Rear View Mirror: Component Locations Ford Escape II

Special Tool(s)

SPECIAL TOOL DESCRIPTION CHART 73III Automotive Meter 105-R0057 or equivalent

Scheme 32

SPECIAL TOOL DESCRIPTION CHART Installer, Rear Mirror 501-025 (T94P-17700-AH) Mirror Remover 501-D118

Scheme 33

Note. Auto-dimming mirror shown, base mirror similar.

Scheme 34

ITEM DESCRIPTION CHART

Scheme 35

1. NOTE: Twisting the interior rear view mirror base from right to left may cause a stress fracture of the windshield. If equipped, remove the wire cover.
2. If equipped, disconnect the auto-dimming mirror electrical connector.
3. Insert the Mirror Remover between the mirror mount and windshield bracket from the bottom.
4. Release the mirror mount from the windshield bracket by pulling the Mirror Remover away from the windshield.

Scheme 36

Scheme 37

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the up position.
2. Using the Rear View Mirror Installer, press the mirror assembly downward along the windshield until the mount is fully seated onto the windshield bracket.
3. If equipped, connect the auto-dimming mirror electrical connector.
4. If equipped, install the wire cover.
5. If equipped, check the compass zone and calibration. For additional information, refer to «ELECTRONIC COMPASS»(ref-344146) .
