INTRODUCTION
Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article to use when you are familiar with an adjustment procedure and only need a specification.
CAPACITIES
| Application & Group | Amp Hr. Rating |
| Escort & Tracer | 460 |
| Mustang | 540 |
| Probe 2.2L | 505 |
| Taurus 2.5L | 540 |
| Tempo & Topaz | 540 |
4-CYLINDER FLUID CAPACITIES
| Application | Quantity |
| Crankcase (Includes Filter) |
| 1.8L & 1.9L | 4.0 qts. (3.8L) |
| 2.2L & 2.3L | 5.0 qts. (4.7L) |
| 2.5L | 4.5 qts. (4.2L) |
| Cooling System (Includes Heater) |
| 1.8L & 1.9L |
| With A/C |
| Auto. Trans. | 7.3 qts. (6.9L) |
| Man. Trans. | 6.8 qts. (6.4L) |
| Without A/C | 7.9 qts. (7.5L) |
| 2.2L | 7.9 qts. (7.5L) |
| 2.3L HSC (Incl. MA) | 7.3 qts. (6.9L) |
| 2.3L OHC & 2.5L CFI | 8.3 qts. (7.9L) |
| Manual Transaxle (Type F, Dexron-II or Mercon ATF) |
| MTX II & III 4- & 5-Speed | 6.1 pts. (2.9L) |
| Probe Transaxle (Mercon ATF) |
| Non-Turbo | 7.1 pts. (3.4L) |
| Turbo | 7.7 pts. (3.7L) |
| Manual Transmission (Type F, Dexron-II or Mercon ATF) |
| M5R2 (Dexron-II) | 6.3 pts. (3.0L) |
| T5OD 5-Speed Overdrive | 5.6 pts. (2.6L) |
| Automatic Transaxle (Mercon ATF) |
| ATX | 8.3 qts. (7.9L) |
| AXOD | 12.8 qts. (12.1L) |
| G4A-EL | 8.3 qts. (7.9L) |
| Automatic Transmission (Dexron-II) |
| AOD | 12.3 qts. (11.6L) |
| A4LD | 9.5 qts. (9.0L) |
| C3 | 8.0 qts. (7.6L) |
| Differential (SAE 80W-90/API GL-5) |
| Mustang | 3.5 pts. (1.7L) |
| Tempo & Topaz AWD | 1.3 pts. (.6L) |
SERVICE INTERVALS & SPECIFICATIONS
| Component | Interval (Miles) (1) |
| Air Filter | 30,000 |
| Cam Timing Belt | 60,000 |
| Coolant | 30,000 |
| Oil & Filter | (2) 7500 |
| PCV Filter | (3) 30,000 |
| Spark Plugs | 30,000 |
| (1) Mileage intervals are for vehicles driven under normal driving conditions. (2) Replace at 5000 mile intervals on turbo model. (3) Inspect and replace if necessary. |
| (1) | Mileage intervals are for vehicles driven under normal driving conditions. |
| (2) | Replace at 5000 mile intervals on turbo model. |
| (3) | Inspect and replace if necessary. |
DRIVE BELT ADJUSTMENT SPECIFICATIONS
| Application | New Belt | Used Belt |
| 1.8L & 2.2L (All) | 86-103 (38-45) | 69-86 (31-38) |
| 1.9L |
| Alternator | 140-180 (62-80) | 120-140 (53-62) |
| P/S Pump | 120-160 (53-71) | 100-120 (45-53) |
| 2.3L & 2.5L |
| Alternator | 150-170 (67-75) | 140-160 (62-71) |
| Water Pump | 50-90 (24-40) | 40-60 (20-27) |
| (1) Tension In Lbs. (kg) Using Standard Belt Tension Gauge. |
| (1) | Tension In Lbs. (kg) Using Standard Belt Tension Gauge. |
ENGINE COMPRESSION
Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed (on dual plugs, remove exhaust side only) and throttle wide open. Ensure crankcase is full and oil is correct viscosity. With compression gauge installed, use remote starter to crank engine.
Crank engine at least 5 revolutions and record highest reading. Repeat procedure for all cylinders using approximately the same number of revolutions. The lowest compression reading should not be less than 75 percent of the highest compression reading. No cylinder compression reading should be less than 100 psi (7 kg/cm 2 ).
| Application | Compression Ratio |
| 1.8L | 9.0:1 |
| 1.9L | 9.0:1 |
| 2.2L Non-Turbo | 8.6:1 |
| 2.2L Turbo | 7.8:1 |
| 2.3L HSC & HSC MA (1) | 9.0:1 |
| 2.3L OHC | 9.5:1 |
| 2.5L | 9.0:1 |
| (1) Engine is High Output with Mass Air Flow meter. |
| (1) | Engine is High Output with Mass Air Flow meter. |
COMPRESSION RATIO SPECIFICATIONS
VALVE CLEARANCE
Note. On 1.8L models, hydraulic valve lash adjusters are used and no maintenance is required. On 2.2L models, valve clearance is zero and no adjustment is possible. On all other models, hydraulic valve lifters are used and no valve adjustment is required. If incorrect valve clearance is suspected, lifter must be collapsed before clearance can be checked.
| Application | In. (mm) |
| 1.9L | 0-.177 (0-4.5) |
| 2.3L & 2.5L HSC | .072-.174 (1.83-4.42) |
| 2.3L OHC | .035-.055 (.89-1.40) |
COLLAPSED VALVE LIFTER CLEARANCE
IGNITION COIL RESISTANCE
| Application | Primary (Ohms) | Secondary (Ohms) |
| Probe |
| Non-Turbo | 1.04-1.27 | 7100-9700 |
| Turbo | .72-.88 | 10,300-13,900 |
| Except Probe | .8-1.6 | 800-11,500 |
HIGH TENSION WIRE RESISTANCE
| Application (1) | Ohms |
| Probe | 5000 Per Foot |
| Except Probe | 7000 Per Foot |
| (1) DIS systems are 30,000 ohms total per wire. |
| (1) | DIS systems are 30,000 ohms total per wire. |
HIGH TENSION WIRE RESISTANCE
SPARK PLUG SPECIFICATIONS
| Application | Motorcraft No. |
| 1.8L | AGSP-32C |
| 1.9L | AGSF-34C6 |
| 2.2L | AGSP-33C |
| 2.3L |
| HSC & HSC | AWSF-42C |
| OHC | AWSF-32C |
| 2.5L | AWSF-32C |
| Application | Plug Gap In. (mm) | Torque Ft. Lbs (N.m) |
| 1.8L | .039-.043 | 11-17 (15-23) |
| 1.9L | .052-.056 | 7-15 (10-20) |
| 2.2L | .039-.043 | 11-17 (15-23) |
| 2.3L |
| HSC & HSC | .052-.056 | 5-10 (7-14) |
| OHC | .030-.034 | 5-10 (7-14) |
| 2.5L | .042-.046 | 7-15 (10-20) |
SPARK PLUG SPECIFICATIONS
Firing Order & Timing Marks (1.8L). Scheme 1
Scheme 1: Firing Order & Timing Marks (1.8L)
Firing Order & Timing Marks (1.9L). Scheme 2
Scheme 2: Firing Order & Timing Marks (1.9L)
Scheme 3
Scheme 3: Spark Plug Wire Routing (1.9L)
Firing Order & Timing Marks (2.2L). Scheme 4
Scheme 4: Firing Order & Timing Marks (2.2L)
Firing Order & Timing Marks (2.3L HSC & HSO). Scheme 5
Scheme 5: Firing Order & Timing Marks (2.3L HSC & HSO)
Firing Order & Timing Marks (2.3L OHC). Scheme 6
Scheme 6: Firing Order & Timing Marks (2.3L OHC)
Firing Order & Timing Marks (2.5L). Scheme 7
Scheme 7: Firing Order & Timing Marks (2.5L)
IGNITION TIMING
| Application | Degrees BTDC @ RPM |
| 1.8L |
| USA | (1) 10 @ 700-800 |
| Canada | (1) 10 @ 750-850 |
| 1.9L | (1) 10 @ 760-840 |
| 2.2L |
| Non-Turbo | (1) 6 @ 750 |
| Turbo | (1) 9 @ 750 |
| 2.3L OHC |
| Auto. Trans. | (2) 10 @ 790-850 |
| Man. Trans. | (2) 10 @ 830-890 |
| 2.3L HSC |
| Auto Trans. | (2) 10 @ 680-760 |
| Man. Trans. | (2) 10 @ 810-890 |
| 2.5L HSC | (2) 10 @ 675-725 |
| (1) With STI terminal grounded. (2) With SPOUT in-line connector disconnected. |
| (1) | With STI terminal grounded. |
| (2) | With SPOUT in-line connector disconnected. |
DISTRIBUTOR SPECIFICATIONS
Note. All models except Probe 2.2L use computed timing advance and no adjustment is possible.
| Application | Degrees Advance |
| Centrifugal | 12.5 @ 2400 RPM |
| Centrifugal | 15.5 @ 3400 RPM |
| Centrifugal | 22 @ 4500 RPM |
| Vacuum Control Unit | 20 @ 10.8 in. Hg |
IGNITION TIMING ADVANCE SPECIFICATIONS
FUEL PUMP
Note. Fuel pump performance is a measurement of fuel pressure and volume availability, not regulated fuel pressure.
| Application | Specification |
| Pressure | (1) |
| Volume | 1.5 pts. (.72L) In 30 Seconds |
| (1) For fuel pressure specifications, see FUEL PRESSURE SPECIFICATIONS article. |
IDLE SPEED & MIXTURE
Note. No idle mixture adjustments are possible. If engine performance is unsatisfactory, see appropriate H - TESTS W/CODES article in this section.
| Model | RPM |
| Except 2.2L | (1) |
| 2.2L | 700-750 |
| (1) Refer to underhood decal for specification. |
| (1) | Refer to underhood decal for specification. |
IDLE SPEED SPECIFICATIONS
FAST IDLE SPEED
Note. Refer to underhood engine decal for engine fast idle RPM specification.
THROTTLE POSITION SENSOR/SWITCH
| Application | Idle | Wide Open Throttle |
| 1.8L A/T & 2.2L | .99 | 4.02 |
| 1.9L | 0.34 | 4.84 |
| 2.3L HSC | 0.20 | 4.84 |
| 2.3L OHC | 0.34 | 4.84 |
| 2.5L | 0.39 | 4.84 |
| (1) Minimum and maximum specifications are given. |
| (1) | Minimum and maximum specifications are given. |
TPS VOLTAGE SPECIFICATIONS (1)
