HVAC Climate Control System: Component Locations Ford Escape II

Automatic HVAC System 4 illustrations ~169 words

Special Tool(s)

SPECIAL TOOL CHART Installer, A/C Clutch 412-136 Protector, A/C Compressor Shaft 412-137

Scheme 220

Scheme 220: Special Tool(s)
ItemPart NumberDescription
1A/C clutch disc and hub bolt (part of 19D784)
2A/C clutch disc and hub (part of 19D784)
3A/C clutch hub disc and hub spacer (part of 19D784)
4A/C compressor pulley snap ring (part of 19D784)
5A/C compressor pulley (part of 19D784)
6A/C clutch field coil screw (4 required) (part of 19D784)
7A/C clutch field coil (part of 19D784)

ITEM DESCRIPTION

Scheme 221

Scheme 221: Removal

Scheme 222

Scheme 222
  1. Remove the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR - 2.5L»(ref-344137-S00557641092009101600000) or «AIR CONDITIONING (A/C) COMPRESSOR - 3.0L (4V)»(ref-344137-S42905223332009101600000) .
  2. Remove the A/C clutch disc and hub bolt. Using a suitable spanner-type wrench, hold the A/C clutch disc and hub. Remove the A/C clutch disc and hub bolt.
  3. Remove the A/C clutch disc and hub and the A/C clutch disc and hub spacer(s).
  4. Remove the A/C compressor pulley snap ring.
  5. Remove the A/C compressor pulley. Install the A/C Compressor Shaft Protector. Install a suitable 3-jaw puller on the A/C compressor shaft protector and A/C compressor pulley. Remove the A/C compressor pulley.
  6. Remove the 4 A/C clutch field coil screws.
  7. Remove the A/C clutch field coil.

SPECIAL TOOL CHART Compressor Clutch Holding Tool 412-098 (T94P-19703-AH) Installer, A/C Compressor Pulley 412-109 (T97P-19D786-A) Remover, Compressor Pulley 412-001 (T71P-19703-B)

Scheme 223

Scheme 223: Special Tool(s)
