DISABLING AIR SUSPENSION SYSTEM
Before lifting vehicle equipped with air suspension system, locate and turn service switch to OFF position. See LOCATING AIR SUSPENSION SHUTOFF SWITCH table. Failure to turn off air suspension system may result in unexpected inflation or deflation of air shocks or springs.
| Application | Specification |
|---|---|
| Expedition & Navigator | Right Kick Panel |
| Explorer & Mountaineer | Rear Cargo Area Near Jack Storage |
LOCATING AIR SUSPENSION SHUTOFF SWITCH
RIDING HEIGHT
Note. On vehicles equipped with electronic suspension, see appropriate ELECTRONIC article in SUSPENSION.
| CAUTION | Use hand tools to adjust riding height. DO NOT use power tools. |
Except Pickup (F250/F350 Super Duty) & Econoline
Adjust riding height by turning torsion bar adjustment bolt. Tighten torsion bar adjusting bolt to raise height. Loosen torsion bar adjusting bolt to lower height. On rear of vehicle, repair or replace worn or damaged components.
Pickup (F250/F350 Super Duty) & Econoline
Rear side lean can be adjusted .38" (10 mm) by installing shim D7TZ-5742-A on low side, or both sides if rear is low. Raise and support vehicle so weight is off springs and tires are still touching ground. Loosen 4 U-bolt nuts. Separate spring from axle. Install shim with recess facing upward in between spring and spring seat. Tighten 4 U-bolts to specification. See TORQUE SPECIFICATIONS .
Before adjusting alignment, check riding height. Riding height must be checked with vehicle on level floor, tires properly inflated and fuel tanks full. Bounce vehicle several times and allow suspension to settle. Visually inspect vehicle for signs of abnormal height from front to rear or side to side. Check passenger compartment or vehicle bed for extra heavy items and remove if present.
On Econoline and Villager, ride height is measured from front (dimension "A") and rear (dimension "B") fender lip openings to ground. (Scheme 1) On Expedition and Navigator models, rear ride height is measured between rear suspension travel stop bracket and top of axle housing. Ride height should be within specifications. See RIDE HEIGHT SPECIFICATIONS (ECONOLINE, EXPEDITION, NAVIGATOR & VILLAGER) table. If ride height is not as specified, check, repair or replace suspension components as necessary. On Econoline, rear side lean can be adjusted by installing shim. See ADJUSTMENT.
Scheme 1
| Application | Ride Height - In. (mm) | |||
|---|---|---|---|---|
| Expedition & Navigator | ||||
| Front 2WD (1) | ||||
| With Air Suspension | 6.6-7.0 (168-178) | |||
| Without Air Suspension | 8.6-9.5 (218-242) | |||
| Front 4WD (1) | ||||
| Base Suspension With Original Components | 4.21 To 4.44 (107 To 113) | |||
| Base Suspension With New Components | 4.8 To 5.04 (122 To 128) | |||
| Rear (2) | ||||
| 2WD | ||||
| With Air Suspension (3) | 5.8 (146.8) | |||
| Without Air Suspension | 6.6 To 7.5 (168 To 192) | |||
| 4WD | ||||
| With Air Suspension (3) | 5.8 (146.8) | |||
| Without Air Suspension | 8.6-9.5 (218-242) | |||
| Econoline | ||||
| Front (1) | (4) | |||
| Rear (2) | (4) | |||
| Villager (6) | ||||
| Front (5) | 30.0 To 30.8 (762 To 782) | |||
| Rear (5) | 30.8 To 31.6 (783 To 803) | |||
| (1) Difference between left and right side should not be more than 5/8" (16 mm). (2) Difference between left and right side should not be more than 3/4" (19 mm). (3) With Ignition on and 4WAS Activated. For More information on 4WAS See ELECTRONIC article in SUSPENSION. (4) Information not available. (5) Difference between left and right side should not be more than 13/32" (10 mm). (6) (Scheme 1) | ||||
| (1) | Difference between left and right side should not be more than 5/8" (16 mm). |
| (2) | Difference between left and right side should not be more than 3/4" (19 mm). |
| (3) | With Ignition on and 4WAS Activated. For More information on 4WAS See ELECTRONIC article in SUSPENSION. |
| (4) | Information not available. |
| (5) | Difference between left and right side should not be more than 13/32" (10 mm). |
| (6) | (Scheme 1) |
RIDE HEIGHT SPECIFICATIONS (ECONOLINE, EXPEDITION, NAVIGATOR & VILLAGER)
Explorer, Mountaineer, Pickup (F150/250 Light Duty) & Ranger
- Measure front (dimension "A") and rear (dimension "B") fender lip openings to ground. (Scheme 1) Maximum front side-to-side difference is.06" (16 mm). Maximum rear side-to-side height difference is.78" (20 mm). To check riding height, go to next step.
- Bounce vehicle front and rear suspension. Raise vehicle on hoist with frictionless plates to support front wheels. Measure distance between center of lower control arm front bolt and ground (STEP 1). Measure distance between bottom of steering knuckle and ground (STEP 2). Subtract smaller measurement from larger measurement. This is ride height measurement. (Scheme 2)and (Scheme 3).
- Measure and record dimension "B" between lowest point on steering knuckle and ground. Subtract dimension "B" from dimension "A" to obtain ride height. See «RIDE HEIGHT SPECIFICATIONS (EXPLORER, MOUNTAINEER, PICKUP (F150/250 LIGHT DUTY) & RANGER)»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) table.
- Measure rear ride height on driver's side between bottom of frame to rear jounce bumper bolt at rear side of head base. (Scheme 4)and (Scheme 5). See «RIDE HEIGHT SPECIFICATIONS (EXPLORER, MOUNTAINEER, PICKUP (F150/250 LIGHT DUTY) & RANGER)»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) table.
- If ride height is not within specified range, adjust torsion bars (if equipped). Turn torsion bar adjusting bolt clockwise to increase height or counterclockwise to decrease height. If not equipped with torsion bar, check and replace worn or damaged springs or control arms.
Scheme 2
Scheme 3
Scheme 4
Scheme 5
| Application | In. (mm) | |||
|---|---|---|---|---|
| Expedition & Mountaineer | ||||
| New Vehicles With less Than 500 Miles (Front). | ||||
| With ARC | 3.0 To 3.8 (76 To 97) | |||
| Without ARC | 4.0 To 4.8 (102 To 122) | |||
| Front With Original Parts | ||||
| With ARC | 2.7 To 3.5 (69 To 89) | |||
| Without ARC | 3.6 To 4.4 (91 To 112) | |||
| Front With Replacement Parts | ||||
| With ARC | 3.3 To 3.54 (84 To 89) | |||
| Without ARC | 4.1 To 4.5 (109 To 114) | |||
| 4X4 & AWD | 4.3 To 4.6 (109 To 117) | |||
| Rear | ||||
| With ARC 4-Door | 4.0 (102) | |||
| Without ARC | ||||
| 2-Door | 4.3 To 4.8 (109 To 122) | |||
| 4-Door | 5.0 To 5.8 (127 To 147) | |||
| F150 2WD | ||||
| Front | ||||
| Regular Cab | 3.7 To 5.3 (94 To 135) | |||
| Super Cab | 4.0 To 5.6 (102 To 142) | |||
| Rear | 6.0 To 8.5 (152 To 216) | |||
| F150 4WD | ||||
| Front | ||||
| Regular & Super Cab | 3.65 To 5.15 (93 To 131) | |||
| Rear | 5.9 To 8.1 (150 To 206) | |||
| F250 2WD | ||||
| Front | ||||
| Regular Cab | 3.7 To 5.3 (94 To 135) | |||
| With Load Leveling Suspension | 3.7 To 5.3 (119 To 135) | |||
| Super Cab | 4.0 To 5.6 (102 To 142) | |||
| Rear | 6.8 To 9.25 (173 To 235) | |||
| With Load Leveling Suspension | 3.3 To 4.0 (84 To 102) | |||
| F250 4WD | ||||
| Front | ||||
| Regular & Super Cab | 3.65 To 5.15 (93 To 131) | |||
| Rear | 6.7 To 8.9 (170 To 226) | |||
| With Load Leveling Suspension | 3.1 To 3.9 (79 To 99) | |||
| Ranger (Except Splash) | ||||
| 2WD | ||||
| Front | ||||
| 1998 With Original Parts | 3.4 To 4.2 (86 To 107) | |||
| 1999 With Original Parts | 3.5 To 4.68 (89 To 119) | |||
| 1998 With Replacement Parts | 3.7 To 3.9 (94 To 99) | |||
| 1999 With Replacement Parts | 3.5 To 4.68 (89 To 119) | |||
| Rear | 7 To 9 (178 To 229) | |||
| Ranger (Splash) | ||||
| 2WD | ||||
| Front | ||||
| With Original Parts | 2.8 To 3.6 (71 To 91) | |||
| With Replacement Parts | 3.1 To 3.3 (79 To 84) | |||
| Rear | 7.0 To 7.5 (178 To 191) | |||
| 4WD (All) | ||||
| Front | ||||
| New Vehicle (Less Than 500 Miles) | 4.0 To 4.8 (102 To 122) | |||
| With Original Parts | 3.6 To 4.4 (91 To 112) | |||
| With Replacement Parts | 4.3 To 4.5 (109 To 114) | |||
| Rear | ||||
| 1998 Models | 6.0 To 8.0 (152 To 203) | |||
| 1999 Models | 6.24 To 8.08 (158 To 205) | |||
RIDE HEIGHT SPECIFICATIONS (EXPLORER, MOUNTAINEER, PICKUP (F150/250 LIGHT DUTY) & RANGER)
Pickup (F250/F350 Super Duty)
- Measure front right height(s) between I beam or front axle (4WD) and vehicle frame. See . See «RIDE HEIGHT SPECIFICATIONS (PICKUP F250/F350 SUPER DUTY)»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) table.
- Measure rear ride height between vehicle frame and rear axle housing or jounce pad stops (4WD). See . See «RIDE HEIGHT SPECIFICATIONS (PICKUP F250/F350 SUPER DUTY)»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) . Rear side-to-side difference can be adjusted by adding shim between spring and spring seat. See . See «ADJUSTMENT»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) .
| Application | In. (mm) | ||
|---|---|---|---|
| F250 2WD (1) | |||
| Front | |||
| Left | 4.2 (107) | ||
| Right | 4.6 (117) | ||
| Rear | |||
| Standard Suspension | 6.2 To 8.6 (157.5 To 218.4) | ||
| Heavy Duty Suspension | 5.7 To 8.1 (144.8 To 205.7) | ||
| F250 4WD (1) | |||
| Front | 4.7 (119.4) | ||
| Rear | |||
| Standard Suspension | 5.7 To 8.1 (144.8 To 205.7 | ||
| Heavy Duty Suspension | 5.2 To 7.6 (132.1 To 193) | ||
| F350 Pickup 2WD Single Rear Wheel (1) | |||
| Front | |||
| Left | 4.6 (117) | ||
| Right | 4.2 (107) | ||
| Rear | |||
| Standard Suspension | 6.2 To 8.6 (157.5 To 218.4) | ||
| Heavy Duty Suspension | 5.7 To 8.1 (144.8 To 205.7) | ||
| F350 4WD Pickup Single Rear Wheel (1) | |||
| Front | 4.7 (119.4) | ||
| Rear | |||
| Standard Suspension | 5.7 To 8.1 (144.8 To 205.7) | ||
| Heavy Duty Suspension | 5.2 To 7.6 (132.1 To 193) | ||
| F350 2WD Pickup Dual Rear Wheel (1) | |||
| Front | |||
| Left | 4.6 (117) | ||
| Right | 4.2 (107) | ||
| Rear | |||
| Standard Suspension | 6.5 To 8.9 (165.1 To 226.1) | ||
| Heavy Duty Suspension | 5.9 To 8.4 (149.9 To 213.4) | ||
| F350 Pickup 4WD Dual Rear Wheel (1) | |||
| Front | 4.7 (119.4) | ||
| Rear | |||
| Standard Suspension | 6.0 To 8.5 (152.4 To 215.9) | ||
| Heavy Duty Suspension | 5.5 To 8.0 (139.7 To 203.2) | ||
| F350 Chassis Cab 2WD Single Rear Wheel (1) | |||
| Front | |||
| Left | 4.6 (117) | ||
| Right | 4.2 (107) | ||
| Rear Standard Suspension | 5.6 To 8.0 (132 To 203.2) | ||
| F350 Chassis Cab 4WD Single Rear Wheel (1) | |||
| Front | 4.7 (119.4) | ||
| Rear Standard Suspension | 5.6 To 8.0 (132 To 203.2) | ||
| F350 Chassis Cab 2WD Dual Rear Wheel (1) | |||
| Front | |||
| Left | 4.6 (117) | ||
| Right | 4.2 (107) | ||
| Rear | 5.8 To 8.3 (147.3 To 210.8) | ||
| F350 Chassis Cab 4WD Dual Rear Wheel (1) | |||
| Front | 4.7 (119.4) | ||
| Rear | 5.8 To 8.3 (147.3 To 210.8) | ||
| (1) Maximum side-to-side differences 0.75" (19 mm). | |||
| (1) | Maximum side-to-side differences 0.75" (19 mm). |
RIDE HEIGHT SPECIFICATIONS (PICKUP F250/F350 SUPER DUTY)
Scheme 6
Windstar
- Measure dimension "A" between bottom of front ball joint and floor. Measure dimension "B" between center of front lower control arm mounting bolt and floor. See. Subtract dimension "A" from dimension "B". This is the riding height. (Scheme 7) See «RIDE HEIGHT SPECIFICATIONS (WINDSTAR)»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) table.
- Measure rear ride height between vehicle body and rear axle. (Scheme 7) See «RIDE HEIGHT SPECIFICATIONS (WINDSTAR)»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) table.
| Application | In. (mm) | |
|---|---|---|
| Windstar | ||
| Front | 2.03 To 2.69 (51.6 To 68.3) | |
| Rear | 6.12 To 7.08 (155.4 To 179.8) | |
RIDE HEIGHT SPECIFICATIONS (WINDSTAR)
Scheme 7
JACKING & HOISTING
| WARNING | Before lifting vehicle equipped with air suspension system, turn service switch to OFF position. Failure to turn off air suspension system may result in unexpected inflation or deflation of air shocks or springs. |
FLOOR JACK
| WARNING | When jacking a vehicle, always set parking brake to prevent vehicle from rolling. On vehicles equipped with a Traction-Lok axle, DO NOT run engine with one wheel off the ground, or vehicle could move. If vehicle is equipped with an under-chassis mounted spare tire, remove wheel or tire carrier before placing vehicle in a high lift position, or chassis may shift suddenly. |
Econoline
Floor jack may be used under front suspension lower control arms. Place floor jack under rear axle housing under leaf spring "U" bolts. DO NOT place floor jack under rear differential housing.
Floor jack may be positioned as shown. (Scheme 8)- (Scheme 12). Observe the following precautions
- Before lifting vehicle equipped with air suspension system, turn service switch to OFF position. See «DISABLING AIR SUSPENSION SYSTEM»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks__disabling-air-suspension-system) . Failure to turn off air suspension system may result in unexpected inflation or deflation of air shocks or springs.
- Never use jack on any part of underbody.
- DO NOT raise entire vehicle at side rail, with jack midway between front and rear wheels, or permanent body damage may result.
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Villager
If jacking entire vehicle, raise and support rear of vehicle first. To raise front of vehicle, position floor jack under front frame member behind bumper. Place safety stands under frame at lift points. To raise rear of vehicle, position floor jack under rear axle housing. (Scheme 13)
Scheme 13
Use hoist lifting points to jack vehicle. (Scheme 14)
Scheme 14
FRAME CONTACT HOIST
| CAUTION | If single post hoist is being used, add additional weight on rear end of vehicle before removing rear axle, fuel tank, spare tire or liftgate. This will prevent vehicle from tipping as center of gravity changes. |
Vehicle may be raised on single- or twin post swiveling arm, or ramp-type drive hoist as long as wide hoist adapters are used. (Scheme 13)- (Scheme 16). If using single post hoist, ensure lifting arms, pads or ramps are positioned at proper lifting points, and adequate underbody clearance is maintained.
If vehicle is to be raised on a twin post hoist, use caution not to damage suspension, rear axle cover and/or steering linkage components. DO NOT allow lift pads to contact exhaust system components. Position front adapter pads carefully to ensure maximum support under center of lower suspension arms or spring supports as near wheels as possible. Position rear suspension hoist adapters under spring mounting pads or rear axle housing, away from shock absorber or stabilizer bar mounting brackets.
Scheme 15
Scheme 16
CAMBER & CASTER ADJUSTMENT
Note. Some models are equipped with square (nonadjustable) camber/caster adjustment plates. To adjust caster/camber, install eccentric cam kit if camber or caster adjustment is necessary.
Econoline & F250/350 Super Duty (2WD)
- Measure camber and caster to determine adjustment required. Record specifications for use in selection of camber/caster adjusters. To adjust, raise and support vehicle. Remove wheel assembly. Loosen pinch bolt at top of upper ball joint and pry adjuster out of axle.
- Install appropriate camber/caster adjuster and rotate to desired adjustment. Camber/caster adjusters are available in 0.5, 1.0 and 1.5 degree increments. (Scheme 17) Tighten pinch bolt to specification. See «TORQUE SPECIFICATIONS»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks__torque-specifications). Install wheel assembly. Check wheel alignment to verify correct adjustment.
Scheme 17
To adjust caster and camber, loosen upper control arm cam bolts. Turn cam bolt as necessary to obtain correct camber or caster specification. (Scheme 18) Tighten upper control arm cam bolts to specification when adjustment is complete. See TORQUE SPECIFICATIONS.
Scheme 18
Explorer, Mountaineer & Ranger
- To adjust caster and camber, loosen upper control arm cam bolts and install eccentric cam. Turn cam bolt as necessary to obtain correct camber or caster specification. (Scheme 19)
- To adjust caster, loosen caster adjusting nuts. To increase caster split, adjust caster bolts to move suspension arm forward. To decrease caster split, adjust caster bolts to move suspension arm rearward. Tighten nuts to specifications. See «TORQUE SPECIFICATIONS»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks__torque-specifications).
Scheme 19
F250/350 Super Duty (4WD)
- Measure camber and caster to determine adjustment required. Record specifications for use in selection of camber/caster adjusters. To adjust, raise and support vehicle. Remove wheel assembly. Remove upper ball joint castle nut. Reinstall nut leaving gap between nut and camber adjuster sleeve. Loosen lower ball joint nut. Separate spindle from axle.
- Remove upper castle nut. Using suitable puller, remove camber adjuster sleeve. (Scheme 20) Install appropriate NEW camber adjuster sleeve. Install castle nut. Apply Threadlock & Sealer (EOAZ-199554-AA) or equivalent to lower ball joint stud. Tighten lower and upper nuts to specification. See «TORQUE SPECIFICATIONS»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks__torque-specifications).
- Verify camber change. Adjust as necessary. Adjust toe-in. See «TOE-IN ADJUSTMENT»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks).
Scheme 20
Camber and caster are not adjustable. If vehicle does not meet alignment specifications, check frame and/or suspension components for damage.
| CAUTION | DO NOT drill deeper than 3/8" (9.6 mm) into strut tower. |
- Check subframe alignment before adjusting camber/caster. Using a 3/4" (19 mm) dowel, insert dowel into alignment hole in front subframe, near right front mounting bolt. Dowel should fit loosely through subframe and body.
- Loosen 3 upper strut mounting bracket-to-strut tower attaching nuts. Drill out 4 or 5 spot welds at upper strut alignment plate. (Scheme 21)
- DO NOT drill deeper than necessary to move alignment plate. Remove 3 upper strut mounting bracket-to-strut tower attaching nuts and alignment plate. Clean burrs from strut tower and alignment plate. Paint exposed metal surfaces.
- Position strut and alignment plate. Loosely install attaching nuts. Adjust camber/caster by moving top of strut. Tighten attaching nuts to specification. Drill 3 holes for rivets in perimeter of alignment plate. (Scheme 21) Install 3 rivets.
Scheme 21
Explorer, Mountaineer, Villager & Windstar
- Start engine. Center steering wheel. Secure steering wheel with holder and turn engine off. Loosen tie rod end lock nut. Loosen steering gear dust boot clamp(s) at tie rod end. Turn tie rod end to obtain correct toe. See «WHEEL ALIGNMENT SPECIFICATIONS»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks) table.
- Clean and lubricate lock nut and tie rod threads. Tighten lock nut to specification. See «TORQUE SPECIFICATIONS»(/ford/econoline/i-1985-2013/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures-specifications-procedures-trucks__torque-specifications) . Ensure steering gear dust boot is straight after adjustment. Reinstall dust boot clamp.
All Other Models
- Measure toe-in with front wheels straight-ahead, and steering wheel locked in centered position. Adjust toe-in by loosening clamps and adjusting sleeve to obtain correct specification. Maintain steering wheel in centered position.
- If steering wheel is not centered prior to wheel alignment, determine which wheel assembly is out of adjustment, and compensate that side to center steering wheel. Multiple attempts may be necessary to properly center steering wheel.
- When tightening clamps, ensure clamp bolts are positioned so there will be no interference with other parts throughout entire travel of steering linkage.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Expedition & Navigator | |||
| Upper Control Arm Cam Bolt | 84-112 (113-153) | ||
| Tie Rod Jam Nut | 57-77 (77-104) | ||
| Explorer & Mountaineer | |||
| Caster Set Nut | 129 (175) | ||
| Upper Control Arm Cam Bolt | 98 (133) | ||
| Tie Rod Jam Nut | 59 (80) | ||
| Pickup | |||
| F150/250 Light Duty | |||
| Upper Control Arm Cam Bolt | 84-112 (113-153) | ||
| Tie Rod Jam Nut | 57-77 (77-104) | ||
| F250/350 Super Duty | |||
| Tie Rod Adjusting Clamp Nut | 41 (55) | ||
| Lower Ball Joint Stud Nut | 55-110 (128-149) | ||
| Rear Spring "U" Bolt Nut | 185 (251) | ||
| Upper Ball Joint Pinch Bolt | 60 (81) | ||
| Wheel Lug Nut | 148 (201) | ||
| Ranger | |||
| Upper Control Arm Cam Bolt Nut | 80-113 (113-153) | ||
| Upper Ball Joint Pinch Bolt | |||
| 2WD | 35-46 (47-62) | ||
| 4WD | 41-55 (56-75) | ||
| Rear Axle "U" Bolt | 65-75 (88-102) | ||
| Econoline | |||
| Upper Ball Joint Pinch Bolt | 64-88 (87-119) | ||
| Rear Axle "U" Bolt | |||
| Except E150 | 110-150 (149-203) | ||
| E150 | 73-97 (98-132) | ||
| Villager | |||
| Control Arm Bolt | |||
| Front | 94-115 (127-156) | ||
| Rear | 87-108 (118-146) | ||
| Tie Rod Lock Nut | |||
| 1998 | 30-60 (41-81) | ||
| 1999 | 55 (75) | ||
| Windstar | |||
| Alignment Plate Nuts | 26 (35) | ||
| Subframe Mounting Bolts | 66 (89) | ||
| Tie Rod Lock Nut | 41 (56) | ||
TORQUE SPECIFICATIONS
| Application | Preferred | Range | |||
|---|---|---|---|---|---|
| Econoline | |||||
| E150 | |||||
| Camber (1) | 0.25 | 0.25 To .75 | |||
| Caster (1) | 4.75 | 2 To 7.5 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| E250 | |||||
| Camber (1) | 0.5 | 0 To 1 | |||
| Caster (1) | 4.75 | 2 To 7.5 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| Expedition | |||||
| 2WD | |||||
| Camber (1) | 0.3 | 1 To 0.4 | |||
| Caster (1) | |||||
| Left Front | 6.1 | 5.1 To 7.1 | |||
| Right Front | 6.6 | 5.6 To 7.6 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| 4WD With Air Suspension | |||||
| Camber (1) | 0.4 | 1.1 To 0.3 | |||
| Caster (1) | |||||
| Left Front | 5 | 4 To 6 | |||
| Right Front | 5.5 | 4.5 To 6.5 | |||
| Toe-In (1) | 0.2 | 0.05 To 0.45 | |||
| Toe-In (2) | 0.1 (2.5) | 0.02 To 0.24 (-0.5 To 6.0) | |||
| 4WD Without Air Suspension | |||||
| Camber (1) | 0.2 | 0.9 To 0.5 | |||
| Caster (1) | |||||
| Left Front | 5.1 | 4.1 To 6.1 | |||
| Right Front | 5.6 | 4.6 To 6.6 | |||
| Toe-In (1) | 0.3 | 0.05 To 0.55 | |||
| Toe-In (2) | 0.15 (3.81) | 0.03 To 0.27 (0.08 To 0.69) | |||
| 1998 Explorer | |||||
| With ARC | |||||
| Camber (1) | 0.7 | 1.4 To 0 | |||
| Caster (1) | 4.5 | 3.5 To 5.5 | |||
| Toe-In (1) | 0.12 | 0.13 To 0.37 | |||
| Toe-In (2) | 0.06 (1.5) | 0.06 To 0.18 (-1.5 To 4.5) | |||
| Without ARC | |||||
| Camber (1) | 0.5 | 1 To 0 | |||
| Caster (1) | 4.2 | 3.2 To 5.2 | |||
| Toe-In (1) | 0.12 | 0.13 To 0.37 | |||
| Toe-In (2) | 0.06 (1.5) | 0.06 To 0.18 (-1.5 To 4.5) | |||
| 1999 Explorer | |||||
| Camber (1) | 0.5 | 1 To 0 | |||
| Caster (1) | 4.2 | 3.2 To 5.2 | |||
| Toe-In (1) | 0.12 | 0.13 To 0.37 | |||
| Toe-In (2) | 0.06 (1.5) | 0.06 To 0.18 (-1.5 To 4.5) | |||
| F150 (2WD) | |||||
| Camber (1) | 0.3 | 1 To 0.4 | |||
| Caster (1) | |||||
| Left Front | 6.2 | 5.2 To 7.2 | |||
| Right Front | 6.7 | 5.7 To 7.7 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| F150 (4WD) | |||||
| Camber (1) | 0.1 | 0.8 To 0.6 | |||
| Caster (1) | |||||
| Left Front | 4.6 | 3.6 To 5.6 | |||
| Right Front | 5.3 | 4.3 To 6.3 | |||
| Toe-In (1) | 0.02 | 0.05 To 0.45 | |||
| Toe-In (2) | 0.1 (2.5) | 0.02 To 0.24 (-0.5 To 6) | |||
| F250 Light Duty (2WD) | |||||
| With Load Leveling Suspension | |||||
| Camber (1) | 0.3 | 1 To 0.4 | |||
| Caster (1) | |||||
| Left Front | 6.9 | 5.9 To 7.9 | |||
| Right Front | 7.4 | 6.4 To 8.4 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| Without Load Leveling Suspension | |||||
| Camber (1) | 0.3 | 1 To 0.4 | |||
| Caster (1) | |||||
| Left Front | 5.9 | 4.9 To 6.9 | |||
| Right Front | 6.4 | 5.4 To 7.4 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| F250 Light Duty (4WD) | |||||
| With Load Leveling Suspension | |||||
| Camber (1) | 0.1 | 0.8 To 0.6 | |||
| Caster (1) | |||||
| Left Front | 5.3 | 4.3 To 6.3 | |||
| Right Front | 6 | 5 To 7 | |||
| Toe-In (1) | 0.2 | 0.05 To 0.45 | |||
| Toe-In (2) | 0.1 (2.5) | 0.02 To 0.22 (-0.50 To 5.58) | |||
| Without Load Leveling Suspension | |||||
| Camber (1) | 0.1 | 0.8 To 0.6 | |||
| Caster (1) | |||||
| Left Front | 4.3 | 3.3 To 5.3 | |||
| Right Front | 5 | 4 To 6 | |||
| Toe-In (1) | 0.2 | 0.05 To 0.45 | |||
| Toe-In (2) | 0.1 (2.5) | 0.02 To 0.22 (-0.50 To 5.58) | |||
| F250/350 Super Duty (2WD) | |||||
| Camber (1) | 0.62 | 0.38 To 1.62 | |||
| Caster (1) | 3.5 | 1.5 To 5.5 | |||
| Toe-In (1) | 0 | 0.25 To 0.25 | |||
| Toe-In (2) | 0 (0) | 0.12 To 0.12 (-3 To 3) | |||
| F250/350 Super Duty (4WD) | |||||
| Camber (1) | 0.25 | 0.75 To 1.25 | |||
| Caster (1) | 4 | 2 To 6 | |||
| Toe-In (1) | 0 | 0.25 To 0.25 | |||
| Toe-In (2) | 0 (0) | 0.12 To 0.12 (-3 To 3) | |||
| Navigator | |||||
| 2WD | |||||
| Camber (1) | 0.3 | 1 To 0.4 | |||
| Caster (1) | |||||
| Left Front | 6.1 | 5.1 To 7.1 | |||
| Right Front | 6.6 | 5.6 To 7.6 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| 4WD With Air Suspension | |||||
| Camber (1) | 0.4 | 1.1 To 0.3 | |||
| Caster (1) | |||||
| Left Front | 5 | 4 To 6 | |||
| Right Front | 5.5 | 4.5 To 6.5 | |||
| Toe-In (1) | 0.2 | 0.05 To 0.45 | |||
| Toe-In (2) | 0.1 (2.5) | 0.02 To 0.24 (-0.5 To 6.0) | |||
| 4WD Without Air Suspension | |||||
| Camber (1) | 0.2 | 0.9 To 0.5 | |||
| Caster (1) | |||||
| Left Front | 5.1 | 4.1 To 6.1 | |||
| Right Front | 5.6 | 4.6 To 6.6 | |||
| Toe-In (1) | 0.3 | 0.05 To 0.55 | |||
| Toe-In (2) | 0.15 (3.81) | 0.03 To 0.27 (0.08 To 0.69) | |||
| 1998 Mountaineer | |||||
| With ARC | |||||
| Camber (1) | 0.70 | 1.4 To 0 | |||
| Caster (1) | 4.5 | 3.5 To 5.5 | |||
| Toe-In (1) | 0.12 | 0.13 To 0.37 | |||
| Toe-In (2) | 0.06 (1.5) | 0.06 To 0.18 (-1.5 To 4.5) | |||
| Without ARC | |||||
| Camber (1) | 0.50 | 1 To 0 | |||
| Caster (1) | 4.2 | 3.2 To 5.2 | |||
| Toe-In (1) | 0.12 | 0.13 To 0.37 | |||
| Toe-In (2) | 0.06 (1.5) | 0.06 To 0.18 (-1.5 To 4.5) | |||
| 1999 Mountaineer | |||||
| Camber (1) | 0.50 | 1 To 0 | |||
| Caster (1) | 4.2 | 3.2 To 5.2 | |||
| Toe-In (1) | 0.12 | 0.13 To 0.37 | |||
| Toe-In (2) | 0.06 (1.5) | 0.06 To 0.18 (-1.5 To 4.5) | |||
| Ranger | |||||
| 2WD (Except Splash) | |||||
| Camber (1) | 0.5 | 1.2 To 0.2 | |||
| Caster (1) | |||||
| Left Front | 4.1 | 3.1 To 5.1 | |||
| Right Front | 4.5 | 3.5 To 5.5 | |||
| Toe-In (1) | 0.06 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| 2WD (Splash) | |||||
| Camber (1) | 0.7 | 1.4 To 0 | |||
| Caster (1) | |||||
| Left Front | 4.6 | 3.6 To 5.6 | |||
| Right Front | 5 | 4 To 6 | |||
| Toe-In (1) | 0.6 | 0.19 To 0.31 | |||
| Toe-In (2) | 0.03 (0.8) | 0.09 To 0.15 (-2.28 To 3.81) | |||
| 4WD (All Models) | |||||
| Camber (1) | 0.5 | 1.2 To 0.2 | |||
| Caster (1) | |||||
| Left Front | 3.9 | 2.9 To 4.9 | |||
| Right Front | 4.4 | 3.4 To 5.4 | |||
| Toe-In (1) | 0.12 | 0.13 To 0.37 | |||
| Toe-In (2) | 0.06 (1.5) | 0.06 To 0.18 (-1.5 To 4.5) | |||
| 1998 Villager | |||||
| Camber (1) | |||||
| Front | 0.3 | 0.45 To 1.05 | |||
| Rear | 0 | 0.25 To 0.25 | |||
| Caster (1) | 0.8 | .05 To 1.55 | |||
| Toe-In (1) | |||||
| Front | 0.24 | 0.16 To 0.32 | |||
| Rear | 0 | 0.32 To 0.32 | |||
| Toe-In (2) | |||||
| Front | 0.12 (3) | 0.08 To 0.16 (2 To 4) | |||
| Rear | 0 (0) | 0.16 To 0.16 (-4 To 4) | |||
| 1999 Villager | |||||
| Camber (1) | |||||
| Front | 0.3 | 0.45 To 1.05 | |||
| Rear | 0 | 0.25 To 0.25 | |||
| Caster (1) | 0.8 | 0.05 To 1.55 | |||
| Toe-In (1) | |||||
| Front | 0.27 | 0.18 To 0.36 | |||
| Rear | 0 | 0.12 To 0.12 | |||
| Toe-In (2) | |||||
| Front | 0.12 (3) | 0.08 To 0.16 (2 To 4) | |||
| Rear | 0 (0) | 0.06 To 0.06 (-1.5 To 1.5) | |||
| Windstar | |||||
| Camber (1) | |||||
| Front | 0.25 | 0.75 To 0.25 | |||
| Rear | 0 | 0.40 To 0.40 | |||
| Caster (1) | |||||
| Left Front | 3.3 | 2.55 To 4.05 | |||
| Right Front | 3.8 | 3.05 To 4.55 | |||
| Toe-In (1) | |||||
| Front | 0.1 | 0.4 To 0.2 | |||
| Rear | 0.06 | 0.34 To 0.46 | |||
| Toe-In (2) | |||||
| Front | 0.05 (-1.3) | 0.2 To 0.1 (-5 To 2.5) | |||
| Rear | 0.03 (-0.8) | 0.17 To 0.23 (-4 To 6) | |||
| (1) Measurement in degrees. (2) Measurement in inches (millimeters). | |||||
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (millimeters). |
WHEEL ALIGNMENT SPECIFICATIONS
