Engine - 3.0L (4V): Component Locations Ford Escape I facelift

Special Tool(s)

SPECIAL TOOL DESCRIPTION Strap Wrench 303-D055 (D85L-6000-A) Replacer, Crankshaft Damper 303-102 (T74P-6316-B) Remover, Crankshaft Vibration Damper 303-009 (T58P-6316-D)

Scheme 335

Scheme 336

SPECIAL TOOL DESCRIPTION Remover, Oil Seal 303-409 (T92C-6700CH) Installer, Front Cover Seal 303-335 (T88T-6701-A)

Scheme 337

SPECIAL TOOL DESCRIPTION Slide Hammer 307-005 (T59L-100-B) Remover, Crankshaft Rear Seal 303-519 (T95P-6701-DH) Installer, Crankshaft Rear Main Oil Seal 303-178 (T82L-6701-A) Installer Bolts, Crankshaft Rear Main Oil Seal 303-384 (T91P-6701-A)

Scheme 338

Scheme 339

Scheme 340

SPECIAL TOOL DESCRIPTION Service Set, Water Pump Pulley 303-S455 (T94P-6312-AH) Remover, Crankshaft Vibration Damper 303-009 (T58P-6316-D) Remover, Oil Seal 303-409 (T92C-6700-CH) Installer, Camshaft Oil Seal 303-464 (T94P-6256-BH) Protector, Camshaft Oil Seal 303-463 (T94P-6256-AH) Installer, Power Steering Pump Pulley 211-185 (T91P-3A733-A)

Scheme 341

Scheme 342

Scheme 343

SPECIAL TOOL DESCRIPTION Compressor, Valve Spring 303-473 (T94P-6565-BH)

Scheme 344

SPECIAL TOOL DESCRIPTION Compressor, Valve Spring 303-473 (T94P-6565-BH) Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH)

Scheme 345

SPECIAL TOOL DESCRIPTION 3-Bar Engine Support Kit 303-F072 Lifting Brackets, Engine 303-050 (T70P-6000) Universal Adapter Brackets 014-0001

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

1. Remove the lower intake manifold. For additional information, refer to «LOWER INTAKE MANIFOLD»(ref-232195-S19814883242006051600000) .
2. Remove the engine support insulator bracket bolt. To install, tighten to 90 Nm (66 lb-ft).
3. Install the special tools. Position the 2 universal adapter brackets on top of the cylinder block. Install 2 M8 x 1.25 x 36 mm (1.41 in) bolts and tighten to 10 Nm (89 lb-in). Position the universal lifting bracket onto the 2 universal adapter brackets. Fasten the universal lifting bracket to the 2 universal adapter brackets with a suitable nut and bolt.
4. Using the special tools, lift the engine 12 mm (0.47 in).
5. Remove the nut and position the PSP tube bracket aside. To install, tighten to 25 Nm (18 lb-ft).
6. Remove the 3 nuts and the engine support insulator bracket. To install, tighten to 55 Nm (41 lb-ft).
7. Remove the 3 bolts and the engine support insulator. To install, tighten to 55 Nm (41 lb-ft).
8. To install, reverse the removal procedure.

SPECIAL TOOL DESCRIPTION Lifting Brackets, Engine 303-050 (T70P-6000) Powertrain Lift with Tilting Plate 014-00765 Universal Adapter Brackets 014-0001 Spreader Bar 303-D089 (D93P-6001-A3) or Equivalent

Scheme 352

SPECIAL TOOL DESCRIPTION Slide Hammer 307-005 (T59L-100-B) Strap Wrench 303-D055 (D85L-6000-A) Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Remover, Crankshaft Vibration Damper 303-009 (T58P-6316-D) Remover, Oil Seal 303-409 (T92C-6700CH) Service Set, Water Pump Pulley 303-S455 (T94P-6312-AH)

Note. For additional information, refer to the exploded view under the assembly procedure in this article.

Scheme 353

Scheme 354

Scheme 355

Scheme 356

Scheme 357

Scheme 358

Scheme 359

Scheme 360

Scheme 361

Scheme 362

Scheme 363

Scheme 364

Scheme 365

Scheme 366

Scheme 367

Scheme 368

Scheme 369

Scheme 370

Scheme 371

Scheme 372

Scheme 373

Scheme 374

Scheme 375

Scheme 376

Scheme 377

Scheme 378

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

Scheme 384

Scheme 385

Scheme 386

Scheme 387

Scheme 388

Scheme 389

Scheme 390

Scheme 391

Scheme 392

Scheme 393

Scheme 394

Scheme 395

Scheme 396

Scheme 397

Scheme 398

Scheme 399

Scheme 400

Scheme 401

1. Remove the bolts and the flexplate.
2. Using the special tools, remove and discard the crankshaft rear oil seal.
3. Mount the engine on a suitable stand.
4. Detach the engine control sensor wiring connectors from the upper intake manifold.
5. Detach the wiring retainer, remove the nut and the heated oxygen sensor (HO2S) electrical connector bracket.
6. Disconnect the exhaust gas recirculation (EGR) vacuum regulator electrical connector and remove the nut. Detach the wiring harness retainer.
7. Disconnect the knock sensor (KS) electrical connector.
8. Remove the nuts and the engine control wire harness.
9. Disconnect the idle air control (IAC) valve and the throttle position (TP) sensor electrical connectors, and detach the wiring retainer.
10. Remove the positive crankcase ventilation (PCV) tube.
11. Disconnect the vacuum tube fittings from the EGR valve, EGR vacuum regulator and the intake manifold.
12. Disconnect the throttle body coolant hose.
13. Remove the bolts and upper intake manifold. Discard the gaskets.
14. Disconnect the engine coolant temperature (ECT) sensor electrical connector.
15. Disconnect the RH coil-on-plug electrical connectors and detach the wiring retainer.
16. Disconnect the radio interference capacitor electrical connector and detach the wiring retainers.
17. Disconnect the LH coil-on-plug electrical connectors and detach the wiring retainers.
18. Disconnect the camshaft position sensor (CMP) and oil pressure sensor electrical connectors and detach the wiring retainers.
19. Disconnect the crankshaft position (CKP) sensor electrical connector and detach the wiring retainers.
20. Disconnect the fuel rail pressure and temperature sensor electrical connector and vacuum tube. Remove the engine vacuum harness.
21. Disconnect the fuel injector electrical connectors and remove the fuel charging wiring harness.
22. Remove the bolts and the lower intake manifold. Discard the gaskets.
23. Remove the bolts and the 6 coil-on-plugs.
24. Remove the nut and the radio interference capacitor.
25. Remove the bolts and the RH valve cover. Discard the gasket.
26. Remove the bolt and the engine lift bracket.
27. Remove the nuts and the coolant pump belt cover.
28. Remove the bolts and the LH valve cover. Discard the gasket.
29. Remove the nuts, the LH exhaust manifold and the gasket. Discard the gasket.
30. Remove the nuts, the RH exhaust manifold and the gasket. Discard the gasket.
31. Remove the bolts and the halfshaft support bracket.
32. If equipped, disconnect the coolant hoses and detach the hoses from the retainer. Remove the coolant hoses.
33. Remove and discard the oil filter.
34. If equipped, remove and discard the oil cooler.
35. Cut and remove the coolant pump belt.
36. Disconnect the hoses.
37. Remove the 3 bolts and the coolant pump.
38. Disconnect the hoses and remove the coolant tube.
39. Remove the nut, bolt and the coolant bypass tube.
40. Remove the stud bolt and the oil level indicator and tube. Remove and discard the O-ring seal.
41. Remove the bolts, studs and the oil pan. Discard the gasket.
42. Remove the bolts, nut and the oil pump screen and pickup tube.
43. Remove and discard the O-ring seal.
44. Remove the nuts and the oil pan baffle.
45. Remove the oil pressure sender and, if equipped, the block heater.
46. Remove the bolt and the KS.
47. Use the special tool to hold the crankshaft damper and remove the bolt.
48. Using the special tool, remove the crankshaft damper.
49. Remove and discard the crankshaft front seal from the front cover.
50. Remove the bolt and the idler pulley.
51. Remove the bolt and the belt tensioner.
52. Remove the bolts, studs and the front cover. Discard the gaskets.
53. Remove the ignition pulse wheel.
54. Install the damper bolt.
55. Remove the LH and RH spark plugs.
56. Rotate the crankshaft clockwise to position the crankshaft keyway in the 11 o'clock position and position the camshafts in the correct position. This will position the number one cylinder at top dead center (TDC). Verify that the camshafts are correctly located. If not, rotate the crankshaft one additional turn and recheck.
57. Rotate the crankshaft clockwise 120 degrees to the 3 o'clock position to position the RH camshafts in the neutral position.
58. Verify that the RH camshafts are in the neutral position.
59. Remove the RH timing chain tensioner arm. Remove the bolts. Remove the tensioner. Remove the tensioner arm.
60. Remove the bolts, RH timing chain guide and the timing chain.
61. Rotate the crankcase clockwise 600 degrees (1-2/3 turns) to position the crankcase key way in the 11 o'clock position. This will position the LH camshafts in the neutral position.
62. Verify the LH camshafts are in the neutral position.
63. Remove the LH timing chain and tensioner arm. Remove the bolts. Remove the tensioner. Remove the tensioner arm.
64. Remove the LH timing chain and timing chain guide.
65. Remove the damper bolt and the crankshaft sprockets.
66. Using the special tools, remove the coolant pump drive pulley and discard.
67. Using the special tools, remove the camshaft oil seal and discard.
68. Remove the intake camshaft oil seal retainer and discard the press-in-place gasket.
69. Loosen the LH and RH camshaft cap bolts in the indicated sequence and remove the camshaft caps. Tap the caps lightly with a soft-faced mallet to loosen the camshaft caps.
70. Remove the LH and RH camshafts.
71. Remove the LH and RH camshaft roller followers. Mark the location of the roller followers, using a permanent-type marker.
72. Loosen the bolts in the indicated sequence and remove the LH and RH cylinder heads. Discard the bolts and the gaskets.
73. Support the cylinder head on a bench with the head gasket side up.
74. Inspect all areas of the deck face with a straightedge and feeler gauge. The cylinder head must not have depressions deeper than 0.0254 mm (0.001 in) across a 38.1 mm (1.5 in) square area, or scratches more than 0.0254 mm (0.001 in).
75. Remove the bolts and the oil separator cover. Discard the gasket.
76. Remove the crankshaft key.

SPECIAL TOOL DESCRIPTION Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH)

Scheme 402

Scheme 403

SPECIAL TOOL DESCRIPTION Lifting Bracket, Engine 303-050 (T70P-6000) Powertrain Lift with Tilting Plate 014-00765 Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Universal Adapter Brackets 014-0001
