Customer Preference Items

This method is used to enable or disable module-controlled items or systems to suit the preference of the customer. Not all features controlled by the module are listed in this configuration method. Refer to the Module Configuration Index in this section for a list of features for each module.

If a feature is changed using the customer preference items configuration method, the changed information will not be stored in the PCM VID block. The VID block will retain the original settings as they were recorded when the vehicle left the factory.

Scheme 38

Scheme 38: Inspection and Verification
  1. Visually inspect for obvious signs of electrical damage. (Scheme 38)
  2. If the concern remains after inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check that the ignition switch is in the RUN position.
  3. If the diagnostic tool still does not communicate with the vehicle, refer to «MODULE COMMUNICATIONS NETWORK»(ref-177213).
  4. Refer to the Symptom Chart. (Scheme 42)

Module Configuration Index

Note. Do not contact the As-Built Data Center unless the diagnostic tool instructs you to do so. The diagnostic tool will not allow you to use as-built data information unless the diagnostic tool first prompts you for the As-Built Data Center information.

Scheme 39

Scheme 39: Module Configuration Index

Scheme 40

Scheme 40: Diagnostic Tool Message Index

Scheme 41

Scheme 41

Scheme 42

Scheme 42: Symptom Chart

Scheme 43

Scheme 43: Pinpoint Test A: Unable To Configure The New Module

Scheme 44

Scheme 44

Note. If using the WDS, select Module Configuration and Programming, then follow the screen prompts.

Note. Make sure module is listed as supporting customer preference items and supports the specific item to be configured in the Module Configuration Index Module Configuration Index in this section.

  1. Select Service Bay Functions on the diagnostic tool.
  2. Select the module that contains the customer preference item to be programmed. Refer to the «Module Configuration Index»(ref-177262-S36919039242005052600000) .
  3. Select Customer Preference Items on the diagnostic tool.
  4. Select Module Option Content.
  5. Select the item to be enabled or disabled.
  6. Enable or disable the item as necessary to reflect the customer preference.
