Multifunction Electronic Module System: Diagnosis Ford Escape I

Communication Devices 5 illustrations ~315 words

Inspection and Verification

  1. Verify the customer concern by operating the system in question.
  2. Visually inspect for obvious signs of mechanical and electrical damage. VISUAL INSPECTION CHART Electrical Fuse Wiring harness Connector(s) Circuitry Generic electronic module (GEM)
  3. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: Check that the program card is correctly installed. Check the connections to the vehicle. Check the ignition switch position.
  4. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manufacturer's manual.
  5. Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(ref-177213) . NO RESP/NOT EQUIP for generic electronic module (GEM), go to «PINPOINT TEST A»(ref-204647-S28909798872005111200000) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the GEM.
  6. If the DTCs retrieved are related to the concern, go to the GEM Diagnostic Trouble Code (DTC) Index to continue diagnostics. See «GEM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-204647-S17892122622005111200000) .
  7. If no DTCs related to the concern are retrieved, refer to «SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV»(ref-132995) .
DTCDescriptionSourceAction
B1217Horn Relay Coil Circuit FailureGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B1218Horn Relay Coil Circuit Short to BatteryGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B1244Wiper Rear Motor Run Relay Circuit FailureGEMREFER to WIPERS & WASHERS .
B1245Wiper Rear Motor Run Relay Circuit Short to BatteryGEMREFER to WIPERS & WASHERS .
B1300Power Door Lock - Circuit FailureGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B1302Accessory Delay Relay Coil Circuit FailureGEMREFER to GLASS, FRAMES & MECHANISMS .
B1304Accessory Delay Relay Coil Circuit Short to BatteryGEMREFER to GLASS, FRAMES & MECHANISMS .
B1309Power Door Lock Short to GroundGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B1310Power Door Unlock - Circuit FailureGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B1317Battery Voltage HighGEMREFER to INTERIOR LIGHTING .
B1318Battery Voltage LowGEMREFER to INTERIOR LIGHTING .
B1319Driver Door Ajar Circuit FailureGEMREFER to INTERIOR LIGHTING .
B1323Door Ajar Lamp Circuit FailureGEMREFER to INSTRUMENT CLUSTER & PANEL ILLUMINATION .
B1325Door Ajar Lamp Circuit Short to BatteryGEMREFER to INSTRUMENT CLUSTER & PANEL ILLUMINATION .
B1327Passenger Door Ajar Circuit FailureGEMREFER to INTERIOR LIGHTING .
B1331Decklid Ajar Rear Door Circuit FailureGEMREFER to INTERIOR LIGHTING .
B1335Door Ajar RR Circuit FailureGEMREFER to INTERIOR LIGHTING .
B1342ECU is DefectiveGEMCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new GEM. REFER to GENERIC ELECTRONIC MODULE (GEM) .
B1352Ignition Key-In Circuit FailureGEMREFER to STEERING COLUMN SWITCHES .
B1359Ignition Run/ACC Circuit FailureGEMREFER to STEERING COLUMN SWITCHES .
B1371Illuminated Entry Relay Circuit FailureGEMREFER to INTERIOR LIGHTING .
B1470Lamp Headlamp Input Circuit FailureGEMREFER to EXTERIOR LIGHTING .
B1499Lamp Turn Signal Left Circuit FailureGEMREFER to EXTERIOR LIGHTING .
B1501Lamp Turn Signal Left Circuit Short to BatteryGEMREFER to EXTERIOR LIGHTING .
B1519Hood Switch Circuit FailureGEMREFER to ANTI-THEFT - PATS .
B1571Door Ajar LR Circuit FailureGEMREFER to INTERIOR LIGHTING .
B1611Wiper Rear Mode Select Switch Circuit FailureGEMREFER to WIPERS & WASHERS .
B2100Door Driver Key Cylinder Switch FailureGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B2104Door Passenger Key Cylinder Switch FailureGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B2141NVM Configuration FailureGEMREFER to MODULE CONFIGURATION .
B2425Remote Keyless Entry (RKE) Out of SynchronizationGEMREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS .
B2494Anti-Theft Horn Output Circuit Short to BatteryGEMREFER to ANTI-THEFT - PATS .
B2495Anti -Theft Horn Output Circuit FailureGEMREFER to ANTI-THEFT - PATS .
B2598Headlamp Relay Circuit FailureGEMREFER to EXTERIOR LIGHTING .
C1961Park Lamp Relay Coil Circuit FailureGEMREFER to EXTERIOR LIGHTING .
C1962Park Lamp Relay Coil Circuit Short to BatteryGEMREFER to EXTERIOR LIGHTING .

GEM DIAGNOSTIC TROUBLE CODE (DTC) INDEX

Symptom Chart

ConditionPossible SourcesAction
No communication with the generic electronic module (GEM)Central junction box (CJB) fuse 26 (30A). Circuitry. GEM.GO to PINPOINT TEST A .

TROUBLESHOOTING SYMPTOM

Scheme 45

Scheme 45: PINPOINT TEST A: NO COMMUNICATION WITH THE GENERIC ELECTRONIC MODULE (GEM)

Scheme 46

Scheme 46

Scheme 47

Scheme 47

Scheme 48

Scheme 48: Removal and Installation

Scheme 49

Scheme 49
  1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204629) .
  2. Remove the floor console. Refer to «INSTRUMENT PANEL & CONSOLE»(ref-177104) .
  3. Disconnect the GEM electrical connectors.
  4. Remove the GEM Pull back the insulation and remove the nuts. Remove the GEM.
  5. To install, reverse the removal procedure. Configure the GEM. Refer to «MODULE CONFIGURATION»(ref-177262) .
