Parking Aid System: Removal & Installation Ford Edge I

Collision/avoidance 2 illustrations ~126 words

REMOVAL AND INSTALLATION

CAUTIONElectronic modules are sensitive to electrical charges. If exposed to these charges, damage may result.
  1. Remove the LH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-292546) article.
  2. Remove the 2 nuts and the parking aid module (PAM).
  3. Disconnect the PAM electrical connector.
  4. To install, reverse the removal procedure.

Scheme 10

Scheme 10: Parking Aid Sensor
Scheme 10: Parking Aid Sensor
ItemPart NumberDescription
1Parking aid sensor electrical connectors (part of 14N139)
214489Parking aid sensors
  1. Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-292550) article.
  2. Disconnect the parking aid sensor(s) electrical connector(s).
  3. Press the retaining tabs and remove the parking aid sensor(s).
  4. To install, reverse the removal procedure.

Scheme 11

Scheme 11: Parking Aid Speaker
Scheme 11: Parking Aid Speaker
ItemPart NumberDescription
115K864Parking aid speaker
2W705635Parking aid speaker push pins (2 required)
3Parking aid speaker electrical connector (part of 14A005)
  1. Remove the LH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-292546) article.
  2. Remove the 2 push pin and the parking aid speaker. Disconnect the parking aid speaker electrical connector.
  3. To install, reverse the removal procedure.
