Special Tool(s)
SPECIAL TOOL REFERENCE Holding Tool, Compressor Clutch 412-134 Remover, Compressor Pulley 412-001 (T71P-19703-B)
Scheme 234
| Item | Part Number | Description |
|---|---|---|
| 1 | W711887 | A/C clutch disc and hub bolt |
| 2 | 19D786 | A/C clutch disc and hub |
| 3 | 19N689 | A/C clutch hub disc and hub spacer |
| 4 | N805338 | A/C compressor pulley snap ring |
| 5 | 19D784 | A/C compressor pulley |
| 6 | W711883 | A/C clutch field coil snap ring |
| 7 | W710797 | A/C clutch field coil electrical connector screw |
| 8 | 19D798 | A/C clutch field coil |
ITEM DESCRIPTION
Scheme 235
Scheme 236
- Remove the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR»(ref-364092-S09579994892010062700000) .
- Remove the A/C clutch disc and hub bolt. Using the Compressor Clutch Holding Tool, hold the A/C clutch disc and hub. Remove the A/C clutch disc and hub bolt.
- Remove the A/C clutch disc and hub.
- Remove the A/C compressor pulley snap ring.
- NOTE: Do not use air tools. Damage to the Air Conditioning (A/C) clutch pulley or A/C compressor may result. Using the Compressor Pulley Remover, remove the A/C compressor pulley. Install the Compressor Pulley Remover. Remove the A/C compressor pulley.
- Remove the A/C clutch field coil snap ring.
- Remove the A/C clutch field coil electrical connector screw.
- Remove the A/C clutch field coil.
