Engine Controls - Service & Adjustment Specifications: Other Ford Excursion I

Specifications 22 illustrations ~631 words

Diesel Engines

Note. On diesel engines, a mechanical compression testing procedure is not available from manufacturer.

To diagnose possible cylinder compression loss, perform CRANKCASE PRESSURE TEST under ENGINE PERFORMANCE DIAGNOSIS in SYSTEM & COMPONENT TESTS - EEC-V - DIESEL article and/or KOER CYLINDER CONTRIBUTION SELF-TEST under QUICK TEST in SELF-DIAGNOSTICS - EEC-V - DIESEL article.

Gasoline Engines

Note. DO NOT use ignition switch to crank engine. Fuel injection and coils will activate and may cause damage.

Check engine compression with engine at normal operating temperature, all spark plugs removed (on dual plugs, remove exhaust side only), and throttle wide open. Ensure crankcase is full and oil is of correct viscosity. With compression gauge installed, use remote starter switch to crank engine.

Crank engine at least 5 revolutions, and record highest reading. Repeat procedure for all cylinders, using approximately same number of revolutions. Lowest compression reading should not be less than 75 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (7 kg/cm 2 ).

VALVE CLEARANCE

Note. All models are equipped with hydraulic valve lifters; valve adjustment is not required. If valves are noisy or incorrect clearance is suspected, worn components are indicated. Check collapsed valve lifter clearance. See appropriate article in ENGINES.

HIGH TENSION WIRE RESISTANCE

On all models, high tension wire resistance should be no more than 7000 ohms per foot.

SPARK PLUGS

Note. See vehicle underhood emissions information decal for spark plug gap specification.

Note. If reusing originally installed spark plugs, reinstall them in original position. Some cylinders use platinum ground electrodes and some cylinders use platinum positive electrodes. Replacement platinum spark plugs are double platinum electrode spark plugs and are used for all cylinders.

FIRING ORDER & TIMING MARKS

Note. Use illustrations for firing order and timing marks. (Scheme 1)- (Scheme 22). Timing mark information is not available for all models.

Scheme 1

Scheme 1: Firing Order & Timing Marks (2.0L)

Scheme 2

Scheme 2: Spark Plug Wire Routing (2.0L)

Scheme 3

Scheme 3: Firing Order & Timing Marks (2.3L)

Scheme 4

Scheme 4: Firing Order & Timing Marks (3.0L Ranger)

Scheme 5

Scheme 5: Firing Order & Timing Marks (3.0L Escape)

Scheme 6

Scheme 6: Firing Order (3.3L)

Scheme 7

Scheme 7: Firing Order & Timing Marks (3.8L)

Scheme 8

Scheme 8: Spark Plug Wire Routing (3.8L)

Scheme 9

Scheme 9: Firing Order (4.0L - Explorer & Mountaineer)

Scheme 10

Scheme 10: Spark Plug Wire Routing (4.0L - Explorer & Mountaineer)

Scheme 11

Scheme 11: Firing Order & Timing Marks (4.0L - Ranger)

Scheme 12

Scheme 12: Spark Plug Wire Routing (4.0L - Ranger)

Scheme 13

Scheme 13: Firing Order & Timing Marks (4.2L - E-Series)

Scheme 14

Scheme 14: Spark Plug Wire Routing (4.2L - E-Series)

Scheme 15

Scheme 15: Firing Order & Timing Marks (4.2L - F-Series)

Scheme 16

Scheme 16: Spark Plug Wire Routing (4.2L - F-Series)

Scheme 17

Scheme 17: Firing Order & Timing Marks (4.6L & 5.4L)

Scheme 18

Scheme 18: Spark Plug Coils (4.6L & 5.4L)

Scheme 19

Scheme 19: Spark Plug Coils (5.4L)

Scheme 20

Scheme 20: Firing Order (6.8L)

Scheme 21

Scheme 21: Spark Plug Coils (6.8L)

Scheme 22

Scheme 22: Firing Order (7.3L Diesel)

IGNITION TIMING

Note. On all models with distributorless electronic ignition, manufacturer does not recommend checking ignition timing, as faulty readings are common and timing is not adjustable.

ApplicationDegrees BTDC
Except Villager8-12
Villager13-17

BASE IGNITION TIMING

FUEL PUMP

Note. Fuel pump performance is a measurement of fuel pressure and volume availability, not regulated fuel pressure.

Note. For fuel pressure specifications, see FUEL PRESSURE SPECIFICATIONS .

IDLE MIXTURE

Note. Idle mixture is not adjustable. For additional information, see appropriate THEORY & OPERATION article.

Villager

  1. Ensure all vehicle accessories are off and front wheels are straight. Apply parking brake. Ensure transmission is in Neutral or Park. Connect scan tool to Data Link Connector (DLC) and start engine. Using scan tool, monitor ECT and RPM PIDs.
  2. Loosen cold idle adjust nut and turn cold idle adjust screw to align fast idle cam cold mark with cam follower lever roller while ECT PID reads 66-86°F (20-30°C). Tighten cold idle adjust nut.
  3. Loosen base idle adjust nut and turn base idle adjust screw to adjust idle speed while ECT PID reads 167-185°F (75-85°C) and RPM PID reads 650-750 RPM. Tighten base idle adjust nut. Turn air conditioning on. Place A/C control in MAX position and blower fan control in HI position. Make sure idle speed is more than 800 RPM.

THROTTLE POSITION SENSOR

Note. Throttle Position (TP) sensor is not serviceable. TP sensor may also be referred to as Accelerator Pedal (AP) sensor. If TP sensor service is required, see TEST DH in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

TP SENSOR OUTPUT (VILLAGER)

Throttle Position(1) Voltage
Closed.4
1/41.3
Half Open2.2
3/43.1
Fully Open4.1
(1) Values may vary by 15 percent.
(1)Values may vary by 15 percent.

TP SENSOR OUTPUT (VILLAGER)

TP SENSOR OUTPUT (EXCEPT VILLAGER)

Throttle Angle Degrees(1) Volts
Clockwise
201.00
402.00
603.00
803.80
1004.50
Counterclockwise
01.00
202.00
403.00
603.80
804.65
(1) Throttle position may vary by 6 percent. For testing, refer to TEST DH in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.
(1)Throttle position may vary by 6 percent. For testing, refer to TEST DH in SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article.

TP SENSOR OUTPUT (EXCEPT VILLAGER)
