GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Base ignition timing | 10° before top dead center and not adjustable |
| Firing order | 1-6-5-10-2-7-3-8-4-9 |
| Spark plug gap | 1.32-1.42 mm (0.052-0.056 in) |
| Spark plug type | AGSF-22WM |
| Lubricant | |
| Brake Caliper Grease and Silicone Dielectric Compound | ESE-M1C171A |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Ignition coil bolts | 6 |
| Spark plugs | 14 |
TORQUE SPECIFICATIONS
The electronic ignition (El) system is a coil-on-plug (COP) ignition system. The COP ignition system consists of the following components
- crankshaft position (CKP) sensor
- ignition coils
- spark plugs
The CKP sensor
- is a variable reluctance sensor.
- is triggered by a 40-minus-l tooth trigger wheel mounted on the crankshaft.
- provides base timing and crankshaft speed (rpm) to the powertrain control module (PCM). For additional information, refer to «ELECTRONIC ENGINE CONTROLS - GASOLINE ENGINES»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#electronic-engine-controls-gasoline-engines) .
The 10 separate ignition coils
- change low voltage signals from the PCM to high voltage pulses.
- produce the high voltage pulses to the spark plugs.
- are connected directly to each spark plug.
The spark plugs
- change a high voltage pulse into a spark which ignites the fuel and air mixture.
- originally equipped on the vehicle have a platinum-enhanced electrode for long life.
See INTRODUCTION - GASOLINE article.
Material
| Item | Specification |
|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound D7AZ-19A331-A or equivalent | ESE-M1C171-A |
MATERIAL SPECIFICATION
Scheme 4
Scheme 5
- Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
- Remove the air cleaner assembly. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
- Disconnect the ignition coil electrical connector.
- Remove the bolt and the ignition coil.
- To install, reverse the removal procedure. Apply Dielectric compound to the inside of the coil boots.
Scheme 6
- Remove the ignition coil. For additional information, refer to «IGNITION COIL-ON-PLUG»(/ford/cutaway-e350/2004-2007/remont/ignition-system/#engine-ignition-68l) .
- Remove the spark plugs.
- Inspect the spark plugs. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-system-general-information) .
- To install, reverse the removal procedure.
