Engine Controls - Reference Values (Except Diesel & Hybrid): Other Ford Escape I facelift 2

Testing & Diagnostics 1 illustration ~480 words

3.0L 4V Fusion/Milan

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B25	4	4	3.9	3.7	VOLTS
APP2	B26	1.5	1.5	1.6	1.8	VOLTS
APP3	B27	1	1	1.1	1.2	VOLTS
FPM	B30	OFF	ON	ON	ON	ON/OFF
MAF	B41	0	0.68	1.27	1.83	VOLTS
IAT	B43	1.75/120 (K)	2.02/109 (K)	3.16/64 (K)	3.22/63 (K)	VOLTS/DEG F
FTP	B44	2.6/-0	2.6/-0	2.57/-0.01	2.5/-0.03	VOLTS/PSI
BOO	B46	OFF	ON (E)	OFF	OFF	ON/OFF
BPA	B47	OFF	ON (E)	OFF	OFF	ON/OFF
A/CT	B53	3.1/73.4	3.05/75.2 (A)	4/39	3.92/42	VOLTS/DEG F
ACP_PRESS	B63	2.36/235	2.39/239	2.24/223	2.12/210	VOLTS/PSI
O2S12	E3	(L)	(D)	(D)	(D)	VOLTS
O2S22	E4	0.1	(D)	(D)	(D)	VOLTS
ECT	E18	0.45/210	0.44/210	0.53/199	0.57/196	VOLTS/DEG F
HTRCM12	E23	617	617	617	617	MA
HTRCM22	E24	605	605	605	605	MA
GENMON	E26	0	35.16	28.13	25	%
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
KNOCK	1	E49	654	650	1366	1621 N/A
TP2	E60	1.22/24.31	0.74/14.9	0.99/19.61	1.3/25.88	VOLTS/%
TP1	E61	4.05/18.82	4.29/13.73	4.17/16.47	4/19.61	VOLTS/%
MAP	E62	4.02/98.93/14.35/28.93 (W)	1.28/30.95/4.49/9.15 (W)	2.37/58.95/8.55/20.67 (W)	1.86/45.98/ 6.67/28.93 (W)	VOLTS/kPa/PSI/inHg
PSP	E65	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
HTRCM11	E69	1.62	1.62	1.62	1.62	AMPS
HTRCM21	E70	1.58	1.58	1.58	1.58	AMPS
APP	PID	0	0	4	11	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/Hz
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	8	2.62	6.45	8.93	DEG
ETC_DSD	PID	7.79	2.62	6.45	9.08	DEG
FLI	PID	73.5 (H)	73 (H)	90 (H)	83 (H)	%
LOAD	PID	65 (L)	17	19	25	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	766	1600	1700	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 3.0L 4V FUSION/MILAN

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVMV	B4	0/OFF	0/OFF	480/VARYING	962/VARYING	MA/OFF-VARYING
FANVAR	B8	0	38	32	71	%
FP	B62	OFF	ON	ON	ON	ON/OFF
WAC/ACCR	B64	OFF	ON	OFF	OFF	ON/OFF
PCVHC	E2	0	0	0	0	%
SPKDUR_6	E10	0	2.18	2.12	1.15	Ms
SPKDUR_5	E11	0	2.06	1.87	1.09	Ms
SPKDUR_4	E12	0	2.37	2.15	1.43	Ms
GENCMD	E13	3.79	0 (Q)	0 (Q)	0 (Q)	%
SPKDUR_3	E15	0	1.71	2.12	0.875	Ms
SPKDUR_2	E16	0	2.28	1.71	1	Ms
SPKDUR_1	E17	0	2.4	2	1.46	Ms
HTR12	E23	OFF	ON	ON	ON	ON/OFF
HTR22	E24	OFF	ON	ON	ON	ON/OFF
VCTDC	E67	0	0	41.7	39.5	%
VCTDC2	E68	0	0	43.3	33.7	%
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/DISALLOW
EVAP020R	PID	READY	READY	READY	READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	14	36	40	DEG
VCTADV	PID	0	0.37	10.8	32	DEG
VCTADV2	PID	0	1	8	33.7	DEG
VCTADVERR	PID	0	0.68	0.81	1.12	DEG
VCTADVERR2	PID	0	1	1.56	0.43	DEG

ACTUATORS/OUTPUTS - 3.0L 4V FUSION/MILAN

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 3.0L 4V FUSION/MILAN

3.5L 4V Edge/MKX

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B17	0.1/LOW	VBAT/HIGH (I)	0.1/LOW	0.1/LOW	VOLTS/HIGH-LOW
GENMON	B23	0	41.41	30.47	27.34	%
APP1	B25	3.9	3.9	3.5	3.3	VOLTS
APP2	B26	1.6	1.7	1.8	2.1	VOLTS
APP3	B27	1.0	1.0	1.3	1.5	VOLTS
FPM	B30	OFF	ON	ON	ON	ON/OFF
ACP	B37	0.8/70	0.86/73	0.9/75	1.0/87	VOLTS/PSI
MAF	B41	0	0.7	1.4	1.5	VOLTS
IAT	B43	80 (K)	50 (K)	37 (K)	34 (K)	DEG F
FTP	B44	2.6/-0.01	2.6/-0.01	2.6/-0.01	2.6/-0.01	VOLTS/PSI
BOO	B46	VBAT/OFF	0.1/ON (E)	VBAT/OFF	VBAT/OFF	VOLTS/ ON-OFF
BPA	B47	0.1/OFF	VBAT/ON (E)	0.1/OFF	0.1/OFF	VOLTS/ ONOFF
FEPS	B55	0.5-0.6	0.5-0.6	0.5-0.6	0.5-0.6	VOLTS
O2S12	E23	(L)	(D)	(D)	(D)	VOLTS
O2S22	E24	0.1	(D)	(D)	(D)	VOLTS
O2S21	E28	0	Switching (C)	Switching (C)	Switching (C)	VOLTS
O2S11	E29	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS
CHT	E41	3.6/199	3.6/199	3.58/201	3.45/208	VOLTS/DEG F
CMP2	E44	0	5-7	13-16	20-23	Hz
CMP1	E45	0	5-7	13-16	20-23	Hz
CKP	E47	0	400-500	850-1050	1050-1150	Hz
KNOCK	1	E49	23.99k	25.01k	25.73k	44.51k N/A
TP2	E60	1.1/25	0.8/15	1.0/19	1.4/27	VOLTS/%
TP1	E61	4.1/17	4.4/13	4.2/16	4.0/19	VOLTS/%
ACCS	PID	VBAT/OFF	VBAT/ON (A)	VBAT/OFF	VBAT/OFF	VOLTS/ ONOFF
APP	PID	3.9	0	0	22	%
APP_FLT	PID	NO	FAULT	NO	FAULT	NO FAULT NO FAULT FAULT/NO FAULT
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
ETC_ACT	PID	7.56	1.27	6.22	12.74	DEG
ETC_DSD	PID	7.62	1.31	6.19	12.73	DEG
ETC_TRIM	PID	0.23 (X)	0.21 (X)	0.24 (X)	0.24 (X)	DEG
FANVAR_F	PID	NO	FAULT	NO	FAULT	NO FAULT NO FAULT FAULT/NO FAULT
FLI	PID	71 (H)	72 (H)	82 (H)	81 (H)	%
LOAD	PID	51.4 (L)	16.1	35.4	34.7	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	600	1200	1500	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH
WAC_F	PID	NO	FAULT	NO	FAULT	NO FAULT NO FAULT FAULT/NO FAULT

SENSORS/INPUTS - 3.5L 4V EDGE/MKX

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
GENCMD	B22	3.79	0 (Q)	0 (Q)	0 (Q)	%
SMC	B34	0	0	0	0	VOLTS
CTO	B49	0	0	0	0	Hz
EVMV	B50	0	337	0	847	MA
EVAPCV	B61	0	0	0	0	%
FP	B62	8.3/75	3.6/27	3.6/27	3.8/29	VOLTS/%
WAC/ACCR	B64	OFF	OFF	OFF	OFF	ON/OFF
HTR12	E1	VBAT/OFF	0.2/ON	0.2/ON	0.2/ON	VOLTS/ ON-OFF
HTR22	E2	VBAT/OFF	0.2/ON	0.2/ON	0.2/ON	VOLTS/ ON-OFF
CD6F (CYL 6)	E10	VBAT	VBAT	VBAT	VBAT	VOLTS
CD5D (CYL 5)	E11	VBAT	VBAT	VBAT	VBAT	VOLTS
CD4B (CYL 4)	E12	VBAT	VBAT	VBAT	VBAT	VOLTS
CD3E (CYL 3)	E15	VBAT	VBAT	VBAT	VBAT	VOLTS
CD2C (CYL 2)	E16	VBAT	VBAT	VBAT	VBAT	VOLTS
CD1A (CYL 1)	E17	VBAT	VBAT	VBAT	VBAT	VOLTS
PCVHC	E33	0	0	0	0	%
TACM (+)	E34	3.7	VBAT	VBAT	VBAT	VOLTS
TACM (-)	E51	3.7	VBAT	VBAT	VBAT	VOLTS
VCTADV	E67	0	.031	27.56	30.94	DEG
VCTADV2	E68	0	0	27.69	31.06	DEG
HTR11	E69	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	VOLTS/ ON-OFF
HTR21	E70	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	VOLTS/ ON-OFF
FANVAR	PID	0	0	0	0	%
FANDC	PID	7.5	7.5	7.5	7.5	%
FP	PID	ON/OFF	ON	ON	ON	ON/OFF
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	13.25	44	45.25	DEG
VCTDC	PID	0	0	47.32	80	%
VCTDC2	PID	0	0	46.8	80	%
VCTADVERR	PID	0	0.18	0.37	0.18	DEG
VCTADVERR2	PID	0	0.06	0.43	0	DEG

ACTUATORS/OUTPUTS - 3.5L 4V EDGE/MKX

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
ETCVREF	B21/28	5	5	5	5	VOLTS
VREF	B33/E57	5	5	5	5	VOLTS
VPWR	B51/52	VBAT	VBAT	VBAT	VBAT	VOLTS
KAPWR	B54	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 3.5L 4V EDGE/MKX

3.5L 4V MKZ

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B25	4.06	4.06	3.8	3.67	VOLTS
APP2	B26	1.48	1.47	1.69	1.78	VOLTS
APP3	B27	0.92	0.92	1.14	1.23	VOLTS
FPM	B30	OFF	ON	ON	ON	ON/OFF
MAF	B41	0	0.65	1.26	1.6	VOLTS
IAT	B43	1.44/131 (K)	2.39/95 (K)	4.3/-0.4 (K)	4.31/-2.2 (K)	VOLTS/DEG F
FTP	B44	2.61/0.61	2.56/0.61	2.54/0.61	2.56/0.61	VOLTS/PSI
BOO	B46	OFF	ON	(E)	OFF	OFF ON/OFF
BPA	B47	OFF	ON	(E)	OFF	OFF ON/OFF
ACP_PRESS	B63	2.23/147.9	2.08/127.97	1.38/37.99	1.36/35.98	VOLTS/PSI
O2S12	E3	0.02 (L)	0.21 (D)	0.64 (D)	0.67 (D)	VOLTS
O2S22	E4	0.09 (L)	0.76 (D)	0.68 (D)	0.64 (D)	VOLTS
HTRCM12	E23	727 (mA)	727 (mA)	1.29 (A)	570 (mA)	MA/A
HTRCM22	E24	758 (mA)	758 (mA)	1.25 (A)	602 (mA)	MA/A
GENMON	E26	0	44.53	30.47	25.78	%
O2S11	E28	0.06 (L)	0.14 (C)	0.71 (C)	0.77 (C)	VOLTS/RICH-LEAN
O2S21	E29	0.02 (L)	0.1 (C)	0.64 (C)	0.83 (C)	VOLTS/ RICH-LEAN
CHT	E41	3.35/213.8	3.43/210.2	0.68/186.6	0.66/186.8	VOLTS/DEG F
KNOCK	1	E49	299	267	345	627 N/A
TP2	E60	1.27/25.1	0.85/16.86	1.31/25.88	1.3/25.88	VOLTS/%
TP1	E61	4.08/18.04	4.29/13.73	4.05/18.82	4.06/18.43	VOLTS/%
PSP	E65	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
HTRCM11	E69	1.58	1.58	2.13	1.54	AMPS
HTRCM21	E70	1.65	1.65	2.08	1.52	AMPS
ACCS	PID	OFF	ON (A)	OFF	OFF	ON/OFF
APP	PID	0	0	10	16.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.24/155.8	PSI/Hz
B+	PID	12.56	13-14	13-14	13-14	VOLTS
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_ACT	PID	7.5	2.31	6.43	9.75	DEG
ETC_DSD	PID	7.62	2.27	8.81	5.09	DEG
FLI	PID	30.96 (H)	31.11 (H)	27.59 (H)	24.09 (H)	%
LOAD	PID	50.15 (L)	16.01	30.54	35.63	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	774.5	1216	1621	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V MKZ

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVMV	B4	0/OFF	588/VARYING	661/ OFF	589/ OFF	MA/OFF-VARYING
EVAPCV	B61	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
FP	B62	OFF	ON	ON	ON	ON/OFF
WAC/ACCR	B64	OFF	OFF	OFF	OFF	ON/OFF
PCVHC	E2	0	0	100	100	%
SPKDUR_6	E10	2.21	2.25	1.56	1.0	Ms
SPKDUR_5	E11	2.09	2.06	1.56	1.62	Ms
SPKDUR_4	E12	2.25	2.21	1.62	1.81	Ms
GENCMD	E13	3.79	0 (Q)	0 (Q)	0 (Q)	%
SPKDUR_3	E15	2.18	2.21	1.87	1.53	Ms
SPKDUR_2	E16	2.18	2.15	1.71	1.34	Ms
SPKDUR_1	E17	2.15	2.15	1.68	1.75	Ms
HTR12	E23	OFF	ON	ON	ON	ON/OFF
HTR22	E24	OFF	ON	ON	ON	ON/OFF
VCTADV	E67	0	0.06	30.56	29.63	DEG
VCTADV2	E68	0	0	31.31	30.13	DEG
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	YES	YES	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FANDC	PID	4.99	4.99	4.99	4.99	%
FANVAR	PID	0	0	0	0	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	33	13.5	37.25	27.75	DEG
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
VCTADVERR	PID	0	0.06	1.18	0.25	DEG
VCTADVERR2	PID	0	0	1.43	0.68	DEG
VCTDC	PID	0	0	42.01	80	%
VCTDC2	PID	0	0	41.67	80	%

ACTUATORS/OUTPUTS - 3.5L 4V MKZ

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52	12.31	13-14	13-14	13-14	VOLTS

OTHER - 3.5L 4V MKZ

3.5L 4V Flex/Taurus/Taurus X/Sable

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B17	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
GENMON	B23	0	42.97	34.38	30.47	%
APP1	B25	4.08	4.08	3.95	3.56	VOLTS
APP2	B26	1.42	1.42	1.52	1.82	VOLTS
APP3	B27	0.88	0.88	0.99	1.28	VOLTS
FPM	B30	OFF/0	ON/0	ON/0	ON/0	ON/OFF / %
ACP_PRESS	B37	1.42/113.97	1.36/107.98	1.10/73.97	1.12/75.98	VOLTS/PSI
MAF	B41	0.01	0.52	1.57	1.8	VOLTS
IAT	B43	1.69/122 (K)	2.67/84.2 (K)	3.39/55.4 (K)	3.95/22.6 (K)	VOLTS/DEG F
FTP	B44	2.62/0.6	2.47/0.6	2.56/0.6	2.38/0.6	VOLTS/PSI
BPA	B47	OFF	OFF	OFF	OFF	ON/OFF
O2S11_CUR	E18	256 (mA)	256 (mA)	82 (uA)	256 (mA)	MA/uA
O2S21_CUR	E20	256 (mA)	20 (uA)	137 (uA)	256 (mA)	MA/uA
O2S12	E23	0	0.72	0.69	0.64	VOLTS
O2S22	E24	0	0.76	0.72	0.72	VOLTS
CHT	E41	3.49/206.6	3.54/204.8	0.7/183.2	0.65/188.6	VOLTS/DEG F
TP2	E60	1.33/26.67	0.82/16.47	1.54/30.59	1.49/29.8	VOLTS/%
TP1	E61	4.09/18.04	4.35/12.55	3.98/20	4.01/19.61	VOLTS/%
TSS	T15	0	580.8	1427	1413	RPM
ACCS	PID	OFF	OFF	OFF	OFF	ON/OFF
APP	PID	0	0	4.5	17	%
B+	PID	12.31	13.81	14.06	14.06	VOLTS
BARO	PID	14.12/155.1	14.12/155.1	14.12/155.1	14.12/155.1	PSI/Hz
BOO	PID	OFF	ON	(E)	OFF	OFF ON/OFF
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EQ_RAT11	PID	0	(-)2 TO (+)2	(-)2 TO (+)2	(-)2 TO (+)2	RATIO
EQ_RAT21	PID	0	(-)2 TO (+)2	(-)2 TO (+)2	(-)2 TO (+)2	RATIO
ETC_ACT	PID	7.81	1.22	11.4	8.04	DEG
ETC_DSD	PID	7.62	1.21	11.36	7.68	DEG
ETC_TRIM	PID	0.01 (X)	0.01 (X)	0.02 (X)	0.05 (X)	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	57 (H)	54.59 (H)	58.48 (H)	51.32 (H)	%
GEAR	PID	1	1	5	6	GEAR
INJPWR_M	PID	12.28	13.99	13.79	13.97	VOLTS
LOAD	PID	50.85	(L)	16.48	27.32	46.08 %
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
NM	PID	0	0	0	0	COUNT
O2S11_IMPED	PID	4.94	1.0	0.93	1.03	VOLTS
O2S21_IMPED	PID	4.94	1.01	1.04	0.95	VOLTS
OSS	PID	0	0	997.8	1859	RPM
OSS_SRC	PID	0	0	997.3	1865	RPM
RPM	PID	0	619.5	1415	1358	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TFT	PID	163.4	122	147.2	176	DEG F
TFTV	PID	0.98	1.75	1.24	0.82	VOLTS
TORQUE	PID	142.9	4	110.9	142.9	Nm
TR	PID	PARK	PARK	OVER DRIVE	OVER DRIVE	POSITION
TR2	PID	OPEN	OPEN	CLOSED	CLOSED	OPEN/ CLOSED
TSS/ISS	PID	0	576.3	1501	1428	RPM
TSS_SRC	PID	0	578	1503	1428	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V FLEX/TAURUS/TAURUS X/SABLE

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
GENCMD	B22	3.57	0 (Q)	0 (Q)	0 (Q)	%
EVMV	B50	0/OFF	736/VARYING	655/OFF	910/VARYING	MA/OFF/ON/VARYING
FP	B62	OFF	ON	ON	ON	ON/OFF
HTR12	E1	OFF	ON	ON	ON	ON/OFF
HTRCM12	E1	1.3 (Amps)	1.3 (Amps)	1.3 (Amps)	543 (mA)	MA/Amps
HTR22	E2	OFF	ON	ON	ON	ON/OFF
HTRCM22	E2	1.3 (Amps)	1.3 (Amps)	1.3 (Amps)	598 (mA)	MA/Amps
VCTADV	E67	0	0.37	38.69	37.88	DEG
VCTADV2	E68	0	0	38.56	38.94	DEG
O2S11_HTR	E69	0	36.4	34.02	35.22	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTRCM11	E69	1.40	1.40	1.44	1.44	Amps
O2S21_HTR	E70	0	36.48	33.62	34.18	%
HTR21	E70	OFF	(O)	ON	ON	ON ON/OFF
HTRCM21	E70	2	2	2	1.47	Amps
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
CLRDIST	PID	1.85	1.85	1.85	12.41	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FANDC	PID	7.99	7.99	42	7.99	%
FANVAR	PID	0	0	38.71	0	%
FTP_H20	PID	0.1	1	0.24	0.61	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
IGN_R/S	PID	ON	ON	ON	ON	ON/OFF
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2S_EVAL	PID	YES	YES	YES	YES	YES/NO
O2SHTR_EVAL	PID	YES	YES	YES	YES	YES/NO
RPMDSD	PID	800	608	608	608	RPM
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	12	43	25.25	DEG
TRIP_CNT	PID	0	0	0	0	COUNT
VCTADVERR	PID	0	0.37	0.93	0.18	DEG
VCTADVERR2	PID	0	0.06	0.93	0.06	DEG
VCTDC	PID	0	0	80	44.84	%
VCTDC2	PID	0	0	80	45.72	%
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.5L 4V FLEX/TAURUS/TAURUS X/SABLE

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52/53	12	13-14	13-14	13-14	VOLTS
VREF	B64	5	5	5	5	VOLTS

OTHER - 3.5L 4V FLEX/TAURUS/TAURUS X/SABLE

3.7L 4V MKS

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B17	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
GENMON	B23	0	42.19	33.59	24.22	%
APP1	B25	4.07	4.07	3.86	3.66	VOLTS
APP2	B26	1.42	1.42	1.57	1.73	VOLTS
APP3	B27	0.88	0.88	1.08	1.22	VOLTS
FPM	B30	0	0	0	0	%
ACP_PRESS	B37	1.26/93.97	1.47/119.97	1.06/69.99	1.04/65.99	VOLTS/PSI
MAF	B41	0.01	0.56	1.34	1.56	VOLTS
IAT	B43	1.94/113 (K)	2.01/109.4 (K)	3.65/44.6 (K)	3.99/24.8 (K)	VOLTS/DEG F
FTP	B44	2.62/0.61	2.43/0.61	2.62/0.61	2.32/0.61	VOLTS/PSI
BPA	B47	OFF	OFF	OFF	OFF	ON/OFF
O2S11_CUR	E18	256 (mA)	256 (mA)	148 (uA)	255.9 (mA)	MA/uA
O2S21_CUR	E20	256 (mA)	117 (uA)	238 (uA)	256 (mA)	MA/uA
O2S12	E23	0.67	0.72	0.06	0.8	VOLTS
O2S22	E24	0.13	0.68	0.75	0.84	VOLTS
CHT	E41	0.56/197.6	0.54/199.4	3.68/195.8	3.73/192.2	VOLTS/DEG F
TP2	E60	1.27/25.49	0.81/16.08	0.96/19.22	1.35/26.67	VOLTS/%
TP1	E61	4.09/18.04	4.32/13.33	4.24/14.9	4.04/18.82	VOLTS/%
TSS	T15	0	585.8	1136	1612	RPM
ACCS	PID	OFF	OFF	OFF	OFF	ON/OFF
APP	PID	0	0	7	14	%
B+	PID	12.19	13.94	14.0	13.94	VOLTS
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
BOO	PID	OFF	OFF	OFF	OFF	ON/OFF
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EQ_RAT11	PID	0	1.03	1.02	1.0	RATIO
EQ_RAT21	PID	0	1.02	0.98	0.97	RATIO
ETC_ACT	PID	7.62	1.20	7.81	9.54	DEG
ETC_DSD	PID	7.62	1.33	7.79	9.58	DEG
ETC_TRIM	PID	0.05 (X)	0.24 (X)	0.24 (X)	0.24 (X)	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	40.7 (H)	56.42 (H)	54.81 (H)	51.34 (H)	%
GEAR	PID	1	1	5	6	GEAR
INJPWR_M	PID	12.31	13.94	13.94	13.99	VOLTS
LOAD	PID	51.3	(L)	16.97	27.92	32.57 %
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	NO	YES	YES	YES/NO
NM	PID	0	0	0	0	COUNT
O2S11_IMPED	PID	4.95	1.01	1.03	0.99	VOLTS
O2S21_IMPED	PID	4.95	1.0	1.05	1.02	VOLTS
OSS	PID	0	0	1224	2163	RPM
OSS_SRC	PID	0	0	1220	2159	RPM
RPM	PID	0	616.5	1277	1605	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TFT	PID	185	120.2	165.2	168.8	DEG F
TFTV	PID	0.7	1.79	0.95	0.89	VOLTS
TORQUE	PID	155	6.67	36.07	108.2	Nm
TR	PID	PARK	PARK	OVER DRIVE	OVER DRIVE	POSITION
TR2	PID	OPEN	OPEN	CLOSED	CLOSED	OPEN/ CLOSED
TSS/ISS	PID	0	585.3	1135	1614	RPM
TSS_SRC	PID	0	585.8	1136	1614	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 3.7L 4V MKS

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
GENCMD	B22	3.57	0 (Q)	0 (Q)	0 (Q)	%
EVMV	B50	0/OFF	778/VARYING	935/VARYING	648/ON	MA/ON-OFFVARYING
FP	B62	OFF	ON	ON	ON	ON/OFF
HTR12	E1	OFF	ON	ON	ON	ON/OFF
HTRCM12	E1	613	652	652	652	MA
HTR22	E2	OFF	ON	ON	ON	ON/OFF
HTRCM22	E2	648	676	676	676	MA
VCTADV	E67	0	0.06	12.38	39	DEG
VCTADV2	E68	0	0.12	34.13	37.13	DEG
O2S11_HTR	E69	0	36.8	36.08	35.32	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTRCM11	E69	1.4	1.43	1.43	1.43	Amps
O2S21_HTR	E70	0	36.09	35.35	34.89	%
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	1.45	1.46	1.46	1.46	Amps
CAT_EVAL	PID	YES	NO	NO	YES	YES/NO
CLRDIST	PID	54.04	1.86	2.48	11.18	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FANDC	PID	7.99	10	7.99	7.99	%
FANVAR	PID	0	0	0	0	%
FTP_H20	PID	0.03	1.3	0	2.13	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
IGN_R/S	PID	ON	ON	ON	ON	ON/OFF
LONGFT1	PID	2.73 (L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	4.29 (L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2S_EVAL	PID	YES	NO	NO	YES	YES/NO
O2SHTR_EVAL	PID	YES	NO	NO	YES	YES/NO
RPMDSD	PID	800	608	608	608	RPM
SHRTFT1	PID	0 (L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	0 (L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	13.25	30	38.5	DEG
TRIP_CNT	PID	0	0	0	0	COUNT
VCTADVERR	PID	0	0.06	0.31	1.87	DEG
VCTADVERR2	PID	0	0.12	0	1.62	DEG
VCTDC	PID	0	0	47.32	48.56	%
VCTDC2	PID	0	0	47.93	49.45	%
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.7L 4V MKS

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52/53	12	13-14	13-14	13-14	VOLTS
VREF	B64	5	5	5	5	VOLTS

OTHER - 3.7L 4V MKS

Scheme 107

Scheme 107: 4.0L Mustang

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.62/0.61	2.64/0.6	2.58/0.61	2.63/0.61	VOLTS/PSI
FTP_H2O	B3	0.33	0.17	0.27	0.03	In-H 2 O
APP1	B5	4.07	4.07	3.67	3.61	VOLTS
BOO	B9	OFF	OFF	OFF	OFF	ON/OFF
ACCS	B15	OFF	OFF	OFF	OFF	ON/OFF
APP2	B17	1.43	1.43	1.74	1.79	VOLTS
FPM	B21	0	0	0	0	%
ACP_PRESS	B26	1.32/121.97	1.4/129.97	0.98/83.98	0.95/81.98	VOLTS/PSI
APP3	B28	0.87	0.87	1.17	1.2	VOLTS
TCS (A/T)	B29	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/NOT DEPRESSED
PSP	B34	LOW	LOW	LOW	LOW	HIGH/LOW
BPA	B39	OFF	OFF	OFF	OFF	ON/OFF
GENMON	E5	0	41.41	10.16	21.88	%
ECT	E18	0.44/215.6	0.45/208.4	0.59/199.4	0.58/197.6	VOLTS/DEG F
FRT	E19	2.08/107.6 (K)	2.12/107.6 (K)	3.32/64.4 (K)	3.42/60.8 (K)	VOLTS/DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	VOLTS
IAT	E22	1.98/111.2 (K)	2.97/73.4 (K)	4.03/21.2 (K)	4.04/21.2 (K)	VOLTS/DEG F
MAF	E25	0	0.77	2.39	2.2	VOLTS
O2S11	E28	0/switching (L)	0.67/switching (C)	0.13/switching (C)	0.79/switching (C)	VOLTS/RICH-LEAN
O2S21	E29	0/switching (L)	0.74/switching (C)	0.11/switching (C)	0.72/switching	VOLTS/ RICH-LEAN
FRP	E32	3.76/59.91	3.84/58.62	2.8/40.23	2.73/39.12	VOLTS/PSI
KNOCK	1	E49	16380	172	152	208 N/A
TP2	E60	1.26/25.0	0.72/14.51	0.81/16.08	1.34/26.67	VOLTS/%
TP1	E61	4.05/18.82	4.32/13.33	4.28/14.12	4.01/19.61	VOLTS/%
MAP	E62	4.3/99.97/14.5/29.53 (W)	1.11/27.99/4.06/8.26 (W)	2.74/64.94/9.42/19.19 (W)	2.68/62.94/9.13/18.6 (W)	VOLTS/kPa/PSI/inHg
OSS_SRC	T3	0	0	1256	2254	RPM
TSS (A/T)	T15	0	616.8	1253	1698	RPM
O2S12	T24	0 (L)	0.83 (D)	0.74 (D)	0.76 (D)	VOLTS
O2S22	T25	0	0.84 (D)	0.76 (D)	0.76 (D)	VOLTS
TFT (A/T)	T29	1.1/159.8 (K)	0.8/176 (K)	0.87/172.4 (K)	0.92/168.8 (K)	VOLTS/DEG F
APP	PID	0	0	13.5	15.5	%
B+	PID	12.69	13-14.5	13-14.5	13-14.5	VOLTS
BARO	PID	14.42/157	14.42/157	14.42/157	14.42/157	PSI/Hz
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.75	0.75	10.25	4.25	DEG
ETC_DSD	PID	7.62	0.76	10.27	4.22	DEG
ETC_TRIM	PID	0.1 (X)	0.1 (X)	0.07 (X)	0.07 (X)	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	0 (H)	22.08 (H)	29.76 (H)	28.56 (H)	%
GEAR	PID	1	1	5	5	GEAR
LOAD	PID	67.77	(L)	15.2	32.66	15.57 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	636	1128	1631	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.0L MUSTANG

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	25.5/ON	22.22/ON	19.89/ON	%/ON-OFF
WAC/ACCR	B14	OFF	OFF	OFF	OFF	ON-OFF
GENCMD	B32	3.57	0 (Q)	0 (Q)	0 (Q)	%
HFC	E4	OFF	OFF	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	484/VARYING	515/VARYING	328/OFF	MA/OFF-VARYING
LFC	E7	OFF	OFF	OFF	OFF	ON/OFF
EGRVR	E63	0	0	51.48	(T)	0 (T) %
HTR11	E69	OFF	(O)	ON	ON	ON ON/OFF
HTRCM11	E69	1.16	1.16	1.16	1.16	AMPS
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	1.18	1.18	1.18	1.18	AMPS
TCC (A/T)	T46	0/OFF	0/OFF	0/OFF	100/ENGAGED	% / OFFENGAGED
HTR12	T47	OFF	(O)	ON	ON	ON ON/OFF
HTRCM12	T47	691	691	691	691	MA
HTR22	T48	OFF	(O)	ON	ON	ON ON/OFF
HTRCM22	T48	672	672	672	672	MA
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	0 (L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
LONGFT2	PID	0 (L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	0 (L)	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SHRTFT2	PID	0 (L)	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SPARKADV	PID	10	13.25	34	22	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

ACTUATORS/OUTPUTS - 4.0L MUSTANG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	12.38	13-14.5	13-14.5	13-14.5	VOLTS
VREF	B40/E57	5	5	5	5	VOLTS

OTHER - 4.0L MUSTANG

4.6L 3V Mustang

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.61/0.61 (M)	2.53/0.61 (M)	2.59/0.6 (M)	1.5/0.6 (M)	VOLTS/PSI
FTP_H2O	B3	0.06	0.61	0.24	7.93	In-H 2 O
APP1	B5	4.08	4.08	3.7	3.41	VOLTS
ACCS	B15	ON	ON	(A)	OFF	OFF ON/OFF
APP2	B17	1.43	1.43	1.72	1.94	VOLTS
FPM	B21	0	0	0	0	%
ACP	B26	OPEN	OPEN	OPEN	OPEN	OPEN/ CLOSED
APP3	B28	0.88	0.88	1.16	1.38	VOLTS
TCS (A/T)	B29	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
GENMON	E5	0	28.13	16.41	17.19	%
FRT	E19	2.57/89.6 (K)	2.61/89.6 (K)	3.35/64.4 (K)	3.43/60.8 (K)	VOLTS/DEG F
IAT	E22	2.28/98.6 (K)	2.9/75.2 (K)	3.74/39.2 (K)	3.86/32 (K)	VOLTS/DEG F
MAF (A/T)	E25	0	0.8	1.04	2.74	VOLTS
MAF (M/T)	E25	0	1	1.5	1.3	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
KNOCK	2	E31	0	81	106	297 N/A
FRP	E32	3.74/56.73	2.74/39	2.75/39.33	2.71/38.65	VOLTS/PSI
CHT	E41	3.59/199.4	3.57/201.2	0.73/179.6	3.56/201.2	VOLTS/DEG F
KNOCK	1	E49	0	69	175	265 N/A
TP2	E60	1.22/24.31	0.74/14.9	1.27/25.1	1.14/22.75	VOLTS/%
TP1	E61	4.12/17.26	4.37/12.16	4.14/16.86	4.11/17.26	VOLTS/%
HTRCM11	E69	1.13	1.13	1.13	1.13	AMPS
HTRCM21	E70	1.14	1.14	1.14	1.14	AMPS
OSS	(A/T)	T3	0	0	1385	2400 RPM
OSS	(M/T)	T3	0	0	1420	2500 RPM
TSS	(A/T)	T15	0	721	890	1674 RPM
TR2	(A/T)	T17	CLOSED	CLOSED	OPEN	OPEN OPEN/ CLOSED
O2S12	T24	0.22 (L)	0.8 (D)	0.75 (D)	0.73 (D)	VOLTS
O2S22	T25	0.23	0.83 (D)	0.73 (D)	0.81 (D)	VOLTS
TFT (A/T)	T29	0.88/170.6 (K)	0.88/170.6 (K)	1/165.2 (K)	0.87/172.4 (K)	VOLTS/DEG F
HTRCM12	T47	707	707	707	707	MA
HTRCM22	T48	703	703	703	703	MA
APP	PID	0	0	12.5	22.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
B+	PID	12.69	13-14.5	13-14.5	13-14.5	VOLTS
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.56	1.31	8.41	13.25	DEG
ETC_DSD	PID	7.62	1.31	8.42	13.32	DEG
ETC_TRIM	PID	0.1 (X)	0.1 (X)	0.17 (X)	0.17 (X)	DEG
FLI	PID	0 (H)	64.28 (H)	69.33 (H)	69 (H)	%
GEAR (A/T)	PID	1	1	5	5	GEAR
LOAD	PID	48.93 (L)	15.19	17.79	52.08	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	711	1299	1815	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
TR (A/T)	PID	P	P	OD	OD	POSITION
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 3V MUSTANG

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	21.53/ON	24.31/ON	23.78/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0 (R)/OFF	0 (R)/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
GENCMD	B32	3.57	0 (Q)	0 (Q)	0 (Q)	%
HFC	E4	OFF	ON (B)	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	377/VARYING	0/VARYING	533/OFF	MA/OFFVARYING
LFC	E7	OFF	ON (B)	OFF	OFF	ON/OFF
IMRC	E50	OFF	OFF	OFF	OFF	ON/OFF
VCTDC	E67	0	0	42.53	0	%
VCTDC2	E68	0	0	39.58	0	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
TCC (A/T)	T46	0/OFF	0/OFF	0/OFF	100/ENGAGED	%/OFFENGAGED
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	YES	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	6-MONITOR COMPLETE	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
LONGFT1	PID	0 (L)	2.34 (L)	(-)20 TO (+)20	(-)20 TO (+) 20	%
LONGFT2	PID	0 (L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	0 (L)	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+) 10	%
SHRTFT2	PID	0 (L)	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+) 10	%
SPARKADV	PID	10	19.75	34.25	36.75	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
VCTADV	PID	0	0.18	47.88	0.56	DEG
VCTADV2	PID	0	0.68	48	0.81	DEG
VCTADVERR	PID	0	0.18	0.93	0.56	DEG
VCTADVERR2	PID	0	0.68	0.62	0.81	DEG

ACTUATORS/OUTPUTS - 4.6L 3V MUSTANG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	12	13-14.5	13-14.5	13-14.5	VOLTS
VREF	B40/E57	5	5	5	5	VOLTS

OTHER - 4.6L 3V MUSTANG

5.4L 4V Mustang

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.63/0.61 (M)	2.61/0.61 (M)	2.33/0.61 (M)	2.33/0.61 (M)	VOLTS/PSI
APP1	B5	4.0	4.0	3.8	3.6	VOLTS
ACCS	B15	OFF	ON	(A)	OFF	OFF ON/OFF
APP2	B17	1.43	1.43	1.57	1.66	VOLTS
APP3	B28	0.88	0.88	1.06	1.15	VOLTS
CPP-BOT	B33	NO	NO	NO	NO	YES/NO
GENMON	E5	0	34	20.31	20.31	%
FRT	E19	1.36/140 (K)	1.49/132.8 (K)	2.1/107.6 (K)	1.93/114.8 (K)	VOLTS/DEG F
IAT	E22	1.45/131 (K)	2.28/98.6 (K)	3.29/60.8 (K)	3.39/55.4 (K)	VOLTS/DEG F
MAF	E25	0.01	0.6	0.92	1.7	VOLTS
IAT2	E27	0.83/174.2 (K)	1.19/149 (K)	1.91/114.8 (K)	2.12/107.6 (K)	VOLTS/DEG F
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
FRP	E32	3.01/43.89	2.89/41.92	2.73/39.1	2.69/38.32	VOLTS/PSI
CHT	E41	3.27/217.4	3.35/213.8	3.49/206.6	3.41/210.2	VOLTS/DEG F
TP2	E60	1.29/25.88	0.79/15.69	1.13/22.75	1.13/22.75	VOLTS/%
TP1	E61	4.1/18.43	4.35/13.33	4.15/16.86	4.15/16.86	VOLTS/%
HTRCM11	E69	2.1	2.1	1.89	1.06	AMPS
HTRCM21	E70	2.07	2.07	1.87	1.02	AMPS
OSS_SRC	T3	0	0	1290	2361	RPM
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
O2S22	T25	0.1	(D)	(D)	(D)	VOLTS
HTRCM12	T47	1.57 (AMPS)	1.57 (AMPS)	1.32 (AMPS)	648 (mA)	MA/AMPS
HTRCM22	T48	1.57 (AMPS)	1.57 (AMPS)	1.32 (AMPS)	664	MA/AMPS
APP	PID	0	0	6.5	10.5	%
BARO	PID	14.73/158.9	14.73/158.9	14.73/158.9	14.73/158.9	PSI/Hz
B+	PID	12.88	13-14.5	13-14.5	13-14.5	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.56	1.06	3.5	7.62	DEG
ETC_DSD	PID	7.62	0.99	3.49	7.62	DEG
ETC_TRIM	PID	0 (X)	0.01 (X)	0.15 (X)	0.1 (X)	DEG
FLI	PID	0 (H)	75.7 (H)	72.45 (H)	70.33 (H)	%
LOAD	PID	73.37 (L)	16.22	34.92	41.87	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	660-780	1200-1300	1450-1740	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 4V MUSTANG

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	21.59/ON	21.26/ON	22.41/ON	%/ON-OFF
EVAPCV	B13	OFF	OFF	OFF	OFF	ON/OFF
WAC/ACCR	B14	OFF	ON	(A)	OFF	OFF ON/OFF
FPM	B21	99.71	99.71	103.4	99.71	%
GENCMD	B32	3.79	0 (Q)	0 (Q)	0 (Q)	%
HFC	E4	OFF	ON (B)	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	574/VARYING	633/VARYING	666/OFF	MA/OFFVARYING
LFC	E7	OFF	ON (B)	OFF	OFF	ON/OFF
SPKDUR_8	E9	0	1.84	1.56	1.65	Ms
SPKDUR_5	E10	0	1.81	1.59	1.4	Ms
SPKDUR_2	E11	0	1.81	1.62	1.5	Ms
SPKDUR_3	E12	0	1.78	1.4	1.59	Ms
SPKDUR_4	E14	0	1.87	1.68	1.68	Ms
SPKDUR_6	E15	0	1.68	1.78	1.59	Ms
SPKDUR_7	E16	0	1.75	1.71	1.37	Ms
SPKDUR_1	E17	0	1.56	1.46	1.5	Ms
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	14.5	31.75	33.25	DEG

ACTUATORS/OUTPUTS - 5.4L 4V MUSTANG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	12.69	13-14.5	13-14.5	13-14.5	VOLTS
VREF	B40/E57	5	5	5	5	VOLTS

OTHER - 5.4L 4V MUSTANG

4.6L 2V Crown Victoria/Grand Marquis

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0.61 (M)	2.6/0.61 (M)	2.6/0.61 (M)	2.6/0.61 (M)	VOLTS/PSI
FTP_H2O	B3	0	0	0.13	0.06	In-H 2 O
APP1	B5	4.0	4.0	3.8	3.6	VOLTS
BPP/BOO	B9	OFF	OFF	OFF	OFF	ON/OFF
ACCS	B15	OFF	OFF	OFF	OFF	ON/OFF
APP2	B17	1.43	1.43	1.55	1.57	VOLTS
ACP_PRESS	B26	1.55/146	1.53/143.97	0.99/85.98	1.01/87.98	VOLTS/PSI
APP3	B28	1.0	1.1	1.03	1.06	VOLTS
TCS	B29	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/NOT DEPRESSED
GENMON	E5	0	47.66	17.97	15.63	%
FRT	E19	1.35/140 (K)	1.39/138.2 (K)	3.2/68 (K)	3.05/73.4 (K)	VOLTS/DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	VOLTS
IAT	E22	1.1/154.4 (K)	1.28/141.8 (K)	3.77/37.4 (K)	3.76/39.2 (K)	VOLTS/DEG F
MAF	E25	0	0.9	1.56	1.87	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
FRP	E32	3.56/53.57	3.84/58.53	2.8/39	2.8/39	VOLTS/PSI
CHT	E41	3.4/201.2	3.53/195.8	3.76/186.8	3.76/186.8	VOLTS/DEG F
KNOCK	1	E49	16380	352	408	438 N/A
TP2	E60	1.2	0.7	1.21	1.36	VOLTS
TP1	E61	4.1	4.29	4.1	4.1	VOLTS
MAP	E62	4.39/98.93/14.35/29.23 (W)	1.25/30.95/ 4.49/9.15 (W)	1.76/42.95/6.23/12.69 (W)	2.26/53.98/7.83/15.94 (W)	VOLTS/kPa/PSI/inHg
OSS_SRC	T3	0	0	1027	1871	RPM
TSS	T15	0	624	737	1339	RPM
TR	T16	P	P	OD	OD	MODE
TR2	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
O2S22	T25	0.1	(D)	(D)	(D)	VOLTS
TFT	T29	1.8/120 (K)	1.8/120 (K)	1.41/141 (K)	1.03/163 (K)	VOLTS/DEG F
APP	PID	0	0	6	7	%
B+	PID	12-13.5	14-15	14-15	14-15	VOLTS
BARO	PID	14.18/155.4	14.18/155.4	14.18/155.4	14.18/155.4	PSI/Hz
BPA	PID	OFF	OFF	OFF	OFF	ON/OFF
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.87	1.62	4.5	7.97	DEG
ETC_DSD	PID	7.55	1.96	4.41	7.93	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	58 (L)	15	25	31.46	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	638	1065	1330	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 2V CROWN VICTORIA/GRAND MARQUIS

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	22.46/ON	17.58/ON	18.27/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	OFF (A)	ON	ON	ON/OFF
EVMV	E6	0	0	0	637	MA
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTRCM11	E69	2.12	2.12	2.12	1.11	AMPS
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	2.12	2.12	2.12	1.09	AMPS
TCC	T46	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFFENGAGED
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTRCM12	T47	1.7 (AMP)	1.7 (AMP)	1.7 (AMP)	637 (mA)	MA/AMP
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
HTRCM22	T48	1.7 (AMP)	1.7 (AMP)	1.7 (AMP)	625 (mA)	MA/AMP
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/ NOT READY
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
GENCMD	PID	3.57	0 (Q)	0 (Q)	0 (Q)	%
LONGFT1	PID	(L)	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	17.7	32.5	30.25	DEG

ACTUATORS/OUTPUTS - 4.6L 2V CROWN VICTORIA/GRAND MARQUIS

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	13.5	14-15	14-15	14-15	VOLTS
VREF	E57	5	5	5	5	VOLTS

OTHER - 4.6L 2V CROWN VICTORIA/GRAND MARQUIS

4.6L 2V Town Car

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.6/0 (M)	1.4/-0.3 (M)	VOLTS/PSI
FTP_H2O	B3	0.06	0	0	0.48	In-H 2 O
APP1	B5	4.0	4.0	3.8	3.6	VOLTS
BPP/BOO	B8	OFF	ON (E)	OFF	OFF	ON-OFF
BPA	B9	OFF	ON (E)	OFF	OFF	ON-OFF
ACCS	B15	0.1/OFF	VBAT/ON (A)	0.1/OFF	0.1/OFF	VOLTS/ON-OFF
APP2	B17	1.5	1.5	1.7	1.7	VOLTS
FP	B21	75/OFF	16.35/ON	18.11/ON	17.73/ON	%/ON-OFF
ACP_PRESS	B26	1.4/129.97	2.1/205.9	1.4/129.97	1.46/135.96	VOLTS/PSI
APP3	B28	1.0	1.1	1.3	1.5	VOLTS
TCS	B29	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	VOLTS/ON-OFF
PSP	B34	0.1/LOW	VBAT/HIGH (I)	0.1/LOW	0.1/LOW	VOLTS/HIGH-LOW
GENMON	E5	0	39.8	30	24	%
FRT	E19	2.6/90 (K)	3.2/ 70 (K)	3.1/72 (K)	3.2/70 (K)	VOLTS/DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	VOLTS
IAT	E22	2.74/81 (K)	2.9/73 (K)	4/27 (K)	3.9/30 (K)	VOLTS/DEG F
MAF	E25	0	0.9	1	1.5	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS
FRP	E32	3.35/50	3/43	2.8/39	2.8/39	VOLTS/PSI
CHT	E41	3.54/194	3.54/194	3.72/188.6	3.65/190.4	VOLTS/DEG F
KNOCK	1	E49	0	235	266	357 N/A
TP2	E60	1.2	0.7	0.90	1.2	VOLTS
TP1	E61	4.1	4.4	4.1	4.1	VOLTS
MAP	E62	4.3/99.97/14.5/29.52 (W)	1.2/31.02/ 4.5/9.16 (W)	1.2/30.33/4.4/8.95 (W)	1.7/39.98/5.8/11.8 (W)	VOLTS/kPa/PSI/inHg
OSS_SRC	T3	0	0	1201	2236	RPM
TSS	T15	0	623	825	1569	Hz/RPM
TR	1	T16	P	P	OD	OD MODE
TR	2	T17	CLOSED	CLOSED	OPEN	OPEN OPEN/ CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
O2S22	T25	0.1	(D)	(D)	(D)	VOLTS
TR3A	T27	0/PARK	0/PARK	1.7/OD	1.7/OD	VOLTS/MODE
TR	4	T28	0	0	11.5	11.5 VOLTS
TFT	T29	1.5/135 (K)	1.5/136 (K)	1.2/154 (K)	1.2/156 (K)	VOLTS/ DEG F
CPP/PNP	PID	NEUTRAL	DRIVE	DRIVE	DRIVE	NEUTRAL/ DRIVE
FLI	PID	50	(H)	50	(H)	50 (H) 50 (H) %
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	14	(L)	14	17	19 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	660-780	1200-1300	1450-1740	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 2V TOWN CAR

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PATSTRT	B2	0	0	0	0	VOLTS
FP	B12	3.7/75	1.3/28	1.3/28	1.3/28	VOLTS/%
EVAPCV	B13	0	0	0 (R)	0 (R)	%
WAC/ACCR	B14	OFF	OFF	(A)	OFF	OFF ON-OFF
GENCMD	B32	3.79	0 (Q)	0 (Q)	0 (Q)	%
EVMV	E6	0/OFF	0/VARYING	553/VARYING	442/VARYING	MA/OFFVARYING
EGRVR	E63	VBAT/0	VBAT/0	(T)	(T)	VOLTS/%
HTR11	E69	0.1/ON	(O)	0.1/ON	0.1/ON	0.1/ON VOLTS/ON-OFF
HTR21	E70	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	VOLTS/ ON-OFF
EPC	T11	7.9/20	9.5/20	9.3/22	9.5/22	VOLTS/PSI
SSA (SS1)	T42	0.1/ON	0.1/ON	VBAT/OFF	VBAT/OFF	VOLTS/ ON-OFF
SSB (SS2)	T43	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	VOLTS/ ON-OFF
TCC	T46	0.1/100	VBAT/0	VBAT/0	0.2/95-100	VOLTS/%
HTR12	T47	0.2/ON (O)	0.2/ON	0.2/ON	0.2/ON	VOLTS/ON-OFF
HTR22	T48	0.2/ON (O)	0.2/ON	0.2/ON	0.2/ON	VOLTS/ON-OFF
LONGFT1	PID	(L)	(L)	(-)20 TO (+)20	(-)20 TO (+)20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+)20	(-)20 TO (+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+)10	(-)10 TO (+)10	%
SHRTFT2	PID	(L)	(-)10 TO (+)	10 (-)10 TO (+)10	(-)10 TO (+)10	%
SPARKADV	PID	10	17.5	32.7	37.7	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

ACTUATORS/OUTPUTS - 4.6L 2V TOWN CAR

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	VOLTS
VREF	B40/E57	5	5	5	5	VOLTS
KAPWR	B45	VBAT	VBAT	VBAT	VBAT	VOLTS
ETCVREF	E66	5	5	5	5	VOLTS

OTHER - 4.6L 2V TOWN CAR

2.5L 4V Escape/Mariner

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	41.38	21.07	17.68	%
APP1	B28	0.79	0.79	1.03	1.13	VOLTS
APP2	B29	0.38	0.38	0.58	0.62	VOLTS
ACP_PRESS	B31	1.56/66.26	1.52/63.94	1.23/45.82	1.13/39.44	VOLTS/PSI
MAF (A/T)	B40	0.01	0.53	1.17	1.91	VOLTS
MAF (M/T)	B40	0.01	0.41	0.73	1.97	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.4/136.4 (K)	1.54/131 (K)	2.71/86 (K)	2.75/84.2 (K)	VOLTS/DEG F
FTP	B65	2.6/0	2.56/0	2.61/0	2.61/0	VOLTS/PSI
FTP_H2O	B65	0.03	0.44	0.03	0.03	In-H 2 O
O2S11	E8	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS
CHT	E39	3.4/210	3.66/206	0.64/190.4	0.57/195.8	VOLTS/DEG F
MAP	E40	4/98.93/14.3/29.11 (W)	1.2/27.99/4.06/8.26 (W)	0.89/21.99/3.19/6.49 (W)	2.9/70.94/10.29/20.95 (W)	VOLTS/kPa/PSI/inHg
TP1	E41	4.1	4.34	4.16	4.2	VOLTS
TP2	E58	1.19	0.71	1.08	0.98	VOLTS
TSS_SRC (A/T)	T16	0	716.8	1265	1710	RPM
TFT (A/T)	T19	145.4 (K)	145.4 (K)	152.6 (K)	185 (K)	DEG F
TFTV (A/T)	T19	1.27 (K)	1.28 (K)	1.18 (K)	0.71 (K)	VOLTS
OSS_SRC (A/T)	T25	0	0	1248	2290	RPM
CPP_BOT (M/T)	T26	NO	NO	NO	NO	YES/NO
CPP_TOP (M/T)	T27	NO	NO	NO	NO	YES/NO
O2S12	T29	(L)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	7	10.5	%
B+	PID	12.47	13-14	13-14	13-14	VOLTS
BARO	PID	14.35/156.1	14.35/156.1	14.35/156.1	14.21/155.2	PSI/Hz
ETC_TRIM	PID	0.15 (X)	0.06 (X)	0.05 (X)	0.02 (X)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR (A/T)	PID	1	1	5	6	GEAR
HTRCM11	PID	0	0	1.5	1.5	Amps
HTRCM12	PID	0	0	630	630	MA
LOAD (A/T)	PID	0 (L)	20.78	30.98	54.51	%
LOAD (M/T)	PID	0 (L)	20	86.67	44.71	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	649.5	1189	2171	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 2.5L 4V ESCAPE/MARINER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75	40.04	40.09 (R)	40.29 (R)	%
EVAPCV	B20	0/OFF	0/OFF	0/OFF (R)	0/OFF (R)	%/ON-OFF
GENCMD	B53	3.57	0 (Q)	0 (Q)	0 (Q)	%
EVAPCP	E32	0	24.71	21.96	0	%
HTR11	E69	OFF	ON	ON	ON	ON-OFF
HTR12	T49	OFF (O)	ON	ON	ON	VOLTS / ONOFF
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
HFC	PID	OFF	ON (B)	OFF	OFF	ON-OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON-OFF
LONGFT1	PID	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
RPMDSD	PID	650	650	650	650	RPM
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV (A/T)	PID	10	14-20	36-44	30-40	DEG
SPARKADV (M/T)	PID	10	14.25	45.25	53	DEG
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
TCC (A/T)	PID	0	0	19.14	27.55	PSI
TCIL (A/T)	PID	OFF	OFF	OFF	OFF	ON/OFF
TQ_CNTRL	PID	NONE	NONE	NONE	NONE

ACTUATORS/OUTPUTS - 2.5L 4V ESCAPE/MARINER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B67/68	12.39	13-14	13-14	13-14	VOLTS

OTHER - 2.5L 4V ESCAPE/MARINER

3.0L 4V Escape/Mariner

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON	(E)	OFF	OFF ON-OFF
GENMON	B14	0	44.58	31.54	31.28	%
APP1	B28	0.77	0.77	1.28	1.44	VOLTS
APP2	B29	0.37	0.37	0.65	0.72	VOLTS
ACP_PRESS	B31	1.3/54.37	1.3/50.17	1.3/51.04	1.3/49.59	VOLTS/PSI
MAF	B40	0	0.69	0.7-1.5	1.3-2	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON-OFF
IAT	B47	2.25/102.2 (K)	2.45/95 (K)	2.61/89.6 (K)	2.96/77 (K)	VOLTS/DEG F
FTP	B65	2.6/0	2.47/-0.03	2.6/0.01	2.6/0	VOLTS/PSI
O2S11	E8	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS
O2S21	E9	0	Switching (C)	Switching (C)	Switching (C)	VOLTS
MAP	E40	4/97.97/14.21/28.93 (W)	1.4/34.95/5.07/10.32 (W)	1.13/27.99/4.06/8.26 (W)	3.23/79.97/11.6/23.61 (W)	VOLTS/kPa/PSI/inHg
TSS_SRC	T16	0	625.8	1250	1684	RPM
TFT	T19	102.2 (K)	102.2 (K)	220-125 (K)	220-125 (K)	DEG F
OSS_SRC	T25	0	0	1277	2284	RPM
O2S12	T29	(L)	(D)	(D)	(D)	VOLTS
TR	T39	PARK	PARK	DRIVE/OVERDRIVE	DRIVE/OVERDRIVE	MODE
O2S22	T40	0.1	(D)	(D)	(D)	VOLTS
APP	PID	0	0	16	20.5	%
B+	PID	12.03	13-14	13-14	13-14	VOLTS
BARO	PID	14.21/155.2	14.21/155.2	14.21/155.2	14.35/156.1	PSI/Hz
CAT_EVAL	PID	NO	NO	NO	NO	YES/NO
ETC_TRIM	PID	0.22 (X)	0.21 (X)	0.33 (X)	0.28 (X)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	6	GEAR
HTRCM11	PID	0	0	0	1.51	Amps
HTRCM12	PID	0	0	0	581	MA
HTRCM21	PID	0	0	0	1.52	Amps
HTRCM22	PID	0	0	0	591	MA
LOAD	PID	(L)	29.02	19-30	30-48	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	689.5	1954	2294	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 3.0L 4V ESCAPE/MARINER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75	40.04	40.09	40.29	%
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
GENCMD	B53	3.57	0 (Q)	0 (Q)	0 (Q)	%
EVAPCP	E32	0	56.08	20.39	0	%
HTR11	E69	OFF	ON	ON	OFF	ON/OFF
HTR21	E70	OFF	(O)	ON	ON	OFF ON/OFF
HTR22	T48	OFF	ON	ON	ON	ON/OFF
HTR12	T49	OFF	ON	ON	ON	ON/OFF
CAT_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FTP_H2O	PID	0.06	1.03	1.03	0.06	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
HFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LONGFT1	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
RPMDSD	PID	680	680	650	650	RPM
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	26.75	5-20	36-44	43.5	DEG
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
TCC	PID	0	0	22.04	40.89	PSI
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TQ_CNTRL	PID	NONE	NONE	NONE	NONE

ACTUATORS/OUTPUTS - 3.0L 4V ESCAPE/MARINER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B67/68	12.06	13-14	13-14	13-14	VOLTS

OTHER - 3.0L 4V ESCAPE/MARINER

2.3L Ranger

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6	2.6	2.6	2.6	VOLTS
FTP_H2O	B3	0	0	0	0	In-H 2 O
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
FPM	B21	OFF	ON	ON	ON	ON/OFF
TCS	B29	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	VOLTS/ON-OFF
CPP/PNP	B33	NEUTRAL	NEUTRAL	DRIVE	DRIVE	MODE
PSP	B34	LOW	HIGH(I)	LOW	LOW	HIGH/LOW
FEPS	B44	0.1	0.1	0.1	0.1	VOLTS
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	VOLTS/DEG F
MAF	E25	0	0.7-0.9	1.2-1.6	1.6-2.1	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS
CHT	E41	0.67 or 3.7/194 - 230	0.67 or 3.7/194 - 230	0.67 or 3.7/194 - 230	0.67 or 3.7/194 - 230	VOLTS/DEG F
KNOCK 1	E49	0	0	0	0	N/A
TP	E61	0.53-1.27	0.53-1.27	0.8-1.1	1.2-1.7	VOLTS
MAP	E62	3.99/97.97/14.21/28.9 (W)	0.95/22.95/3.33/6.79 (W)	1.58/40.74/5.91/12.03 (W)	2.01/46.95/6.81/13.87 (W)	VOLTS/kPa/PSI/inHg
HTRCM11	E69	531	531	531	531	MA
OSS	T3	0	0	1250-1290	2100-2400	RPM
TSS	T15	0	320-360/ 630-670	500-713/1100-1300	845-985/1700-1800	Hz/RPM
TR	1	T16	0	0	VBAT	VBAT VOLTS
TR	2	T17	0	0	VBAT	VBAT VOLTS
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
TR3	V/TR3	T27	0/PARK	0/PARK	1.7/OD	1.7/OD VOLTS/MODE
TR	4	T28	0	0	VBAT	VBAT VOLTS
TFT	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	VOLTS/DEG F
HTRCM12	T47	977	977	977	977	MA
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	17-28	19-26	30-40	%
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	750	1300	1780	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 2.3L RANGER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	OFF	ON	ON	ON	ON/OFF
EVAPCV	B13	0 (R)/OFF	0 (R)/OFF	0 (R)/OFF	0 (R)/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	0/OFF	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFFVARYING
IAC	E33	0	35	35-41 (L)	57-68 (L)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
EPC	T11	6.0	8.0	10.0	10.0	VOLTS
SSA (SS1)	T42	0.1/ON	0.1/ON	VBAT/OFF	VBAT/OFF	VOLTS/ ON-OFF
SSB (SS2)	T43	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	VOLTS/ ON-OFF
SSC (SS3)	T44	VBAT/OFF	VBAT/OFF	VBAT/OFF	0.1/ON	VOLTS/ ON-OFF
SSD (SS4)	T45	0.1/ON	0.1/ON	0.1/ON	0.1/ON	VOLTS/ ON-OFF
TCC	T46	VBAT/0	VBAT/0	VBAT/0	0.2/100	VOLTS/%
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
EGR_EVAL	PID	YES	YES	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	0	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	0	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	0	20-25	30-35	30-35	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

ACTUATORS/OUTPUTS - 2.3L RANGER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	VOLTS
VREF	E57	5	5	5	5	VOLTS

OTHER - 2.3L RANGER

4.0L Ranger

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	2.6/0	2.6/0	2.6/0	VOLTS/PSI
FTP_H2O	B3	0	0	0	0	In-H 2 O
BOO	B8	OFF	OFF	OFF	OFF	ON/OFF
FPM	B21	OFF	ON	ON	ON	ON/OFF
TCS	B29	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/NOT DEPRESSED
CPP/PNP	B33	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
ECT	E18	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	VOLTS/DEG F
DPFEGR	E21	0.25-1.30	0.25-1.30	0.25-4.65	0.25-4.65	VOLTS
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	VOLTS/DEG F
MAF	E25	0	0.7-0.9	1.2-1.6	1.6-2.1	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
KNOCK	1	E49	16380	196	173	212 N/A
TP	E61	1.05/CT	1.05/CT	1.21/PT	1.29/PT	VOLTS/CT/ PT/WOT
OSS	T3	0	0	1261	2294	RPM
TSS	T15	0	775	926	1716	RPM
TR2	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
O2S22	T25	0.1	(D)	(D)	(D)	VOLTS
TFT	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	VOLTS/DEG F
ACCS	PID	OFF	ON (A)	OFF	OFF	ON/OFF
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
BARO	PID	14.18/155.1	14.18/155.1	14.18/155.1	14.18/155.1	PSI/Hz
DECHOKE	PID	YES	NO	NO	NO	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	17-28	19-26	30-40	%
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	750	1300-1350	1780	RPM
TORQUE	PID	238.7	10.85	8.13	179	Nm
TPCT	PID	1.05	1.05	1.05	1.05	VOLTS
TR	PID	P	P	OD	OD	MODE
TSS/ISS	PID	0	750	990	1720	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.0L RANGER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	OFF	ON	ON	ON	ON/OFF
PCVHC	E3	0	0	0	0	%
EVMV	E6	0	0	500-900 (F)	500-900 (F)	MA
IAC	E33	0	35	35-41 (L)	57-68 (L)	%
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTRCM11	E69	539	539	535	535	MA
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	504	504	500	500	MA
TCC	T46	0/OFF	0/OFF	0/OFF	100/ENGAGED	%/OFFENGAGED
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTRCM12	T47	938	938	906	906	MA
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
HTRCM22	T48	922	922	945	945	MA
EGR_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	YES	YES	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	0	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	0	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	0	20-25	30-35	30-35	DEG

ACTUATORS/OUTPUTS - 4.0L RANGER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	VOLTS
VREF	B40/T40	5	5	5	5	VOLTS

OTHER - 4.0L RANGER

4.0L Explorer/Explorer Sport Trac/Mountaineer

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.61/0	2.61/0	2.19/-0.11	2.62/0	VOLTS/PSI
APP1	B5	4.0	4.0	3.4-4.0	2.9-4.0	VOLTS
BOO	B8	OFF	ON	(E)	OFF	OFF ON/OFF
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
ACDS1	B16	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLED
APP2	B17	1.4	1.5	1.5-1.9	1.5-2.4	VOLTS
ACP_PRESS	B18	117.97	101.97	81.98	83.98	PSI
APP3	B28	0.9	0.9	0.9-1.3	0.9-1.8	VOLTS
TCS	B29	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/NOT DEPRESSED
ECT	E18	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	VOLTS/DEG F
FRT	E19	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	VOLTS/DEG F
DPFEGR	E21	0.25-1.30	0.25-1.30	0.25-4.65	0.25-4.65	VOLTS
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	VOLTS/DEG F
FANSS	E24	0	300-500	300-550	300-500	RPM
MAF	E25	0	0.7-0.9	1.2-1.8	1.6-2.1	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
FRP	E32	3.4/55	2.8/40	2.8/40	2.8/38	VOLTS/PSI
KNOCK	1	E49	8.19k	132	127	121 N/A
TP2	E60	1.23/24.31	0.75/14.9	0.85/16.86	1.43/28.63	VOLTS/%
TP1	E61	4.05/18.82	4.29.13.73	4.24/14.9	3.96/20.39	VOLTS/%
MAP	E62	4.3/99.97/14.5/29.53 (W)	1.21/29.99/4.35/8.85 (W)	1.43/35.99/5.22/10.63 (W)	0.74/17.23/2.9/5.9 (W)	VOLTS/kPa/PSI/inHg
HTRCM11	E69	523	523	523	523	MA
HTRCM21	E70	477	477	477	477	MA
OSS_SRC	T3	0	0	1250-1330	2100-2400	RPM
TSS	T15	0	630-670	1100-1310	1700-1800	RPM
TR	T16	P	P	OD	OD	MODE
TR2	T17	CLOSED	CLOSED	OPEN	OPEN	VOLTS
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
O2S22	T25	0.1	(D)	(D)	(D)	VOLTS
TFT	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	VOLTS/DEG F
HTRCM12	T47	852	852	852	852	MA
HTRCM22	T48	887	887	887	887	MA
ACDS2	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLED
APP	PID	0	0	15.5	23.5	%
BARO	PID	14.54/157.7	14.54/157.7	14.54/157.7	14.54/157.7	PSI/Hz
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.39	1.5	5.14	12.15	DEG
ETC_DSD	PID	7.62	1.42	5.12	12.22	DEG
ETC_TRIM	PID	0.18 (X)	0.19 (X)	0.21 (X)	0.26 (X)	DEG
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	15-28	19-26	30-40	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	750-820	1300-1520	1600-1780	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.0L EXPLORER/EXPLORER SPORT TRAC/MOUNTAINEER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	20.44/ON	20.65/ON	23.04/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
GENCMD (ILINE)	B32	0	8.62	8.75	8.81	VOLTS
PCVHC	E3	0	0	0	0	%
EVMV	E6	0/OFF	0/OFF	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFFVARYING
FANVAR	E7	0	0/100	13	10	%
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
TCC	T46	0/OFF	0/OFF	0/OFF	100/ON	%/ON-OFF
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	0	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SHRTFT2	PID	0	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SPARKADV	PID	10	13-25	26-35	21-35	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

ACTUATORS/OUTPUTS - 4.0L EXPLORER/EXPLORER SPORT TRAC/MOUNTAINEER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	VOLTS
VREF	E57/T40	5	5	5	5	VOLTS

OTHER - 4.0L EXPLORER/EXPLORER SPORT TRAC/MOUNTAINEER

4.6L 3V Explorer/Explorer Sport Trac/Mountaineer

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	2.6/0	1.98/-0.16	2.05/-0.14	VOLTS/PSI
APP1	B5	4.0	4.0	3.4-4.0	2.9-4.0	VOLTS
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
ACDS1	B16	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLE
APP2	B17	1.4	1.4	1.4-1.9	1.4-2.4	VOLTS
ACP_PRESS	B18	101.97	105.98	87.98	87.98	PSI
APP3	B28	0.9	0.9	0.9-1.3	0.9-1.8	VOLTS
TCS	B29	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/NOT DEPRESSED
FRT	E19	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	VOLTS/DEG F
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	VOLTS/DEG F
FANSS	E24	0	300-1040	300-500	300-500	RPM
MAF	E25	0	0.7-0.9	1.2-1.7	1.5-2.4	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
FRP	E32	3.0/50	2.8/40	2.8/39	2.8/39	VOLTS/PSI
CHT	E41	0.6-3.7/194 (K)	0.6-3.7/194 (K)	0.6-3.7/194 (K)	0.6-3.7/194 (K)	VOLTS/DEG F
TP2	E60	1.27/25.1	0.72/14.51	0.76/14.9	3.96/78.82	VOLTS/%
TP1	E61	4.03/19.22	4.3/13.73	4.28/14.12	2.71/45.88	VOLTS/%
MAP	E62	4.3/99.97/14.5/29.53 (W)	1.21/29.99/4.35/8.85 (W)	1.43/35.99/5.22/10.63 (W)	0.74/17.23/2.9/5.9 (W)	VOLTS/kPa/PSI/inHg
HTRCM11	E69	512	512	512	512	MA
HTRCM21	E70	512	512	512	512	MA
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
O2S22	T25	0.1	(D)	(D)	(D)	VOLTS
HTRCM12	T47	863	863	863	863	MA
HTRCM22	T48	863	863	863	863	MA
ACDS2	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLE
APP	PID	0	0	7	13	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/Hz
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.98	1.43	4.37	5	DEG
ETC_DSD	PID	7.6	1.37	4.24	4.77	DEG
ETC_TRIM	PID	0.3 (X)	0.3 (X)	0.31 (X)	0.31 (X)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	16-23	15-20	25-37	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	630-850	1400-1465	1500-1726	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 3V EXPLORER/EXPLORER SPORT TRAC/MOUNTAINEER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	22.03/ON	19.89/ON	19.5/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
GENCMD (ILINE)	B32	0	8.68	8.81	8.81	VOLTS
EVMV	E6	0/OFF	0/OFF	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFFVARYING
SPKDUR_8	E9	0	1.71	1.65	1.53	MS
SPKDUR_5	E10	0	1.62	1.65	1.59	MS
SPKDUR_2	E11	0	1.71	1.68	1.21	MS
SPKDUR_3	E12	0	1.84	1.78	1.43	MS
SPKDUR_4	E14	0	1.71	1.71	1.4	MS
SPKDUR_6	E15	0	1.65	1.68	1.5	MS
SPKDUR_7	E16	0	1.65	1.59	1.53	MS
SPKDUR_1	E17	0	1.68	1.62	1.21	MS
IMRC	E50	OFF	OFF	OFF	OFF	ON/OFF
VCTDC	E67	0	0	47.49	48.31	DEG
VCTDC2	E68	0	0	41.94	47	DEG
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	0	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SHRTFT2	PID	0	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SPARKADV	PID	0-10	9-16	30-35	28-35	DEG
VCTADV	PID	0	0.37	40.06	47.5	DEG
VCTADV2	PID	0	1	41.94	49.63	DEG
VCTADVERR	PID	0	0.37	1.06	0.75	DEG
VCTADVERR2	PID	0	1	0.75	1.25	DEG

ACTUATORS/OUTPUTS - 4.6L 3V EXPLORER/EXPLORER SPORT TRAC/MOUNTAINEER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	VOLTS
VREF	E57/T40	5	5	5	5	VOLTS

OTHER - 4.6L 3V EXPLORER/EXPLORER SPORT TRAC/MOUNTAINEER

4.6L 2V F-150

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	52.3	33.03	29.4	%
PSP	B15	OFF	ON (I)	OFF	OFF	ON-OFF
APP1	B28	0.78	0.78	0.92	1.41	VOLTS
APP2	B29	0.39	0.39	0.59	0.66	VOLTS
ACP_PRESS	B31	1.63/71.05	1.49/61.91	1.27/48.14	1.2/44.08	VOLTS/PSI
FPM	B32	60.3	60.33	59.7	59.66	%
MAF	B40	0	0.64	1.25	1.89	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.69/123.8 (K)	2.01/109.4 (K)	3.15/73.4 (K)	3.54/57.2 (K)	VOLTS/DEG F
FTP	B65	2.62/0	2.37/-0.06	2.41/-0.05	2.26/-0.09	VOLTS/PSI
CHT	E15	0.6/195.8	0.6/194	0.66/186.8	0.66/186.8	VOLTS/DEG F
MAP	E40	4.34/100.9/14.64/29.8 (W)	1.24/30.95/4.49/9.14 (W)	1.84/44.95/6.52/13.27 (W)	3.05/71.98/10.44/21.25 (W)	VOLTS/kPa/PSI/inHg
TP1	E44	4.06	4.28	3.91	3.94	VOLTS
TP2	E45	1.25	0.82	1.55	1.48	VOLTS
KNOCK_1	E46	261	320	887	774	N/A
DPFEGR	E48	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	VOLTS
OSS_SRC	T2	0	0	1214	2266	RPM
O2S12	T16	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
TFT	T19	179.6 (K)	176 (K)	154.4 (K)	150.8 (K)	DEG F
TFTV	T19	0.77 (K)	0.81 (K)	1.13 (K)	1.19 (K)	VOLTS
O2S22	T20	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
TR	T26	PARK	PARK	OVERDRIVE	OVERDRIVE	MODE
TR2	T27	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
TSS_SRC	T37	0	593.3	858.3	1581	RPM
APP	PID	0	0	5	20.5	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/Hz
B+	PID	12.6	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_ACT	PID	7.66	1.94	3.03	11.66	DEG
ETC_DSD	PID	7.62	1.97	2.99	11.34	DEG
ETC_TRIM	PID	0.36 (X)	0.36 (X)	0.36 (X)	0.36 (X)	DEG
GEAR	PID	1	1	3	4	GEAR
LOAD	PID	0	(L)	21.96	37.26	60.39 %
O2S11_CUR	PID	255.7 (mA)	256 (mA)	86 (uA)	66 (uA)	MA/uA
O2S11_IMPED	PID	4.95	1.05	0.97	1.04	VOLTS
O2S21_CUR	PID	255.6 (mA)	256 (mA)	98 (uA)	74 (uA)	MA/uA
O2S21_IMPED	PID	4.96	1.01	1.07	1	VOLTS
PSP_V	PID	0.5	0.67	0.79	0.77	VOLTS
RPM	PID	0	597.5	1222	1584	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 2V F-150

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/OFF	30.37/ON	31.05/ON	30.76/ON	%/ON-OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
GENCMD	B53	3.57	0 (Q)	0 (Q)	0 (Q)	%
PCVHC	E6	0	0	0	0	%
EGRPCT	E21	0	0	0 (T)	60.39 (T)	%
EVAPCP	E31	0	41.57	42.75	0	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T18	OFF (O)	ON	ON	ON	ON/OFF
TCC	T22	0	0	0	100	%
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
OTS_STAT	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	1.75	12.5	31.75	19.25	DEG

ACTUATORS/OUTPUTS - 4.6L 2V F-150

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E63/T10	5	5	5	5	VOLTS
VPWR	B67/B68	12.62	13-14	13-14	13-14	VOLTS

OTHER - 4.6L 2V F-150

4.6L 3V F-150

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FANSS	B12	6375	250	375	400	RPM
BOO1	B13	OFF	ON	(E)	OFF	OFF ON/OFF
GENMON	B14	0	37.71	27.03	23.14	%
PSP	B15	OFF	ON (I)	OFF	OFF	ON-OFF
APP1	B28	0.78	0.78	0.92	1.18	VOLTS
APP2	B29	0.39	0.39	0.46	0.59	VOLTS
ACP_PRESS	B31	1.59/68.29	1.5/62.78	1.28/48.72	1.17/42.19	VOLTS/PSI
FPM	B32	59.7	60.33	59.66	59.76	%
MAF	B40	0	0.68	1.45	1.53	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.81/118.4 (K)	2.11/107.6 (K)	3.09/71.6 (K)	3.39/62.6 (K)	VOLTS/DEG F
FTP	B65	2.62/0	2.62/0	2.02/-0.15	2.47/-0.03	VOLTS/PSI
CHT	E15	3.52/201.2	3.48/203	3.42/206.6	3.44/206.6	VOLTS/DEG F
TP1	E44	4.12	4.34	4.25	4.06	VOLTS
TP2	E45	1.18	0.73	0.91	1.3	VOLTS
KNOCK_1	E46	175	120	219	180	N/A
KNOCK_2	E62	176	197	364	222	N/A
O2S12	T16	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
O2S22	T20	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
APP	PID	0	0	4.5	13	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.35/156.1	PSI/Hz
B+	PID	12.6	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_ACT	PID	7.37	1.45	3.82	7.98	DEG
ETC_DSD	PID	7.62	1.5	3.86	8.41	DEG
ETC_TRIM	PID	0.13 (X)	0.13 (X)	0.19 (X)	0.12 (X)	DEG
FLI	PID	61.96	61.96	57.65	58.43	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	0	(L)	20	60	50.59 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	16 (uA)	256 (mA)	255.9 (mA)	255.9 (mA)	MA/uA
O2S11_IMPED	PID	4.97	1.04	0.87	1	VOLTS
O2S21_CUR	PID	255.9	256	255.9	255.9	MA
O2S21_IMPED	PID	4.97	1.01	1	1.07	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
PSP_V	PID	0.48	0.71	0.75	0.76	VOLTS
RPM	PID	0	619	1401	1549	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 3V F-150

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/OFF	30.42/ON	30.7/ON	30.59/ON	%/ON-OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
GENCMD	B53	3.57	0 (Q)	0 (Q)	0 (Q)	%
IMRC	E22	OFF	OFF	OFF	OFF	ON/OFF
EVAPCP	E31	0	0	47.06	0	%
VCTDC	E67	0	0	43.45	47.73	%
VCTDC2	E68	0	0	43.51	44.69	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T18	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
OTS_STAT	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
PCVHC	PID	0	0	0	0	%
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	34	18	40	36.75	DEG
VCT_DSD	PID	0	0	39.44	49.75	DEG
VCTADV	PID	0	0.56	40.69	49.13	DEG
VCTADV2	PID	0	0.06	39.13	49.44	DEG
VCTADVERR	PID	0	0.56	1.12	0.62	DEG
VCTADVERR2	PID	0	0.06	0.25	0.31	DEG

ACTUATORS/OUTPUTS - 4.6L 3V F-150

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E63/T10	5	5	5	5	VOLTS
VPWR	B67/B68	12.7	13-14	13-14	13-14	VOLTS

OTHER - 4.6L 3V F-150

5.4L 3V F-150

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FANSS	B12	6375	225	350	450	RPM
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	30.44	21.47	14.44	%
PSP	B15	OFF	ON (I)	OFF	ON	ON-OFF
APP1	B28	0.73	0.73	0.89	1.44	VOLTS
APP2	B29	0.37	0.37	0.44	0.72	VOLTS
ACP_PRESS	B31	1.38/64.38	1.3/60.17	1.18/53.79	1.22/55.68	VOLTS/PSI
FPM	B32	60.3	60.33	60.33	59.66	%
MAF	B40	0.01	0.71	1.31	1.87	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	2.08/109.4 (K)	2.42/96.8 (K)	3.26/66.2 (K)	3.26/66.2 (K)	VOLTS/DEG F
FTP	B65	2.62/0	2.5/-0.02	1.53/-0.27	2.03/-0.15	VOLTS/PSI
CHT	E15	3.6/201	3.5/204	3.5/201	3.5/207	VOLTS/DEG F
TP1	E44	4.08	4.32	4.26	4.14	VOLTS
TP2	E45	1.26	0.73	1.22	1.27	VOLTS
KNOCK_1	E46	254	185	256	434	N/A
KNOCK_2	E62	215	202	242	469	N/A
HTRCM11	E69	0	0	1.83	1.83	AMPS
O2S12	T16	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
HTRCM12	T18	0	0	989	989	MA
O2S22	T20	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
APP	PID	0	0	5	22	%
BARO	PID	14.67/158.5	14.67/158.5	14.67/158.5	14.67/158.5	PSI/Hz
B+	PID	12.83	13-14	13-14	13-14	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.65	0.71	3.49	11.52	DEG
ETC_DSD	PID	7.6	0.75	3.47	11.52	DEG
ETC_TRIM	PID	0.26 (X)	0.22 (X)	0.19 (X)	0.19 (X)	DEG
FLI	PID	90.98	90.98	87.84	85.88	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	0	(L)	18.82	34.12	83.92 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	256 (mA)	20 (uA)	8 (uA)	148 (uA)	MA/uA
O2S11_IMPED	PID	4.97	1.03	0.88	1.05	VOLTS
O2S21_CUR	PID	255.9 (mA)	256 (mA)	8 (uA)	184 (uA)	MA/uA
O2S21_IMPED	PID	4.97	1	0.88	0.94	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
PSP_V	PID	0.49	0.67	0.73	0.76	VOLTS
RPM	PID	0	605	1013	1487	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 3V F-150

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/OFF	29.08/ON	28.08/ON	28.29/ON	%/ON-OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
GENCMD	B53	3.57	0 (Q)	0 (Q)	0 (Q)	%
EVAPCP	E31	0	39.61	0	0	%
VCTDC	E67	0	0	42.33	43.89	%
VCTDC2	E68	0	0	43.23	45.18	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T18	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	YES	YES	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
OTS_STAT	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
PCVHC	PID	0	0	0	0	%
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	33.75	13	33.5	41.75	DEG
VCT_DSD	PID	0	0	38.44	51.19	DEG
VCTADV	PID	0	0	36.13	50.63	DEG
VCTADV2	PID	0	0	38.81	51	DEG
VCTADVERR	PID	0	0.43	0.56	0.25	DEG
VCTADVERR2	PID	0	0.25	0.87	0.25	DEG

ACTUATORS/OUTPUTS - 5.4L 3V F-150

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E63/T10	5	5	5	5	VOLTS
VPWR	B67/B68	12.62	13-14	13-14	13-14	VOLTS

OTHER - 5.4L 3V F-150

4.6L 2V E-Series

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	30.45	21.87	19.53	%
APP1	B28	0.79	0.79	1.44	1.89	VOLTS
APP2	B29	0.39	0.39	0.72	0.94	VOLTS
FPM	B32	60.3	60.33	60.24	59.66	%
MAF	B40	0.01	0.61	1.7	2.42	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	2.55/91.4 (K)	3.28/66.2 (K)	4.22/26.6 (K)	4.26/24.8 (K)	VOLTS/DEG F
FTP	B65	2.62/0	2.62/0	1.66/-0.24	2.62/0	VOLTS/PSI
CHT	E15	0.65/188.6	0.78/177.8	0.64/190.4	0.69/185	VOLTS/DEG F
MAP	E40	4.3/100.93/ 14.64/29.8 (W)	1.2/31.99/ 4.64/9.44 (W)	2.7/64.94/9.42/19.17 (W)	3.39/78.94/11.45/23.31 (W)	VOLTS/kPa/PSI/inHg
TP1	E44	4.1	4.32	3.8	3.81	VOLTS
TP2	E45	1.25	0.9	1.86	1.83	VOLTS
KNOCK_1	E46	259	260	953	867	N/A
DPFEGR	E48	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	VOLTS
HTRCM11	E69	0	1.8	1.71	1.74	AMPS
OSS_SRC	T2	0	0	1415	2623	RPM
O2S12	T16	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
HTRCM12	T18	0 (A)	1.15	(A) 979 (mA)	983 (mA)	MA/A
TFT	T19	104 (K)	105.8 (K)	100.4 (K)	111.2 (K)	DEG F
TFTV	T19	2.22	(K)	2.19	(K)	2.32 (K) 2.03 (K) VOLTS
O2S22	T20	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
TR	T26	PARK	PARK	OVERDRIVE	OVERDRIVE	MODE
TR2	T27	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
TSS_SRC	T37	0	604.5	595.8	1813	RPM
APP	PID	0	0	20.5	34.5	%
BARO	PID	14.36/156.6	14.36/156.6	14.36/156.6	14.36/156.6	PSI/Hz
B+	PID	12.9	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_ACT	PID	7.56	2.18	5.18	7.99	DEG
ETC_DSD	PID	7.62	2.15	5.22	8.01	DEG
ETC_TRIM	PID	0.12 (X)	0.12 (X)	0.04 (X)	0.13 (X)	DEG
FLI	PID	9.8 (H)	10.2 (H)	7.84 (H)	10.98 (H)	%
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	0	(L)	20.78	20	79.61 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	255.2 (mA)	256 (mA)	86 (uA)	51 (uA)	MA/uA
O2S11_IMPED	PID	4.96	1	0.95	0.93	VOLTS
O2S21_CUR	PID	255.8 (mA)	78 (uA)	256 (mA)	70 (uA)	MA/uA
O2S21_IMPED	PID	4.96	1.02	1.02	0.94	VOLTS
RPM	PID	0	626	937	1771	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 2V E-SERIES

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
GENCMD	B53	3.57	0 (Q)	0 (Q)	0 (Q)	%
PCVHC	E6	0	0	100	100	%
EGRPCT	E21	0	0	36.86	(T)	66.67 (T) %
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T18	OFF (O)	ON	ON	ON	ON/OFF
TCC	T22	0	0	0	100	%
EGR_EVAL	PID	YES	YES	NO	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	YES	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
OTS_STAT	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	7.25	12.75	34.25	29.75	DEG

ACTUATORS/OUTPUTS - 4.6L 2V E-SERIES

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E63/T10	5	5	5	5	VOLTS
VPWR	B67/B68	12.44	13-14	13-14	13-14	VOLTS

OTHER - 4.6L 2V E-SERIES

5.4L 2V E-Series

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PTO (5R110W)	B3	OFF	OFF	OFF	OFF	ON/OFF
PTOLOAD	B6	NO	NO	NO	NO	YES/NO
PTOIR_V (5R110W)	B8	0	0	0	0	VOLTS
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	52.95	30.3	33.43	%
APP1	B28	0.78	0.78	1.33	1.62	VOLTS
APP2	B29	0.39	0.39	0.67	0.81	VOLTS
FPM	B32	59.7	60.3	60.33	59.66	%
MAF	B40	0	0.71	1.49	1.58	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.9/114.8 (K)	2.51/93. (K)	3.91/41 (K)	4/35.6 (K)	VOLTS/DEG F
FTP	B65	2.6/0 (M)	2.6/0 (M)	2.1/-0.13 (M)	1.95/-0.17 (M)	VOLTS/PSI
FTP_H2O	B65	0.06	0.75	0.03	0.13	In-H 2 O
CHT	E15	0.61/192	0.67/190.4	0.91/167	0.65/188.6	VOLTS/DEG F
TP1	E44	4.11	4.31	3.88	3.64	VOLTS
TP2	E45	1.23	0.92	1.78	2.27	VOLTS
KNOCK	1	E46	41	41	61	91 N/A
HTRCM11	E69	0	1.7	1.7	1.7	AMPS
OSS_SRC	T2	0	0	1298	2359	RPM
O2S12	T16	(L) (M)	(D) (M)	(D) (M)	(D) (M)	VOLTS
HTRCM12	T18	0	1.26	1.33	1.33	AMPS
O2S22	T20	0 (M)	(D) (M)	(D) (M)	(D) (M)	VOLTS
APP	PID	0	0	17	26	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.21/155.2	PSI/Hz
B+	PID	12.52	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_ACT	PID	7.47	2.1	11.09	15.9	DEG
ETC_DSD	PID	7.62	2.06	11.06	15.87	DEG
ETC_TRIM	PID	0.33 (X)	0.35 (X)	0.3 (X)	0.3 (X)	DEG
FLI	PID	9.41 (H)	9.41 (H)	6.27 (H)	6.66 (H)	%
GEAR (4R75E)	PID	1	1	4	4	GEAR
GEAR (5R110W)	PID	1	1	5	6	GEAR
LOAD	PID	0	(L)	24.71	34.9	52.16 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	255.9 (mA)	256 (mA)	246 (uA)	8 (uA)	MA/uA
O2S11_IMPED	PID	4.96	1.02	1.07	1.03	VOLTS
O2S21_CUR	PID	255.9 (mA)	256 (mA)	211 (uA)	256 (mA)	MA/uA
O2S21_IMPED	PID	4.97	1.02	0.97	0.99	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
RPM	PID	0	720	1100	1600	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 2V E-SERIES

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PTOIL	B11	OFF	OFF	OFF	OFF	ON-OFF
FP	B19	75/OFF	20/ON	20/ON	23/ON	%/ON-OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
GENCMD	B53	3.57	0	0	0	%
EVAPCP	E31	0	39.61	0	0	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T18	OFF (O)	ON	ON	ON	ON/OFF
TCC (4R75E)	T22	0/OFF	0/OFF	0/OFF	39.29/ENGAGED	%/OFFENGAGED
HTR22	T48	ON (M) (O)	ON (M)	ON (M)	ON (M)	ON/OFF
TSPC (5R110W)	T50	VBAT	VBAT	VBAT	VBAT	VOLTS
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	27.5	11	22.75	8.75	DEG

ACTUATORS/OUTPUTS - 5.4L 2V E-SERIES

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B67/B68	12-13	13-14	13-14	13-14	VOLTS
VREF	B52/E63/T10	5	5	5	5	VOLTS

OTHER - 5.4L 2V E-SERIES

6.8L 2V E-Series

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	1.77/0 (M)	1.6/0 (M)	2.18/-0.11 (M)	VOLTS/PSI
FTP_H2O	B3	0	6	7.2	3.1	In-H 2 O
APP1	B5	4.09	4.09	4.07	3.83	VOLTS
PTOIR_V	B7	0	0	0	0	VOLTS
BOO1	B8	OFF	ON (E)	OFF	OFF	ON/OFF
PTOLOAD	B9	NO	NO	NO	NO	YES/NO
APP2	B17	1.44	1.44	1.46	1.64	VOLTS
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
APP3	B28	0.9	0.9	0.91	1.2	VOLTS
GENMON	E6	0	39.43	22.27	19.13	%
IAT	E22	2.2/104 (K)	2.62/89 (K)	3.16/69.8 (K)	3.12/71.6 (K)	VOLTS/DEG F
MAF	E25	0	0.75	1.56	1.8	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
CHT	E41	0.7/186.8	0.7/183.2	0.7/192.2	0.68/186.8	VOLTS/DEG F
TP2	E60	1.16	0.73	0.82	1.54	VOLTS
TP1	E61	4.09	4.32	4.29	3.93	VOLTS
BOO2	E65	OFF	ON (E)	OFF	OFF	ON/OFF
HTRCM11	E69	0	0	0	479	MA
OSS_SRC	T3	0	0	1317	2261	RPM
TSS_SRC	T15	0	588.5	824	1618	RPM
O2S12	T24	(L) (M)	(D) (M)	(D) (M)	(D) (M)	VOLTS
O2S22	T25	0 (M)	(D) (M)	(D) (M)	(D) (M)	VOLTS
TFT	T29	105 (K)	102 (K)	143 (K)	165 (K)	DEG F
TFT_V	T29	2.2 (K)	2.27 (K)	1.32 (K)	0.97 (K)	VOLTS
HTRCM12	T47	0	0	0	916	MA
ACC_CMD	PID	OFF	ON (A)	OFF	OFF	ON/OFF
APP	PID	0	0	0.5	12.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
B+	PID	12.54	13-14	13-14	13-14	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.54	1.62	7.29	7.75	DEG
ETC_DSD	PID	8	1.6	6.93	7.68	DEG
ETC_TRIM	PID	0.03 (X)	0.04 (X)	0.03 (X)	0.07 (X)	DEG
GEAR	PID	1	1	6	6	GEAR
LOAD	PID	0	(L)	26	44	51 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	670	1290	1659	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 6.8L 2V E-SERIES

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B13	0/OFF (M)	0/OFF (M)	0/OFF (M) (R)	0/OFF (M) (R)	%/ON-OFF
PTOIL	B42	OFF	OFF	OFF	OFF	ON/OFF
TCIL	B43	OFF	OFF	OFF	OFF	ON/OFF
EVAPCP	E1	0	93.73	97.26	0	%
PCVHC	E2	0	0	0	0	%
GENCMD	E7	3.57	0	0	0	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T47	OFF (M) (O)	ON (M)	ON (M)	ON (M)	ON/OFF
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	YES	YES	YES	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+)20	(-)20 TO (+)20	%
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+)10	(-)10 TO (+)10	%
SPARKADV	PID	10	13.5	33.5	26-34	DEG

ACTUATORS/OUTPUTS - 6.8L 2V E-SERIES

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	12-13	13-14	13-14	13-14	VOLTS
VREF	E57/T40	5	5	5	5	VOLTS

OTHER - 6.8L 2V E-SERIES

5.4L 3V Expedition/Navigator

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FANSS	B12	6375	250	225	300	RPM
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	42.75	23.8	19.71	%
PSP	B15	OFF	ON (I)	OFF	ON	ON-OFF
APP1	B28	0.8	0.8	1.28	1.63	VOLTS
APP2	B29	0.41	0.41	0.64	0.82	VOLTS
ACP_PRESS	B31	1.54/73.51	1.5/70.76	1.47/69.16	1.33/62.06	VOLTS/PSI
FPM	B32	40.34	40.3	40.3	39.66	%
MAF	B40	0	0.77	1.03	1.75	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	2.12/107.6 (K)	2.62/89.6 (K)	3.01/75.2 (K)	3.07/73.4 (K)	VOLTS/DEG F
FTP	B65	2.6/0	2.6/0	1.78/-0.21	2.3/-0.08	VOLTS/PSI
FTP_H2O	B65	2.6/0	2.6/0	1.78/-0.21	2.3/-0.08	In-H 2 O
CHT	E15	3.6/201	3.5/204	3.37/208	3.5/201	VOLTS/DEG F
TP1	E44	4	4.3	4.2	4.2	VOLTS
TP2	E45	1.26	0.74	1.02	1.01	VOLTS
KNOCK_1	E46	181	184	193	261	N/A
KNOCK_2	E62	240	267	206	351	N/A
HTRCM11	E69	0	0	1.68	1.68	AMPS
O2S12	T16	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
HTRCM12	T18	0	0	909	909	MA
O2S22	T20	(L)	Switching (D)	Switching (D)	Switching (D)	VOLTS
APP	PID	0	0	14.5	26	%
B+	PID	12.65	13-14	13-14	13-14	VOLTS
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_ACT	PID	7.56	0.83	2.76	15.27	DEG
ETC_DSD	PID	7.62	0.85	2.79	15.29	DEG
ETC_TRIM	PID	0 (X)	0 (X)	0 (X)	0 (X)	DEG
FLI	PID	91.77 (H)	92.16 (H)	91.37 (H)	87.45 (H)	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	0	(L)	22.35	41.96	60.39 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	256 (mA)	256 (mA)	621 (uA)	55 (uA)	MA/uA
O2S11_IMPED	PID	4.97	1.01	1.05	0.96	VOLTS
O2S21_CUR	PID	256	(mA)	4	(uA)	680 (uA) -66 (uA) mA/uA
O2S21_IMPED	PID	4.97	1.03	0.82	1.02	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
PSP_V	PID	0.5	0.69	0.79	0.77	VOLTS
RPM	PID	0	695	1087	1497	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 3V EXPEDITION/NAVIGATOR

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/OFF	29.4/ON	28.5/ON	28.96/ON	%/ON-OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
GENCMD	B53	3.57	0 (Q)	0 (Q)	0 (Q)	%
EVAPCP	E31	0	32.16	0	98.82	%
VCTDC	E67	0	0	42.26	42.56	%
VCTDC2	E68	0	0	43.77	41.35	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T18	OFF (O)	ON	ON	ON	ON/OFF
CHT_F	PID	NO	FAULT	NO	FAULT	NO FAULT NO FAULT FAULT/ NO FAULT
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+) 20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
OTS_STAT	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
PCVHC	PID	0	0	0	0	%
SHRTFT1	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+) 10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	29.5	11.25	45.25	46.75	DEG
VCTADV	PID	0	0.31	45	20.5	DEG
VCTADV2	PID	0	0.3	45.5	20.13	DEG
VCTADVERR	PID	0	0.5	0.62	0.25	DEG
VCTADVERR2	PID	0	0.62	0.31	0.62	DEG
VCT_DSD	PID	0	0	50.56	40.38	DEG

ACTUATORS/OUTPUTS - 5.4L 3V EXPEDITION/NAVIGATOR

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E63/T10	5	5	5	5	VOLTS
VPWR	B67/B68	12.77	13-14	13-14	13-14	VOLTS

OTHER - 5.4L 3V EXPEDITION/NAVIGATOR

5.4L 3V

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
SMC_MON	B2	OFF	OFF	OFF	OFF	ON/OFF
FTP	B3	2.6/0.61 (M)	2.6/0.61 (M)	2.3/0.61 (M)	1.45/0.61 (M)	VOLTS/PSI
FTP_H2O	B3	0.06 (M)	0.03 (M)	2.17 (M)	8.34 (M)	In-H 2 O
APP1	B5	4.1	4.1	3.47	3.73	VOLTS
PTOIR_V	B7	0	0	0	0	VOLTS
BOO	B8	OFF	ON (E)	OFF	OFF	ON-OFF
APP2	B17	1.5	1.5	1.8	1.66	VOLTS
FPM	B21	0	0	0	0	%
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
APP3	B28	0.9	0.9	1.32	1.12	VOLTS
TCSS/VSS	B29	0	0	30	55	MPH
CPP/PNP (M/T)	B34	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
WAC/ACCR	E3	OFF	OFF	OFF	OFF	ON/OFF
ACCS	E4	OFF	OFF	OFF	OFF	ON/OFF
FRT	E19	1.9/116.6 (K)	1.94/114.8 (K)	2.38/98.6 (K)	2.28/102.2 (K)	VOLTS/DEG F
IAT	E22	1.96/111.2 (K)	2.11/105.8 (K)	2.65/84.2 (K)	3.38/57.2 (K)	VOLTS/DEG F
MAF (A/T)	E25	0	0.8	1.33	2.28	VOLTS
MAF (M/T)	E25	0	0.83-0.91	1-1.6	1.7-2.4	VOLTS
O2S11	E28	(L)	(D)	(D)	(D)	VOLTS
O2S21	E29	(L)	(D)	(D)	(D)	VOLTS
KNOCK	2	E31	0	171	329	381 N/A
FRP	E32	3.77/57.34	2.8/40	2.8/40	2.7/41.26	VOLTS/PSI
CHT	E41	0.56/197.6	0.55/199.4	3.51/204	3.4/210	VOLTS/DEG F
KNOCK	1	E49	0	235	443	393 N/A
TP2	E60	1.2/27	0.7/17	1.1/23.53	1.85/36.47	VOLTS/%
TP1	E61	4.1/18.43	4.3/13.73	4.1/17	3.8/23.92	VOLTS/%
BPA	E65	OFF	OFF	OFF	OFF	ON/OFF
HTRCM11	E69	1.66	1.66	1.66	1.49	AMPS
HTRCM21	E70	1.66	1.66	1.66	1.5	AMPS
OSS (A/T)	T3	0	0	1185	2042	RPM
TSS	T15	0	619	1127	1472	RPM
O2S12	T24	(L)	(D)	(D)	(D)	VOLTS
O2S22	T25	0	(D)	(D)	(D)	VOLTS
TFT (A/T)	T29	1.92/116.6 (K)	1.94/114 (K)	1.2/149 (K)	0.94/168.8 (K)	VOLTS/DEG F
HTRCM12	T47	1.09 (AMP)	1.09 (AMP)	1.09 (AMP)	895 (mA)	MA/AMP
HTRCM22	T48	1.08 (AMP)	1.08 (AMP)	1.08 (AMP)	883 (mA)	MA/AMP
ACP	PID	OPEN (OK)	OPEN (OK)	OPEN (OK)	OPEN (OK)	OPEN/CLOSED
APP	PID	0	0	16	8	%
APP_MODE	PID	NO PEDAL	NO PEDAL	PART PEDAL	PART PEDAL	NO PEDAL/PART PEDAL
BARO	PID	14.79/159.3	14.79/159.3	14.73/158.9	14.86/159.7	PSI/Hz
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
ETC_ACT	PID	7.62	1.43	9.02	11.83	DEG
ETC_DSD	PID	7.62	1.36	9.01	11.71	DEG
ETC_TRIM	PID	0.02 (X)	0.02 (X)	0 (X)	0.03 (X)	DEG
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	89 (H)	88 (H)	85 (H)	95 (H)	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	61	15	36	46	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	NO	NO	NO	NO	YES/NO
O2S_EVAL	PID	NO	NO	YES	YES	YES/NO
PTOLOAD	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	722	1288	1565	RPM
VCTADVERR	PID	0	0.62	1	1.37	DEG
VCTADVERR2	PID	0	0.18	1	1.12	DEG
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 3V F-SUPER DUTY

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	20.4/ON	24.5/ON	24.9/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	(R)	0/OFF (R) %/ON-OFF
PTOIL	B42	OFF	OFF	OFF	OFF	ON/OFF
TCIL	B43	OFF	OFF	OFF	OFF	ON/OFF
EVMV	E1	0	207 (mA)	716 (mA)	506 (mA)	MA
PCVHC	E2	0	0	0	0	%
WAC/ACCR	E3	OFF	OFF (A)	OFF	OFF	ON-OFF
VCTDC	E67	0	0	39	44.46	VOLTS
VCTDC2	E68	0	0	45.92	43.12	VOLTS
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR21	E70	OFF	ON	ON	ON	ON/OFF
HTR12	T47	OFF	ON	ON	ON	ON/OFF
HTR22	T48	OFF	ON	ON	ON	ON/OFF
VCTADV	PID	0	0.62	52.06	50.25	DEG
VCTADV2	PID	0	0.18	52.06	49.88	DEG
O2SHTR_EVAL	PID	NO	NO	YES	YES	YES/NO
FRP_DSD	PID	49.99	40	40	40	PSI
RPMDSD	PID	640	640	624	624	RPM
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	15.75	43.25	23	DEG

ACTUATORS/OUTPUTS - 5.4L 3V F-SUPER DUTY

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	12-13	13-14	13-14	13-14	VOLTS
VREF	E57	5	5	5	5	VOLTS

OTHER - 5.4L 3V F-SUPER DUTY

6.8L 3V

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.6/0 (M)	1.6/-0.26 (M)	VOLTS/PSI
APP1	B5	4	4	3.9	3.7	VOLTS
PTOIR_V	B7	0.02	0.02	0.02	0	VOLTS
BOO	B8	VBAT/OFF	0.1/ON	(E)	VBAT/OFF	VBAT/OFF VOLTS/ ON-OFF
PTOLOAD	B9	NO	NO	NO	NO	YES/NO
O2S13	B14	0 (M)	(D) (M)	(D) (M)	(D) (M)	VOLTS
APP2	B17	1.5	1.5	1.6	1.8	VOLTS
FPM	B21	0.1-VBAT	0.1-VBAT	0.1-VBAT	0.1-VBAT	VOLTS
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
TCS (A/T)	B27	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	VOLTS/ON-OFF
APP3	B28	1	1.1	1.3	1.5	VOLTS
VSS	B29	0	0	30	55	MPH
CPP BOT (M/T)	B34	NO	NO	NO	NO	YES/NO
ACCS	E4	0.1/OFF	VBAT/ON (A)	0.1/OFF	0.1/OFF	VOLTS/ON-OFF
FRT	E19	2.5/97 (K)	2.5/93 (K)	2.9/79 (K)	3/79 (K)	VOLTS/DEG F
IAT	E22	2.9/73 (K)	3.3/59 (K)	3.7/45 (K)	3.7/43 (K)	VOLTS/DEG F
MAF (A/T)	E25	0	1.1	1.2	2.1	VOLTS
MAF (M/T)	E25	0	1.1	1.2	2.1	VOLTS
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	VOLTS
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	VOLTS
KNOCK	2	E31	32770	206	245	303 N/A
FRP	E32	3.5/53	3.7/39	3.7/39	2.7/39	VOLTS/PSI
CHT	E41	0.61/192.2	0.6/194	3.58/201.2	3.56/204.8	VOLTS/DEG F
CMP	E45	0	6.5-10	10-13	13-16	Hz
CKP	E47	0	420-520	800-1050	1100-1300	Hz
KNOCK	1	E49	32770	205	212	319 N/A
TP2	E60	1.3	0.9	1	1.4	VOLTS
TP1	E61	4.1	4.3	4.2	4	VOLTS
BPA	E65	0.1/OFF	VBAT/ON (E)	0.1/OFF	0.1/OFF	VOLTS/ ON-OFF
OSS	T3	0	0	1194	2278	RPM
ISS	T4	0	782	860	1623	RPM
TSS	T15	0	782	860	1623	RPM
O2S12	T24	(L) (M)	(D) (M)	(D) (M)	(D) (M)	VOLTS
O2S22	T25	0 (M)	(D) (M)	(D) (M)	(D) (M)	VOLTS
TFT (A/T)	T29	1.6/132 (K)	1.5/136 (K)	1.1/154 (K)	1.1/158 (K)	VOLTS/DEG F
APP	PID	0	0	15.5	26.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.05/154.7	14.3/156.2	PSI/Hz
CPP/PNP	(A/T)	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE NEUTRAL/ DRIVE
ETC_TRIM	PID	0.11 (X)	0.11 (X)	0.12 (X)	0.13 (X)	DEG
GEAR (A/T)	PID	1	1	6	6	GEAR
LOAD	PID	63	(L)	14.37	17	36.92 %
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	654	1127	1618	RPM
VSS	PID	0	0	48km/h (30MPH)	89km/h (55MPH)	Km/h / MPH

SENSORS/INPUTS - 6.8L 3V F-SUPER DUTY

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VSO	B1	0	0	65	125	Hz
SMC	B2	0	0	0	0	VOLTS
FP	B12	75	20	20.8	21.3	%
EVAPCV	B13	VBAT/0 (M)	VBAT/0 (M)	VBAT/0 (M) (R)	VBAT/0 (M) (R)	VOLTS/%
PTOIL	B42	OFF	OFF	OFF	OFF	ON/OFF
TCIL (A/T)	B43	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	VOLTS/ON-OFF
EVMV	E1	0	363	0	620	MA
PCVHC	E2	0 (M)	0 (M)	0 (M)	0 (M)	%
WAC/ACCR	E3	VBAT/OFF	0.1/ON (A)	VBAT/OFF	VBAT/OFF	VOLTS/ ON-OFF
CDD (CYL 10)	E8	VBAT	VBAT	VBAT	VBAT	VOLTS
CDH (CYL 8)	E9	VBAT	VBAT	VBAT	VBAT	VOLTS
CDC (CYL 5)	E10	VBAT	VBAT	VBAT	VBAT	VOLTS
CDE (CYL 2)	E11	VBAT	VBAT	VBAT	VBAT	VOLTS
CDG (CYL 3)	E12	VBAT	VBAT	VBAT	VBAT	VOLTS
CDJ (CYL 9)	E13	VBAT	VBAT	VBAT	VBAT	VOLTS
CDI (CYL 4)	E14	VBAT	VBAT	VBAT	VBAT	VOLTS
CDB (CYL 6)	E15	VBAT	VBAT	VBAT	VBAT	VOLTS
CDF (CYL 7)	E16	VBAT	VBAT	VBAT	VBAT	VOLTS
CDA (CYL 1)	E17	VBAT	VBAT	VBAT	VBAT	VOLTS
TACM (+)	E34	3.7	VBAT	VBAT	VBAT	VOLTS
TACM (-)	E51	3.7	VBAT	VBAT	VBAT	VOLTS
IMTV	E64	0	0	0	VBAT	VOLTS
HTR11	E69	0.1/ON	(O)	0.1/ON	0.1/ON	0.1/ON VOLTS/ ON-OFF
HTR21	E70	0.1/ON	(O)	0.1/ON	0.1/ON	0.1/ON VOLTS/ ON-OFF
HTR12	T47	0.2/ON (M) (O)	0.2/ON (M)	0.2/ON (M)	0.2/ON (M)	VOLTS/ON-OFF
HTR22	T48	0.2/ON (M) (O)	0.2/ON (M)	0.2/ON (M)	0.2/ON (M)	VOLTS/ON-OFF
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
LONGFT1	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
LONGFT2	PID	(L)	(-)20 TO (+)20	(-)20 TO (+) 20	(-)20 TO (+) 20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SHRTFT2	PID	(L)	(-)10 TO (+)10	(-)10 TO (+) 10	(-)10 TO (+) 10	%
SPARKADV	PID	10	13.75	29.5	27.25	DEG

ACTUATORS/OUTPUTS - 6.8L 3V F-SUPER DUTY

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	Ignition On Engine Off	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 6.8L 3V F-SUPER DUTY
