Steering Linkage: Component Locations Ford Escape II

Manual & Power Steering 2 illustrations ~116 words

Special Tool(s)

SPECIAL TOOL DESCRIPTION CHART Separator, Ball Joint 204-592

Scheme 13

Scheme 13: Special Tool(s)

Scheme 14

Scheme 14: Removal and Installation
  1. Remove the wheel and tire. For additional information, refer to «WHEELS & TIRES»(ref-344055) .
  2. Loosen the tie-rod end jam nut. To install, tighten to 40 Nm (30 lb-ft).
  3. Remove and discard the outer tie-rod end nut. To install, tighten the new nut to 80 Nm (59 lb-ft).
  4. Using the Ball Joint Separator, separate the outer tie-rod end from the front wheel knuckle.
  5. Remove the outer tie-rod end.
  6. To install, reverse the removal procedure. Check and, if necessary, adjust the front toe. For additional information, refer to «SUSPENSION SYSTEM-GENERAL INFORMATION»(ref-344068) .

SPECIAL TOOL DESCRIPTION CHART Separator, Ball Joint 204-592
