Exhaust System: Other Ford Econoline E150

Exhaust 13 illustrations ~201 words

Turbocharger Inlet Y-Pipe

MATERIAL

ItemSpecification
High Temperature Nickel Anti-SeizeLubricantXL-2ESE-M12A4-A

MATERIAL SPECIFICATIONS

Scheme 12

Scheme 12

Scheme 13

Scheme 13: Removal

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19
  1. On high series console, remove the storage bin. Release the locking tabs and remove the storage bin.
  2. Remove the floor console. Through the floor console opening, push and hold the locking clip while lifting upward.
  3. Remove the RH lower instrument panel finish panel.
  4. Remove the engine cover.
  5. Remove the LH turbocharger inlet pipe bolts.
  6. Remove the RH turbocharger inlet pipe bolts.
  7. Remove the exhaust inlet pipe-to-EGR cooler clamp.
  8. Remove the turbocharger inlet clamp.
  9. Carefully remove the turbocharger inlet pipe assembly from the vehicle.

Scheme 20

Scheme 20: Installation

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24
  1. Position the turbocharger inlet pipe and install the turbocharger inlet clamp. Tighten to 12 Nm (9 lb-ft).
  2. Install the EGR cooler clamp. Tighten to 6 Nm (53 lb-in).
  3. Install the RH bolts for the turbocharger inlet pipe. Tighten to 27 Nm (20 lb-ft).
  4. Install the LH bolts for the turbocharger inlet pipe. Tighten to 27 Nm (20 lb-ft).
  5. Check the system for leaks.
  6. Install the engine cover.
  7. Install the RH lower instrument panel finish panel.
  8. Install the floor console.
  9. Install the storage bin.
