VECI Decal Location
The typical location of the decal is on the underside of the hood or the radiator support sight shield.
VC Label Decal Location
The VC label is on the LH door or the door post pillar.
PCM Location
The PCM is located behind the instrument panel (cowl), center to both driver and passenger sides (access from the engine compartment).
Scheme 117
| Item | Number | Description |
|---|---|---|
| 1 | Body | |
| 2 | Engine | |
| 3 | Transmission |
ITEM DESCRIPTION CHART
| Function | Description | Connector/Pin |
|---|---|---|
| VPWR | Voltage to module | B67 |
| VPWR | Voltage to module | B68 |
| PWRGND | Power ground | B69 |
| PWRGND | Power ground | B70 |
| CSEGND | Case ground | B50 |
| SIGRTN | Connector B signal return | B58 |
| SIGRTN | Connector E signal return | E64 |
| SIGRTN | Connector T signal return | T40 |
| VREF | Connector B buffered 5 volt reference | B52 |
| VREF | Connector E buffered 5 volt reference | E63 |
| KAPWR | Keep alive power | B62 |
190-PIN PCM POWER AND GROUNDS TABLE 1
