Electronic Engine Control - (Hybrid): Component Locations Ford Escape II

Special Tool(s)

SPECIAL TOOLS DESCRIPTION CHART Aligner, Crankshaft Sensor 303-1417 Timing Peg, Crankshaft TDC 303-507

Scheme 4

Scheme 5

Scheme 6

PART DESCRIPTION CHART

Scheme 7

Scheme 8

Scheme 9

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-344051) .
2. Remove the 5 bolts, the pin-type retainer (not shown) and the RH splash shield.
3. Turn the crankshaft clockwise until the hole in the crankshaft pulley is in the 3 o'clock position.
4. Remove the engine plug bolt.
5. Install the Crankshaft TDC Timing Peg and turn the crankshaft clockwise until the crankshaft contacts the Crankshaft TDC Timing Peg.
6. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
7. Remove the bolts and the CKP sensor.

Scheme 10

Scheme 11

Scheme 12

1. Install a 6 mm x 18 mm bolt in the crankshaft pulley and thread it into the front cover.
2. Install the CKP sensor and the 2 bolts. Do not tighten the bolts at this time.
3. Adjust the CKP sensor with the Crankshaft Sensor Aligner. Tighten the 2 CKP bolts to 7 Nm (62 lb-in).
4. Connect the CKP sensor electrical connector.
5. Remove the 6 mm x 18 mm bolt from the crankshaft pulley.
6. Install the engine plug bolt. Tighten to 20 Nm (177 lb-in).
7. Install the RH splash shield, 5 bolts and the pin-type retainer (not shown).

Scheme 13

PART DESCRIPTION CHART

SPECIAL TOOLS DESCRIPTION CHART Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

SPECIAL TOOLS DESCRIPTION CHART Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)
