Steering Linkage: Component Locations Ford Escape I рестайлинг

Special Tool(s)

TIE ROD END OUTER SPECIAL TOOL Tie Rod End Remover 211-105 (T85M-3395-A)

Scheme 53

Scheme 54

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-232183) .
2. Remove the cotter pin and the tie-rod end nut. To install, tighten to 55 Nm (41 lb-ft).
3. Loosen the tie-rod end jam nut. To install, tighten to 40 Nm (30 lb-ft).
4. Using the special tool, separate the outer tie-rod end from the front wheel knuckle.
5. Remove the tie-rod end.
6. To install, reverse the removal procedure. Adjust the front toe. For additional information, refer to «SUSPENSION SYSTEM-GENERAL INFORMATION»(ref-232234) .

Scheme 55

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-232183) .
2. Remove the outer tie-rod end. For additional information, refer to «TIE ROD END - OUTER»(ref-232233-S24726442102006051600000) .
3. Remove the tie-rod end jam nut. To install, tighten to 40 Nm (30 lb-ft).
4. Remove the 2 steering gear boot clamps and the steering gear boot.
5. To install, reverse the removal procedure.
