Accessory Drive System: Removal & Installation Ford Econoline E150

Drive Belt - Incorrect Installation

Non-standard accessory drive belts can track differently or incorrectly. If an accessory drive belt tracks incorrectly, install a new accessory drive belt to avoid performance failure or loss of the drive belt.

Scheme 19

Scheme 20

With the engine running, check accessory drive belt tracking on all pulleys. If the edge of the accessory drive belt rides beyond the edge of the pulleys, noise and premature wear will occur. Make sure the accessory drive belt rides correctly on the pulley. If an accessory drive belt tracking condition exists, proceed with the following

1. Visually check the accessory drive belt tensioner for damage, especially the mounting pad surface. If the accessory drive belt tensioner is not installed correctly, the mounting surface pad will be out of position. This will result in chirp and squeal noises.
2. With the engine running, visually observe the grooves in the pulleys (not the pulley flanges or the pulley forward faces) for excessive wobble. Install new components as necessary.
3. Check all accessories, mounting brackets and the accessory drive belt tensioner for any interference that would prevent the component from mounting correctly. Correct any interference condition and recheck the accessory drive belt tracking.
4. Tighten all accessories, mounting brackets and accessory drive belt tensioner retaining hardware to specification. Recheck the accessory drive belt tracking.

Removal and Installation

1. Remove the cooling fan stator. For additional information, refer to «COOLING FAN STATOR -- 6.0L DIESEL»(ref-210139-S35768490102005121300000) .
2. Rotate the tensioner clockwise and remove the accessory drive belt.
3. To install, reverse the removal procedure.

1. Remove the drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITH A/C»(ref-234567-S09248162352006061100000) or «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITHOUT A/C»(ref-234567-S07771865272006061100000) .
2. Remove the bolts and the drive belt tensioner.
3. To install, reverse the removal procedure.

Scheme 21

1. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 6.0L DIESEL»(ref-234567-S40722222702006061100000) .
2. Remove the bolts and the accessory drive belt tensioner.
3. To install, reverse the removal procedure.

Scheme 22

1. Remove the drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITH A/C»(ref-234567-S09248162352006061100000) or «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITHOUT A/C»(ref-234567-S07771865272006061100000) .
2. Remove the belt idler pulley. Remove the bolt. Remove the pulley.

Installation

1. To install, reverse the removal procedure.

Scheme 23

1. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 6.0L DIESEL»(ref-234567-S40722222702006061100000) .
2. Remove the bolt and the accessory drive belt idler pulley.
3. To install, reverse the removal procedure.
