Ignition Coil-On-Plug
| Item | Specification |
|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound D7AZ-19A331-A or equivalent | ESE-M1C171-A |
MATERIALS
Scheme 1
Scheme 2
- Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
- Remove the air cleaner assembly. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-210150) .
- Disconnect the ignition coil electrical connector.
- Remove the bolt and the ignition coil.
- To install, reverse the removal procedure. Apply Dielectric compound to the inside of the coil boots.
Scheme 3
- Remove the ignition coil. For additional information, refer to «IGNITION COIL-ON-PLUG»(ref-210145-S26407764752005121300000) .
- Remove the spark plugs.
- Inspect the spark plugs. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-210133) .
- To install, reverse the removal procedure.
