Climate Control System (Datc): Removal & Installation Ford Escape III

Adding Refrigerant Oil After A/C Compressor Replacement

1. Remove the A/C compressor drain/fill bolt and collect oil in a clean measuring device. If the amount of oil drained from the old A/C compressor is between 59-118 ml (2-4 fl oz), pour the same amount of clean PAG Refrigerant Compressor Oil (R-134a Systems) (YN-12-D) WSH M1C231-B or equivalent into the new A/C compressor. If the amount of oil that was removed from the old A/C compressor is greater than 118 ml (4 fl oz), pour the same amount drained of clean PAG Refrigerant Compressor Oil (R-134a Systems) or equivalent into the new A/C compressor. If the amount of oil that was removed from the old A/C compressor is less than 85 ml (3 fl oz), pour 85 ml (3 fl oz) of clean A/C Refrigerant Compressor Oil (R-134a Systems) or equivalent into the new A/C compressor.

Removal

Note. If installing a new Air Conditioning (A/C) compressor due to an internal failure of the old unit, carry out the following procedures to remove contamination from the A/C system. Failure to remove contamination from the A/C system, if present, will result in poor A/C performance and/or damage to the new A/C compressor and other components. If A/C flushing equipment is available, carry out flushing of the A/C system prior to installing a new A/C compressor. For additional information, refer to AIR CONDITIONING (A/C) SYSTEM FLUSHING . If A/C flushing equipment is not available, replace all contaminated components after a new A/C compressor has been installed. Install a new Thermostatic Expansion Valve (TXV) as directed by the A/C flushing. Install a new receiver/drier as directed by the A/C flushing.

Note. Installation of a new receiver/drier is not required when repairing the A/C system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

Note. A new A/C compressor may come equipped with an A/C clutch disc and hub, A/C compressor pulley and A/C clutch field coil already installed. If these components are not pre-installed, it will be necessary to transfer these parts from the old A/C compressor to the new compressor prior to installation of the A/C compressor if suitable for reuse.

Note. Removal steps in this procedure may contain installation details.

Scheme 212

Scheme 213

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. Position aside the accessory drive belt.
4. To install, tighten to 25 Nm (18 lb-ft).
5. To install, tighten to 9 Nm (80 lb-in).
6. To install, tighten to 15 Nm (133 lb-in). To install, tighten to 25 Nm (18 lb-ft).

Installation

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. If installing a new Air Conditioning (A/C) compressor due to an internal failure of the old unit, carry out the following procedures to remove contamination from the A/C system. Failure to remove contamination from the A/C system, if present, will result in poor A/C performance and/or damage to the new A/C compressor and other components. If A/C flushing equipment is available, carry out flushing of the A/C system prior to installing a new A/C compressor. For additional information, refer to AIR CONDITIONING (A/C) SYSTEM FLUSHING . If A/C flushing equipment is not available, replace all contaminated components after a new A/C compressor has been installed. Install a new Thermostatic Expansion Valve (TXV) as directed by the A/C flushing. Install a new receiver/drier as directed by the A/C flushing.

Note. Installation of a new receiver/drier is not required when repairing the A/C system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

Note. A new A/C compressor may come equipped with an A/C clutch disc and hub, A/C compressor pulley and A/C clutch field coil already installed. If these components are not pre-installed, it will be necessary to transfer these parts from the old A/C compressor to the new compressor prior to installation of the A/C compressor if suitable for reuse.

Note. Removal steps in this procedure may contain installation details.

Scheme 214

Scheme 215

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. Remove the A/C compressor belt. Refer to «ACCESSORY DRIVE»(ref-569614) .
4. To install, tighten to 15 Nm (133 lb-in).
5. To install, tighten to 15 Nm (133 lb-in). To install, tighten to 25 Nm (18 lb-ft).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. If installing a new Air Conditioning (A/C) compressor due to an internal failure of the old unit, carry out the following procedures to remove contamination from the A/C system. Failure to remove contamination from the A/C system, if present, will result in poor A/C performance and/or damage to the new A/C compressor and other components. If A/C flushing equipment is available, carry out flushing of the A/C system prior to installing a new A/C compressor. For additional information, refer to AIR CONDITIONING (A/C) SYSTEM FLUSHING . If A/C flushing equipment is not available, replace all contaminated components after a new A/C compressor has been installed. Install a new Thermostatic Expansion Valve (TXV) as directed by the A/C flushing. Install a new receiver/drier as directed by the A/C flushing.

Note. Installation of a new receiver/drier is not required when repairing the A/C system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

Note. A new A/C compressor may come equipped with an A/C clutch disc and hub, A/C compressor pulley and A/C clutch field coil already installed. If these components are not pre-installed, it will be necessary to transfer these parts from the old A/C compressor to the new compressor prior to installation of the A/C compressor if suitable for reuse.

Note. Removal steps in this procedure may contain installation details.

Scheme 216

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. Remove the A/C compressor belt. Refer to «ACCESSORY DRIVE»(ref-569614) .
4. To install, tighten to 15 Nm (133 lb-in). To install, tighten to 25 Nm (18 lb-ft).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 217

1. Tighten to 8 Nm (71 lb-in).

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 218

Scheme 219

Scheme 220

1. Remove the BCM. Refer to «MULTIFUNCTION ELECTRONIC MODULES»(ref-569586) .
2. To install, tighten to 15 Nm (133 lb-in).
3. To install, tighten to 8 Nm (71 lb-in).
4. To install, tighten to 8 Nm (71 lb-in).
5. Disconnect the air inlet door actuator electrical connector, and remove the front air inlet duct retainer.
6. Install the ratchet, extension and socket as shown in illustration. Remove the upper air inlet duct retainer.
7. Install the ratchet, extension and socket as shown in illustration. Remove the lower air inlet duct retainer and the air inlet duct.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 221

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 222

1. Remove the accelerator pedal. Refer to «ACCELERATION CONTROL»(ref-569598) .
2. Remove the BCM. Refer to «MULTIFUNCTION ELECTRONIC MODULES»(ref-569586) .
3. To install, tighten to 15 Nm (133 lb-in).
4. To install, tighten to 8 Nm (71 lb-in).
5. To install, tighten to 8 Nm (71 lb-in).
6. Disconnect the air inlet door actuator electrical connector, and remove the front air inlet duct retainer.
7. Install the ratchet, extension and socket as shown in illustration. Remove the upper air inlet duct retainer.
8. Install the ratchet, extension and socket as shown in illustration. Remove the lower air inlet duct retainer and the air inlet duct.
9. Release the retaining clip holding the blower motor while an assistant from the passenger side compartment reaches through the blower motor cage and turns the blower motor housing 45 degrees clockwise to release and remove the blower motor.

1. To install, reverse the removal procedure. Make a reference mark on the blower motor before installing.

Note. Removal steps in this procedure may contain installation details.

1. Remove the accelerator pedal. Refer to «ACCELERATION CONTROL»(ref-569598) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 223

1. Remove the BCM. Refer to «MULTIFUNCTION ELECTRONIC MODULES»(ref-569586) .
2. If equipped, remove the cabin air filter access door screw.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 224

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. To install, tighten to 15 Nm (133 lb-in).
4. To install, tighten to 15 Nm (133 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 225

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. To install, tighten to 15 Nm (133 lb-in).
4. To install, tighten to 15 Nm (133 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 226

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. To install, tighten to 15 Nm (133 lb-in).
4. To install, tighten to 15 Nm (133 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

1. Remove the Radiator. Refer to «ENGINE COOLING»(ref-569571) .

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 227

1. Remove the A/C compressor. Refer to «AIR CONDITIONING (A/C) COMPRESSOR - 2.0L GTDI»(ref-569574-S22078435852013072700000) or «AIR CONDITIONING (A/C) COMPRESSOR - 2.5L»(ref-569574-S14193986072013072700000) .
2. To install, tighten to 13 Nm (115 lb-in).
3. NOTE: Note the position of the component before removal.

1. NOTE: Make sure that the component is installed to the position noted before removal. To install, reverse the removal procedure.
2. Check the A/C clutch air gap. Refer to «AIR CONDITIONING (A/C) CLUTCH AIR GAP ADJUSTMENT»(ref-569574-S01292583642013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 228

Scheme 229

1. Remove the instrument panel. Refer to «INSTRUMENT PANEL AND CONSOLE»(ref-569596) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 230

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. To install, tighten to 15 Nm (133 lb-in).
4. To install, tighten to 15 Nm (133 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. To install, tighten to 15 Nm (133 lb-in).
4. To install, tighten to 15 Nm (133 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 231

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. To install, tighten to 15 Nm (133 lb-in).
4. To install, tighten to 15 Nm (133 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

1. Remove the Audio Control Module. Refer to «INFORMATION AND ENTERTAINMENT SYSTEMS - MONOCHROMATIC DISPLAY, 6 SPEAKERS»(ref-569630) , «INFORMATION AND ENTERTAINMENT SYSTEMS - 4.2-INCH (107MM) SCREEN, 6 SPEAKERS»(ref-569631) , «INFORMATION AND ENTERTAINMENT SYSTEMS - 8 INCH (203MM) TOUCHSCREEN, 9 SPEAKERS»(ref-569632) or «INFORMATION AND ENTERTAINMENT SYSTEMS - SONY 8 INCH (203MM) TOUCHSCREEN, 10 SPEAKERS»(ref-569633) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 232

Scheme 233

Scheme 234

1. Remove the instrument panel. Refer to «INSTRUMENT PANEL AND CONSOLE»(ref-569596) .
2. Tighten to 10 Nm (89 lb-in).

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

1. Remove the driver lower air bag. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) .
2. Torque: 3 Nm.
3. Remove the instrument panel. Refer to «INSTRUMENT PANEL AND CONSOLE»(ref-569596) .
4. If equipped.

Scheme 240

1. To install, reverse the removal procedure.
2. NOTE: If the heater core and evaporator core housing is being replaced, remove the air plenum bezel from the new heater core and evaporator core housing prior to installation.

Note. Removal steps in this procedure may contain installation details.

Scheme 241

Scheme 242

Scheme 243

Scheme 244

1. Tighten to 3.5 Nm (31 lb-in).
2. Tighten to 2.0 Nm (16 lb-in).

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 245

Scheme 246

Scheme 247

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 248

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. Remove the knee air bag module. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 249

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 250

1. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
2. Remove the front bumper cover. Refer to «BUMPERS»(ref-569628) .
3. To install, tighten to 8 Nm (71 lb-in). To install, tighten to 11 Nm (97 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 251

Scheme 252

Scheme 253

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
3. Remove the front bumper cover. Refer to «BUMPERS»(ref-569628) .
4. Both sides To install, tighten to 25 Nm (18 lb-ft).
5. Both sides To install, tighten to 25 Nm (18 lb-ft).
6. To install, tighten to 25 Nm (18 lb-ft).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

Upper

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 254

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 255

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 256

1. Remove the knee air bag module. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. Remove the Audio Control Module. Refer to «INFORMATION AND ENTERTAINMENT SYSTEMS - MONOCHROMATIC DISPLAY, 6 SPEAKERS»(ref-569630) , «INFORMATION AND ENTERTAINMENT SYSTEMS - 4.2-INCH (107MM) SCREEN, 6 SPEAKERS»(ref-569631) , «INFORMATION AND ENTERTAINMENT SYSTEMS - 8 INCH (203MM) TOUCHSCREEN, 9 SPEAKERS»(ref-569632) or «INFORMATION AND ENTERTAINMENT SYSTEMS - SONY 8 INCH (203MM) TOUCHSCREEN, 10 SPEAKERS»(ref-569633) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 257

Scheme 258

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 259

1. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
2. To install, tighten to 11 Nm (97 lb-in).
3. To install, tighten to 3 Nm (27 lb-in).
4. To install, tighten to 8 Nm (71 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 260

Scheme 261

1. Recover the refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
2. To install, tighten to 11 Nm (97 lb-in).
3. To install, tighten to 3 Nm (27 lb-in).
4. To install, tighten to 11 Nm (97 lb-in). To install, tighten to 15 Nm (133 lb-in).

1. To install, reverse the removal procedure. Install new O-ring seals and gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. Refer to «REFRIGERANT OIL ADDING»(ref-569574-S06412344612013072700000) .
2. Evacuate, leak test and charge the refrigerant system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-569574-S16336179572013072700000) .
