Windows and Glass - Glass, Frames and Mechanisms: Specifications Ford Econoline E150

Windows 8 illustrations ~187 words

General Specifications

ItemSpecification
Sealants and Primers
Urethane Adhesive Essex 400-HVWSB-M2G316-B
Pumpable Foam DamESB-M4G309-A
RTV SealerWSE-M4G323-A4
Urethane Metal Primer Essex U-413WSB-M2G234-C
Urethane Glass Primer Essex U-402WSB-M5B280-C
Urethane Glass Prep Essex U-401WSB-M2G314-B
Window Motor Current Draw
Window Down (Under Load)4-8 Amps
Window Up (Under Load)5-10 Amps
Motor Stall14 Amps
No Load4 Amps Maximum with No Fluctuation

General Specifications

TORQUE SPECIFICATIONS

DescriptionNm
Window Regulator Bracket Upper Nuts8-14
Rear Glass Channel Bolt7-11

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: Glass, Frames and Mechanisms

The window regulator control switches (14529) are located on the front door trim panels (23942). The master window regulator control switch is located on the driver side front door trim panel and can be used to activate all of the power windows.

A single window regulator control switch is located on the passenger side front door trim panel. This window regulator control switch allows activation of the power window for that door only.

Refer to the appropriate SYSTEM WIRING DIAGRAMS article, Power Windows for schematic and connector information.

Scheme 2

Scheme 2: Glass, Frames and Mechanisms

Scheme 3

Scheme 3: Inspection and Verification
  1. Visually inspect the components of the power window system to determine if any of the following electrical or mechanical concerns apply.
  2. Check the wiring harness for obvious signs of shorts, opens, bad connections or damage.
  3. If the fault is not visually evident, determine the symptom. GO to «SYMPTOM CHART»(ref-210208-S27838671732005121400000) .

Scheme 4

Scheme 4: Symptom Chart

Scheme 5

Scheme 5: PINPOINT TEST A: ALL POWER WINDOWS ARE INOPERATIVE

Scheme 6

Scheme 6: PINPOINT TEST B: SINGLE POWER WINDOW IS INOPERATIVE (LH)

Scheme 7

Scheme 7: PINPOINT TEST C: SINGLE POWER WINDOW IS INOPERATIVE (RH)

Scheme 8

Scheme 8

Switch - Window Regulator Control

Refer to the COMPONENT TESTING article.

See also:
COMPONENT TESTING
