Front Suspension: Component Locations Ford Econoline E150

Special Tool(s)

SPECIAL TOOLS Adapter for 204-S059 204-061 (T80T-5638-A2) Adapter for 204-S030 204-031 (T78P-5638-A1) Adapter for 204-S059 204-060 (T80T-5638-A1) Adapter for 204-S030 204-034 (T78P-5638-A4) Adapter for 204-S030 204-033 (T78P-5638-A3) Installer, Twin I-Beam Pivot Bushing 204-091 (T85T-5638-A2)

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Remove the stabilizer bar. For additional information, refer to «STABILIZER BAR»(ref-235434-S17293886132006062100000) .
2. Using the special tools, remove the stabilizer bar bushing.

Scheme 37

1. Using the special tools, install the stabilizer bar bushing.
2. Install the stabilizer bar. For additional information, refer to «STABILIZER BAR»(ref-235434-S17293886132006062100000) .

SPECIAL TOOLS Adapter for 204-S059 204-061 (T80T-5638-A2) Adapter for 204-S030 204-033 (T78P-5638-A3) Adapter for 204-S030 204-031 (T78P-5638-A1) Adapter for 204-S030 204-034 (T78P-5638-A4)

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. Remove the coil spring. For additional information, refer to «SPRING»(ref-235434-S30690628302006062100000) .
2. Remove the bolt and lower the pivot end of the front axle.
3. Using the special tools, remove the axle pivot bushing.

Scheme 42

Scheme 43

Scheme 44

1. Position the new pivot bushing. NOTE: The flanged end of the pivot bushing faces the front of the vehicle. Position the special tools and the new pivot bushing on the front axle.
2. Press the new pivot bushing into the front axle, leaving the specified clearance between the pivot bushing flange and the front axle.
3. Position the front axle, bolt and nut into the pivot bracket. Tighten the nut hand-tight.
4. Install the front coil spring. For additional information, refer to «SPRING»(ref-235434-S30690628302006062100000) .
5. Lower the vehicle and, with the vehicle weight on the suspension, tighten the axle pivot nut.

SPECIAL TOOLS Remover, Steering Arm 211-003 (T64P-3590-F)

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. Remove the brake disc. For additional information, refer to «DISC & DRUM»(ref-161514) article .
2. Remove the wheel speed sensor. For additional information, refer to «ANTI-LOCK CONTROL»(ref-210121) article .
3. Remove and discard the cotter pin and nut.
4. Using the special tool, disconnect the tie-rod end.
5. Remove and discard the cotter pin and the nut.
6. Remove the pinch bolt adjuster.
7. Remove the front wheel spindle. Strike the lower end of the front axle to loosen the ball joint. Remove the front wheel spindle.
8. To install, reverse the removal procedure. Check and, if necessary, align the front end. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(ref-234565) article .

SPECIAL TOOLS Installer/Remover, C-Frame and Screw 205-086 (T74P-4635-C) Ball Joint Remover 204-D015 (D89P-3010-A) or equivalent Ball Joint Replacer 204-D016 (D89P-3010-B) or equivalent Receiving Cup 211-D006 (D84P-3395-A4) or equivalent

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Remove the wheel spindle assembly. For additional information, refer to «WHEEL SPINDLE»(ref-235434-S40478323062006062100000) .
2. Position the front wheel spindle in a vise, and remove the snap ring from the lower ball joint.
3. Using the special tool and suitable receiver cup, remove the lower ball joint from the front wheel spindle.
4. Using the special tool and suitable receiver cup, remove the upper ball joint.

Scheme 57

Scheme 58

1. Using the special tool with suitable receiver cups, install the lower ball joint.
2. Using the special tool with suitable receiver cups, install the upper ball joint.
3. Install the snap ring in the groove at the bottom of the ball joint.
4. Install the front wheel spindle. For additional information, refer to «WHEEL SPINDLE»(ref-235434-S40478323062006062100000) .

Scheme 59

Scheme 60

Scheme 61

1. Remove the stabilizer bar. For additional information, refer to «STABILIZER BAR»(ref-235434-S17293886132006062100000) .
2. Use a suitable jack to support the affected front axle.
3. Remove the nut and disconnect the shock absorber.
4. Remove the bolt and the upper spring retainer.
5. Lower the jack supporting the front axle and remove the front coil spring.
6. To install, reverse the removal procedure.

SPECIAL TOOLS Remover, Steering Arm 211-003 (T64P-3590-F)

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. Remove the spindle. For additional information, refer to «WHEEL SPINDLE»(ref-235434-S40478323062006062100000) .
2. Using a suitable jack, support the axle.
3. Remove the four bolts and the stabilizer bar.
4. Loosen the shock absorber upper nut.
5. Remove the shock absorber lower nut, then slide the shock absorber off the radius arm.
6. Remove the front spring upper retainer bolt and the upper spring retainer.
7. Lower the jack supporting the axle, then remove the front coil spring from the lower retainer. Using a suitable spray lubricant, spray the lower spring and spring retainer. Rotate the spring 180 degrees counterclockwise, tilt the spring outward and remove.
8. Remove the spring insulator. Remove the radius arm-to-axle nut and bolt. Remove the spring retainer and insulator.
9. Remove the radius arm. Remove the nut. Remove the washer and rear insulator. Remove the radius arm from the bracket, and remove the spacer, insulator and washer.
10. Remove the pivot nut and bolt and remove the axle.
11. To install, reverse the removal procedure.
12. Check and, if necessary, align the front end. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(ref-234565) article .
