Special Tool(s)
SPECIAL TOOL (CLIMATE CONTROL SYSTEM) Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool R-134a Manifold Gauge Set 176-R032A or equivalent Connector, Refrigerant Pressure Line 412-093 (T94P-19623-E) Set, A/C Fittings 412-DS028 (D93L-19703-B) or equivalent Refrigerant Leak Detector 216-00001 or equivalent 73 III Automotive Meter 105-R0057 or equivalent Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent
Scheme 103
Scheme 104
Scheme 105
Scheme 106
Scheme 107
Scheme 108
Scheme 109
Scheme 110
Scheme 111
Function Selector Switch Vacuum Application Chart
Note. A leak in the vacuum control circuit may occur during acceleration (slow leak) or may exist at all times (large leak), and may exist only when specific functions are selected (indicating a leak in that portion of the circuit). The vacuum hoses used in the passenger compartment control circuit are constructed from PVC plastic material. The vacuum hoses used in the engine compartment are constructed of Hytrel®. Because of the materials used, never pinch off the vacuum hoses to locate a leak during diagnosis. A golf tee can be used as a plug when it is necessary to plug one end of the vacuum hose for leak test purposes.
| Switch Port | Color | Function | Function Selector Switch Position | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAX A/C | A/C | Panel | Floor/ Panel | OFF | Floor | Floor/ Defrost | Defrost | |||
| 1 | White | Recirc/fresh | V | NV | NV | NV | V | NV | NV | NV |
| 2 | Yellow | Defrost | V | V | V | V | V | V | NV | NV |
| 3 | Red | Floor | NV | NV | NV | V | V | V | V | NV |
| 4 | Orange | Panel/Floor | V | V | V | V | NV | NV | NV | NV |
| 5 | Black | Vacuum source | V | V | V | V | V | V | V | V |
| 6 | Not Used | Not Used | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A |
| V=Vacuum NV=No vacuum | ||||||||||
FUNCTION SELECTOR SWITCH VACUUM APPLICATION CHART
SPECIAL TOOL (AIR CONDITIONING (A/C) ODOR TREATMENT) 30oz Sure Shot Pressure Sprayer 167-R4700 or equivalent
Scheme 112
SPECIAL TOOL (SPRING LOCK COUPLING) Remover, Refrigerant Coupling Spring 412-039 (T84L-19623-B)
Scheme 113
SPECIAL TOOL (REFRIGERANT SYSTEM TESTS) R-134a Refrigerant Center 176-00002 or equivalent R-134a Refrigerant Center 023-00174 or equivalent R-134a Manifold Gauge Set 023-00047 or equivalent
Scheme 114
Scheme 115
SPECIAL TOOL (ELECTRONIC LEAK DETECTION) H10PM Refrigerant Leak Detector With Battery 216-00001 or equivalent
| CAUTION | Good ventilation is necessary in the area where electronic A/C leak testing is to be carried out. If the surrounding air is contaminated with refrigerant gas, the leak detector will indicate this gas all the time. Odors from other chemicals such as antifreeze, diesel fuel, disc brake cleaner, or other cleaning solvents can cause the same problem. Using a fan to ventilate the area to be tested before proceeding with the leak detection procedure is helpful in removing small traces of contamination from the air, but the fan should be turned off during the actual testing. |
Scheme 116
- Leak test the refrigerant system using the refrigerant leak detector. Follow the instructions included with the leak detector for handling and operation techniques.
- If a leak is found, recover the refrigerant. For additional information, refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-232279-S03696491132006051600000) . Repair the system. Test the system for normal operation.
SPECIAL TOOL (FLUORESCENT DYE LEAK DETECTION) R-134a Refrigerant Center 176-00002 or equivalent R-134a Refrigerant Center 023-00174 or equivalent R-134a Manifold Gauge Set 023-00047 or equivalent 120 Watt UV Spot Lamp 164-R0721 or equivalent High Intensity UV Lamp - 12 Volt 164-R6000 or equivalent R-134a Fluorescent Dye Injector 164-R0775 or equivalent Deluxe Loop Kit 219-00069 or equivalent R-134a Leak Detection Dye 164-R6060
Scheme 117
Scheme 118
Scheme 119
SPECIAL TOOL (AIR CONDITIONING (A/C) SYSTEM FLUSHING) A/C Flush and Purge Machine 219-00022 (part of 219-00023) or equivalent A/C Flush and Purge Fitting Kit 219-00024 (part of 219-00023) or equivalent
Scheme 120
Scheme 121
SPECIAL TOOL R-134a Refrigerant Center 176-00002 or equivalent R-134a Refrigerant Center 023-00174 or equivalent R-134a Manifold Gauge Set 023-00047 or equivalent 1.2 CFM Vacuum Pump 023-00162 or equivalent 4.0 CFM Vacuum Pump 023-00163 or equivalent Automatic Refrigerant Charging Meter 023-00155 or equivalent
Scheme 122
Scheme 123
Scheme 124
SPECIAL TOOL (REFRIGERANT OIL ADDING) Dye/Lubricant Injector 164-R0775 Add-On Module Kit 219-00069
SPECIAL TOOL (REFRIGERANT IDENTIFICATION TESTING) Refrigerant Identifier with Air-Radiator 198-00003 or equivalent
Scheme 125
SPECIAL TOOL (VACUUM HOSE REPAIR) Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent
Scheme 126
- Measure the length of the damaged area of the mini-tube vacuum hose.
- Cut a piece of standard 1/8-inch inner diameter vacuum hose approximately 25 mm (1 inch) longer than the damaged area of the mini-tube vacuum hose.
- Cut off the mini-tube vacuum hose on each side of the damaged area.
- Dip the mini-tube hose ends in commercially available paint thinner containing methyl ethyl ketone (MEK). This solvent will seal the mini-tube in the vacuum hose.
- Insert the ends of the mini-tube vacuum hose approximately 9 mm (3/8 inch) into the ends of the standard 1/8-inch repair vacuum hose section.
- Shake the repair joint after assembly to make sure the solvent is dispersed and the vacuum line is not plugged.
- Test the system for a vacuum leak in the repair area. Use a vacuum pump.
