Removal & Installation ("F" Series Pickup)
Door lock control module is located below instrument panel, on right side of steering column. Disconnect negative battery cable. Disconnect 3 electrical connectors and antenna from module. Remove 2 attaching bolts and remove module from support bracket. To install, reverse removal procedure.
Removal & Installation (Van)
Disconnect negative battery cable. Remove left-side quarter trim panel. Disconnect electrical connectors. Remove 2 nuts and module. To install, reverse removal procedure.
Removal & Installation
Antenna is part of harness and cannot be removed. If damaged or faulty, disconnect antenna connector from control module. Secure connector aside. Connect NEW antenna to control module. Using plastic tape, complete installation by securing antenna along path followed by original antenna.
