Starting System: Other Ford Escape I рестайлинг

Hybrid

For Hybrid starting system diagnostics, refer to INTRODUCTION- HYBRID ESCAPE article for to diagnose the cooling fan system.

Anti-Theft Intervention

The starting system is electronically controlled by the passive anti-theft system (PATS). The PATS recognizes the correct electronically coded ignition key and signals the instrument cluster to provide a ground for the starter relay. The energized relay provides voltage to the starter solenoid, thereby allowing the starter motor to activate.

Possible Causes

1. Battery
2. Fuse(s)
3. Ignition switch
4. Starter relay
5. Anti-theft system
6. Circuitry

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. A1 CHECK THE CONDITION OF THE PATS Observe the PATS warning indicator. Does the indicator flash when attempting to start the vehicle? Yes : REFER to «ANTI-THEFT - PATS»(ref-232268) to diagnose the PATS DTCs. No : GO to A2.
2. A2 CHECK THE BATTERY Check the battery condition and charge. Refer to «BATTERY, MOUNTING AND CABLES»(ref-232248) . Is the battery OK? Yes : GO to A3. No : CHARGE or INSTALL a new battery as necessary. REFER to «BATTERY, MOUNTING AND CABLES»(ref-232248) . TEST the system for normal operation.
3. A3 CHECK THE BATTERY GROUND CABLE Measure the voltage between the positive battery post and the battery ground cable connection at the engine. Is the voltage greater than 10 volts? Yes : GO to A4. No : INSTALL a new battery ground cable. REFER to «BATTERY, MOUNTING AND CABLES»(ref-232248) . TEST the system for normal operation.
4. A4 CHECK STARTER MOTOR GROUND Measure the voltage between the positive battery post and the starter motor case. Is the voltage greater than 10 volts? Yes : GO to A5. No : CLEAN the starter motor mounting flange and make sure the starter motor is correctly mounted. TEST the system for normal operation.
5. A5 CHECK THE POWER SUPPLY TO THE STARTER MOTOR Measure the voltage between starter motor C197A, circuit 2037 (RD) and ground. Is the voltage greater than 10 volts? Yes : GO to A6. No : INSTALL a new positive battery cable. REFER to «BATTERY, MOUNTING AND CABLES»(ref-232248) . TEST the system for normal operation.
6. A6 CHECK THE STARTER MOTOR B-PIN Connect one end of a fused (30A) jumper wire to starter motor C197A, circuit 2037 (RD). Momentarily connect the other end of the jumper to starter motor C197B, circuit 33 (WH/PK). Did the starter motor engage and the engine crank? Yes : GO to A7. No : INSTALL a new starter motor. REFER to «STARTER MOTOR - 2.3L»(ref-232203-S13615494892006051600000) or «STARTER MOTOR - 3.0L»(ref-232203-S25888077632006051600000) . TEST the system for normal operation.
7. A7 CHECK THE STARTER MOTOR RELAY Key in OFF position. Disconnect: Starter Motor Relay. Carry out the component test on the starter motor relay. Is the starter motor relay OK? Yes : GO to A8. No : INSTALL a new starter motor relay. TEST the system for normal operation.
8. A8 CHECK STARTER MOTOR RELAY POWER Measure the voltage between the battery junction box (BJB) starter motor relay pin 30, circuit 16 (RD/LG) harness side and ground. Is the voltage greater than 10 volts? Yes : GO to A9. No : REPAIR the circuit. TEST the system for normal operation.
9. A9 CHECK THE START SIGNAL TO THE STARTER MOTOR RELAY NOTE: For manual transaxle, fully disengage the clutch. Measure the voltage between the BJB starter motor relay pin 85, circuit 1093 (TN/RD), harness side and ground with the ignition switch in the START position. Is the voltage greater than 10 volts? Yes : GO to A10. No : For A/T, GO to A14 . For M/T, GO to A18 .
10. A10 CHECK THE GROUND SIGNAL TO THE STARTER RELAY Measure the voltage between the BJB starter relay pin 85, circuit 1093 (TN/RD) and pin 86, circuit 32 (RD/LB), while placing the ignition switch in the START position. Is the voltage greater than 10 volts? Yes : GO to A12 . No : GO to A11.
11. A11 CHECK CIRCUIT 32 (RD/LB)/325 (DB/OG) FOR AN OPEN Disconnect: PCM C175B. Measure the resistance between the BJB starter relay pin 86, circuit 32 (RD/LB)/325 (DB/OG), harness side and PCM C175B-2, circuit 32 (RD/LB)/325 (DB/OG), harness side. Is the resistance less than 5 ohms? Yes : INSTALL a new PCM. No : REPAIR the circuit. TEST the system for normal operation.
12. A12 CHECK THE CIRCUIT TO THE STARTER MOTOR Key in OFF position. Disconnect: Starter Solenoid C197b. Measure the resistance between starter solenoid S-terminal C197b, circuit 33 (WH/PK) harness side and the BJB starter motor relay pin 87, circuit 33 (WH/PK) harness side. Is the resistance less than 5 ohms? Yes : REINSTALL the starter motor relay. GO to A13. No : REPAIR the circuit. TEST the system for normal operation.
13. A13 CHECK THE STARTER MOTOR GROUND CIRCUIT Connect: Starter Solenoid C197b. Carry out the Starter Motor - Ground Circuit Test. Refer to the «COMPONENT TEST»(ref-232203-S29050604882006051600000) . Is the starter motor ground circuit OK? Yes : CARRY OUT the «STARTER MOTOR - MOTOR FEED CIRCUIT»(ref-232203-S22566965052006051600000) test. REFER to the «COMPONENT TEST PROCEDURES»(ref-232203-S29050604882006051600000) . No : REPAIR or INSTALL a new battery ground cable and/or engine ground cable as necessary. TEST the system for normal operation.
14. A14 CHECK THE LINKAGE ADJUSTMENT Key in OFF position. Check the transaxle linkage adjustment. Refer to «AUTOMATIC TRANSAXLE-TRANSMISSION EXTERNAL CONTROLS - CD4E»(ref-232269) . Is the linkage adjustment OK? Yes : GO to A15. No : ADJUST the linkage. TEST the system for normal operation.
15. A15 VERIFY THE TRANSMISSION RANGE (TR) SENSOR ADJUSTMENT Verify the TR sensor adjustment. Refer to «AUTOMATIC TRANSAXLE-TRANSMISSION - CD4E»(ref-232215) A. Does the TR sensor need adjustment? Yes : ADJUST the TR sensor. TEST the system for normal operation. No : GO to A16.
16. A16 CHECK THE VOLTAGE TO THE TR SENSOR Disconnect: TR Sensor C167. Key in START position. Measure the voltage between TR sensor C167-4, circuit 306 (TN/LB), harness side and ground with the ignition switch in the START position. Is the voltage greater than 10 volts? Yes : GO to A17. No : REPAIR the circuit. TEST the system for normal operation.
17. A17 CHECK THE CIRCUIT BETWEEN THE TR SENSOR AND THE STARTER MOTOR RELAY Key in OFF position. Measure the resistance between TR sensor C167-9, circuit 1093 (TN/RD), harness side and the BJB starter motor relay pin 85, circuit 1093 (TN/RD) harness side. Is the resistance less than 5 ohms? Yes : INSTALL a new TR sensor. REFER to «AUTOMATIC TRANSAXLE-TRANSMISSION - CD4E»(ref-232215) A. TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
18. A18 CHECK THE VOLTAGE TO THE CLUTCH CUTOFF SWITCH Key in OFF position. Disconnect: Clutch Cutoff Switch C2072. Key in START position. Measure the voltage between clutch cutoff switch C2072-1, circuit 306A (TN/LB), harness side and ground with the ignition switch in the START position. Is the voltage greater than 10 volts? Yes : GO to A19. No : REPAIR the circuit. TEST the system for normal operation.
19. A19 CHECK THE CIRCUIT BETWEEN THE CLUTCH CUTOFF SWITCH AND THE STARTER MOTOR RELAY Key in OFF position. Measure the resistance between clutch cutoff switch C2072-2, circuit 1093 (TN/RD) harness side and the BJB starter motor relay pin 85, circuit 1093 (TN/RD) harness side. Is the resistance less than 5 ohms? Yes : INSTALL a new clutch cutoff switch. TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.

1. Loose starter motor mounting bolts or brackets
2. Worn or damaged flywheel ring gear
3. Worn or damaged starter motor drive gear

Component Tests

Connect the 73III Automotive Meter at the component terminal rather than at the wiring end connector. Making a connection at the wiring end connector could result in false readings because the meter will not pick up a high resistance between the wiring connector and the component.

Scheme 16

1. Make sure the battery is fully charged. Carry out a battery load test. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-232248) .
2. Disconnect the inertia fuel shutoff (IFS) switch.
3. Connect a remote starter switch between the starter solenoid S-terminal and the battery positive (+) terminal.
4. Connect the 73III Automotive Meter positive lead to the battery positive (+) post. Connect the negative lead to the M-terminal.
5. Engage the remote starter switch. Read and record the voltage. The voltage reading should be 0.8 volt or less.
6. If the voltage reading is 0.8 volt or less, go to the «STARTER MOTOR-GROUND CIRCUIT COMPONENT TEST»(ref-232203-S31535685752006051600000) .
7. If the voltage reading is greater than 0.8 volt, this is an indication of excessive resistance in the connections, the positive battery cable or in the starter solenoid. Move the 73III Automotive Meter negative lead to the starter solenoid B-terminal and repeat the test. If the voltage reading at the B-terminal is lower than 0.8 volt, the concern is either in the connections at the starter solenoid or in the solenoid contacts.
8. Remove the cables from solenoid B-, S- and M-terminals. Clean the cables and connections and reinstall the cables to the correct terminals. Repeat Steps 3 through 6 . If the voltage drop reading is still greater than 0.8 volt when checked at the M-terminal and less than 0.8 volt when checked at the B-terminal, the concern is in the solenoid contacts. Install a new starter motor.
9. If the voltage reading taken at the solenoid B-terminal is still greater than 0.8 volt after cleaning the cables and the connections at the solenoid, the concern is either in the positive (+) battery cable connection or in the positive battery cable itself. Clean the positive (+) battery cable connection. If this does not solve the problem, install a new positive battery cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-232248) .

Starter Motor - Ground Circuit

A slow cranking condition can be caused by resistance in the ground or return portion of the cranking circuit. Check the voltage drop in the ground circuit as follows

Scheme 17

1. Connect the 73III Automotive Meter positive lead to the starter motor housing (the connection must be clean and free of rust or grease). Connect the negative lead to the negative (-) battery terminal.
2. Engage the remote starter switch and crank the engine. Read and record the voltage reading. The reading should be 0.5 volt or less.
3. If the voltage is more than 0.5 volt, clean the negative cable connections at the battery, the body ground connections and the starter ground connections. Retest.
4. If the voltage is more than 0.5 volt, install a new cable. If the voltage reading is less than 0.5 volt and the engine still cranks slowly, install a new starter motor.

Scheme 18
