GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator pulley ratio | 2.66:1 |
| Rating | 78/143 amp (max) @ 620-2,500 engine RPM @ normal engine temperature |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Generator B+ terminal nut | 12 |
| Generator bolts | 47 |
| Generator nuts | 47 |
| Generator stud | 8 |
TORQUE SPECIFICATIONS
The charging system consists of the following components
- Generator
- Integral voltage regulator
The generator is belt-driven by the engine accessory drive system. The generator has an internal voltage regulator that is not replaced separately. The generator and voltage regulator are repaired as an assembly.
Refer to CHARGING SYSTEM - GENERAL INFORMATION article.
Scheme 11
| Item | Part Number | Description |
|---|---|---|
| 1 | W712609 | Generator stud |
| 2 | W520414 | Generator nut |
| 3 | W709986 | Generator bolt |
| 4 | 7H953 | Generator B+ terminal nut |
| 5 | 10300 | Generator |
| 6 | Generator electrical connector (part of 14B060) | |
| 7 | Generator B+ terminal (part of 14B060) | |
| 8 | Pin-type retainer, wiring harness |
