Maintenance Information Ford Econoline I

Procedures 10 illustrations ~2678 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 1

Scheme 1: VIN Code ID Explanation
Scheme 1: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (About 10 Miles) In Freezing Temperatures
  2. Towing Or Heavily Loaded
  3. Severe Dust Conditions
  4. Hot Weather, Stop-And-Go Driving
  5. Extensive Idling Conditions (Taxi Or Delivery Type Service)
  6. Snow Plowing
  7. Off-Road Operation
  8. High Speed Operation With Fully Loaded Vehicle

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Operating Conditions From Severe Service List
CAUTIONDiesel-powered models require additional servicing. Refer to SCHEDULED SERVICES - DIESEL article in this section.

TIRE ROTATION & WHEEL TORQUE INFORMATION

On dual rear wheel light trucks, rotate the front tires side to side without disturbing the rear tires. Wheel lug nuts must be retightened to proper torque specifications after 500 miles (800 km) of new vehicle operation 100 miles (160 km) for vehicles equipped with dual rear wheels or equipped for snowplowing, and 500 miles (800 km) after any wheel change, or any other time lug nuts have been loosened.

REAR AXLE LUBRICATION

Rear axle lube quantities must be replaced every 100,000 miles (Except F-Super Duty), or if the axle has been submerged in water. Otherwise lube should not be checked unless a leak is suspected or repair required. F-Super Duty rear axle lube quantities must be replaced every 30,000 miles unless synthetic oil is used. Super Duty vehicles are NOT equipped with synthetic oil from the factory.

COOLING SYSTEM, HOSES & CLAMPS INFORMATION

Replace engine coolant every 36 months or 30,000 miles. Add supplemental coolant additive every 18 months or 15,000 miles (Diesel Engine Only). Check coolant strength, condition of hoses and clamps annually regardless of mileage or driving conditions. Replace hoses and clamps as necessary.

OFF-HIGHWAY VEHICLES INFORMATION

If vehicle is operated off-highway, perform the following items every 1000 miles. If vehicle is operated in mud and/or water, perform the following items daily

  1. Lubricate Front Axle, Steering And Clutch Linkages, Axle And Driveshaft U-Joints, And Slip Yoke If Equipped With Fittings.
  2. Lubricate Automatic Transmission External Controls (Cables).
  3. Inspect Front Wheel Bearings And Lubrication.
  4. Inspect Disc And Drum Brake Systems, Hoses And Lines, Lube Caliper Slide Rails.
  5. Inspect Exhaust System For Leaks, Damage, Or Loose Parts And Remove Any Foreign Material Trapped By Shielding.
  6. Lubricate Clutch Release Lever Pivot.

Scheme 2

Scheme 2: SERVICE POINT LOCATIONS
Scheme 2: SERVICE POINT LOCATIONS

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

SERVICE LABOR TIMES

Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

Inflation pressure and recommended tire size can be found on the Safety Compliance Certification Label decal attached to the driver's door latch post pillar.

WHEEL TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
E150 (5 Lug Wheel)100 (135)
E250/350 (8-Lug Wheel)140 (190)

WHEEL LUG NUT TORQUE SPECIFICATIONS

Note. If wheels are equipped with locking type lug nuts, ALWAYS position the keyed nut opposite the valve stem.

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM

Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.

The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.

When performing maintenance on air bag equipped vehicles always observe proper safety precautions.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

ANTI-LOCK BRAKE SYSTEM (ABS)

CAUTIONNever mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below.

REPLACING BLOWN FUSES

CAUTIONBefore replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

CAUTIONContinued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) or Ethylene-Glycol -35° F (-37°C) - 263° F (128°C).
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

DIESEL FUEL ANTI-FUNGAL ADDITIVES

CAUTIONIf fuel contamination due to fungi or other microorganisms is suspected a fuel additive with a biocide may be used. Follow the manufacturers dosage as recommended on product label. Use biocides ONLY when necessary, excessive use can may cause other fuel system problems.

DIESEL FUEL CONTAMINATION

WARNINGDiesel fuel system may be contaminated with fungi or other microorganisms. Keep contaminated fuel away from open skin cuts or sores to prevent skin irritation or infection.

DIESEL FUEL REQUIREMENTS

CAUTIONAll diesel engines are to use Diesel Fuel #2 when the outside temperature is above 20°F (-7°C). In temperatures that are below 20°F (-7°C) use Diesel Fuel #1, this will reduce the chance of the fuel thickening and forming wax.

Note. A Diesel Fuel #1 and #2 combination (Blended Fuel) may be used, and is recommended for mild winter driving.

FUEL PUMP SHUT-OFF SWITCH

This switch stops flow of fuel to engine after a collision. The impact does not have to be great to trigger the switch. To reset, press White reset button on switch located on floorboard, to left and above where steering column passes through the floorboard.

FUEL CONDITIONER (DIESEL ENGINES)

Allowing water to remain in fuel conditioner could result in extensive damage to or failure of fuel injection system. Diesel fuel can damage asphalt and other surfaces. Always place a drain pan under fuel conditioner to collect fuel, and dispose of fuel properly.

JUMP STARTING (TURBO DIESEL)

WARNINGDO NOT USE a booster battery or power source that has more than 12 volts of power. NEVER USE a 24 volt power source.

STARTING FLUID USE (TURBO DIESEL)

WARNINGDO NOT USE starting fluids (ether) or flammable liquids to aid the starting of a Diesel engine. NEVER pour diesel fuel, flammable liquids or starting fluids into the air cleaner canister, air intake or turbocharger housing in an attempt to start the vehicle. A flash fire may result causing personal injury.

TURBOCHARGED MODELS (TURBO-DIESEL)

CAUTIONDo not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BASIC NEW CAR LIMITED WARRANTY

All parts of the vehicle, except tires, are covered against defects in factory-supplied materials and workmanship for 12 months or 12,000 miles, whichever occurs first.

POWERTRAIN WARRANTY

Note. Powertrain Warranty varies in coverage length (either 4 years/50,000 miles or 6 years/60,000 miles) depending on model year.

Under this warranty, certain parts of the engine, transmission, axle and driveline are warranted against defects in materials and workmanship. This coverage begins after 12 months or 12,000 miles. See copy of warranty for specific components covered and length of coverage.

BUMPER-TO-BUMPER COVERAGE

All 1994 vehicles have complete warranty coverage against defects in materials and workmanship for 3 years or 36,000 miles, whichever occurs first. There is no deductible with this warranty. Items not covered include tires and parts that are subject to normal wear and tear, such as windshield wiper blades, brake linings, brake pads, clutch linings and scheduled maintenance items. There is no extended powertrain coverage included in this warranty.

BATTERY COVERAGE

Begins at warranty start date and lasts up to 3 years or 36,000 miles, whichever occurs first. For the first 12 months in service (less than 36,000 miles), battery will be replaced at no charge. After that, battery will be replaced on a customer-participation basis: For the 13th-24th month in service, Ford will pay 50%; for the 25th-36th month, Ford will pay 25%. Labor is covered for 3 years or 36,000 miles, whichever occurs first.

SAFETY RESTRAINT SYSTEM COVERAGE

Begins at warranty start date and lasts for 5 years or 50,000 miles, whichever occurs first. Covers safety restraint problems not related to comfort or appearance.

CORROSION COVERAGE

Begins at warranty start date and lasts for 6 years or 60,000 miles, whichever occurs first. Covers any holes in body sheet metal caused by corrosion.

EMISSIONS DEFECT & PERFORMANCE WARRANTIES (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed for the vehicle to pass a Federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered. Performance Warranty coverage is limited to fewer components after 2 years or 24,000 miles.

EMISSIONS PERFORMANCE WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSIONS DEFECT WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

GVWR Over 8500 Lbs.

If an emission-related part on a vehicle with a GVWR over 8500 lbs. is defective, the part will be repaired or replaced by Ford Motor Co. for a period of 5 years or 50,000 miles (gasoline engines), or 5 years or 100,000 miles (diesel engines), whichever occurs first.

INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1994-96

The fuse panel for E-150/250/350 is located on a mounting bracket under the instrument panel, left of the steering column.

Scheme 6

Scheme 6: INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1994-96
Scheme 6: INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1994-96

Interior Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp (1994-95) - Stoplights, Hazard Flasher, Speed Control 15 Amp (1996) - Brake Pressure Switch, DLC, PSOM, Stoplights, Hazard Flasher, Speed Control
  2. 2 - 8.25 Amp (Circuit Breaker) (1994-95) - Wiper/Washer 30 Amp (1996) - Wiper Control Module, Windshield Wiper Motor
  3. 3 - Not Used
  4. 4 - 20 Amp - Turn, Instrument Illumination, License & Running Lights, Flash-To-Pass, Anti-Theft Module, Warning Chime, Trailer Running/Backup Light Relay
  5. 5 - 15 Amp - Air Bag Module, DRL Module, Trailer Battery Charge Relay, Aux Battery Relay, Starting System, Turn Signal, Back-Up Lights, Transmission Control Switch
  6. 6 - 20 Amp - Speed Control, Illuminated Entry, Anti-Theft Module Customer Convenience Plug (located Below Fuse) Hot In RUN or ACCY
  7. 7 - 10 Amp - Ignition Coil, Anti-Theft Module, Transmission Range Sensor, Park/Neutral Position Switch, PCM
  8. 8 - 15 Amp - Courtesy Light Switch, Illuminated Entry, Power Mirrors, Power Door Lock, Anti-Theft Indicator, Dome, Map & Rear Cargo Lights, Radio Memory, PSOM, Remote Convenience Module
  9. 9 - 15 Amp - A/C-Heater Blower Motor Switch
  10. 10 - 20/30 Amp (1994-95) - Cigarette Lighter, Rear Power Outlet 25 Amp (1996) - Cigarette Lighter, Power Amplifier, Rear Power Outlet
  11. 11 - 15 Amp - Radio, Clock, Headlight Switch
  12. 12 - 20 Amp (Circuit Breaker) - Power Door Locks, Anti-Theft Module, Remote Convenience Module, Memory Lock Module
  13. 13 - 5 Amp - Instrument Panel Illumination
  14. 14 - 20 Amp (Circuit Breaker) - Power Windows
  15. 15 - 20 Amp - Air Bag Module
  16. 16 - 30 Amp - Power Lumbar, Modified Vehicle Tap
  17. 17 - 20 Amp - Anti-Lock Brake Module, PSOM
  18. 18 - 15 Amp - Instrument Warning Lights, Warning Buzzer, Rear Anti-Lock Warning

UNDERHOOD FUSE PANEL IDENTIFICATION - 1994-96

The underhood fuse panel (power distribution box) is located in the engine compartment near the left-hand fender apron.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Fuse & Relay Identification

  1. A - 60 Amp (1994-95) - Aux Heater-A/C, Remote Convenience Module 50 Amp (1996) - Aux Heater-A/C
  2. B - 50 Amp - Modified Vehicle Power
  3. C - 30 Amp - EEC/TCM
  4. D - 20 Amp - Electric Brake
  5. E - 50 Amp - Power Seats, Driver Power Lumbar
  6. F - 60 Amp - Blower Motor, Cigarette Lighter
  7. G - 60 Amp - Ignition Switch
  8. H - 30 Amp - Fuel Pump
  9. J - 40 Amp - Trailer Tow
  10. K - 30 Amp - Trailer Tow, Back-up Lights
  11. L - Diode - Electronic Engine Control
  12. M - 10 Amp - Trailer R/H Turn/Stop Light
  13. N - 10 Amp - Trailer L/H Turn/Stop Light
  14. P - 10 Amp - Class I Trailer Running Lights, Class II Trailer Running Lights Relay
  15. R - 15 Amp - DRL Module, Horn Relay, Underhood Light
  16. S - 60 Amp (1994-95) - Headlight Switch, I/P
  17. 60 Amp (1996) - Interior Fuse Panel Power Feed
  18. T - 60 Amp - Trailer Tow, Aux Battery Relay
  19. RA - Relay - Electronic Engine Control
  20. RB - Relay - Fuel Pump
  21. RC - Relay - Horn
  22. RD - Relay (1994-95) - Blower Motor
  23. RD - 60 Amp & 30 Amp (1996) - ABS Module, ECC Relay Coil

INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1997-99

The fuse panel for E-150/250/350 is located on a mounting bracket under the instrument panel, left of the steering column.

Scheme 9

Scheme 9: INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1997-99
Scheme 9: INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1997-99

Interior Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp - RABS/4WABS Module
  2. 2 - 15 Amp - Brake Warinin Diode/Resistor, Instrument Cluster, Warning Chime, 4WABS Relay, Warning Indicators
  3. 3 - 15 Amp - Main Light Switch, RKE Module, Radio
  4. 4 - 15 Amp - Power Locks w/ RKE, Illuminated Entry, Warning Chime, Modified Vehcicle, Power Mirrors, Main Light Switch, Courtesy Lamps
  5. 5 - 20 Amp - RKE Module, Power Lok Switches, Memory Lock
  6. 6 - 10 Amp - Shift Interlock, Speed Control, DRL Module
  7. 7 - 10 Amp - Multi-Function Switch
  8. 8 - 30 Amp - Radio Capacitors, Ignition Coil, PCM Diode, PCM Power Relay, Fuel Heater, Glow Plug Relay (Diesel)
  9. 9 - 30 Amp - Wiper Control Module, Windshield Wiper Motor
  10. 10 - 20 Amp - Main Light Switch, (External Lamps) Multi-Function Switch (Flash to Pass)
  11. 11 - 15 Amp - Brake Pressure Switch, Multi-Function Switch (Hazards), RABS, Brake Pedal Position Switch
  12. 12 - 15 Amp - Transmission Range Sensor, Auxiliary Battery Relay
  13. 13 - 15 Amp - Blend Door Actuator, Function Selector Switch
  14. 14 - 5 Amp - Instrument Cluster (Air Bag & Charge Indicator)
  15. 15 - 5 Amp - Trailer Battery Charge Relay
  16. 16 - 30 Amp - Power Seats
  17. 17 - Not Used
  18. 18 - Not Used
  19. 19 - 10 Amp - Airbag Diagnostic Monitor
  20. 20 - 5 Amp - Overdrive Cancel Switch
  21. 21 - 30 Amp - Power Windows
  22. 22 - 15 Amp - Memory Power Radio
  23. 23 - 20 Amp - Cigar Lighter, Data Link Connector (DLC)
  24. 24 - 5 Amp - Illuminated Entry Module
  25. 25 - 10 Amp - Left Headlamp (Low Beam)
  26. 26 - Not Used
  27. 27 - 5 Amp - Radio
  28. 28 - 25 Amp - Power Plug
  29. 29 - Not Used
  30. 30 - 15 Amp - Headlamps (High Beam Indicator), DRL
  31. 31 - 10 Amp - Right Headlamp (Low Beam), DRL
  32. 32 - Not Used
  33. 33 - Not Used
  34. 34 - 10 Amp - Transmission Range Sensor
  35. 35 - Not Used
  36. 36 - 5 Amp - (Cluster, A/C, Illumination, Radio), Steering Column Assembly
  37. 37 - Not Used
  38. 38 - 10 Amp - Air Bag Diagnostic Monitor
  39. 39 - Not Used
  40. 40 - 30 Amp - Modified Vehicle
  41. 41 - 30 Amp - Modified Vehicle
  42. 42 - Not Used
  43. 43 - 20 Amp (Circuit Breaker) - Power Windows
  44. 44 - Not Used

UNDERHOOD FUSE PANEL IDENTIFICATION - 1997-99

The underhood fuse panel (power distribution box) is located in the engine compartment near the left-hand fender apron.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Scheme 10

Scheme 10
Scheme 10

Fuse & Relay Identification

  1. 1 - Not Used
  2. 2 - Not Used
  3. 3 - Not Used
  4. 4 - 5 Amp (1997) - PCM Keep Alive Memory 10 Amp (1998) - PCM Keep Alive Memory, Instrument Cluster
  5. 5 - 10 Amp - Right Trailer Turn Signal
  6. 6 - 10 Amp - Left Trailer Turn Signal
  7. 7 - Not Used
  8. 8 - 60 Amp - I/P Fuses 5,11,23,38,4,10,16,28
  9. 9 - 30 Amp - PCM Power Relay
  10. 10 - 60 Amp - Auxiliary Battery Relay, Engine Compartment Fuses 14, 22
  11. 11 - Not Used
  12. 12 - 60 Amp - Engine Compartment Fuses 26,27
  13. 13 - 50 Amp - Blower Motor Relay (Blower Motor)
  14. 14 - 30 Amp - Trailer Running Lamps, Trailer Back-Up Lamps
  15. 15 - 40 Amp - Main Light Switch
  16. 16 - 50 Amp - Auxiliary A/C, RKE Module
  17. 17 - 30 Amp - Fuel Pump Relay, IDM (Diesel)
  18. 18 - 60 Amp - I/P Fuses 40 & 41
  19. 19 - 60 Amp - 4WABS Module
  20. 20 - 20 Amp - Electric Brake Controller
  21. 21 - 50 Amp - Modified Vehicle Power
  22. 22 - 40 Amp - Trailer Battery Charge Relay, Modified Vehicle
  23. 23 - 60 Amp - Ignition Switch
  24. 24 - Not Used
  25. 25 - Not Used
  26. 26 - 10 Amp - Generator/Voltage Regulator (Diesel Only)
  27. 27 - 15 Amp - Horn, DRL Module
  28. 28 - Diode - PCM Diode
  29. 29 - Not Used
  30. A - Not Used
  31. B - Not Used
  32. C - Relay - Trailer Backup Lamps Relay
  33. D - Relay - Trailer Running Lamps Relay
  34. E - Relay - Trailer Battery Charge Relay
  35. F - Relay - Not Used
  36. G - Relay - PCM Relay
  37. H - Relay - Blower Motor Relay
  38. J - Relay - Horn Relay
  39. K - Relay - Fuel Pump Relay, IDM Relay (Diesel)
