Audio System
There are 5 audio system configurations available
- M 100 AM/FM ULC (2-channel) with 2 front door mounted speakers
- M 100 AM/FM ULC (4-channel) with 2 front door mounted speakers, 2 central mounted speakers, and 2 rear door mounted speakers (optional)
- M 100 AM/FM/Cassette with 2 front door mounted speakers, 2 central mounted speakers, and 2 rear door mounted speakers (optional)
- DM 100i AM/FM/Cassette/CD with clock and 6 speakers
- CDX6 AM/FM/6-Disc CD in-dash (premium) with clock and 6 speakers
Depending on vehicle trim level, the audio system will have 2, 4 or 6 radio speakers.
An optional video system is available on this vehicle. Refer to VIDEO SYSTEM .
Scheme 18
The radio suppression equipment reduces interference transmitted through the radio speakers by the engine ignition and electrical systems. When installing any radio suppression equipment components, make sure that a good contact is made at all connections. Remove any paint or dirt from between a component and its ground. Tighten all connectors and screws securely according to torque specifications.
Refer to ENTERTAINMENT SYSTEM - GENERAL INFORMATION .
Scheme 19
Scheme 20
- Using the special tool, pull the audio unit out.
- Remove the audio unit. Disconnect the antenna lead-in cable and the electrical connectors.
- To install, reverse the removal procedure.
