SPECIFICATIONS
| Description | Nm |
|---|---|
| Accelerator pedal and sensor assembly bolts | 25 |
TORQUE SPECIFICATIONS
The acceleration control consists of the following
- Fixed accelerator pedal and position sensor assembly
The throttle is controlled by an Accelerator Pedal Position (APP) sensor on the accelerator pedal assembly. The APP sensor sends a signal to the PCM in response to throttle pedal movement initiated by the driver. The PCM sends a signal to the electronic throttle control which increases and decreases throttle position.
The components in the acceleration control system are not adjustable and new components must be installed if damaged or worn.
Refer to the INTRODUCTION - GASOLINE MODELS .
Scheme 33
| Item | Part Number | Description |
|---|---|---|
| 1 | Accelerator Pedal Position (APP) sensor electrical connector (part of 14401) | |
| 2 | W611636 | Accelerator pedal bracket bolts (2 required) |
| 3 | 9F836 | Accelerator pedal and position sensor assembly |
Scheme 34
| Item | Part Number | Description |
|---|---|---|
| 1 | Accelerator Pedal Position (APP) sensor electrical connector (part of 14401) | |
| 2 | W611636 | Accelerator pedal bracket bolt (2 required) |
| 3 | 9F836 | Accelerator pedal and position sensor assembly |
Removal and Installation
All vehicles
- Disconnect the Accelerator Pedal Position (APP) sensor electrical connector. 4.6L and 5.4L engines
- Remove the 2 bolts and the accelerator pedal. To install, tighten to 25 Nm (18 lb-ft). 6.8L engine
- Remove the 2 bolts and slide the accelerator pedal and position sensor assembly up and off the anchor bolt. To install, tighten to 25 Nm (18 lb-ft). All vehicles
- To install, reverse the removal procedure.
