REMOVAL & INSTALLATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
- Disconnect negative battery cable. Remove trim panel and shield. Disconnect motor wiring and window switch.
- Using care not to enlarge sheet metal holes in door inner panel, remove 1/4" rivets attaching motor bracket to inner panel. Use drift to knock out center pins from each rivet. Using 1/4" drill bit, drill out remaining rivet.
- Working through access hole, remove motor bracket from inner panel. Rotate bracket to gain access to 3 screws retaining window regulator and motor. Remove screws and separate window regulator and motor from bracket and cable drum housing. Remove window regulator and motor.
- To install, reverse removal procedure. Tighten motor mounting screws to 53-62 INCH lbs. (6-7 N.m). Install motor bracket to inner panel using 1/4-20 X 1/2" bolts, nuts and washers.
Gently pry up on rear of switch plate to remove switch housing from door trim panel. Remove screws and switch/harness connector assembly from switch plate. Using thin-blade screwdriver, pry harness connector from switch plate. To install, reverse removal procedure.
