Material Specifications
| Item | Specification | Fill Capacity |
|---|
| Motorcraft® A/C Cooling Coil Coating YN-29 | | |
| Motorcraft® A/C System Flushing Solvent YN-23 | | |
| Motorcraft® PAG Refrigerant Compressor Oil YN-12-D | WSH-M1C231-B | 130 ml (4.5 fl oz) |
| Motorcraft® R-134a Refrigerant YN-19 (US); CYN-16-R (Canada) | WSH-M17B19-A | 0.80 kg (27 oz) for 2.0L Trailer Tow Only, 0.71 kg (24 oz) for all other vehicles |
| Stay-Brite® R-134a Leak Detection Dye 164-R6060 (Rotunda) | | |
General Specifications
| Item | Specification |
|---|
| A/C Compressor Type | VS-16 |
| A/C Compressor Magnetic Clutch |
| Air gap clearance | 0.35-0.65 mm (0.014-0.026 in) |
Scheme 151
Scheme 151: Component Location
| Item | Description |
|---|
| 1 | Sunload sensor |
| 2 | Register discharge air temperature sensors |
| 3 | In-vehicle temperature and humidity sensor |
| 4 | HVAC module |
Scheme 152
| Item | Description |
|---|
| 1 | Air inlet duct |
| 2 | Blower motor |
| 3 | Evaporator core |
| 4 | Heater core |
| Item | Description |
|---|
| 1 | Actuating assembly |
| 2 | Floor door airflow mode door actuator |
| 3 | Blower motor speed control |
| 4 | LH temperature blend door actuator |
| 5 | Evaporator temperature sensor |
| 6 | Floor discharge air temperature sensor |
| 7 | Air inlet door mode door actuator |
| 8 | RH temperature blend door actuator |
| 9 | Defrost/panel door airflow mode door actuator |
Scheme 153
Scheme 153: 1.6L GTDI, 2.5L
| Item | Description |
|---|
| 1 | A/C compressor |
| 2 | Evaporator-to-compressor suction line |
| 3 | Integrated receiver/drier (part of condenser core) |
| 4 | Condenser core |
| 5 | Compressor-to-condenser discharge line |
| 6 | TXV manifold and tube assembly |
| 7 | TXV |
| 8 | A/C pressure transducer |
| 9 | Evaporator core |
Scheme 154
| Item | Description |
|---|
| 1 | A/C compressor |
| 2 | Evaporator-to-compressor suction line |
| 3 | Receiver/drier |
| 4 | Condenser core |
| 5 | Compressor-to-condenser discharge line |
| 6 | TXV manifold and tube assembly |
| 7 | TXV |
| 8 | A/C pressure transducer |
| 9 | Evaporator core |
