Electronic Engine Controls- Diesel Engines: Other Ford Econoline E150

Camshaft Position (CMP) Sensor

MATERIAL

Scheme 59

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-210109) .
2. Turn the ignition switch to the OFF position.
3. Disconnect the camshaft position (CMP) sensor electrical connector.
4. Remove the bolt and the CMP sensor.
5. To install, reverse the removal procedure.

Crankshaft Position (CKP) Sensor

MATERIAL

Scheme 60

Scheme 61

Scheme 62

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-210109) .
2. Turn the ignition switch to the OFF position.
3. Remove the bolt and position the ground cable aside.
4. Disconnect the crankshaft position (CKP) sensor electrical connector.
5. Remove the bolt and the CKP sensor.
6. To install, reverse the removal procedure.

Engine Coolant Temperature (ECT) Sensor

MATERIAL

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. Turn the ignition switch to the OFF position.
2. Partially drain the cooling system.
3. Remove the retainers and the air deflector.
4. Remove the power steering reservoir bracket retainers.
5. Remove the power steering fluid indicator and retainers. Remove the power steering reservoir bracket. Install the power steering indicator and position aside.
6. Disconnect the coolant hoses from the air cleaner outlet pipe.
7. Loosen the clamps and remove the air cleaner outlet pipe.
8. Loosen the clamps and remove the charge air cooler (CAC) pipe.
9. Disconnect the engine coolant temperature (ECT) electrical connector.
10. Remove the ECT sensor.
11. To install, reverse the removal procedure. Fill and bleed the engine cooling system. For additional information refer to «ENGINE COOLING»(ref-210139) .

Scheme 69

Scheme 70

1. Turn the ignition switch to the OFF position.
2. Remove the turbocharger inlet tube. For additional information, refer to «FUEL CHARGING & CONTROLS-TURBOCHARGER»(ref-210143) .
3. Loosen the clamps and remove the charge air cooler duct.
4. Remove the bolts and position the turbocharger oil tube aside. Remove and discard the gasket.
5. Disconnect the engine oil pressure (EOP) switch electrical connector.
6. Remove the EOP switch.
7. To install, reverse the removal procedure. Install a new turbocharger oil tube gasket.

Scheme 71

1. Turn the ignition switch to the OFF position.
2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
3. Disconnect the exhaust back pressure (EBP) sensor electrical connector.
4. Remove the EBP sensor.
5. To install, reverse the removal procedure.

Scheme 72

Scheme 73

Scheme 74

Scheme 75

1. Turn the ignition switch to the OFF position.
2. Remove the bolts and position the degas bottle aside.
3. Disconnect the fuel injector control module (FICM) electrical connectors. Position the wiring harness aside.
4. Disconnect the bulkhead connector and position aside.
5. Remove the bolts and the fuel injector control module (FICM).
6. To install, reverse the removal procedure.

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

1. Turn the ignition switch to the OFF position.
2. Remove the retainers and the air deflector.
3. Remove the power steering reservoir bracket retainers.
4. Remove the power steering fluid indicator and retainers. Remove the power steering reservoir bracket. Install the power steering indicator and position aside.
5. Disconnect the coolant hoses from the air cleaner outlet tube.
6. Loosen the clamps and remove the air cleaner outlet pipe.
7. Loosen the clamps and remove the charge air cooler (CAC) pipe.
8. Disconnect the intake air temperature (IAT) electrical connector.
9. Remove the IAT sensor.
10. To install, reverse the removal procedure.

Scheme 82

Scheme 83

1. Turn the ignition switch to the OFF position.
2. Disconnect the manifold absolute pressure (MAP) sensor. Disconnect the pressure hose. Disconnect the electrical connector.
3. Remove the mounting screws and the MAP sensor.
4. To install, reverse the removal procedure.

Scheme 84

Scheme 85

1. Turn the ignition switch to the OFF position.
2. Disconnect the mass airflow (MAF) sensor electrical connector.
3. Remove the screws and the MAF sensor.
4. To install, reverse the removal procedure.

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. Turn the ignition switch to the OFF position.
2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
3. Loosen the CAC tube clamps.
4. Remove the bolt and position the ground wire aside. Disconnect the electrical connector push pin.
5. Remove the conduit and position the wiring aside. Disconnect the locking tab. Remove the bolts. Disconnect the push pin and remove the wiring harness.
6. Remove the bolts for the charge air cooler tube and the oil fill tube.
7. Disconnect and remove the oil fill tube at the valve cover.
8. Remove the retaining nuts, charge air cooler tube, oil fill tube and bracket.
9. Disconnect the engine oil temperature (EOT) sensor.
10. Remove the EOT sensor.
11. To install, reverse the removal procedure.

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

1. Turn the ignition switch to the OFF position.
2. Remove the retainers and the air deflector.
3. Remove the power steering reservoir bracket retainers.
4. Remove the power steering fluid indicator and retainers. Remove the power steering reservoir bracket. Install the power steering indicator and position aside.
5. Disconnect the coolant hoses from the air cleaner outlet pipe.
6. Loosen the clamps and remove the air cleaner outlet pipe.
7. Disconnect the powertrain control module (PCM) electrical connectors.
8. Remove the bolt and PCM.
9. To install, reverse the removal procedure.

Turbocharger Variable Vane Hydraulic Control Valve

MATERIAL

Scheme 99

Scheme 100

1. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
2. Disconnect the turbocharger variable vane hydraulic control valve electrical connector.
3. Remove the bolt, bracket and the turbocharger variable vane hydraulic control valve.
4. To install, reverse the removal procedure. Apply clean engine oil to the O-ring seals prior to installing.
