Engine Code Information Label

The engine code information label, located on the front side of the valve cover, contains the following

Scheme 1426

Scheme 1427

Exhaust Emission Control System

Operation and required maintenance of the exhaust emission control devices used on this engine is covered in the INTRODUCTION article.

Induction System

The SFI provides the fuel/air mixture needed for combustion in the cylinders. The 6 solenoid-operated fuel injectors

1. are mounted between the fuel rail and the intake manifold.
2. meter fuel into the air intake stream in accordance with engine demand.
3. are positioned so that their tips direct fuel just ahead of the engine intake valves.

Valve Train

The valve train uses Direct Acting Mechanical Buckets (DAMB). The camshaft lobes are positioned directly above mechanical buckets which are positioned on top of the valves.

Twin Independent Variable Camshaft Timing (VCT) System

The twin independent VCT system allows variable control of intake valve closing which optimizes combustion at full load providing improved power and low speed torque (broadening the torque curve) which enables variable valve overlap which provides better fuel economy and emissions and provides optimized cold start operation with improved exhaust emissions.

PCV System

All engines are equipped with a closed-type PCV system recycling the crankcase vapors to the upper intake manifold.

Oil Pump

The lubrication system is designed to provide optimum oil flow to critical components of the engine through its entire operating range.

The heart of the system is a positive displacement internal gear oil pump.

Generically, this design is known as a gerotor pump, which operates as follows

1. The oil pump is mounted on the front face of the cylinder block.
2. The inner rotor is piloted on the crankshaft post and is driven through flats on the crankshaft.
3. System pressure is limited by an integral, internally-vented relief valve which directs the bypassed oil back to the inlet side of the oil pump.
4. Oil pump displacement has been selected to provide adequate volume to make sure of correct oil pressure both at hot idle and maximum speed.
5. The relief valve calibration protects the system from excessive pressure during high-viscosity conditions.
6. The relief valve is designed to provide adequate connecting rod bearing lubrication under high-temperature and high-speed conditions.

Scheme 1428

Cooling System

The engine cooling system includes the following

1. Radiator
2. Timing chain driven coolant pump
3. Electric fan assembly
4. Degas bottle (aids in maintaining the correct volume of engine coolant)
5. Coolant thermostat
6. Coolant hoses

For basic engine mechanical concerns, refer to ENGINE SYSTEM - GENERAL INFORMATION . For driveability concerns, refer to the INTRODUCTION article.

Scheme 1429

1. Remove the valve covers. For additional information, refer to «VALVE COVER - LH»(ref-494555-S16131633692012081400000) and «VALVE COVER - RH»(ref-494555-S22477061102012081400000) .
2. Use a feeler gauge to measure the clearance of each valve and record its location. A midrange clearance is the most desirable: Intake: 0.15-0.25 mm (0.006-0.01 in) Exhaust: 0.360-0.460 mm (0.0142-0.0181 in)
3. If any of the valve clearances are out of specification, select new tappets using this formula: tappet thickness = measured clearance the base tappet thickness - most desirable thickness. Select the tappets and mark the installation location.
4. If required, install the new selected valve tappets in the marked locations. For additional information, refer to «VALVE TAPPETS»(ref-494555-S39868208182012081400000) .

Scheme 1430

1. Use only a mild soap and water solution to clean the engine appearance cover.

Scheme 1431

Valve Cover - LH

SPECIAL TOOLS CHART Handle 205-153 (T80T-4000-W) Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Installer, VCT Spark Plug Tube Seal 303-1247/2 Remover, VCT Spark Plug Tube Seal 303-1247/1

Scheme 1432

Scheme 1433

Scheme 1434

MATERIAL SPECIFICATIONS

Scheme 1435

Valve Cover - RH

SPECIAL TOOLS CHART Handle 205-153 (T80T-4000-W) Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Installer, VCT Spark Plug Tube Seal 303-1247/2 Remover, VCT Spark Plug Tube Seal 303-1247/1

Scheme 1436

Scheme 1437

Scheme 1438

MATERIAL SPECIFICATIONS

Scheme 1439

Crankshaft Pulley

SPECIAL TOOLS CHART 3 Jaw Puller 303-D121 or equivalent Installer, Front Cover Oil Seal 303-335 Replacer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Strap Wrench 303-D055 (D85L-6000-A) or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 1440

Scheme 1441

MATERIAL SPECIFICATIONS

Scheme 1442

Scheme 1443

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-494560) .
2. Remove the accessory drive belt and the power steering belt. For additional information, refer to «ACCESSORY DRIVE»(ref-494572) .
3. Using the Strap Wrench, remove the crankshaft pulley bolt and washer. Discard the bolt.
4. Using the 3 Jaw Puller, remove the crankshaft pulley.

Scheme 1444

1. Lubricate the crankshaft front seal inner lip with clean engine oil.
2. Using the Front Cover Oil Seal Installer and Crankshaft Vibration Damper Replacer, install the crankshaft pulley.
3. Using the Strap Wrench, install the crankshaft pulley washer and new bolt and tighten in 4 stages. Stage 1: Tighten to 120 Nm (89 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
4. Install the accessory drive belt and the power steering belt. For additional information, refer to «ACCESSORY DRIVE»(ref-494572) .
5. After completing the repairs, use the scan tool to perform the Misfire Monitor Neutral Profile Correction procedure following the on-screen instructions.

Crankshaft Front Seal

SPECIAL TOOLS CHART Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Installer, Front Crankshaft Seal 303-1251 Remover, Oil Seal 303-409 (T92C-6700CH)

Scheme 1445

Scheme 1446

MATERIAL SPECIFICATIONS

Scheme 1447

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-494560) .
2. Remove the crankshaft pulley. For additional information, refer to «CRANKSHAFT PULLEY»(ref-494555-S31422447902012081400000) .
3. Using the Oil Seal Remover, remove and discard the crankshaft front seal. Clean all sealing surfaces with metal surface prep.

Flexplate

SPECIAL TOOLS CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Crankshaft Rear Seal

SPECIAL TOOLS CHART Handle 205-153 (T80T-4000-W) Installer, Rear Main Seal 303-1250 Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Slide Hammer 307-005 (T59L-100-B)

Scheme 1448

Scheme 1449

MATERIAL SPECIFICATIONS

Scheme 1450

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-494560) .
2. Remove the flexplate. For additional information, refer to «FLEXPLATE»(ref-494555-S23080431252012081400000) .
3. Remove the crankshaft sensor ring.
4. Using the Crankshaft Rear Oil Seal Remover and Slide Hammer, remove and discard the crankshaft rear seal. Clean all sealing surfaces with metal surface prep.

Scheme 1451

1. Position the Rear Main Seal Installer onto the end of the crankshaft and slide a new crankshaft rear seal onto the tool.
2. Using the Rear Main Seal Installer and Handle, install the new crankshaft rear seal.
3. Install the crankshaft sensor ring.
4. Install the flexplate. For additional information, refer to «FLEXPLATE»(ref-494555-S23080431252012081400000) .

Engine Front Cover

SPECIAL TOOLS CHART 3 Jaw Puller 303-D121 or equivalent Alignment Pins 307-399 Installer, Front Cover Oil Seal 303-335 (T88T-6701-A) Installer, Front Crankshaft Seal 303-1251 Remover, Oil Seal 303-409 (T92C-6700CH) Replacer, Crankshaft Vibration Damper 303-102 (T74P-6312-B) Strap Wrench 303-D055 (D85L-6000-A) or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 1452

Scheme 1453

MATERIAL SPECIFICATIONS

Scheme 1454

Timing Drive Components

SPECIAL TOOLS CHART Hold Down, Secondary Chain 303-1530 Tool, Camshaft Holding 303-1248

Scheme 1455

Scheme 1456

Engine Oil Pressure (EOP) Switch

MATERIAL SPECIFICATIONS

Scheme 1457

Exhaust Manifold - RH

MATERIAL SPECIFICATIONS

Scheme 1458

Scheme 1459

1. Remove the RH catalytic converter. For additional information, refer to «EXHAUST SYSTEM»(ref-494567) .
2. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector.
3. Remove the 6 nuts and the RH exhaust manifold. Discard the nuts and gasket.
4. Clean and inspect the RH exhaust manifold. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
5. Remove and discard the 6 RH exhaust manifold studs.
6. Clean the exhaust manifold mating surface of the cylinder head with metal surface prep. Follow the directions on the packaging.

Scheme 1460

1. Install 6 new RH exhaust manifold studs. Tighten to 12 Nm (106 lb-in).
2. Using a new gasket, install the RH exhaust manifold and 6 new nuts. Tighten in 2 stages in the sequence shown in illustration: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft).
3. Connect the RH HO2S electrical connector.
4. Install the RH catalytic converter. For additional information, refer to «EXHAUST SYSTEM»(ref-494567) .

Scheme 1461

Scheme 1462

Scheme 1463

Scheme 1464

1. Remove the engine appearance cover. For additional information, refer to «ENGINE APPEARANCE COVER - EXPLODED VIEW»(ref-494555-S03086729622012081400000) .
2. Position a floor jack with a block of wood under the front of the oil pan.
3. Remove the 3 bolts and position the engine coolant degas bottle aside.
4. Remove the nut, bolt and engine mount brace.
5. Remove the 4 engine mount nuts.
6. Remove the 3 bolts and the engine mount.

Scheme 1465

Scheme 1466

Scheme 1467

1. Install the engine mount and the 3 bolts. Tighten to 90 Nm (66 lb-ft).
2. Install the 4 engine mount nuts. Tighten to 63 Nm (46 lb-ft).
3. Install the engine mount brace, nut and bolt. Tighten to 20 Nm (177 lb-in).
4. Position the engine coolant degas bottle and install the 3 bolts. Tighten to 9 Nm (80 lb-in).
5. Install the engine appearance cover. For additional information, refer to «ENGINE APPEARANCE COVER - EXPLODED VIEW»(ref-494555-S03086729622012081400000) .

Oil Pan

MATERIAL SPECIFICATIONS

Scheme 1468

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

All Vehicles

Scheme 1469

Scheme 1470

Scheme 1471

Scheme 1472

Scheme 1473

Scheme 1474

Scheme 1475

Scheme 1476

Scheme 1477

Scheme 1478

Scheme 1479

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-494560) .
2. Remove the Air Cleaner (ACL) assembly. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
3. Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
4. Remove the oil level indicator.
5. Detach the wiring harness retainer from the starter stud bolt. Remove the starter stud bolt.
6. Loosen the 3 upper bellhousing-to-engine bolts 5 mm (0.19 in).
7. Remove the drain plug and drain the engine oil. Install the drain plug and tighten to 27 Nm (20 lb-ft).
8. Remove and discard the engine oil filter.
9. Remove the exhaust Y-pipe. For additional information, refer to «EXHAUST SYSTEM»(ref-494567) .
10. Remove the engine roll restrictor. For additional information refer to, «AUTOMATIC TRANSMISSION - 6F50/6F55»(ref-494558) . All-Wheel Drive (AWD) vehicles
11. Remove the RH catalytic converter. For additional information, refer to «EXHAUST SYSTEM»(ref-494567) .
12. Remove the RH wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-494563) .
13. Remove the 2 intermediate shaft support bolts, the 5 Power Transfer Unit (PTU) support bracket bolts and the PTU support bracket. All vehicles
14. Remove the A/C compressor nut and stud.
15. Loosen the 3 LH bellhousing-to-engine bolts 5 mm (0.19 in).
16. Loosen the RH engine-to-bellhousing bolt 5 mm (0.19 in).
17. Remove the 2 fasteners and the inspection cover.
18. Remove the 4 oil pan-to-bellhousing bolts.
19. Separate the engine and transaxle 5 mm (0.19 in).
20. Remove the 4 lower engine front cover bolts.
21. Remove the 16 oil pan bolts.
22. Using a suitable pry tool, locate the pry pads and pry the oil pan loose and remove.
23. Clean the engine oil pan using a 3M™ Roloc® Bristle Disk (2-in white, part number 07528) in a suitable tool turning at the recommended speed of 15, 000 rpm. Thoroughly wash the oil pan to remove any foreign material, including any abrasive particles created during the cleaning process.
24. Clean the sealing surfaces of the cylinder block and engine front cover in the following sequence. Remove any large deposits of silicone or gasket material. Apply silicone gasket remover and allow to set for several minutes. Remove the silicone gasket remover. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep to remove any remaining traces of oil and to prepare the surfaces to bond. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.

Crankshaft Rear Seal with Retainer Plate

SPECIAL TOOLS CHART Handle 205-153 (T80T-4000-W) Installer, Rear Main Seal 303-1250 Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Slide Hammer 307-005 (T59L-100-B)

Scheme 1480

Scheme 1481

MATERIAL SPECIFICATIONS

Scheme 1482

Scheme 1483

Scheme 1484

Scheme 1485

Scheme 1486

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-494560) .
2. Remove the flexplate. For additional information, refer to «FLEXPLATE»(ref-494555-S23080431252012081400000) .
3. Remove the crankshaft sensor ring.
4. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
5. Remove the bolt and the CKP sensor.
6. Using the Crankshaft Rear Oil Seal Remover and Slide Hammer, remove and discard the rear crankshaft seal.
7. Remove the 2 oil pan to crankshaft rear seal retainer bolts.
8. Remove the 8 crankshaft rear seal retainer bolts.
9. Install the 2 M6 oil pan bolts (finger-tight) into the 2 threaded holes in the crankshaft rear seal retainer. Alternately tighten the 2 bolts one turn at a time until the crankshaft rear seal retainer-to-cylinder block seal is released. Remove the crankshaft rear seal retainer.
10. Clean the crankshaft rear seal retainer plate using a 3M™ Roloc® Bristle Disk (2-in white, part number 07528) in a suitable tool turning at the recommended speed of 15, 000 rpm. Thoroughly wash the crankshaft rear seal retainer plate to remove any foreign material, including any abrasive particles created during the cleaning process.
11. Clean the sealing surfaces of the cylinder block and oil pan flange in the following sequence. Remove any large deposits of silicone or gasket material. Apply silicone gasket remover and allow to set for several minutes. Remove the silicone gasket remover. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep to remove any remaining traces of oil or coolant and to prepare the surfaces to bond. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.

Scheme 1487

Scheme 1488

Scheme 1489

Scheme 1490

1. Apply 5 mm (0.196 in) beads of Motorcraft® High Performance Engine RTV Silicone to the 2 cylinder block/oil pan joints.
2. Apply a 3 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the sealing surface of the crankshaft rear seal retainer.
3. Install the crankshaft rear seal retainer at an angle above the oil pan flange to avoid scraping off the sealer. Tilt the seal retainer up and onto the rear of the cylinder block.
4. Install the 8 bolts and tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
5. Install the 2 oil pan to crankshaft rear seal retainer bolts. Tighten to 10 Nm (89 lb-in) plus an additional 45 degrees.
6. Position the Rear Main Seal Installer onto the end of the crankshaft and slide a new crankshaft rear seal onto the tool.
7. Using the Rear Main Seal Installer and Handle, install the new crankshaft rear seal.
8. Install the Crankshaft Position (CKP) sensor and install the bolt. Tighten to 10 Nm (89 lb-in).
9. Connect the CKP sensor electrical connector.
10. Install the crankshaft sensor ring.
11. Install the flexplate. For additional information, refer to «FLEXPLATE»(ref-494555-S23080431252012081400000) .

SPECIAL TOOLS CHART Tool, Camshaft Holding 303-1248

Scheme 1491

Scheme 1492

Camshaft

SPECIAL TOOLS CHART 3 Jaw Puller 303-D121 or equivalent Adjustable Grip Arm, 1735A 014-00001 Disconnect Tool, Transmission Cooler Tube 307-569 Handle 205-153 (T80T-4000-W) Hold Down, Secondary Chain 303-1530 Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Powertrain Lift 300-OTC1585AE Remover, Oil Seal 303-409 (T92C-6700CH) Remover, Tie-Rod End 211-105 Remover, VCT Spark Plug Tube Seal 303-1247/1 Strap Wrench 303-D055 (D85L-6000-A) or equivalent Tool, Camshaft Holding 303-1248

Scheme 1493

Scheme 1494

Scheme 1495

Scheme 1496

Scheme 1497

Scheme 1498

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

All vehicles

Scheme 1499

Scheme 1500

Scheme 1501

Scheme 1502

Scheme 1503

Scheme 1504

Scheme 1505

Scheme 1506

Scheme 1507

Scheme 1508

Scheme 1509

Scheme 1510

Scheme 1511

Scheme 1512

Scheme 1513

Scheme 1514

Scheme 1515

Scheme 1516

Scheme 1517

Scheme 1518

Scheme 1519

Scheme 1520

Scheme 1521

Scheme 1522

Scheme 1523

Scheme 1524

Scheme 1525

Scheme 1526

Scheme 1527

Scheme 1528

Scheme 1529

Scheme 1530

Scheme 1531

Scheme 1532

Scheme 1533

Scheme 1534

Scheme 1535

Scheme 1536

Scheme 1537

Scheme 1538

Scheme 1539

Scheme 1540

Scheme 1541

Scheme 1542

Scheme 1543

Scheme 1544

Scheme 1545

Scheme 1546

Scheme 1547

Scheme 1548

Scheme 1549

Scheme 1550

Scheme 1551

Scheme 1552

Scheme 1553

Scheme 1554

Scheme 1555

Scheme 1556

Scheme 1557

Scheme 1558

Scheme 1559

Scheme 1560

Scheme 1561

Scheme 1562

Scheme 1563

Scheme 1564

Scheme 1565

Scheme 1566

Scheme 1567

Scheme 1568

Scheme 1569

Scheme 1570

Scheme 1571

Scheme 1572

Scheme 1573

Scheme 1574

Scheme 1575

Scheme 1576

Scheme 1577

Scheme 1578

Scheme 1579

Scheme 1580

Scheme 1581

Scheme 1582

Scheme 1583

Scheme 1584

Scheme 1585

Scheme 1586

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-494560) .
2. Remove the engine appearance cover. For additional information, refer to «ENGINE APPEARANCE COVER - EXPLODED VIEW»(ref-494555-S03086729622012081400000) .
3. Recover the A/C system. For additional information, refer to «CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS»(ref-494569) .
4. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
5. Using a suitable holding device, hold the steering wheel in the straight-ahead position.
6. Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(ref-494611) .
7. Remove the accessory drive belt and the power steering belt. For additional information, refer to «ACCESSORY DRIVE»(ref-494572) .
8. Remove the LH halfshaft and intermediate shaft. For additional information, refer to «FRONT DRIVE HALFSHAFTS»(ref-494589) .
9. Disconnect the power steering cooler hose and drain the power steering fluid into a suitable drain pan.
10. Remove the degas bottle. For additional information, refer to «ENGINE COOLING»(ref-494611) .
11. Remove the engine Air Cleaner (ACL) and ACL outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
12. Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
13. Remove the 2 nuts and disconnect the power feed from the battery terminal. Disconnect the wiring harness electrical connector.
14. Remove the nut and the ground wire. Disconnect the wiring harness electrical connector.
15. Detach the 2 wiring harness retainers from the stud bolt and bracket.
16. Disconnect the wiring harness electrical connector.
17. Detach the 3 wiring harness retainers from the bracket and inner fender.
18. Disconnect the vacuum hose from the upper intake manifold.
19. Disconnect the upper radiator hose, lower radiator hose and 2 heater hoses from the thermostat housing.
20. Disconnect the transaxle control cable from the control lever. Detach the control cable from the bracket.
21. If equipped, detach the engine block heater harness retainers from the radiator support and the A/C suction tube.
22. Remove the nut and disconnect the A/C pressure tube fitting. Discard the O-ring seal.
23. Remove the safety clip from the A/C fitting. Disconnect the A/C suction tube fitting.
24. Disconnect the hose from the power steering reservoir.
25. Disconnect the 2 PCM electrical connectors. Detach the 3 wiring harness retainers.
26. Disconnect the wiring harness electrical connector. Detach the wiring harness retainer from the RH valve cover stud bolt.
27. Remove the oil level indicator.
28. Remove the bolt and the ground wire from the engine front cover.
29. Remove the nut and the radio interference capacitor wire from the engine front cover stud.
30. Remove the exhaust Y-pipe. For additional information, refer to «EXHAUST SYSTEM»(ref-494567) .
31. Remove the LH inner splash shield. For additional information, refer to «FRONT END BODY PANELS»(ref-494576) .
32. Remove the 2 secondary latches from the transmission fluid cooler tubes.
33. Using the Transmission Cooler Tube Disconnect Tool, disconnect the transmission cooling tubes.
34. Remove the drain plug and drain the engine oil. Install the drain plug and tighten to 27 Nm (20 lb-ft).
35. Remove and discard the engine oil filter.
36. Remove the power steering cooler bracket bolt from the RH side of the subframe. All-Wheel Drive (AWD) vehicles
37. Remove the 4 bolts and support the driveshaft with a length of mechanic's wire. All vehicles
38. Remove the 2 nuts and the roll restrictor heat shield.
39. Remove the engine roll restrictor-to-subframe through bolt.
40. Remove and discard the Power Steering Pressure (PSP) tube-to-steering gear banjo bolt and the 2 seals.
41. Remove and discard the steering intermediate shaft bolt. Separate the steering intermediate shaft from the steering gear.
42. Remove and discard the cotter pins and tie-rod end nuts. Using the Tie-Rod End Remover, separate the tie-rod ends from the wheel knuckles.
43. Remove the 3 RH subframe-to-lower bumper nuts.
44. Remove the 3 LH subframe-to-lower bumper nuts and separate the lower bumper from the subframe.
45. Mark the relationship of the front subframe to the underbody at the mounting locations.
46. Position the Powertrain Lift under the subframe assembly.
47. Remove the 2 bolts and the subframe brace.
48. Remove the 2 nuts, 2 bolts and the 2 subframe support brackets.
49. Remove the 2 front subframe nuts.
50. Remove the 2 middle subframe nuts.
51. Using the Powertrain Lift, lower the subframe assembly from the vehicle.
52. Disconnect the fuel supply tube and Evaporative Emission (EVAP) tube quick connect couplings. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
53. Install the Powertrain Lift and Adjustable Grip Arms.
54. Remove the transaxle support insulator through bolt and nut.
55. Remove the 3 nuts, the bolt and the transaxle support insulator bracket.
56. Remove the nut, bolt and engine mount brace.
57. Remove the 4 engine mount nuts.
58. Remove the 3 bolts and the engine mount.
59. Lower the engine and transaxle assembly from the vehicle.
60. Remove the 3 bolts and the accessory drive belt tensioner.
61. Using the Strap Wrench, remove the crankshaft pulley bolt and washer. Discard the bolt.
62. Using the 3 Jaw Puller, remove the crankshaft pulley.
63. Using the Oil Seal Remover, remove and discard the crankshaft front seal.
64. Remove the crankcase vent tube. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
65. Disconnect the 3 LH coil-on-plug electrical connectors.
66. Remove the 3 bolts and the 3 LH-coil-on-plugs.
67. Detach the wiring harness connector pin-type retainer from the LH valve cover.
68. Detach the 2 wiring harness retainers from the LH valve cover stud bolts and position the harness aside.
69. Disconnect the 2 Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Detach the wiring harness pin-type retainer.
70. Detach the 2 wiring harness pin-type retainers.
71. Disconnect the LH Heated Oxygen Sensor (HO2S) electrical connector. Detach the wiring harness connector pin-type retainer from the LH valve cover.
72. Disconnect the 3 fuel injector electrical connectors. Detach the 2 wiring harness retainers from the LH valve cover stud bolts.
73. Detach the 2 wiring harness retainers and position the harness aside.
74. Loosen the 4 bolts and 7 stud bolts. Remove the LH valve cover. Discard the gasket.
75. Disconnect the Evaporative Emission (EVAP) canister vent solenoid and throttle body electrical connectors. Detach the wiring harness pin-type retainer.
76. Disconnect the EVAP vapor tube from the EVAP canister vent solenoid. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) . Detach the EVAP tube retainer.
77. Detach the 2 wiring harness/coolant tube retainers from the upper intake manifold.
78. Disconnect the crankcase ventilation hose from the Positive Crankcase Ventilation (PCV) valve. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
79. Remove the upper intake manifold support bracket bolt.
80. Remove the 7 bolts and the upper intake manifold. Remove and discard the gasket. Clean and inspect all of the sealing surfaces of the upper and lower intake manifold.
81. Disconnect the 3 RH coil-on-plug electrical connectors.
82. Remove the 3 bolts and the 3 RH-coil-on-plugs.
83. Disconnect the HO2S and CMS electrical connectors. Detach the 2 wiring harness retainers from the RH valve cover.
84. Disconnect the 2 Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Detach the 2 wiring harness retainers.
85. Disconnect the 3 fuel injector electrical connectors. Detach the 2 wiring harness retainers.
86. Detach the wiring harness retainer.
87. Remove the 2 nuts and position aside the 2 power steering hose brackets.
88. Loosen the 3 bolts and 8 stud bolts. Remove the RH valve cover. Discard the gasket.
89. Inspect the VCT solenoid seals. Remove any damaged seals. Using the Differential Bearing Cone Installer and Handle, remove and discard the seal(s).
90. Inspect the spark plug tube seals. Remove any damaged seals. Using the Spark Plug Tube Seal Remover and Handle, remove and discard the seal(s).
91. Clean the valve covers, cylinder heads and engine front cover sealing surfaces with metal surface prep.
92. Remove the 3 bolts and the power steering pump.
93. Remove the 26 front cover bolts.
94. Using a suitable pry tool, locate the 7 pry pads shown in illustration and pry the engine front cover loose and remove.
95. Rotate the crankshaft clockwise and align the timing marks on the intake Variable Camshaft Timing (VCT) assemblies as shown in illustration.
96. Remove the 3 bolts and the LH valve train oil tube.
97. Install the Camshaft Holding Tool onto the flats of the LH camshafts.
98. Remove the 3 bolts and the RH valve train oil tube.
99. Install the Camshaft Holding Tool onto the flats of the RH camshafts.
100. Mark the timing chain link that aligns with the timing mark on the LH intake VCT assembly as shown in illustration.
101. Mark the timing chain link that aligns with the timing mark on the RH intake VCT assembly as shown in illustration.
102. Mark the 2 timing chain links that align with the timing mark on the crankshaft sprocket as shown in illustration.
103. Remove the 2 bolts and the primary timing chain tensioner.
104. Remove the primary timing chain tensioner arm.
105. Remove the 2 bolts and the lower LH primary timing chain guide.
106. Remove the bolt and the LH intake VCT oil control solenoid. 107.
107. Remove the bolt and the RH intake VCT oil control solenoid.
108. Remove the primary timing chain. LH camshafts
109. Compress the LH secondary timing chain tensioner and install the Secondary Chain Hold Down in the hole on the rear of the secondary timing chain tensioner guide and let it hold against the mega cap to retain the tensioner in the collapsed position.
110. Remove and discard the 2 LH VCT assembly bolts.
111. Remove the 2 LH VCT assemblies and secondary timing chain. Remove the Secondary Chain Hold Down.
112. Remove the Camshaft Holding Tool from the LH camshafts.
113. Remove the 12 bolts, 6 camshaft caps, mega cap and the LH camshafts. RH camshafts
114. Compress the RH secondary timing chain tensioner and install the Secondary Chain Hold Down in the hole on the rear of the secondary timing chain tensioner guide and let it hold against the mega cap to retain the tensioner in the collapsed position.
115. Remove and discard the 2 RH VCT assembly bolts.
116. Remove the 2 RH VCT assemblies and secondary timing chain. Remove the Secondary Chain Hold Down.
117. Remove the Camshaft Holding Tool from the RH camshafts.
118. Remove the 12 bolts, 6 camshaft caps, mega cap and the RH camshafts.

Valve Tappets

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

1. Depending on the valve tappets being serviced, remove the LH and/or the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-494555-S03332497282012081400000) .
2. Remove the valve tappets from the cylinder head.

Valve Spring, Retainer and Seal

SPECIAL TOOLS CHART Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-1249

Scheme 1587

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Scheme 1588

Scheme 1589

1. Remove the valve tappets from the cylinder being serviced. For additional information, refer to «VALVE TAPPETS»(ref-494555-S39868208182012081400000) .
2. Rotate the crankshaft until the piston for the valve being serviced is at the top of its stroke.
3. Pressurize the cylinder using compressed air.
4. Using the Valve Spring Compressors, remove the keys, retainer and spring.
5. Remove and discard the valve stem seal.

Cylinder Head - RH

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.

Note. If the cylinder head is replaced, a new secondary timing chain tensioner will need to be installed.

Scheme 1590

Scheme 1591

Scheme 1592

Scheme 1593

Scheme 1594

Scheme 1595

Scheme 1596

Scheme 1597

Scheme 1598

Scheme 1599

Scheme 1600

Scheme 1601

Scheme 1602

Scheme 1603

Scheme 1604

Scheme 1605

Scheme 1606

Scheme 1607

1. Remove the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-494555-S03332497282012081400000) .
2. If equipped, remove the heat shield and disconnect the block heater electrical connector. Remove the block heater wiring harness from the engine.
3. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector.
4. Disconnect the 2 RH Camshaft Position Camshaft Position (CMP) sensor electrical connectors.
5. Remove the 2 bolts and the 2 CMP sensors.
6. Remove the bolt and the ground cable from the RH cylinder.
7. Disconnect the 6 fuel injector electrical connectors (3 shown in illustration).
8. Disconnect the Cylinder Head Temperature (CHT) sensor electrical connector.
9. Remove the LH cylinder block drain plug. Allow coolant to drain from the cylinder block.
10. Remove the 4 nuts and the RH catalytic converter. Discard the nuts and the gasket.
11. Remove the RH cylinder block drain plug or, if equipped, the block heater. Allow coolant to drain from the cylinder block.
12. Remove the 6 nuts and the RH exhaust manifold. Discard the nuts and exhaust manifold gaskets.
13. Clean and inspect the RH exhaust manifold. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
14. Remove and discard the 6 RH exhaust manifold studs.
15. Remove the bolt and the RH primary timing chain guide.
16. Remove the 2 bolts and the engine lifting eye.
17. Remove the bolt and the upper intake manifold bracket.
18. Disconnect the fuel supply tube-to-fuel rail quick connect coupling. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
19. Remove the 2 thermostat housing-to-lower intake manifold bolts.
20. Remove the 10 bolts and the lower intake manifold. Remove and discard the intake manifold and thermostat housing gaskets. Clean and inspect all sealing surfaces.
21. Disconnect and remove the CHT sensor jumper harness.
22. Remove the valve tappets from the cylinder head.
23. Inspect the valve tappets. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
24. Remove and discard the M6 bolt.
25. Remove and discard the 8 bolts from the cylinder head. Remove the cylinder head. Discard the cylinder head gasket.
26. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder heads and the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.
27. Support the cylinder head on a bench with the head gasket side up. Check the cylinder head distortion and the cylinder block distortion. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .

Cylinder Head - LH

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.

Scheme 1608

Scheme 1609

Scheme 1610

Scheme 1611

Scheme 1612

Scheme 1613

Scheme 1614

Scheme 1615

Scheme 1616

Scheme 1617

Scheme 1618

Scheme 1619

Scheme 1620

Scheme 1621

Scheme 1622

Scheme 1623

Scheme 1624

Scheme 1625

Scheme 1626

Scheme 1627

Scheme 1628

Scheme 1629

Scheme 1630

1. Remove the LH camshafts. For additional information, refer to «CAMSHAFT»(ref-494555-S03332497282012081400000) .
2. If equipped, remove the heat shield and disconnect the block heater electrical connector. Remove the block heater wiring harness from the engine.
3. Disconnect the 6 fuel injector electrical connectors (3 shown in illustration).
4. Disconnect the 2 LH Camshaft Position (CMP) sensor electrical connectors.
5. Remove the 2 bolts and the 2 LH CMP sensors.
6. Disconnect the LH Heated Oxygen Sensor (HO2S) electrical connector.
7. Disconnect the LH Catalyst Monitor Sensor (CMS) electrical connector. Remove the wiring harness retainer from the rear of the LH cylinder head.
8. Disconnect the A/C compressor electrical connector.
9. Remove the nut and disconnect the generator B+ cable.
10. Disconnect the generator electrical connector.
11. Detach the wiring harness retainer from the generator.
12. Disconnect the Engine Oil Pressure (EOP) switch electrical connector and the wiring harness pin-type retainer.
13. Remove the nut, 2 bolts and the A/C compressor.
14. Remove the nut, bolt and the generator.
15. Remove the LH Heated Oxygen Sensor (HO2S).
16. Remove the 3 bolts and the LH exhaust heat shield.
17. Remove the 6 nuts and the LH catalytic converter. Discard the nuts and the gasket.
18. Clean and inspect the catalytic converter flange. For additional information, refer to exhaust manifold cleaning and inspection in «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
19. Remove and discard the 6 LH exhaust manifold studs.
20. Remove the LH cylinder block drain plug. Allow coolant to drain from the cylinder block.
21. Remove the 4 nuts and the RH catalytic converter. Discard the nuts and the gasket.
22. Remove the RH cylinder block drain plug or, if equipped, the block heater. Allow coolant to drain from the cylinder block.
23. Disconnect the fuel supply tube-to-fuel rail quick connect coupling. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
24. Remove the 2 thermostat housing-to-lower intake manifold bolts.
25. Remove the 10 bolts and the lower intake manifold. Remove and discard the intake manifold and thermostat housing gaskets. Clean and inspect all sealing surfaces.
26. Remove the bolt and the upper LH primary timing chain guide.
27. Remove the valve tappets from the cylinder head.
28. Inspect the valve tappets. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
29. Remove and discard the M6 bolt.
30. Remove and discard the 8 bolts from the cylinder head. Remove the cylinder head. Discard the cylinder head gasket.
31. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder heads and the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.
32. Support the cylinder head on a bench with the head gasket side up. Check the cylinder head distortion and the cylinder block distortion. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .

SPECIAL TOOLS CHART 3 Jaw Puller 303-D121 or equivalent Handle 205-153 (T80T-4000-W) Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Remover, Oil Seal 303-409 (T92C-6700CH) Remover, VCT Spark Plug Tube Seal 303-1247/1 Slide Hammer 307-005 (T59L-100-B) Strap Wrench 303-D055 (D85L-6000-A) or equivalent Tool, Camshaft Holding 303-1248

Scheme 1631

Scheme 1632

Scheme 1633

Scheme 1634

Scheme 1635

Scheme 1636

Scheme 1637

Scheme 1638

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.

Note. If the cylinder head(s) is replaced, a new secondary timing chain tensioner will need to be installed.

Note. For additional information, refer to the exploded view under the ASSEMBLY service information.

All vehicles

Scheme 1639

Scheme 1640

Scheme 1641

Scheme 1642

Scheme 1643

Scheme 1644

Scheme 1645

Scheme 1646

Scheme 1647

Scheme 1648

Scheme 1649

Scheme 1650

Scheme 1651

Scheme 1652

Scheme 1653

Scheme 1654

Scheme 1655

Scheme 1656

Scheme 1657

Scheme 1658

Scheme 1659

Scheme 1660

Scheme 1661

Scheme 1662

Scheme 1663

Scheme 1664

Scheme 1665

Scheme 1666

Scheme 1667

Scheme 1668

Scheme 1669

Scheme 1670

Scheme 1671

Scheme 1672

Scheme 1673

Scheme 1674

Scheme 1675

Scheme 1676

Scheme 1677

Scheme 1678

Scheme 1679

Scheme 1680

Scheme 1681

Scheme 1682

Scheme 1683

Scheme 1684

Scheme 1685

Scheme 1686

Scheme 1687

Scheme 1688

Scheme 1689

Scheme 1690

Scheme 1691

Scheme 1692

Scheme 1693

Scheme 1694

Scheme 1695

Scheme 1696

Scheme 1697

Scheme 1698

Scheme 1699

Scheme 1700

Scheme 1701

Scheme 1702

Scheme 1703

Scheme 1704

Scheme 1705

Scheme 1706

Scheme 1707

Scheme 1708

Scheme 1709

Scheme 1710

Scheme 1711

Scheme 1712

Scheme 1713

Scheme 1714

Scheme 1715

Scheme 1716

Scheme 1717

Scheme 1718

Scheme 1719

Scheme 1720

Scheme 1721

Scheme 1722

Scheme 1723

Scheme 1724

Scheme 1725

Scheme 1726

Scheme 1727

Scheme 1728

Scheme 1729

Scheme 1730

Scheme 1731

Scheme 1732

Scheme 1733

Scheme 1734

Scheme 1735

Scheme 1736

1. Remove the 8 bolts and the flexplate.
2. Remove the crankshaft sensor ring.
3. Using the Crankshaft Rear Oil Seal Remover and Slide Hammer, remove and discard the rear crankshaft seal.
4. Mount the engine on a suitable engine stand.
5. If equipped, remove the heat shield and disconnect the block heater electrical connector. Detach all of the engine block heater harness retainers and remove the harness.
6. Remove the 3 bolts and the accessory drive belt tensioner.
7. Using the Strap Wrench, remove the crankshaft pulley bolt and washer. Discard the bolt.
8. Using the 3 Jaw Puller, remove the crankshaft pulley.
9. Using the Oil Seal Remover, remove and discard the crankshaft front seal.
10. Remove the crankcase vent tube. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
11. Disconnect the 3 LH coil-on-plug electrical connectors.
12. Detach the wiring harness connector pin-type retainer from the LH valve cover.
13. Detach the 2 wiring harness retainers from the LH valve cover stud bolts and position the harness aside.
14. Disconnect the 2 Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Detach the wiring harness pin-type retainer.
15. Detach the 2 wiring harness pin-type retainers.
16. Disconnect the LH Heated Oxygen Sensor (HO2S) electrical connector. Detach the wiring harness connector pin-type retainer from the LH valve cover.
17. Disconnect the 3 fuel injector electrical connectors. Detach the 2 wiring harness retainers from the LH valve cover stud bolts.
18. Detach the 2 wiring harness retainers and position the harness aside.
19. Disconnect the 2 LH Camshaft Position (CMP) sensor electrical connectors.
20. Disconnect the LH Catalyst Monitor Sensor (CMS) electrical connector. Remove the wiring harness retainer from the rear of the LH cylinder head.
21. Detach the wiring harness retainer from the intake manifold.
22. Disconnect the Evaporative Emission (EVAP) canister vent solenoid and throttle body electrical connectors. Detach the wiring harness pin-type retainer.
23. Detach the 2 wiring harness/coolant tube retainers from the upper intake manifold.
24. Disconnect the crankcase ventilation hose from the Positive Crankcase Ventilation (PCV) valve. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
25. Remove the upper intake manifold support bracket bolt.
26. Remove the 7 bolts and the upper intake manifold. Remove and discard the gasket. Clean and inspect all of the sealing surfaces of the upper and lower intake manifold.
27. Disconnect the 3 RH coil-on-plug electrical connectors.
28. Disconnect the HO2S and CMS electrical connectors. Detach the 2 wiring harness retainers from the RH valve cover.
29. Disconnect the 2 Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Detach the 2 wiring harness retainers.
30. Disconnect the 3 fuel injector electrical connectors. Detach the 2 wiring harness retainers.
31. Detach the wiring harness retainer.
32. Disconnect the 2 RH Camshaft Position Camshaft Position (CMP) sensor electrical connectors.
33. Disconnect the Knock Sensor (KS) electrical connector.
34. Disconnect the Cylinder Head Temperature (CHT) sensor electrical connector.
35. Remove the bolt and the ground cable from the RH cylinder.
36. Remove the nut, the bolt and the heat shield.
37. Remove the wiring harness retainer stud bolt.
38. Remove the wiring harness grommet.
39. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
40. Disconnect the A/C compressor electrical connector.
41. Remove the nut and disconnect the generator B+ cable.
42. Disconnect the generator electrical connector.
43. Detach the wiring harness retainer from the generator.
44. Disconnect the Engine Oil Pressure (EOP) switch electrical connector and the wiring harness pin-type retainer. Remove the wiring harness from the engine.
45. Remove the nut, 2 bolts and the A/C compressor.
46. Remove the A/C compressor mounting stud from the oil pan.
47. Remove the nut, bolt and the generator.
48. Remove the 2 nuts and position aside the 2 power steering hose brackets.
49. Remove the 3 bolts and the power steering pump.
50. Remove the LH Heated Oxygen Sensor (HO2S).
51. Remove the 3 bolts and the LH exhaust heat shield.
52. Remove the 6 nuts and the LH catalytic converter. Discard the nuts and the gasket.
53. Clean and inspect the catalytic converter flange. For additional information, refer to exhaust manifold cleaning and inspection in «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
54. Remove and discard the 6 LH exhaust manifold studs. Front Wheel Drive (FWD) vehicles
55. Remove the 4 nuts and the RH catalytic converter. Discard the nuts and the gasket. All vehicles
56. Remove the 6 nuts and the RH exhaust manifold. Discard the nuts and exhaust manifold gaskets.
57. Clean and inspect the RH exhaust manifold. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
58. Remove and discard the 6 RH exhaust manifold studs.
59. Remove the RH cylinder block drain plug or, if equipped, the block heater. Allow coolant to drain from the cylinder block.
60. Remove the LH cylinder block drain plug. Allow coolant to drain from the cylinder block.
61. Remove the pin-type retainer and the cover.
62. Remove the 2 bolts and the 2 LH CMP sensors.
63. Remove the 2 bolts and the 2 RH CMP sensors.
64. Remove the 2 thermostat housing-to-lower intake manifold bolts.
65. Remove the 10 bolts and the lower intake manifold. Remove and discard the intake manifold and thermostat housing gaskets. Clean and inspect all sealing surfaces.
66. Remove the coolant inlet tube and thermostat assembly. Remove and discard the O-ring seal.
67. Disconnect and remove the CHT sensor jumper harness.
68. Remove the bolt and the CKP sensor.
69. Remove the EOP switch.
70. Remove the 3 bolts and the oil filter adapter. Discard the gasket.
71. Remove the 3 bolts and the 3 LH-coil-on-plugs.
72. Loosen the 4 bolts and 7 stud bolts. Remove the LH valve cover. Discard the gasket.
73. Remove the 3 bolts and the 3 RH-coil-on-plugs.
74. Loosen the 3 bolts and 8 stud bolts. Remove the RH valve cover. Discard the gasket.
75. Inspect the VCT solenoid seals. Remove any damaged seals. Using the Differential Bearing Cone Installer and Handle, remove and discard the seal(s).
76. Inspect the spark plug tube seals. Remove any damaged seals. Using the Spark Plug Tube Seal Remover and Handle, remove and discard the seal(s).
77. Clean the valve covers, cylinder heads and engine front cover sealing surfaces with metal surface prep.
78. Remove the 26 front cover bolts.
79. Using a suitable pry tool, locate the 7 pry pads shown in illustration and pry the engine front cover loose and remove.
80. Rotate the crankshaft clockwise and align the timing marks on the intake Variable Camshaft Timing (VCT) assemblies as shown in illustration.
81. Remove the 3 bolts and the LH valve train oil tube.
82. Install the Camshaft Holding Tool onto the flats of the LH camshafts.
83. Remove the 3 bolts and the RH valve train oil tube.
84. Install the Camshaft Holding Tool onto the flats of the RH camshafts.
85. Mark the timing chain link that aligns with the timing mark on the LH intake VCT assembly as shown in illustration.
86. Mark the timing chain link that aligns with the timing mark on the RH intake VCT assembly as shown in illustration.
87. Mark the 2 timing chain links that align with the timing mark on the crankshaft sprocket as shown in illustration.
88. Remove the 2 bolts and the primary timing chain tensioner.
89. Remove the primary timing chain tensioner arm.
90. Remove the 2 bolts and the lower LH primary timing chain guide.
91. Remove the bolt and the LH intake VCT oil control solenoid.
92. Remove the bolt and the RH intake VCT oil control solenoid.
93. Remove the primary timing chain.
94. Remove the bolt and the upper LH primary timing chain guide.
95. Remove the crankshaft timing chain sprocket.
96. Compress the LH secondary timing chain tensioner and install the Secondary Chain Hold Down in the hole on the rear of the secondary timing chain tensioner guide and let it hold against the mega cap to retain the tensioner in the collapsed position.
97. Remove and discard the 2 LH VCT assembly bolts.
98. Remove the 2 LH VCT assemblies and secondary timing chain. Remove the Secondary Chain Hold Down.
99. Remove the Camshaft Holding Tool from the LH camshafts.
100. Remove the 12 bolts, 6 camshaft caps, mega cap and the LH camshafts.
101. Compress the RH secondary timing chain tensioner and install the Secondary Chain Hold Down in the hole on the rear of the secondary timing chain tensioner guide and let it hold against the mega cap to retain the tensioner in the collapsed position.
102. Remove and discard the 2 RH VCT assembly bolts.
103. Remove the 2 RH VCT assemblies and secondary timing chain. Remove the Secondary Chain Hold Down.
104. Remove the bolt and the RH primary timing chain guide.
105. Remove the Camshaft Holding Tool from the RH camshafts.
106. Remove the 12 bolts, 6 camshaft caps, mega cap and the RH camshafts.
107. Remove the 2 bolts and the engine lifting eye.
108. Remove the bolt and the upper intake manifold bracket.
109. Remove the valve tappets from the cylinder heads.
110. Remove and discard the M6 bolt from each cylinder head.
111. Remove and discard the 8 bolts from each cylinder head. Remove the cylinder heads. Discard the cylinder head gaskets.
112. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder heads and the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal. Make sure the 2 locating dowel pins are seated correctly in the cylinder block.
113. Support the cylinder head on a bench with the head gasket side up. Check the cylinder head distortion and the cylinder block distortion. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
114. Remove the 2 bolts and the KS.
115. Remove the 8 bolts and the coolant pump.
116. Remove the 16 oil pan bolts.
117. Using a suitable pry tool, locate the 5 pry pads shown in illustration and pry the oil pan loose and remove.
118. Remove the 2 bolts and the oil pump screen and pickup tube. Discard the O-ring seal.
119. Remove the 3 bolts and the oil pump.
120. Remove the 8 crankshaft rear seal retainer bolts.
121. Install the 2 M6 oil pan bolts (finger-tight) into the 2 threaded holes in the crankshaft rear seal retainer. Alternately tighten the 2 bolts one turn at a time until the crankshaft rear seal retainer-to-cylinder block seal is released. Remove the crankshaft rear seal retainer.
122. Clean the engine front cover, oil pan and crankshaft rear seal retainer plate using a 3M™ Roloc® Bristle Disk (2 inch, white, part number 07528) in a suitable tool turning at the recommended speed of 15, 000 rpm. Thoroughly wash the engine front cover, oil pan and crankshaft rear seal retainer plate to remove any foreign material, including any abrasive particles created during the cleaning process.
123. Before removing the pistons, inspect the top of the cylinder bores. If necessary, remove the ridge or carbon deposits from each cylinder using an abrasive pad or equivalent, following manufacturer's instructions.
124. Remove the bolts in the sequence shown in illustration. Remove the main bearing cap support brace. Discard the bolts.
125. Remove the connecting rod cap bolts and cap.
126. Remove the piston/rod assembly from the engine block.
127. Repeat the previous 2 steps until all the piston/rod assemblies are removed from the engine block.
128. Remove the 8 main bearing cap side bolts and the 8 main bearing cap bolts in the sequence shown in illustration. Discard the bolts.
129. Remove the 4 main bearing caps.
130. Remove the crankshaft.
131. Remove the 2 crankshaft thrust bearings from the rear main bearing bulkhead.
132. Remove the 4 crankshaft main bearings from the cylinder block.
133. Remove the 4 crankshaft main bearings from the main bearing caps.
134. Inspect the cylinder block, bearing cap support brace, pistons and connecting rods. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-494566) .
135. Clean the sealing surfaces of the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material. Apply silicone gasket remover and allow to set for several minutes. Remove the silicone gasket remover. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep to remove any remaining traces of oil or coolant and to prepare the surfaces to bond. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal. Make sure the 2 locating dowel pins are seated correctly in the cylinder block.

Cylinder Head

SPECIAL TOOLS CHART Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-1249 Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH)

Scheme 1737

MATERIAL SPECIFICATIONS

Scheme 1738

Piston

MATERIAL SPECIFICATIONS

Scheme 1739

SPECIAL TOOLS CHART Alignment Pins 307-399 Handle 205-153 (T80T-4000-W) Hold Down, Secondary Chain 303-1530 Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Installer, Front Cover Oil Seal 303-335 (T88T-6701-A) Installer, Front Crankshaft Seal 303-1251 Installer, VCT Spark Plug Tube Seal 303-1247/2 Powertrain Lift 300-OTC1585AE Replacer, Crankshaft Vibration Damper 303-102 (T74P-6312-B) Strap Wrench 303-D055 (D85L-6000-A) or equivalent Tool, Camshaft Holding 303-1248 Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 1740

Scheme 1741

Scheme 1742

Scheme 1743

Scheme 1744

Scheme 1745

Scheme 1746

MATERIAL SPECIFICATIONS

RH camshafts

Scheme 1747

Scheme 1748

Scheme 1749

Scheme 1750

Scheme 1751

Scheme 1752

Scheme 1753

Scheme 1754

Scheme 1755

Scheme 1756

Scheme 1757

Scheme 1758

Scheme 1759

Scheme 1760

Scheme 1761

Scheme 1762

Scheme 1763

Scheme 1764

Scheme 1765

Scheme 1766

Scheme 1767

Scheme 1768

Scheme 1769

Scheme 1770

Scheme 1771

Scheme 1772

Scheme 1773

Scheme 1774

Scheme 1775

Scheme 1776

Scheme 1777

Scheme 1778

Scheme 1779

Scheme 1780

Scheme 1781

Scheme 1782

Scheme 1783

Scheme 1784

Scheme 1785

Scheme 1786

Scheme 1787

Scheme 1788

Scheme 1789

Scheme 1790

Scheme 1791

Scheme 1792

Scheme 1793

Scheme 1794

Scheme 1795

Scheme 1796

Scheme 1797

Scheme 1798

Scheme 1799

Scheme 1800

Scheme 1801

Scheme 1802

Scheme 1803

Scheme 1804

Scheme 1805

Scheme 1806

Scheme 1807

Scheme 1808

Scheme 1809

Scheme 1810

Scheme 1811

Scheme 1812

Scheme 1813

Scheme 1814

Scheme 1815

Scheme 1816

Scheme 1817

Scheme 1818

Scheme 1819

Scheme 1820

Scheme 1821

Scheme 1822

Scheme 1823

Scheme 1824

Scheme 1825

Scheme 1826

Scheme 1827

Scheme 1828

Scheme 1829

Scheme 1830

Scheme 1831

Scheme 1832

Scheme 1833

Scheme 1834

Scheme 1835

Scheme 1836

Scheme 1837

Scheme 1838

Scheme 1839

Scheme 1840

Scheme 1841

Scheme 1842

Scheme 1843

Scheme 1844

Scheme 1845

Scheme 1846

Scheme 1847

Scheme 1848

Scheme 1849

Scheme 1850

Scheme 1851

1. Position the camshafts onto the RH cylinder head in the neutral position as shown in illustration.
2. Rotate the crankshaft counterclockwise until the crankshaft dowel pin is in the 9 o'clock position.
3. Position the 4 camshaft seals gaps as shown in illustration.
4. Install the 6 camshaft caps, mega cap, valve train oil tube and the 15 bolts in the sequence shown in illustration. Tighten to 8 Nm (71 lb-in) then additional 45 degrees.
5. Loosen the 4 camshaft caps bolts.
6. Tighten the 4 camshaft caps bolts in the sequence shown in illustration. Tighten bolts 8, 9, 10 and 11 to 8 Nm (71 lb-in) then additional 45 degrees.
7. Using a feeler gauge, confirm that the valve tappet clearances are within specification. If valve tappet clearances are not within specification, the clearance must be adjusted by installing new valve tappet(s) of the correct size. For additional information, refer to «VALVE CLEARANCE CHECK»(ref-494555-S00964058092012081400000) .
8. Remove the 3 bolts and the RH valve train oil tube.
9. Rotate the RH camshafts to the TDC position as shown in illustration.
10. Install the Camshaft Holding Tool onto the flats of the RH camshafts.
11. Compress the RH secondary timing chain tensioner and install the Secondary Chain Hold Down to retain the tensioner in the collapsed position.
12. Assemble the RH VCT assembly, the RH exhaust camshaft sprocket and the RH secondary timing chain. Align the colored links with the timing marks.
13. Position the 2 RH VCT assemblies and secondary timing chain onto the camshafts by aligning the holes in the VCT assemblies with the dowel pins in the camshafts.
14. Install the 2 new RH VCT bolts and tighten in 4 stages. Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 25 Nm (18 lb-ft). Stage 4: Tighten an additional 180 degrees.
15. Compress the RH secondary timing chain tensioner and remove the Secondary Chain Hold Down. Make sure the secondary timing chain is centered on the timing chain tensioner guides. LH camshafts
16. Position the camshafts onto the LH cylinder head in the neutral position as shown in illustration.
17. Rotate the crankshaft counterclockwise until the crankshaft dowel pin is in the 9 o'clock position.
18. Position the 4 camshaft seals gaps as shown in illustration.
19. Install the 6 camshaft caps, mega cap, valve train oil tube and the 15 bolts in the sequence shown in illustration. Tighten to 8 Nm (71 lb-in) then additional 45 degrees.
20. Loosen the 4 camshaft caps bolts.
21. Tighten the 4 camshaft caps bolts in the sequence shown in illustration. Tighten bolts 8, 9, 10 and 11 to 8 Nm (71 lb-in) then additional 45 degrees.
22. Using a feeler gauge, confirm that the valve tappet clearances are within specification. If valve tappet clearances are not within specification, the clearance must be adjusted by installing new valve tappet(s) of the correct size. For additional information, refer to «VALVE CLEARANCE CHECK»(ref-494555-S00964058092012081400000) .
23. Remove the 3 bolts and the LH valve train oil tube.
24. Rotate the LH camshafts to the TDC position as shown in illustration.
25. Install the Camshaft Holding Tool onto the flats of the LH camshafts.
26. Compress the LH secondary timing chain tensioner and install the Secondary Chain Hold Down to retain the tensioner in the collapsed position.
27. Assemble the 2 LH VCT assemblies and the LH secondary timing chain. Align the colored links with the timing marks.
28. Position the 2 LH VCT assemblies and secondary timing chain onto the camshafts by aligning the holes in the VCT assemblies with the dowel pins in the camshafts.
29. Install the 2 new LH VCT bolts and tighten in 4 stages. Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 25 Nm (18 lb-ft). Stage 4: Tighten an additional 180 degrees.
30. Compress the LH secondary timing chain tensioner and remove the Secondary Chain Hold Down. Make sure the secondary timing chain is centered on the timing chain tensioner guides. All camshafts
31. Rotate the crankshaft clockwise 60 degrees to the TDC position (crankshaft dowel pin at 11 o'clock).
32. Install the primary timing chain with the colored links aligned with the timing marks on the VCT assemblies and the crankshaft sprocket.
33. Install the lower LH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in).
34. Install the primary timing chain tensioner arm.
35. Reset the primary timing chain tensioner. Release the ratchet detent. Using a soft-jawed vise, compress the ratchet plunger. Align the hole in the ratchet plunger with the hole in the tensioner housing. Install a suitable lockpin.
36. Install the primary tensioner and the 2 bolts. Tighten to 10 Nm (89 lb-in). Remove the lockpin.
37. As a post-check, verify correct alignment of all timing marks. There is 48 links in between the RH intake VCT assembly colored link (1) and the LH intake VCT assembly colored link (2). There is 35 links in between LH intake VCT assembly colored link (2) and the 2 crankshaft sprocket links (3).
38. Install the LH intake VCT oil control solenoid and the bolt. Tighten to 8 Nm (71 lb-in) then an additional 20 degrees.
39. Install the RH intake VCT oil control solenoid and the bolt. Tighten to 8 Nm (71 lb-in) then an additional 20 degrees.
40. Remove the RH Camshaft Holding Tool.
41. Install the RH valve train oil tube and the 3 bolts and tighten in 2 stages. Stage 1: Tighten to 8 Nm (71 lb-in). Stage 2: Tighten an additional 45 degrees.
42. Remove the LH Camshaft Holding Tool.
43. Install the LH valve train oil tube and the 3 bolts and tighten in 2 stages. Stage 1: Tighten to 8 Nm (71 lb-in). Stage 2: Tighten an additional 45 degrees.
44. Clean the engine front cover using a 3M™ Roloc® Bristle Disk (2-in white, part number 07528) in a suitable tool turning at the recommended speed of 15, 000 rpm. Thoroughly wash the engine front cover to remove any foreign material, including any abrasive particles created during the cleaning process.
45. Clean the sealing surfaces of the cylinder heads, the cylinder block and the oil pan in the following sequence. Remove any large deposits of silicone or gasket material. Apply silicone gasket remover and allow to set for several minutes. Remove the silicone gasket remover. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep to remove any remaining traces of oil or coolant and to prepare the surfaces to bond. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal. Make sure the 2 locating dowel pins are seated correctly in the cylinder block.
46. Install the Alignment Pins.
47. Apply a 3.0 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover sealing surfaces including the 4 inner bolt bosses. Apply a 5.5 mm (0.21 in) bead of Motorcraft® High Performance Engine RTV Silicone to the oil pan-to-cylinder block joint and the cylinder head-to-cylinder block joint areas of the engine front cover in 5 places as indicated.
48. Install the engine front cover and bolts 7, 8, 15, 17, 18, 21 and 22. Tighten in sequence to 3 Nm (27 lb-in).
49. Remove the Alignment Pins.
50. Install the M6 engine front cover bolt.
51. Install the 3 M10 engine front cover bolts.
52. Install the remaining engine front cover bolts. Tighten all of the engine front cover bolts and engine mount bracket bolts in the sequence shown in illustration in 7 stages: Stage 1: Tighten bolts 1 thru 22 to 10 Nm (89 lb-in). Stage 2: Tighten bolts 23, 24 and 25 to 15 Nm (133 lb-in). Stage 3: Tighten bolt 26 to 10 Nm (89 lb-in). Stage 4: Loosen bolt 26 one full turn. Stage 5: Tighten bolts 23, 24 and 25 to 30 Nm (22 lb-ft) plus an additional 90 degrees. Stage 6: Tighten bolts 1 thru 22 to 20 Nm (177 lb-in) plus an additional 45 degrees. Stage 7: Tighten bolt 26 to 10 Nm (89 lb-in) plus an additional 45 degrees.
53. Install the power steering pump and the 3 bolts. Tighten to 25 Nm (18 lb-ft).
54. Using the VCT Spark Plug Tube Seal Installer and Handle, install new spark plug tube seals.
55. Using the Differential Bearing Cone Installer and Handle, install new VCT solenoid seal(s).
56. Apply an 8 mm (0.31 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover-to-RH cylinder head joints.
57. Using a new gasket, install the RH valve cover and tighten the 4 bolts and 7 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
58. Make sure the VCT seals in the valve cover are below the top of the VCT oil control solenoid electrical connector or the VCT seal may leak oil.
59. Position the 2 power steering hose brackets and install the 2 nuts. Tighten to 9 Nm (80 lb-in).
60. Attach the wiring harness retainer.
61. Connect the 3 fuel injector electrical connectors. Attach the 2 wiring harness retainers.
62. Connect the 2 Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Attach the 2 wiring harness retainers.
63. Connect the HO2S and CMS electrical connectors. Attach the 2 wiring harness retainers to the RH valve cover.
64. Install the 3 RH-coil-on-plugs and the 3 bolts. Tighten to 7 Nm (62 lb-in).
65. Connect the 3 RH coil-on-plug electrical connectors.
66. Using a new gasket, install the intake manifold and the 7 bolts. Tighten in the sequence shown in illustration in 2 stages. Stage 1: Tighten to 10 Nm (89 lb-in). Stage 2: Tighten an additional 45 degrees.
67. Install the upper intake manifold support bracket bolt. Tighten to 10 Nm (89 lb-in).
68. Connect the crankcase ventilation hose to the Positive Crankcase Ventilation (PCV) valve. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
69. Attach the 2 wiring harness/coolant tube retainers to the upper intake manifold.
70. Connect the EVAP vapor tube to the EVAP canister vent solenoid. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) . Attach the pin-type retainer.
71. Connect the Evaporative Emission (EVAP) canister vent solenoid and throttle body electrical connectors. Attach the wiring harness pin-type retainer.
72. Apply an 8 mm (0.31 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover-to-LH cylinder head joints.
73. Using a new gasket, install the LH valve cover and tighten the 4 bolts and 7 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
74. Make sure the VCT seals in the valve cover are below the top of the VCT oil control solenoid electrical connector or the VCT seal may leak oil.
75. Attach the 2 wiring harness retainers.
76. Connect the 3 fuel injector electrical connectors. Attach the 2 wiring harness retainers to the LH valve cover stud bolts.
77. Connect the LH Heated Oxygen Sensor (HO2S) electrical connector. Attach the wiring harness connector pin-type retainer to the LH valve cover.
78. Attach the 2 wiring harness pin-type retainers.
79. Connect the 2 Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Attach the wiring harness pin-type retainer.
80. Attach the 2 wiring harness retainers to the LH valve cover stud bolts.
81. Attach the wiring harness connector pin-type retainer to the LH valve cover.
82. Install the 3 LH-coil-on-plugs and the 3 bolts. Tighten to 7 Nm (62 lb-in.
83. Connect the 3 LH coil-on-plug electrical connectors.
84. Install the crankcase vent tube. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
85. Using the Crankshaft Vibration Damper Replacer and Front Crankshaft Seal Installer, install a new crankshaft front seal.
86. Using the Crankshaft Vibration Damper Replacer and Front Cover Oil Seal Installer, install the crankshaft pulley.
87. Using the Strap Wrench, install the crankshaft pulley washer and new bolt and tighten in 4 stages. Stage 1: Tighten to 120 Nm (89 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
88. Install the accessory drive belt tensioner and the 3 bolts. Tighten to 11 Nm (97 lb-in).
89. Raise the engine and transaxle assembly into the vehicle.
90. Install the engine mount and the 3 bolts. Tighten to 90 Nm (66 lb-ft).
91. Install the 4 engine mount nuts. Tighten to 63 Nm (46 lb-ft).
92. Install the engine mount brace, the nut and the bolt. Tighten to 20 Nm (177 lb-in).
93. Install the transaxle support insulator bracket, the 3 nuts and the bolt. Tighten the bolt to 80 Nm (59 lb-ft). Tighten the 3 nuts to 63 Nm (46 lb-ft).
94. Install the transaxle support insulator through bolt and nut. Tighten to 175 Nm (129 lb-ft).
95. Connect the fuel supply tube and Evaporative Emission (EVAP) tube quick connect couplings. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
96. Using the Powertrain Lift, raise the subframe into the installed position.
97. Install the 2 middle subframe nuts. Tighten to 133 Nm (98 lb-ft).
98. Install the 2 front subframe nuts. Tighten to 133 Nm (98 lb-ft).
99. Position the subframe support brackets in place and loosely install the 2 bolts and 2 nuts.
100. Position the subframe brace and loosely install the 2 bolts.
101. Tighten the 2 rear subframe bracket nuts to 133 Nm (98 lb-ft).
102. Tighten the 4 bolts to 90 Nm (66 lb-ft).
103. Position the lower bumper on the subframe and install the 3 LH nuts. Tighten to 9 Nm (80 lb-in).
104. Install the 3 RH lower bumper-to-subframe nuts. Tighten to 9 Nm (80 lb-in).
105. Install the tie-rod ends and nuts. Tighten to 48 Nm (35 lb-ft). Install new cotter pins.
106. Install the intermediate shaft onto the steering gear and install a new bolt. Tighten to 23 Nm (17 lb-ft).
107. Using a new banjo bolt and 2 new seals, install the Power Steering Pressure (PSP) tube. Tighten to 48 Nm (35 lb-ft).
108. Install the engine roll restrictor-to-subframe through bolt. Tighten to 115 Nm (85 lb-ft).
109. Install the roll restrictor heat shield and the 2 nuts. Tighten to 9 Nm (80 lb-in). AWD vehicles
110. Line up the index marks on the rear driveshaft to the index marks on the PTU flange made during removal and install the 4 bolts. Tighten to 70 Nm (52 lb-ft). All vehicles
111. Install the power steering cooler bracket bolt to the RH side of the subframe. Tighten to 9 Nm (80 lb-in).
112. Connect the power steering cooler hose.
113. Install a new engine oil filter. Tighten to 5 Nm (44 lb-in) and then rotate an additional 180 degrees.
114. Connect the 2 transmission fluid cooler tubes.
115. Install the 2 secondary latches onto the transmission fluid cooler tubes.
116. Install the LH inner splash shield. For additional information, refer to «FRONT END BODY PANELS»(ref-494576) .
117. Install the exhaust Y-pipe. For additional information, refer to «EXHAUST SYSTEM»(ref-494567) .
118. Install the radio interference capacitor wire and the nut to the engine front cover stud. Tighten to 10 Nm (89 lb-in).
119. Install the ground wire and bolt to the engine front cover. Tighten to 10 Nm (89 lb-in).
120. Install the oil level indicator.
121. Connect the wiring harness electrical connector. Attach the wiring harness retainer to the RH valve cover stud bolt.
122. Connect the 2 PCM electrical connectors. Attach the 3 wiring harness retainers.
123. Connect the hose to the power steering reservoir.
124. Connect the A/C suction tube fitting. Install the safety clip onto the A/C fitting.
125. Using a new O-ring seal, connect the A/C tube fitting and install the nut. Tighten to 8 Nm (71 lb-in).
126. If equipped, attach the engine block heater harness retainers to the radiator support and the A/C suction tube.
127. Attach the control cable to the bracket. Connect the transaxle control cable to the control lever.
128. Connect the upper radiator hose, lower radiator hose and 2 heater hoses to the thermostat housing.
129. Connect the vacuum hose to the upper intake manifold.
130. Attach the 3 wiring harness retainers to the bracket and inner fender.
131. Connect the wiring harness electrical connector.
132. Attach the 2 wiring harness retainers to the stud bolt and bracket.
133. Install the ground wire and bolt. Tighten to 10 Nm (89 lb-in). Connect the wiring harness electrical connector.
134. Connect the power feed to the battery terminal and install the 2 nuts. Tighten to 8 Nm (71 lb-in). Connect the wiring harness electrical connector.
135. Install the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
136. Install the engine Air Cleaner (ACL) and the ACL outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
137. Install the degas bottle. For additional information, refer to «ENGINE COOLING»(ref-494611) .
138. Install the intermediate shaft and the LH halfshaft. For additional information, refer to «FRONT DRIVE HALFSHAFTS»(ref-494589) .
139. Install the accessory drive belt and the power steering belt. For additional information, refer to «ACCESSORY DRIVE»(ref-494572) .
140. Fill the engine with clean engine oil.
141. Fill and bleed the cooling system. For additional information, refer to «ENGINE COOLING»(ref-494611) .
142. Fill the power steering system. For additional information, refer to «STEERING SYSTEM»(ref-494570) .
143. Recharge the A/C system. For additional information, refer to «CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS»(ref-494569) .
144. After completing the repairs, use the scan tool to perform the Misfire Monitor Neutral Profile Correction procedure following the on-screen instructions.

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

1. Install the valve tappets.
2. Depending on the valve tappets being serviced, install the LH and/or the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-494555-S11409700892012081400000) .

SPECIAL TOOLS CHART Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-1249 Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH)

Scheme 1852

Scheme 1853

Scheme 1854

MATERIAL SPECIFICATIONS

Scheme 1855

1. Using the Valve Stem Oil Seal Installer, install a new valve stem seal.
2. Using the Valve Spring Compressors, install the valve spring, retainer and key.
3. Install the valve tappets. For additional information, refer to «VALVE TAPPETS»(ref-494555-S26200713572012081400000) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.

Note. If the cylinder head is replaced, a new secondary timing chain tensioner will need to be installed.

Note. The valve tappets must be installed in their original positions. Coat the valve tappets with clean engine oil prior to installation.

Scheme 1856

Scheme 1857

Scheme 1858

Scheme 1859

Scheme 1860

Scheme 1861

Scheme 1862

Scheme 1863

Scheme 1864

Scheme 1865

Scheme 1866

Scheme 1867

Scheme 1868

Scheme 1869

Scheme 1870

Scheme 1871

Scheme 1872

Scheme 1873

Scheme 1874

Scheme 1875

1. Install a new gasket, the RH cylinder head and 8 new bolts. Tighten in the sequence shown in illustration in 5 stages: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 35 Nm (26 lb-ft). Stage 3: Tighten 90 degrees. Stage 4: Tighten 90 degrees Stage 5: Tighten 45 degrees.
2. Install the M6 bolt. Tighten to 10 Nm (89 lb-in).
3. Install the valve tappets.
4. Install and connect the CHT sensor jumper harness.
5. Using new intake manifold and thermostat housing gaskets, install the lower intake manifold and the 10 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
6. Install the 2 thermostat housing-to-lower intake manifold bolts. Tighten to 10 Nm (89 lb-in).
7. Connect the fuel supply tube-to-fuel rail quick connect coupling. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
8. Install the upper intake manifold bracket and the bolt. Tighten to 10 Nm (89 lb-in).
9. Install the engine lifting eye and the 2 bolts. Tighten to 24 Nm (18 lb-ft).
10. Install the RH primary timing chain guide and the bolt. Tighten to 10 Nm (89 lb-in).
11. Install 6 new RH exhaust manifold studs. Tighten to 12 Nm (106 lb-in).
12. Using a new gasket, install the RH exhaust manifold and 6 new nuts. Tighten in 2 stages in the sequence shown in illustration: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft).
13. If equipped, install the block heater wiring harness onto the engine. Tighten the cylinder block drain plug to 10 Nm (89 lb-in) plus an additional 720 degrees. Tighten the block heater to 40 Nm (30 lb-ft).
14. Using a new gasket, install the RH catalytic converter and 4 new nuts. Tighten to 40 Nm (30 lb-ft).
15. Install the LH cylinder block drain plug. Tighten to 16 Nm (142 lb-in) plus an additional 180 degrees.
16. Connect the Cylinder Head Temperature (CHT) sensor electrical connector.
17. Connect the 6 fuel injector electrical connectors (3 shown in illustration).
18. Install the ground wire and the bolt on the RH cylinder. Tighten to 10 Nm (89 lb-in).
19. Install the 2 CMP sensors and the 2 bolts. Tighten to 10 Nm (89 lb-in).
20. Connect the 2 RH Camshaft Position Camshaft Position (CMP) sensor electrical connectors.
21. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector.
22. If equipped, position the block heater wiring harness onto the engine. Connect the block heater electrical connector and install the heat shield.
23. Install the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-494555-S11409700892012081400000) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.

Note. If the cylinder head is replaced, a new secondary timing chain tensioner will need to be installed.

Note. The valve tappets must be installed in their original positions. Coat the valve tappets with clean engine oil prior to installation.

Scheme 1876

Scheme 1877

Scheme 1878

Scheme 1879

Scheme 1880

Scheme 1881

Scheme 1882

Scheme 1883

Scheme 1884

Scheme 1885

Scheme 1886

Scheme 1887

Scheme 1888

Scheme 1889

Scheme 1890

Scheme 1891

Scheme 1892

Scheme 1893

Scheme 1894

Scheme 1895

Scheme 1896

Scheme 1897

Scheme 1898

Scheme 1899

Scheme 1900

1. Install a new gasket, the LH cylinder head and 8 new bolts. Tighten in the sequence shown in illustration in 5 stages: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 35 Nm (26 lb-ft). Stage 3: Tighten 90 degrees. Stage 4: Tighten 90 degrees Stage 5: Tighten 45 degrees.
2. Install the M6 bolt. Tighten to 10 Nm (89 lb-in).
3. Install the valve tappets.
4. Install the LH upper primary timing chain guide and the bolt. Tighten to 10 Nm (89 lb-in).
5. Using new intake manifold and thermostat housing gaskets, install the lower intake manifold and the 10 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
6. Install the 2 thermostat housing-to-lower intake manifold bolts. Tighten to 10 Nm (89 lb-in).
7. Connect the fuel supply tube-to-fuel rail quick connect coupling. For additional information, refer to the quick connect coupling procedure in «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
8. If equipped, install the block heater wiring harness onto the engine. Tighten the cylinder block drain plug to 10 Nm (89 lb-in) plus an additional 720 degrees. Tighten the block heater to 40 Nm (30 lb-ft).
9. Using a new gasket, install the RH catalytic converter and 4 new nuts. Tighten to 40 Nm (30 lb-ft).
10. Install the LH cylinder block drain plug. Tighten to 16 Nm (142 lb-in) plus an additional 180 degrees.
11. Install 6 new LH exhaust manifold studs. Tighten to 12 Nm (106 lb-in).
12. Using a new gasket, install the LH catalytic converter and 3 new lower LH catalytic converter manifold-to-cylinder head nuts. Install the 3 new upper LH catalytic converter manifold-to-cylinder head nuts and tighten to 25 Nm (18 lb-ft). Tighten the 3 lower LH catalytic converter manifold-to-cylinder head nuts to 25 Nm (18 lb-ft).
13. Install the LH exhaust heat shield and the 3 bolts. Tighten to 12 Nm (106 lb-in).
14. Install the LH HO2S. Tighten to 48 Nm (35 lb-ft).
15. Install the generator, the bolt and the nut. Tighten to 47 Nm (35 lb-ft).
16. Install the A/C compressor, the 2 bolts and the nut. Tighten to 25 Nm (18 lb-ft).
17. Connect the Engine Oil Pressure (EOP) switch electrical connector and the wiring harness pin-type retainer.
18. Attach the wiring harness retainer to the generator.
19. Connect the generator electrical connector.
20. Connect the generator B+ cable and install the nut. Tighten to 7 Nm (150 lb-in).
21. Connect the A/C compressor electrical connector.
22. Connect the LH Catalyst Monitor Sensor (CMS) electrical connector. Install the wiring harness retainer to the rear of the LH cylinder head.
23. Connect the LH Heated Oxygen Sensor (HO2S) electrical connector.
24. Install the 2 LH CMP sensors and the 2 bolts. Tighten to 10 Nm (89 lb-in).
25. Connect the 2 LH CMP sensors electrical connectors.
26. Connect the 6 fuel injector electrical connectors (3 shown in illustration).
27. If equipped, position the block heater wiring harness onto the engine. Connect the block heater electrical connector and install the heat shield.
28. Install the LH camshafts. For additional information, refer to «CAMSHAFT»(ref-494555-S11409700892012081400000) .
