AEROSTAR
| Application | Specification |
|---|---|
| Ride Height in Inches | N/A |
| Adjustment Procedures | 1 |
| Camber in Degrees (Fraction) | 3/10 to 2/10 |
| Camber in Degrees (Decimal) | 0.3 to 0.2 |
| Caster in Degrees (Fraction) | 4 |
| Caster in Degrees (Decimal) | 4.0 |
| Toe-In in Inches (Fraction) | 1/32 to 5/32 |
| Toe-In in Inches (Decimal) | 0.09 to 0.15 |
| Toe-In in Degrees (Fraction) | 3/16 to 5/16 |
| Toe-In in Degrees (Decimal) | 0.18 to 0.31 |
| Toe-Out on Turns (Inner) | (1) |
| Toe-Out on Turns (Outer) | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Not applicable. Preset at factory. | |
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (AEROSTAR)
E150 - 2WD
| Application | Specification | |
|---|---|---|
| Ride Height: 3 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 0 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 3/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 4.75 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4.5 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 1 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 6 +/- 3/4 | |
| Caster in Degrees (Decimal) | 6.0 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 5 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 2.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 7 1/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 7.25 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 5.5 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 3 +/- 3/4 | |
| Camber in Degrees (Decimal) | 3.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 8 3/4 | |
| Caster in Degrees (Decimal) | 8.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (E150 - 2WD)
E250 & E350 - 2WD
| Application | Specification | |
|---|---|---|
| Ride Height: 4 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 1/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | .25 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 3/8 +/- 3/4 | |
| Caster in Degrees (Decimal) | 4.38 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4.5 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 1 1/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.25 +/- 0.75 | |
| Caster in Degrees (Fraction) | 5 3/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 5.75 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 5 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 2 1/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 2.25 +/- 0.75 | |
| Caster in Degrees (Fraction) | 7 +/- 3/4 | |
| Caster in Degrees (Decimal) | 7 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 5.5 Inches | ||
| Adjustment Procedures | N/A | |
| Camber in Degrees (Fraction) | 3 1/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 3.25 +/- 0.75 | |
| Caster in Degrees (Fraction) | 8 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 8.5 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (E250 & E350 - 2WD)
F150 - 2WD
| Application | Specification | |
|---|---|---|
| Ride Height: 3 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0.5 +/- 0.75 | |
| Caster in Degrees (Fraction) | 6 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 6.50 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 3/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.75 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 1/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 4.25 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 3 +/- 3/4 | |
| Camber in Degrees (Decimal) | 3.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 3 1/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 3.25 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 4.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 2 1/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 2.25 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (F150 - 2WD)
F250 & F350 - 2WD
| Application | Specification | |
|---|---|---|
| Ride Height: 3 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 0 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 6 1/8 +/- 3/4 | |
| Caster in Degrees (Decimal) | 6.13 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 3.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 5 +/- 3/4 | |
| Caster in Degrees (Decimal) | 5.0 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 2.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 3 3/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 3.75 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 3 +/- 3/4 | |
| Camber in Degrees (Decimal) | 3.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 2 3/4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 2.75 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (F250 & F350 - 2WD)
BRONCO & F150 - 4WD
| Application | Specification | |
|---|---|---|
| Ride Height: 3 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 3/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0.75+/- 0.75 | |
| Caster in Degrees (Fraction) | 7 +/- 3/4 | |
| Caster in Degrees (Decimal) | 7.0 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 3.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0.5 +/- 0.75 | |
| Caster in Degrees (Fraction) | 5 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 5.5 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.5 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 4.50 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 2 +/- 1/2 | |
| Camber in Degrees (Decimal) | 2.0 +/- 0.5 | |
| Caster in Degrees (Fraction) | 3 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 3.50 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (BRONCO & F150 - 4WD)
F250 & F350 - 4WD
| Application | Specification | |
|---|---|---|
| Ride Height: 5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 3/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.75+/- 0.75 | |
| Caster in Degrees (Fraction) | 4 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 4.50 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 5.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 0 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 5 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 5.50 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 6 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.50 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 1/2 +/- 3/4 | |
| Caster in Degrees (Decimal) | 4.50 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 6.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 2 3/4 +/- 3/4 | |
| Camber in Degrees (Decimal) | 2.75 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 +/- 3/4 | |
| Caster in Degrees (Decimal) | 4.0 +/- 0.75 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (F250 & F350 - 4WD)
F350 MONOBEAM - 4WD
| Application | Specification |
|---|---|
| Ride Height in Inches | N/A |
| Adjustment Procedures | N/A |
| Camber in Degrees (Fraction) | 1 1/2 +/- 3/4 |
| Camber in Degrees (Decimal) | 1.50 +/- 0.75 |
| Caster in Degrees (Fraction) | 5 +/- 1 1/2 |
| Caster in Degrees (Decimal) | 5.0 +/- 1.50 |
| Toe-In in Inches (Fraction) | 1/32 |
| Toe-In in Inches (Decimal) | 0.031 |
| Toe-In in Degrees (Fraction) | 1/16 |
| Toe-In in Degrees (Decimal) | 0.063 |
| Toe-Out on Turns (Inner) | (1) |
| Toe-Out on Turns (Outer) | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Not applicable. Preset at factory. | |
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (F350 MONOBEAM - 4WD)
RANGER - 2WD
| Application | Specification | |
|---|---|---|
| Ride Height: 3.25 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0.5 +/- 0.75 | |
| Caster in Degrees (Fraction) | 6 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 6.0 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 3.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0.5 +/- 0.75 | |
| Caster in Degrees (Fraction) | 5 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 5.0 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 3.75 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 1/2 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 4.50 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.50 +/- 0.75 | |
| Caster in Degrees (Fraction) | 3 7/8 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 3.88 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4.25 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 2 1/2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 2.50 +/- 0.75 | |
| Caster in Degrees (Fraction) | 3 3/4 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 3.75 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (RANGER - 2WD)
RANGER & BRONCO II - 4WD
| Application | Specification | |
|---|---|---|
| Ride Height: 2.75 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 6 3/4 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 6.75 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 3.25 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 0 +/- 3/4 | |
| Camber in Degrees (Decimal) | 0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 5 1/2 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 5.50 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 3.5 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 1 +/- 3/4 | |
| Camber in Degrees (Decimal) | 1.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 4 1/2 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 4.50 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 2 +/- 3/4 | |
| Camber in Degrees (Decimal) | 2.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 3 1/2 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 3.50 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Inner) | (1) | |
| Toe-Out on Turns (Outer) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| Ride Height: 4.25 Inches | ||
| Adjustment Procedures | 2 | |
| Camber in Degrees (Fraction) | 3 +/- 3/4 | |
| Camber in Degrees (Decimal) | 3.0 +/- 0.75 | |
| Caster in Degrees (Fraction) | 2 1/2 +/- 1 1/2 | |
| Caster in Degrees (Decimal) | 2.50 +/- 1.50 | |
| Toe-In in Inches (Fraction) | 1/32 | |
| Toe-In in Inches (Decimal) | 0.031 | |
| Toe-In in Degrees (Fraction) | 1/16 | |
| Toe-In in Degrees (Decimal) | 0.063 | |
| Toe-Out on Turns (Outer) | (1) | |
| Toe-Out on Turns (Inner) | (1) | |
| Steering Axis Inclination (SAI) | (1) | |
| (1) Not applicable. Preset at factory. | ||
| (1) | Not applicable. Preset at factory. |
WHEEL ALIGNMENT SPECIFICATIONS (RANGER & BRONCO II - 4WD)
