HVAC System - Air Conditioning: Component Locations Ford Escape I facelift

Special Tool(s)

SPECIAL TOOL (AIR CONDITIONING COMPRESSOR SHAFT SEAL) Holding Fixture, Compressor Clutch 412-133 Holding Fixture, Compressor Clutch 412-098 (T94P-19703-AH) Protector, A/C Compressor Shaft Oil Seal 412-094 (T94P-19623-F) Remover, A/C Compressor Shaft Oil Seal 412-059 (T89P-19623-BH) Installer, A/C Compressor Shaft Oil Seal 412-058 (T89P-19623-AH) Remover, A/C Compressor Snap Ring 412-063 (T89P-19623-DH) Remover, O-Ring Seal 100-010 (T71P-19703-C)

Scheme 6

Scheme 7

Scheme 8

Scheme 9

SPECIAL TOOL (CLUTCH AND CLUTCH FIELD COIL) 2-Jaw Puller 205-D026 (D80L-1002-L) or equivalent Coil Replacer 412-065 (T89P-19623-EH) Compressor Clutch Holding Tool 412-098 (T94P-19703-AH) Differential Bearing Cone Remover 205-116 (T77F-4220-B1) Field Coil Replacer 412-078 (T91L-19623-CH) Field Coil Remover 412-067 (T89P-19623-FH)

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Remove the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR - 2.3L»(ref-232213-S27470919822006051600000) or «AIR CONDITIONING (A/C) COMPRESSOR - 3.0L (4V)»(ref-232213-S08768045982006051600000) .
2. Using the special tool, remove the A/C clutch bolt.
3. Remove the A/C disc and hub assembly and the A/C clutch hub spacers. Thread an 8 x 1.25 mm bolt into the A/C clutch disc and hub to force it from the compressor shaft. Lift the clutch disc and hub assembly and the A/C clutch disc and hub spacers from the compressor shaft.
4. Remove the A/C clutch pulley snap ring.
5. Remove the A/C clutch pulley.
6. Remove the A/C clutch field coil. Note the location of the A/C clutch field coil electrical connector. Using the special tools, remove the A/C clutch field coil.

Scheme 21

Scheme 22

Scheme 23

1. Clean the A/C clutch field coil and pulley mounting surfaces.
2. Using the special tools, install the A/C clutch field coil.
3. Install the A/C clutch pulley.
4. Install the A/C clutch pulley snap ring with the bevel side out.
5. Place 1 nominal thickness A/C clutch hub spacer inside the clutch hub spline opening.
6. Install the A/C clutch disc and hub assembly.
7. Using the special tool, install the A/C clutch bolt. Tighten to 13 Nm (10 lb-ft).
8. Measure and adjust the clutch air gap by removing or adding A/C clutch hub spacers.
9. Install the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR - 2.3L»(ref-232213-S27470919822006051600000) or «AIR CONDITIONING (A/C) COMPRESSOR - 3.0L (4V)»(ref-232213-S08768045982006051600000) .

SPECIAL TOOL (CLUTCH AND CLUTCH FIELD COIL - HYBRID) Remover, Compressor Pulley 412-001 (T71P-19703-B) Compressor Clutch Holding Tool 412-098 (T94P-19703-AH) Installer, A/C Compressor Pulley 412-109 (T97P-19D786-A)

Scheme 24

SPECIAL TOOL (EVAPORATOR CORE ORIFICE) Remover, Broken Orifice 412-035 (T83L-19990-B) Remover/Installer, Fixed Orifice 412-034 (T38L-19990-A)

SPECIAL TOOL (EVAPORATOR CORE ORIFICE - HYBRID) Remover, Broken Orifice 412-035 (T83L-19990-B) Remover/Installer, Fixed Orifice 412-034 (T38L-19990-A)
