Charging System: Component Locations Ford Expedition III

Charging System 4 illustrations ~502 words

Special Tool(s)

SPECIAL TOOL CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 14

Scheme 14: Special Tool(s)
WARNINGBatteries contain sulfuric acid and produce explosive gases. Work in a well-ventilated area. Do not allow the battery to come in contact with flames, sparks or burning substances. Avoid contact with skin, eyes or clothing. Shield eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes, then get prompt medical attention. If acid is swallowed, call a physician immediately. Failure to follow these instructions may result in serious personal injury.
WARNINGAlways lift a plastic-cased battery with a battery carrier or with hands on opposite corners. Excessive pressure on the battery end walls may cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery.

Note. Do not make jumper connections except as directed. Incorrect connections may damage the voltage regulator test terminals, fuses or fusible links.

Note. Do not allow any metal object to come in contact with the generator housing and internal diode cooling fins. A short circuit may result and burn out the diodes.

Note. While carrying out any pinpoint test, disregard any DTCs set while following a specific pinpoint test. After the completion of a test, be sure to clear all DTCs in the PCM.

Note. All voltage measurements are referenced to the negative (-) battery post unless otherwise specified.

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Battery Front End Accessory Drive (FEAD) belt Generator pulley Wiring, terminals or connectors Cables Battery Generator Fusible links Fuses Radial arm adapter
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. Verify the battery condition. Refer to «BATTERY, MOUNTING AND CABLES»(ref-364088) .
  5. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
  6. If the scan tool does not communicate with the VCM : check the VCM connection to the vehicle. check the scan tool connection to the VCM . refer to «MODULE COMMUNICATIONS NETWORK»(ref-364058) , No Power To The Scan Tool, to diagnose no power to the scan tool.
  7. If the scan tool does not communicate with the vehicle: verify the ignition is ON. The air bag warning indicator prove-out (other indicators may NOT prove ignition is ON) confirms ignition ON. If ignition does not turn ON, refer to «STEERING COLUMN SWITCHES»(ref-364062) to diagnose no power in RUN. refer to «MODULE COMMUNICATIONS NETWORK»(ref-364058) Inspection and Verification to establish a scan tool session (without the ignition ON). verify the scan tool operation with a known good vehicle.
  8. Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-364058) . NOTE: Use the Integrated Diagnostic System (IDS) feature that retrieves all Continuous Memory Diagnostic Trouble Codes (CMDTCs) from all modules at one time.
  9. Retrieve CMDTCs from all modules.
  10. If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-364045-S17073315362010062700000) . For all other DTCs, refer to the Master DTC Chart in «MULTIFUNCTION ELECTRONIC MODULES»(ref-364059) or «INTRODUCTION - GASOLINE MODELS»(ref-355661) .
  11. If no DTCs related to the concern are retrieved, go to the «SYMPTOM CHART»(ref-364045-S36710338932010062700000) .

SPECIAL TOOL CHART Backprobe Pins POM6411 Flex Probe Kit 300-NUD105-R025DE or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Test Light SGT27000 or equivalent 250-350 mA incandescent bulb test lamp SGT27000 Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 15

Scheme 15: Special Tool(s)

Scheme 16

Scheme 16

Scheme 17

Scheme 17
