Interior Lighting System: Other Ford Escape I рестайлинг

Interior/illumination Lights 19 illustrations ~2050 words

Interior Lighting Delay

The purpose of the interior lighting delay feature is to provide temporary illumination of the interior lamps after doors are opened, then closed. The interior lighting delay feature will keep the interior lamps on for a period of up to 25 seconds, or until the ignition cycles from OFF, or the vehicle is locked using the remote keyless entry (RKE) transmitter.

Illuminated Entry

The illuminated entry requests the interior lamps to be illuminated when the ignition is off and the RKE transmitter unlock button is pressed. The illuminated entry requests the interior lamps off after 25 seconds elapse, the ignition is switched to ON, or when the RKE transmitter lock is pressed.

Illuminated Exit

The illuminated exit requests the interior lamps be illuminated for 25 seconds when all doors are closed and the ignition key is removed from the ignition lock cylinder. The illuminated exit will request the interior lamps be deactivated when any door becomes ajar, the key is inserted into the ignition lock cylinder, or 25 seconds expire.

Theater Lighting

The theater lighting option ramps up the interior lamps over 0.7 seconds when interior lamp activation is requested. The theater lighting feature ramps down the interior lamps over 1.7 seconds when interior lighting deactivation is requested by any other feature other than the panic alarm or battery saver.

Interior Lamp Arbitrator

The interior lamp arbitrator (located in the SJB) chooses between the interior lighting, interior mode, interior lighting delay, illuminated entry, illuminated exit and battery saver to determine which feature has precedence of activating and deactivating the interior lamps. The features are prioritized as follows: battery saver, interior mode, interior lighting, interior light delay, illuminated entry, and illuminated exit.

Battery Saver

The battery saver is internal to the SJB and provides automatic shut-off of the demand lamps (vanity lamps and map lamps) and interior lamps after a period of 10 minutes has elapsed in order to save battery voltage. A timer in the SJB is started when the ignition key is turned to the OFF position. When the time-out period for the lamps has elapsed, the voltage is automatically shutoff to the lamps by the battery saver. While battery saver has voltage disabled, if the ignition is turned to any position other than OFF, any door or liftgate becomes ajar or the unlock button of the remote transmitter is pressed, the battery saver will restore voltage and start the timer again. The amount of time that is required to elapse before the voltage to the lamps is shut off is 10 minutes.

Connector Circuit Reference

Liftgate Ajar Switch C478

Scheme 2

Scheme 2: Connector Circuit Reference
Scheme 2: Connector Circuit Reference

Liftgate Glass Ajar Switch C479

Scheme 3

Scheme 3
Scheme 3

Door Ajar Switch LH Front C525, RH Front C609, LH Rear C704, RH Rear C804

Scheme 4

Scheme 4
Scheme 4

Vanity Lamps C906 (RH), C907 (LH)

Scheme 5

Scheme 5
Scheme 5

Interior Lamp C918

Scheme 6

Scheme 6
Scheme 6

Cargo Lamp C926a

Scheme 7

Scheme 7
Scheme 7

Cargo Lamp C926b

Scheme 8

Scheme 8
Scheme 8

Interior Lamp C931

Scheme 9

Scheme 9
Scheme 9

Smart Junction Box (SJB) C2280b

Scheme 10

Scheme 10
Scheme 10

Smart Junction Box (SJB) C2280c

Scheme 11

Scheme 11
Scheme 11

Smart Junction Box (SJB) C2280d

Scheme 12

Scheme 12
Scheme 12

Smart Junction Box (SJB) C2280e

Scheme 13

Scheme 13
Scheme 13

Possible Causes

  1. circuit 1695 (YE/WH) open
  2. circuit 1005 (VT/OG) open or short to ground
  3. circuit 401 (PK) open or short to voltage
  4. SJB

Scheme 14

Scheme 14: PINPOINT TEST A: THE INTERIOR LAMPS ARE INOPERATIVE
Scheme 14: PINPOINT TEST A: THE INTERIOR LAMPS ARE INOPERATIVE

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. A1 CHECK THE SJB DTCS FROM BOTH CONTINUOUS AND ON-DEMAND SELF-TESTS Verify all the interior lamp switches are in the DOOR position. Use the recorded results from the SJB continuous and on-demand self-test. Are any DTCs recorded? Yes : For DTCs B1314 or B1316, GO to A3 . For DTC B1372, GO to A5 . For all other DTCs, REFER to the «SMART JUNCTION BOX (SJB) DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-232287-S00963612672006051600000) . No : GO to A2.
  2. A2 CHECK CIRCUIT 1005 (VT/OG) FOR VOLTAGE Disconnect: Interior Lamp C918. Measure the voltage between the interior lamp C918-1, circuit 1005 (VT/OG), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to A5 . No : GO to A3.
  3. A3 CHECK CIRCUIT 1005 (VT/OG) FOR OPEN OR SHORT TO GROUND Key in OFF position. Disconnect: Interior Lamp C918. Disconnect: SJB C2280c. Measure the resistance between the interior lamp C918-1, circuit 1005 (VT/OG), harness side and the SJB C2280c-25, circuit 1005 (VT/OG), harness side; and between the interior lamp C918-1, circuit 1005 (VT/OG), harness side and ground. Is the resistance less than 5 ohms between the interior lamp and the SJB and is the resistance greater than 10,000 ohms between the interior lamp and ground? Yes : GO to A4. No : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
  4. A4 CHECK CIRCUIT 1695 (YE/WH) FOR VOLTAGE Disconnect: SJB C2280b. Measure the voltage between the SJB C2280b-2, circuit 1695 (YE/WH), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to A7 . No : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
  5. A5 CHECK CIRCUIT 401 (PK) FOR AN OPEN Key in OFF position. Disconnect: Interior Lamp C918. Disconnect: SJB C2280c. Measure the resistance between the SJB C2280c-28, circuit 401 (PK), harness side and the interior lamp C918-2, circuit 401 (PK), harness side. Is the resistance less than 5 ohms? Yes : GO to A6. No : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
  6. A6 CHECK CIRCUIT 401 (PK) FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between the SJB C2280c-28, circuit 401 (PK), harness side and ground. Is any voltage indicated? Yes : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test. No : GO to A7.
  7. A7 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for corrosion pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-232247) . CLEAR the DTCs. REPEAT the self-test. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
  1. circuit 401 (PK) short to ground
  2. circuit 570 (BK/WH) open
  3. circuit 700 (WH/PK) open or short to voltage
  4. circuit 701 (LB/BK) open or short to voltage
  5. circuit 760 (PK/LB) open or short to voltage
  6. circuit 867 (DB) open or short to voltage
  7. circuit 1312 (LG/BK) open or short to voltage
  8. circuit 1742 (VT/LG) open or short to voltage
  9. circuit 1758 (WH/PK) open or short to voltage
  10. ajar switches
  11. SJB

Scheme 19

Scheme 19: PINPOINT TEST B: THE INTERIOR LAMPS STAY ON CONTINUOUSLY
Scheme 19: PINPOINT TEST B: THE INTERIOR LAMPS STAY ON CONTINUOUSLY
  1. B1 CHECK THE SJB DTCS FROM BOTH CONTINUOUS AND ON-DEMAND SELF-TESTS Verify all the interior lamp switches are in the DOOR position. Use the recorded results from the SJB continuous and on-demand self-test. Are any DTCs recorded? Yes : For DTCs B1319, B1327, B1335, B1571, B2077 or B2902, GO to B4 . For DTC B1374, GO to B3 . For all other DTCs, REFER to the «SMART JUNCTION BOX (SJB) DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-232287-S00963612672006051600000) . No : GO to B2.
  2. B2 CHECK THE DOOR AJAR PIDS Key in ON position. Enter the following diagnostic mode on the diagnostic tool: Diagnostic PID Data Monitor. Check the door ajar PIDs while opening and closing all the doors, liftgate and liftgate glass. Do all the door ajar and liftgate ajar PID values agree with the door and liftgate positions? Yes : GO to B3. No : GO to B4 .
  3. B3 CHECK CIRCUIT 401 (PK) FOR A SHORT TO GROUND Key in OFF position. Disconnect: Interior Lamp C918. Disconnect: SJB C2280c. Measure the resistance between the SJB C2280c-28, circuit 401 (PK), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : GO to B8 . No : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
  4. B4 CHECK CIRCUIT 570 (BK/WH) FOR AN OPEN Key in OFF position. Disconnect the inoperative door ajar switch. Measure the resistance between the inoperative door ajar switch connector, circuit 570 (BK/WH), harness side and ground. Refer to the «CONNECTOR REFERENCE»(ref-232287-S03342986762006051600000) for location and connector. CONNECTOR REFERENCE Location Connector LH front door ajar switch C525-6 RH front door ajar switch C609-6 LH rear door ajar switch C704-6 RH rear door ajar switch C804-6 Liftgate ajar switch C478-2 Liftgate glass ajar switch C479-2 Is the resistance less than 5 ohms? Yes : GO to B5. No : REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.
  5. B5 CHECK DOOR AJAR SWITCH OPERATION Measure the resistance between the inoperative door ajar switch connector pins, component side, while toggling the switch open and closed. Refer to «CONNECTOR REFERENCE»(ref-232287-S39881779532006051600000) for location and connector. CONNECTOR REFERENCE Location Connector and Pin Connector and Pin LH front door ajar switch C525-8 C525-6 RH front door ajar switch C609-8 C609-6 LH rear door ajar switch C704-8 C704-6 RH rear door ajar switch C804-8 C804-6 Liftgate ajar switch C478-1 C478-2 Liftgate glass ajar switch C479-1 C479-2 Is the resistance less than 5 ohms when the switch is closed and greater than 10,000 ohms when the switch is open? Yes : GO to B6. No : INSTALL a new door latch in question. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-232261) . CLEAR the DTCs. REPEAT the self-test.
  6. B6 CHECK DOOR AJAR SWITCH CIRCUITS Disconnect: SJB C2280c or SJB C2280d. Measure the resistance between the inoperative door ajar switch connector, harness side and the SJB connector, harness side. Refer to «CONNECTOR CIRCUIT REFERENCE»(ref-232287-S10151337842006051600000) for location, connector and circuit. CONNECTOR CIRCUIT REFERENCE Location SJB Circuit Ajar Switch Circuit LH front door ajar switch C2280d-21 1312 (LG/BK) C525-8 1312 (LG/BK) RH front door ajar switch C2280d-20 867 (DB) C609-8 867 (DB) LH rear door ajar switch C2280d-19 1742 (VT/LG) C704-8 760 (PK/LB) RH rear door ajar switch C2280e-18 760 (PK/LB) C804-8 760 (PK/LB) Liftgate ajar switch C2280d-17 700 (WH/VT) C478-1 701 (LB/BK) Liftgate glass ajar switch C2280e-3 1758 (WH/PK) C479-1 700 (WH/VT) Is the resistance less than 5 ohms? Yes : GO to B7. No : REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.
  7. B7 CHECK AJAR CIRCUIT FOR SHORT TO VOLTAGE Key in ON position. Measure the voltage between the SJB connector, harness side and ground. Refer to «SJB CIRCUIT REFERENCE»(ref-232287-S18828163692006051600000) for connector and circuit. SJB CIRCUIT REFERENCE SJB Circuit C2280d-21 1312 (LG/BK) C2280d-20 867 (DB) C2280d-19 1742 (VT/LG) C2280d-18 760 (PK/LB) C2280d-17 700 (WH/VT) C2280e-3 1758 (WH/PK) Is any voltage indicated? Yes : REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test. No : GO to B8.
  8. B8 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for corrosion pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-232247) . CLEAR the DTCs. REPEAT the self-test. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
  1. circuit 1312 (LG/BK) short to ground
  2. circuit 867 (DB) short to ground
  3. circuit 760 (PK/LB) short to ground
  4. circuit 700 (WH/VT) short to ground
  5. circuit 701 (LB/BK) short to ground
  6. ajar switches
  7. SJB
  1. circuit 1005 (VT/OG) open
  2. circuit 570 (BK) open
  1. circuit 1005 (VT/OG) open
  2. circuit 401 (PK) open
  3. lamp assembly
  1. RKE transmitter
  2. SJB
  1. circuit 1005 short to voltage
  2. SJB

Scheme 20

Scheme 20: PINPOINT TEST G: THE BATTERY SAVER DOES NOT DEACTIVATE AFTER TIME-OUT
Scheme 20: PINPOINT TEST G: THE BATTERY SAVER DOES NOT DEACTIVATE AFTER TIME-OUT
  1. G1 CHECK FOR SHORT TO VOLTAGE Key in OFF position. Disconnect: SJB C2280c. Place all interior lamp switches in the DOOR position. Key in ON position. Measure the voltage between the SJB C2280c-25, circuit 1005 (VT/OG), harness side and ground. Is any voltage indicated? Yes : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test. No : GO to G2.
  2. G2 CHECK FOR CORRECT SJB OPERATION Disconnect all SJB connectors. Check for: corrosion pushed-out pins Connect all SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-232247) . CLEAR the DTCs. REPEAT the self-test. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
