TORQUE SPECIFICATIONS CHART
| Description | Nm |
|---|---|
| Accelerator pedal and sensor assembly bolts | 25 |
TORQUE SPECIFICATIONS CHART
The engine management system electronically operates the throttle of the engine in response to throttle pedal movements initiated by the driver. In the event of a system failure, the engine management system provides a "limp home" mode which allows the vehicle to be driven with limited performance.
See INTRODUCTION - GASOLINE and/or INTRODUCTION -- 6.0L DIESEL articles.
Removal and Installation
| CAUTION | The accelerator pedal and sensor assembly is a non-adjustable, calibrated unit and must be handled with care. |
Scheme 1
- Disconnect the accelerator pedal position sensor electrical connector.
- Remove the two bolts and slide the accelerator pedal and sensor assembly up and off the anchor bolt.
- To install, reverse the removal procedure.
