D5 CHECK FOR DTC U0155 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155 set in the ACM , DSM , audio DSP module or PAM ? Yes: INSTALL a new IC . REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-364063) . No: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-364059-S20508366472010062700000) .

Pinpoint Test D

D5 DLC

NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM .
If the scan tool does not communicate with the VCM

D8 DSM

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	GO to PINPOINT TEST E .
B106F	Module Disabled Due to External Fault	GO to PINPOINT TEST E .
B1317	Battery Voltage High	GO to PINPOINT TEST F .
B1318	Battery Voltage Low	GO to PINPOINT TEST G .
B1342	ECU is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new Driver Seat Module (DSM). REFER to DRIVER SEAT MODULE (DSM) . TEST the system for normal operation.
U0140	Lost Communication With Body Control Module ( GEM )	GO to PINPOINT TEST H .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	GO to PINPOINT TEST I .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) CHART .

DRIVER SEAT MODULE (DSM) DTC CHART

Condition	Possible Sources	Action
The Driver Seat Module (DSM) does not respond to the scan tool	Fuse(s) Wiring, terminals or connectors DSM	REFER to MODULE COMMUNICATIONS NETWORK .

SYMPTOM CHART

PINPOINT TEST E: DTCs B106E, B106F

Note. If DTC B106F is present, the fault condition must be corrected prior to installing a new Driver Seat Module (DSM). Failure to correct the fault condition first may cause damage to the new DSM , resulting in a repeat repair.

E1 REVIEW THE DTCs Review the DTCs from the DSM self-test. Are DTCs B106F and B1342 present? Yes: CORRECT the cause of any other DTCs present. When the other DTCs are corrected, INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-364059-S21959727142010062700000) . TEST the system for normal operation. No: GO to E2 .
E2 REPAIR OTHER DTCs Repair the cause of any DTCs present, other than DTC B106E. Refer to «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-364059-S16814350402010062700000) . Clear the DTCs. Carry out the DSM self-test. Is DTC B106E still present? Yes: The fault causing the output state to be disabled is still present. REPAIR the cause of the concern. CLEAR the DTCs. REPEAT the self-test. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits.

Pinpoint Test F: DTC B1317

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

F1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All Modules) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «CHARGING SYSTEM»(ref-364045) to diagnose an overcharging condition. No: GO to F2 .
F2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-364045) to diagnose an overcharging condition. No: GO to F3 .
F3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: DSM Self-Test. Clear the continuous memory DTCs. Carry out the DSM self-test. Is DTC B1317 present? Yes: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-364059-S21959727142010062700000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test G: DTC B1318

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 109

Scheme 109: PINPOINT TEST G: DTC B1318

Scheme 110

G1 RECHECK THE DSM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: DSM Self-Test. Clear the DTCs. Repeat the DSM self-test. Is DTC B1318 still present? Yes: GO to G2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
G2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «CHARGING SYSTEM»(ref-364045) . No: GO to G3 .
G3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-364088) , Battery Condition Test. Is the battery OK and fully charged? Yes: GO to G4 . No: REFER to «CHARGING SYSTEM»(ref-364045) .
G4 CHECK THE DSM VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: DSM C341A. Ignition ON. Measure the voltage between the DSM C341A-1, circuit SBB74 (YE/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to G5 . No: REPAIR the circuit for high resistance. CLEAR the DTC. REPEAT the self-test.
G5 CHECK THE DSM GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the DSM C341A-2, circuit GD143 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? Yes: CONNECT the negative battery cable. GO to G6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
G6 CHECK FOR CORRECT DSM OPERATION Disconnect the DSM connectors. Check for: corrosion damaged pins pushed-out pins Connect the DSM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-364059-S21959727142010062700000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test H: DTC U0140

H1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to H2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
H2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the SJB pass the network test? Yes: GO to H3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-364058) .
H3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DSM DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST F»(ref-364059-S07999409542010062700000) . For DTC B1318, GO to «PINPOINT TEST G»(ref-364059-S37531732032010062700000) . No: GO to H4 .
H4 RECHECK THE DSM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DSM self-test. Is DTC U0140 still present? Yes: GO to H5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
H5 CHECK FOR DTC U0140 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140 set in the ACM , DSM , audio DSP module or PAM ? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-364059-S20508366472010062700000) . No: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-364059-S21959727142010062700000) .

Pinpoint Test I: DTC U0155

I1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to I2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
I2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IC pass the network test? Yes: GO to I3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-364058) .
I3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DSM DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST F»(ref-364059-S07999409542010062700000) . For DTC B1318, GO to «PINPOINT TEST G»(ref-364059-S37531732032010062700000) . No: GO to I4 .
I4 RECHECK THE DSM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DSM self-test. Is DTC U0155 still present? Yes: GO to I5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
I5 CHECK FOR DTC U0155 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155 set in the ACM , DSM , audio DSP module or PAM ? Yes: INSTALL a new IC . REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-364063) . No: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-364059-S21959727142010062700000) .

Scheme 111

Scheme 111: Smart Junction Box (SJB)

Item	Part Number	Description
1		Smart Junction Box (SJB) electrical connectors (part of 14401)
2		SJB electrical connectors (part of 14A005)
3		SJB electrical connectors (part of 14290)
2	W706287	SJB bolts (2 required)
3	14B207	SJB

ITEM DESCRIPTION CHART

Multifunction Electronic Modules: Diagnosis Ford Expedition III
