Automatic Transmission External Controls - 6F35: Other Ford Escape II

Brake Shift Interlock Actuator (BSIA)

The BSIA system prevents the selector lever from being moved out of the PARK position. The ignition switch must be in the ON position and the brake pedal depressed to move the selector lever out of the PARK position. The brake pedal position is detected by the Brake Pedal Position (BPP) switch.

The manual override button will mechanically bypass the electronic portion of the shift interlock system and allow the selector lever to be moved out of the PARK position. The manual override button is part of the selector lever assembly.

To override the BSIA, remove the tethered cap on the selector lever bezel with a small screwdriver. With the brake pedal depressed, insert a small screwdriver into the access hole, press down and pull the selector lever out of PARK.

Electrical Connectors

Selector Lever Harness C2096 (vehicle harness side)

Scheme 107

CONNECTOR PIN REFERENCE

Selector Lever Harness C2096 (component side)

Scheme 108

CONNECTOR PIN REFERENCE

Brake Shift Interlock Override

Note. If it is necessary to use the override procedure to move the selector lever out of the PARK position, it is possible that a fuse has blown and the brake lights are not operational. Before driving the vehicle, verify that the brake lights are working.

This vehicle is equipped with a brake shift interlock feature that prevents the selector lever from being moved out of PARK when the ignition is in the ON position unless the brake pedal is depressed.

If the selector lever cannot be moved out of the PARK position when the ignition is in the ON position and the brake pedal is depressed

Scheme 109

1. Apply the parking brake and remove the ignition key.
2. Remove the access panel.
3. Using an suitable tool, depress the Brake Shift Interlock Actuator (BSIA) override mechanism on the selector lever, apply the brake, depress the button on the selector lever and move the selector lever into NEUTRAL.
4. Start the vehicle.
5. To install, reverse the removal procedure.

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

1. Place the selector lever in the D position.
2. Disconnect the selector lever cable end from the manual control lever.
3. Place the manual control lever in the D position. Rotate the manual control lever counterclockwise to the PARK position. Rotate the manual control lever clockwise 3 detents to the D position.
4. Release the selector lever cable adjuster lock. Pull out on the adjuster lock tabs. Slide the lock over to unlock the selector lever cable.
5. Align the selector lever cable end to the manual control lever ball stud and install it with the adjuster unlocked.
6. Slide the adjuster tab in place to lock the selector lever cable.

Scheme 115

Scheme 116

PART NUMBER DESCRIPTION

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-344051) .
2. Place the selector level in the D position.
3. Gently pry up to remove the upper selector lever trim ring.
4. Lift the center console lid and remove the center console compartment tray.
5. Remove the top finish panel.
6. Remove the selector lever cable from the selector lever assembly. Disconnect the selector lever cable end from the selector lever. Remove the selector lever cable from the bracket.
7. Remove the 2 grommet nuts for the selector lever cable. To install, tighten to 10 Nm (89 lb-in).
8. Remove the selector lever cable retainer from the transmission fluid filler tube.
9. Disconnect the selector lever cable end from the manual control lever.
10. Release the 2 tabs and remove the selector lever cable from the selector lever cable bracket.
11. To install, reverse the removal procedure. Adjust the selector lever cable after installation. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-344100-S12087866492009101600000) .

Scheme 124

PART NUMBER DESCRIPTION
