Coolant Flow Diagram
Note. Black arrows indicate hot, white arrows indicate cold.
Scheme 37
| Item | Part Number | Description |
|---|---|---|
| 1 | 8A080 | Degas bottle |
| 2 | 8C633 | Degas bottle-to-radiator |
| 3 | 8B273 | Lower radiator hose |
| 4 | 18C553 | Thermostat housing-to-auxiliary coolant pump hose |
| 5 | 18D473 | Auxiliary coolant pump |
| 6 | 8005 | Radiator |
| 7 | 8W005 | Degas bottle overflow hose |
| 8 | 8B274 | Upper radiator hose |
| 9 | 8W005 | Degas bottle-to-coolant adapter assembly hose |
| 10 | 18K580 | Heater outlet hose |
| 11 | 9D475 | EGR valve assembly |
| 12 | 18K579 | Heater inlet hose |
| 13 | 8K556 | Coolant adapter assembly |
| 14 | 6049 | Cylinder head |
| 15 | 6051 | Head gasket |
| 16 | 8501 | Coolant pump |
| 17 | 6010 | Engine block |
| 18 | 8575 | Thermostat housing |
| 19 | 8A582 | Coolant bypass hose |
| 20 | 18A458 | Heater assembly |
ITEM DESCRIPTION
Material
| Item | Specification |
|---|---|
| Motorcraft Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) | WSS-M97B51-A1 |
ITEM SPECIFICATIONS
Thermostat
A new thermostat should be installed only after the following tests and checks have been carried out
- Pinpoint Test A, B or C
- Thermostat Visual Inspection
| Item | Specification |
|---|---|
| Motorcraft Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) | WSS-M97B51-A1 |
ITEM SPECIFICATIONS
| Item | Specification |
|---|---|
| Motorcraft Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) | WSS-M97B51-A1 |
| Premium Cooling System Flush VC-1 | ESR-M14P7-A |
ITEM SPECIFICATIONS
Note. Dispose of old coolant and flushing water contaminated with antifreeze and cleaning chemicals in accordance with local, state or federal laws.
- Remove the radiator. For additional information, refer to «RADIATOR»(ref-344114-S15621813072009101600000) .
- Backflush the radiator with the radiator in an upside-down position and a high-pressure hose in the lower hose location.
- Remove the thermostat housing. For additional information, refer to «THERMOSTAT HOUSING»(ref-344114-S04807739542009101600000) .
- Position a high-pressure water hose into the engine through the engine return and backflush the engine.
Scheme 38
| Item | Part Number | Description |
|---|---|---|
| 1 | W527362 | Heater hose clamp |
| 2 | 18C553 | Heater hose |
| 3 | W527372 | Radiator hose clamp |
| 4 | 8B273 | Radiator hose |
| 5 | W500015 | Thermostat housing bolt (3 required) |
| 6 | 8575 | Thermostat housing |
| 7 | 8K530 | Gasket |
ITEM DESCRIPTION
| Item | Specification |
|---|---|
| Motorcraft Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) | WSS-M97B51-A1 |
ITEM SPECIFICATIONS
Scheme 39
| Item | Part Number | Description |
|---|---|---|
| 1 | W500221 | Coolant pump pulley bolt (3 required) |
| 2 | 8509 | Coolant pump pulley |
| 3 | W500015 | Coolant pump bolt (3 required) |
| 4 | 8501 | Coolant pump |
| 5 | 8507 | Coolant pump O-ring seal |
ITEM SPECIFICATIONS
