MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see appropriate SCHEDULED SERVICES article listed below. Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

1. SCHEDULED SERVICES - 1991-93
2. SCHEDULED SERVICES - 1994-96

Fuse & Circuit Breaker Identification

1. 1 - 10 Amp REAR WIPER - Rear Wiper/Washer Motors, WAC & A/C Relays, Daytime Running Lights (Canada), Climate Control Panel Illumination
2. 2 - 15 Amp HAZARD - Turn Signal Lights & Indicators, Hazard Flasher
3. 3 - 10 Amp ROOM - Dome, Map & Vanity Mirror Lights, TWS Unit (Tracer), Ignition Key Illumination, Luggage Compartment Light, Radio Memory, Door Lock Relay, Shift Lock System (Tracer), EEC Module (1991-93), Powertrain Control Module ((PCM) 1994), EGI Module, EAT Control Unit
4. 4 - 5 Amp ENGINE - Cooling Fan Relays, Ignition & EEC Relays (1991-93), PCM Relay (1994)
5. 5 - 15 Amp RADIO - Radio & Premium Sound Amplifier, Remote Control Mirror, Instrument Panel Dimmer Switch
6. 6 - 30 Amp DOOR LOCK - Door Lock Motor (If Equipped)
7. 7 - 30 Amp BELT - Passive Restraint Control Module, Passive Restraint Motors
8. 8 - 30 Amp POWER WIND - Power Windows (If Equipped)
9. 9 - 15 Amp METER - Instrument Cluster, Back-Up & Turn Signal Lights, Speed Control System, Shift Lock System, TWS Unit, EAT Control Unit, Passive Restraint Control Module, Hazard Flasher, Auto Cruise, Safety Belt Warning Chime (1994), PCM ((1994)1.8L Canada)
10. 10 - 20 Amp WIPER - Front Wiper/Washer Motors, Interval Wiper Relay Unit
11. 11 - 20 Amp STOP - Stoplights & Hi-Mount Stoplight, Shift Interlock, Auto Cruise, EAT & EGI Modules, Horn
12. 12 - 15 Amp TAIL - Taillights & Side Marker Lights, License & Engine Compartment Lights, TNS Relay, EGI Module (1.8L), TWS Unit
13. 13 - 15 Amp SUN ROOF - Moon Roof Motor (If Equipped)
14. 14 - 10 Amp - Anti-Lock Brake System (1994)
15. 15 - 20 Amp DEFOG - Rear Window Defogger (If Equipped), EGI Module (1.8L)
16. 16 - 30 Amp Circuit Breaker - Blower Motor, EGI Module (1.8L)

Scheme 1

Fuse Identification

1. 1 - 30 Amp FUEL INJ - Fuel Injection System
2. 2 - 30 Amp HEAD - Headlights, High Beam Indicator, Foglights, Daytime Running Lights (Canada)
3. 3 - 80 Amp MAIN - Turn Signal Lights, Back-Up Lights, Cigarette Lighter, Power Window Cluster, Shiftlock System, Moon Roof Motor
4. 4 - 60 Amp BTN - Taillights, Stoplights Belt & Hazard Lights, Door Lock Fuses, Charging System
5. 5 - 30 Amp HORN - Horn (1994)
6. 6 - 30 Amp COOLING FAN - Cooling Fan Motor (M/T) 40 Amp COOLING FAN - Cooling Fan Motor (A/T)
7. 7 - 20 Amp AIR CON - A/C Magnetic Clutch (If Equipped)
8. 8 - 10 Amp - Air Bag Diagnostic Module (1994)
9. 9 - 10 Amp ST SIGN - Circuit Relay, EGI Module, PCM (1993-94), Fuel Pump Relay (1994)
10. 10 - Empty

Scheme 2

1. 1 - 30 Amp FUEL INJ - Fuel Injection System
2. 2 - 30 Amp HEAD - Headlights, High Beam Indicator, Foglights, Daytime Running Lights (Canada)
3. 3 - 100 Amp MAIN - Charging System, (FAN, A/C, & BTN fuses), Ignition Switch Wiper/Washer Motors, Audio System
4. 4 - 40 Amp BTN - (Taillights, Stoplights Belt & Hazard Lights, Door Lock Fuses, Charging System (1992-93)), (Interior Lights, Transaxle, PCM, Exterior Lights, Horn, Power Door Locks, Radio, Passive Restraint Control Module, Safety Belt warning Chime (1994))
5. 5 - 60 Amp - Anti-Lock Brake System (1994)
6. 6 - 40 Amp COOLING FAN - Cooling Fan Motor
7. 7 - 10 Amp AIR CON - A/C Magnetic Clutch (If Equipped), EEC Module
8. 8 - 10 Amp - Air Bag Diagnostic Module (1994)
9. 9 - Empty
10. 10 - Empty
